lathes used for sale (3,104)

The largest diameter of the workpiece mm. 4000 The largest diameter of the workpiece above the caliper mm. 3200 Maximum length of workpiece mm.20000 Main motion motor power kW 160 Largest tonn part weight. 160 Machine tonn weight. 314...

modernization 2006 Control system 'Siemens' Max working diameter: 700-1500 mm Distance between railway wheels: 1435 mm Regulating distance between railway wheels: 1524 or 1676 mm Length of railway wheels sets: 1640-3000 mm Jaws clamp diameter: 550-1350 mm Max wheel width: 140 mm Spindle turn range: 4 Spindle turn: 9, 13, 5-18, 27 rpm Stepless feed speed range: 1,6-50 mm/min Machine dimensions: 8700 x 3650 x 3250 mm

Machine is used for the processing of pipe and pipe components, including thread cutting in terms of the single and mass production. Diameter range of processable pipes: 70-290 mm Max diameter of processable work-piece: -Over stand: 800 mm -Over support: 450 mm Diameter of spindle hole: 300 mm Max turning length: -With bevel ruler: 800 mm -W/O bevel ruler: 420 mm Amount of spindle speeds: 12 Limits of spindle rotation frequency: 8-355 turn/min Amount of longitudinal and cross support servings: 32 Limits of: -Longitudinal servings: 0,064-1,025 mm/turn -Cross servings: 0,034-0,458 mm/turn Step limits of cuttable: -Metric threads: 1-12 mm -Inch threads (amount of threads for 1): 2-24 Max turn angle of bevel ruler: +- 10 degrees Overall machine dimensions: -Length: 3600 mm -Width: 1860 mm -Height: 1525 mm Machine weight with electric equipment: 9050 kg

2022 TORNOS SWISS CNC SWISS-TYPE LATHE CNC: FANUC 31iB Maximum spindle speed: 10,000 rpm Bar capacity: up to 25.4 mm The TORNOS SWISS GT 26-6 is a compact, high-speed CNC turning center intended for precision production of small-diameter components. Its twin-spindle arrangement allows machining to be transferred between the main and counter spindle, reducing the number of separate operations required for many parts. The machine is equipped for both conventional Swiss-type work with a motorized guide bush and applications where machining without the guide bush is preferred. Machining Capacity Maximum material diameter: approximately 25.4 mm Typical part length with rotating guide bush: up to 220 mm Main spindle: 0–10,000 rpm Counter spindle: 0–10,000 rpm Main spindle power: 8.2 kW, up to 10.5 kW Counter spindle power: 8.2 kW, up to 10.5 kW Maximum torque  ...

We are pleased to offer the following CNC turning center: DOOSAN PUMA 400LMB Year: 2011 Serial No.: ML0136-004494 Specifications: 15” chuck Spindle bore: 132 mm / 5.197” Through drawbar: 116 mm / 4.56” Maximum work length: 2,028 mm / 80” Approximately 13,000 cutting hours Long-bed configuration Machine reported to be in very good condition

2006 ROMI 33×80 Oilfield Hollow-Spindle CNC Lathe Manufacturer: ROMI Model: 33×80 Year: 2006 CNC Control: FANUC 21iT Application: Oilfield / Heavy-Duty Machining Main Specifications Swing over bed: 33” Swing over cross slide: 23” Chuck size: 24” Spindle bore / bar capacity: 10.5” Maximum turning diameter: 23” Maximum turning length: 90” Maximum spindle speed: 750 rpm Main motor: 60 HP Tailstock: Yes CNC control: FANUC 21iT Electrical: 480 V / 75 A FLA Approx. machine weight: 30,000 lbs Included Equipment 2 × chip pans — approx. 5’ × 11’ × 4’ — 1,000 lbs each Chip conveyor — approx. 4’ × 12’ × 6’ — 2,000 lbs Chiller — approx. 2’ × 2’ × 5’ — 1,200 lbs Hydraulic pump — approx. 2’ × 3’ × 5’ — 1,500 lbs Shipping Dimensions Main machine: 17’ × 8’ × 7’ — approx. 30,00 ...

Key data: 5000 mm, 8000 mm, 4000 mm

Berthiez Vertical Turning Lathe • Year of manufacture: 1982 • CNC type: older system (CNC axes) Dimensions and Working Parameters • Table diameter: 5000 mm • Maximum turning diameter: 8000 mm • Maximum turning diameter at center: 5000 mm • Maximum workpiece height: 4000 mm • Ram travel (T): 3600 mm • Saddle travel (TA): 650 mm Speed and Power • Table rotation range: 0.6 – 60 rpm • Table motor power: 140 kW • Maximum load on hydraulic support: 160 t • Ram feed speed: 400 mm/min • Saddle feed speed: 2500 mm/min • Spindle rotation for milling: 0.01 – 0.50 rpm • Positioning speed: 0.001 – 0.50 rpm Tool Carriages 1. Hand-Operated (Primary) Carriage • Kulannum section size: 360 × 360 mm • Axial travel (CA): 2500 mm • Horizontal travel (CB): 3400 mm • Tilt range (E-F): 15° – 45° 2. Side Tool C ...

TSUGAMI B0385L Swiss-Type CNC Sliding Headstock Lathe Year: 2014 Condition: Tooling included (as shown in photos) Specifications subject to buyer verification Machining Capacity • Max barstock diameter: 32 mm • Max machining length: 100 mm • Max main spindle drilling diameter: 13 mm • Max main spindle tapping: M12 • Max back spindle chucking diameter: 38 mm • Max back spindle drilling diameter: 12 mm • Max back spindle tapping: M12 • Max cross drilling diameter: 10 mm • Max cross tapping: M8 • Max tool spindle slotting cutter diameter: 45 mm Spindle Speeds • Main spindle speed: 200 – 6,000 RPM • Back spindle speed: 200 – 7,000 RPM • Tool spindle speed: 200 – 5,000 RPM Tooling & Axes • Total tool capacity (standard): 20 tools • Tool size: 20 × 20 × 125 mm • Controlled linear axes: 5-axis Ra ...

Key data: 2500 mm, 8000 mm

Poreba TZB-250 CNC Heavy Duty Modular Lathe Fanuc Oi-TF CNC Control with MPG Pendant (Retrofit 2015), 78.74” 4-Jaw Face Plate Type Chuck, 98.42” Swing Over Bed, 314.96” Maximum Turning Length, 125.98” Maximum Swing Over Gap, Spindle Speeds 0.5-1000 RPM, 4.13” Spindle Bore, 4-Way Tool Post, 35,275 Lbs. Approx. Weight Capacity (Unsupported), Power Tailstock, Open Steady Rest, 75 HP Spindle Motor, S/N 1132 070

Gurutzpe B1800/3 CNC Lathe Fanuc Oi-TD CNC Control, 52” Swing Over Bed, 372” Between Centers, 36” Cushman 4-Jaw Independent Chuck, 41” Swing Over Carraige, Spindle Speeds 1-300 RPM, 4.33” Spindle Bore, Sauter 4-Position Turret, 48,400 Lbs. Weight Capacity (Unsupported), 70,500 Lbs. Weight Capacity (2 Steadies), Hydraulic Tailstock, (3) Roller-Type Steady Rests, Full Length Scale on Z-Axis, Hennig Chip Conveyor [CNC Retrofit 2010]

Key data: 6300 mm, 11200 mm, 4800 mm

Completely retrofitted Single Column Vertical Turning Lathe Blansko model SKSJ 1A equipped with one vertical head for turning and milling operations Technical characteristics: Face plate diameter 6300 mm Max. swing with moved out arm 11200 mm Maximum height of the workpiece 4800mm Max. turning diameter with column near the faceplate 8000mm Max. diameter of work piece clamped on floor grid (for internal processing) 14700mm Infinitely variable rotation of the faceplate 0.5 – 20rpm Max. work piece weight 100ton Mi ...

CAPACITIES AND CHARACTERISTICS CNC Fagor 8055 Retrofitted in 2018 TABLE – CROSS SLIDE • D – Table diameter: 2050 mm • A – Maximum turning diameter: 2300 mm • DB – Normal table height from the floor: 731 mm • H – Maximum machinable height (tool overhang 15 mm): 2000 mm • T – Vertical stroke of the cross slide: 1700 mm • Continuous range of table speeds: 1.6 to 200 rpm • Table motor power: 37 kW • Maximum allowable load on table: 20 tons • Cross slide travel speed: 400 mm/min TOOL CARRIAGE • Section of the tool carriage slide: 224 x 224 mm • C – Travel of the tool carriage slide: 1600 mm • CD – Travel to the right of the table axis: 1305 mm • CG – Travel to the left of the table axis: 400 mm • Continuous feed range: 0.05 to 24 mm/rev • Tool positioning speed: 1 to 3600 mm/min Verniers: • 1 divisi ...

Key data: 1350 mm, 11000 mm

CNC Lathe Make Swift CNC Fanuc 21i-MB Inspection Under Power Year 1978 Between centers .. 11,000 mm Swing over Bed .. 1,350 mm Swing over Carriage .. 1,000 mm Chuck dia .. 1 ,200 mm Max. Workpiece weight …….. 20 ton Motor power ………………………… 40 kW RPM …………………………………………….150 c/w 2 steadies

Key data: 1400 , 1000 , 11280

SKODA SRM heavy duty lathe Turning diameter over bed 1400mm Turning diameter over support 1000mm turning length 11280mm faceplate 1250mm Workpiece weight in the stands max. 20000kg Bezel 395mm Bezel 620mm workpiece weight 16000kg Total power requirement 40kW

HNK HCL 41x14 crankshaft CNC lathe Max. Swing Dia. Over Carriage Ø4,100mm Max. Center Distance 14,000mm Chucking Ø700~2,000 mm Steady Rest Ø510~860mm Max. Loading 160Ton

O-M LTD. CNC Vertical Boring Mill FANUC 16T-A CNC CONTROLS, RETROFIT 1994 CAPACITY: TABLE DIAMETER 4000mm MAXIMUM TURNING DIAMETER 7000mm MAXIMUM TURNING HEIGHT 2900mm MAXIMUN HEIGHT UNDER RAIL 3000mm TABLE WEIGHT CAPACITY 45400kg VERTICAL RAM TRAVEL, Z-AXIS 1500mm HORIZONTAL TRAVEL OF RAM, X-AXIS 2550mm TABLE SPEEDS RANGE .55-40 RPM TABLE SPEEDS 16 STEPS FEED RANGE VERTICAL RAM HEAD 0.003-.6 IPR RAPID TRAVERSE, HORIZONTAL HEAD 49 IPM RAPID TRAVERSE, CROSS RAIL 12 IPM RAPID TRAVERSE, COLUMN 21 IPM MAXIMUM TORQUE 58,000 LB/FT EQUIPPED WITH: FANUC 16T-A CNC CONTROLS (RETROFIT 1994) 4000mm T-SLOTTED TABLE WITH 4-TOP JAWS OPENSIDE ADJUSTABLE COLUMN VERTICAL OCTAGONAL RAM ON CROSS RAIL COOLANT CHIP GUARDS MAYFRAN CHIP CONVEYOR 50 HP MAIN MOTOR NOTE: MACHINE IS UNDER POWER FOR INSPECTION. WELL MAINTAINED MACHINE IN EXCELLENT CONDITION! RETROFIT WITH FANUC 16T-A CN ...

FRORIEP CNC Vertical Boring Mill Double Column REBUILT & CNC RETROFIT IN 1999 FEATURES: SIEMENS 840D CNC CONTROL 2-VERTICAL RAM HEADS CAPACITY: TABLE DIAMETER: 10,000mm TURNING DIAMETER WITH VERTICAL RAMS: 15,000mm MAXIMUM TURNING HEIGHT: 5000mm RAM VERTICAL TRAVEL: 2000mm RAM SWIVEL +/- 30/15 DEG MAXIMUM CUTTING FORCE RIGHT RAIL HD: 25t TABLE LOAD CAPACITY: 200t TABLE SPEED RANGES, INF VARIABLE: 4 TABLE SPEEDS: 0.13 TO 13 RPM CROSS RAIL ELEVATION MOTOR: 40.23 HP NUMBER OF FEEDS, VERTICAL & HORIZ: 30 CROSS RAIL ADJUSTMENT MOTOR 86 HP RAPID TRAVERSE MOTORS: 15.5 HP MAIN MOTOR: 250 HP EQUIPPED WITH: SIEMENS 840D CNC CONTROL NEW 1999 DUAL PENDANT OPERATED CONTROLS 2-VERTICAL CNC CONTROLLED RAMS 10,000mm DIAMETER T-SLOTTED TABLE 4-HEAVY DUTY FACE PLATE TYPE JAWS HYDROSTATIC BEARING SYSTEM FOR TABLE DUAL OPERATORS PLATFORMS DUAL JORGANSEN CHIP CONV ...

MORI SEIKI NT6600 CNC INTEGRATED MILL TURN CENTER WITH LIVE MILLING MAXIMUM SWING OVER BED: 42" MAXIMUM WORK PIECE DIAMETER: 42" MAXIMUM WORK PIECE LENGTH: 239" MAXIMUM BAR DIAMETER: 6.4" SPINDLE BORE: 7" X AXIS TRAVEL: 41" Y AXIS TRAVEL: 26" Z AXIS TRAVEL: 242" B AXIS: +/- 120 DEG. MAIN SPINDLE SPEED: 1500 RPM MAIN SPINDLE MOTOR: 40 HP MILLING SPINDLE SPEED: 8000 RPM MILLING SPINDLE MOTOR: 40 HP ELECTRICS: 220V/3P/60Hz/216A OAD (APPROXIMATE): 490" X 182" X 169" HIGH WEIGHT (APPROXIMATE): 120,560 LBS. EQUIPPED WITH: C AXIS YAXIS B AXIS LIVE TOOLING/MILLING 20" CHUCK FS-31iA5 CNC CONTROL 140 POSITION AUTOMATIC TOOL CHANGER PROGRAMMABLE TAILSTOCK COOLANT THROUGH SPINDLE (HIGH PRESSURE) CHIP CONVEYOR Additional Control Options: Automatic Power Shut-Off MAPPS 4 System Part Program Storage: 8mb Stored Programs: 1000 Remote Communication Function ATA Flash M ...

CNC SPINNING LATHE MANUFACTURER: M+M MODEL: HF450TT/2S SERIAL NUMBER: 26-2453-00 YEAR: 2000 CONTROL MANUFACTURER AND MODEL: Tracktronic Z-AXIS CENTER HEIGHT: 419mm DISTANCE BETWEEN CENTERS: 1200mm Z -AXIS TOOLING ADAPTER: DIN 55027/ Size 15 Z-AXIS DRIVE POWER: 80kW Z -AXIS DRIVE ZF REDUCTION RATE: 1:4 Z-AXIS DRIVE SPEED: 0-1000 RPM step less variable X - SLIDE TRAVEL: 500mm X - SLIDE FORCE: 100kN X - SLIDE VELOCITY: 400mm/min Y - SLIDE TRAVEL: 275mm Y - SLIDE FORCE: 100kN Y - SLIDE VELOCITY: 400mm/min TAILSTOCK TRAVEL: 600mm TAILSTOCK CLAMPING FORCE: 80kN EJECTOR TRAVEL: 450mm COOLANT: yes POWER 3PHASE / 50-60 Hz / 200 - 500 Volts: 3PH/60Hz/480V existing SPECIAL FEATURES OR ADDITIONAL ITEMS: POWER RATING 204 HP (152 Kw), CONTROL VOLTAGE 110VOLT / 24 VOLT DC MACHINE WEIGHT: 22000 kg CONDITION: EXCELLENT - VERY LIMITED USE

turning diameter: 186 mmturning length: 350 mmcontrol: FANUC O/T turning speeds: 4.000 U/minspindle bore: 61,0 mmtool holder: 12 Stückchucking diameter: 170 mmoperating hours: htotal power requirement: 7,5 kWweight of the machine ca.: 2,4 t- FANUC - CNC control- SMB 600 bar feeder with magazine- Chip conveyor- 3-jaw lathe chuck, 170 mm- MK 4 tailstock- Various tool holders- Cooling system- Full enclosureThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

weight of the machine ca.:18 tcentre distance:700 mmmax. swing diameter:200 mmLathe with 4 tools only for 3-cylinder crank shaft

Manufacturer: GILDEMEISTERYear: 1996Type: CNC latheNumerical control: Heidenhain ELECTRO PILOT turn plusAxes: 2 axes (X, Z)Turning diameter above the bench: Ø 500 mmTurning diameter above the carriage: Ø 290 mmMax. turning length: 640 mmSpindle: 20–5,000 rpm – 22 kW – max. torque 150 Nm – bore 72 mm – passage 65 mmStrokes: Z 650 mm / X 212 mmFast feeds X/Z: 10 m/minTailstock: sleeve Ø 80 mm – CM4 – stroke 100 mmEquipment: 3-jaw chuck Ø 250 mm, SAUTER turret 12 positions VDI 30, tailstock, full documentationDimensions: approx. 3300 × 1800 × 1900 mmWeight: approx. 5000 kgRemarks: Robust German-made CNC lathe. Auction-ID: A1-50714-4053

CNC control: MSX-850 IIINumber of axes: 2Strokes: X = 260 mm, Z = 590 mmSpindle speed: 50 – 5000 rpmPower: 15 kWBar capacity: Ø 65 mmSpindle bore: 73 mm Turret: 12 stations (BMT)Max turning diameter: 356 mmMax turning length: 510 mmChip conveyor: yes235L high-pressure pump: yes Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-50714-4004

Year of manufacture: 1999CNC : Siemens Sinumerik 840CMax. turning diameter: 254 mmMax. turning length: 500 mmDiameter allowed above the bed: 440 mmBar passage: 51 mmBench inclination: 45°Spindle speed: 36 to 4,000 rpmSpindle nose: A2-6Engine power (cont./30 min): 11 kW / 15 kWChuck: Ø 210 mm (8 inches), hydraulic clampingTurret: 8 positions, indexing 0.5 s station-to-stationTools: square 25 x 25 mm / boring bar Ø 40 mmTailstock: programmable hydraulic sleeve, CM4 taperChip conveyor: hinged type, side outletDimensions (L x W x H): 2,600 x 1,700 x 1,750 mmWeight: approx. 4,200 kg Auction-ID: A1-50714-104

max. workpiece diameter:29 mmmin. workpiece diameter:26 mmworkpiece length:66 mmthe system was originally delivered for the following workpiece sizes: diameter 26mm - 29mm length 65mm - 66mmChanging parts in the clamping device, handling, etc. would probably result in diameters of up to approx. Ø50mmTotal length will probably be almost 400 mm possible with a few conversions.Also dependent on tool lengths, machining lengths on the component, etc.Workpiece: Piston pin Drawing number: WHT 000 718, WHT 000 718 A Workpiece dimensions (Ø, WxH): Ø26 x 66; Ø29 x 65 Length: 66 or 65 mm Material: 17Cr3Quantity: xxx parts / year Cycle time: 5 sec. However, workpiece lengths up to 600mm are manageable. The machining diameter can be adjusted if the appropriate tools are available. The clamping station can currently only accommodate this product. However, this can be adapted by changing the clampi ...

turning diameter:250 mmswing diameter:250 mmturning height:200 mmtotal power requirement:37,7 kWchuck diameter:315 mmspindle speed max.:5500 1/mintravel -x axis:625 mmtravel -y axis:+100/-80 mmtravel -z axis:250 mmworktool system:VDI 30+40 weight of the machine ca.:8 tThe synchronous spindle is powered with 37.7 kW of power, a torque of 300 Nm and a maximum speed of 5,500 rpm.Typical components are ball cages, ball hubs, gear wheels, sliding sleeves,pump wheels, flanges, synchronizer rings, bearing rings and pivot pins.The machine bed is made of Hydropol, a mixture of special concrete and steel, which ensures the greatest smoothness and precision even with larger components and powerful machining.

Manufacturer: HARDINGEYear: 2005Type: CNC Motorized Tool Lathe with C-AxisNumerical Control: FANUC 21i-TBBar Capacity: Ø 51 mmMax. Turning Circle: Ø 310 mmMax. Turning Length: 470 mmChuck: Ø 200 mm (8\")Bed Inclination: 45°Spindle: 50–5,000 rpm – 18.5 kW (max) / 11 kW (continuous)Turret: 12 stations, all motorable positionsMotorized implements: 4,000–5,000 rpm – 3.7 kWFast feeds: X/Z 19 / 24 m/minAccuracy: ±0.005 mmIncluded equipment: Programmable C-axis (0.001°), IEMCA Boss 545 bar feederWeight (kg): approx. 4200 Auction-ID: A1-50714-4029

number of spindles:6 spindle passage:18 mmturning length:63/50 mmweight of the machine ca.:8,6 tspindle drive motor:11 kW

Year of manufacture: 1998Serial No.: 93742Numerical control: Fanuc 18-TTurrets: 2.6 positions per turretMaximum turning diameter: 125 mmDiameter above the bed: 200 mmTurning length: approx. 300 mmTailstock: noPower supply: 400 V three-phase – 50 HzControl circuit: 110 VWeight: approx. 2,600 kg Auction-ID: A1-50714-4064

turning diameter:200 mmturning height:120 mmweight of the machine ca.:18 tAvailable from 01.08.2024
