1,738 presses used for sale

Key data: 600 t

Max Tool length: 3000mm Max Tool Width: 2000mm Min Tool Height: 500mm Total Tool Weight: 20,000kg Max Closing Speed: 400 mm/sec

Nominal weight of the falling parts: 750 kg Max. number of blows per minute: 105 Kinetic energy: 1900 kg Distance from an axis of the slider up to bed: 750 mm Cylinder diameter: 600 mm Diameter of the plunger: 630 mm Max. headstock travel: 835 mm Dimensions: -Left-to-right: 3940 mm -Front-to-back: 1430 mm Height above floor level: 3260 mm Weight: -With an anvil-block: 25600 kg -Without an anvil-block: 16600 kg

Eccentric shaft by drawing K04.038.842-22-402 for hot stamping press K04.038.842 (K8542), 1600T brand new in state stale from stock W 4675 kg

with a brand-new slider also new stale gears and cleaned and painted parts Warranty for all brand new components 12 month. Die Holder included price . All parts of the press were subjected to technical inspection and the main components were replaced . · Completing the press with NEW STALE PARTS and components; · Brand New Ram 2024 - Brand new Pin 2024 · New stale drive hub 2023 · New stale Gear Big 2023 · New stale small gear 2023 · New stale eccentric shaft 2023 connecting rod is in stock Nominal force: 6300 ton Number of continuous strokes per minute: 40 Ram stroke: 460 mm Distance between ram and table (table is in upper position): 1150 mm Table adjustment: 15 mm Distance between press columns: 1950 mm Ram dimensions: -front to back: 1680 mm; -left to right: 1680 mm Table dimens ...

Nominal force, kN 16,000 Slider travel, mm 630 Distance between table and slider, mm 810 The frequency of strokes of the slider continuous, 1/min 16 Table dimensions: length, width, mm 1 600x 1 600 Total power, kW 110.00 Machine size, mm 4670_4670_8110 Machine weight, kg 140 400

Nominal force 1250 ton - first stage : 260 tons, - second stage : 800 tons, - third stage : 1250 tons, Slide stroke 1250 mm Distance between table and slide 2650 mm Main cylinder dia Ø 500mm Return cylinder dia. ( two) 2xØ400mm Distance between column 1800mm Table size width / length 1250 / 3150 mm Main motor power 150 kW Machine dimensions L x W x H 16950 x 12100 x 11410 mm Weight 265000 kg Forging manipulator FS2ЕТС -2T also available 1T and 700t

Pressing force max KN 600 Withdrawal force max KN 300 Die Supporting force max KN 300 Die return force max KN 32 Upper punch travel mm 190 Upper punch adj.travel mm 200 Filling height max mm 180 Pressing travel max. mm 90 Withdraw travel max. mm 95 Top pressing travel max mm 18 Adjustment at Die position mm 50 Filler travel mm 140 Maximum forming Diameter mm 130 Cycle stroke /min 12-25 Main Motor Power KW 15 Total Power KW 15 Speed control method Inverter Driving pressure for Clutch MPa 0.55 Pre-load Travel mm 110 Total air consumption L/min 300 Total weight Kg 5800 Overall size H mm 3200 W mm 1750 D mm 1480

The press is function with two adaptor Pressing force max. kN 1800 Pull-off force max. kN 1500 Counterholding force kN 1200 in pressing position Upper punch stroke mm 220 Filling height max. mm 180 Pull-off travel max.mm 90 Pressing path max. mm 90 Distance of upper pressure max. mm 18 Drive motor kW 30 Stroke rate (infinitely adjustable) min-1 6-24 Pre-suspension. Distance max. mm 62 (surcharge). Force max. kN 5.3 Total height mm 4700 Total width mm 2360 without electricity Total depth mm 2700 Hydraulic unit Total weight, net kg 17000

Press capacity: max. 60 t Stroke of the punch: 125 mm Filling height: max. 110 mm Motor: 15 kW Approx: 1650x1801x3390 mm Net weight: 5800 kg

Capacity, ton 1250 Stroke, mm 500 Min number of no-load stroke: 8 /per min Slider adjustment, mm 215 Max. shut height between bolster plate and slider (stroke down, adjustment up), mm 1100 Table size, mm 1600 x 1850 Slider size, mm 1300 x 1400 Table gap size, mm 1100 x 1100 Distance between columns, mm 1630 Distance between slides, mm 1580 Cushion travel, mm 200 Cushion capacity, ton 200 main motor power, kW 90 Press weight, kg 110000

Nominal force: 2500 tons Slider stroke: 600 mm Slide strokes per min: 11 Distance between table and slider: 1500 mm Capacity of the main drive: 220 kW Table size: 2000x4500 mm Machine dimensions: 5910x8700x10355

Capacity :10 tons, Weight of falling part,nominal mass of drop parts without upper instr.:9 tons, Effective working kinetic energy after blow :25000 kg mtr., Max. working ram stroke :1400 mm, Max no of blows : 30/min , Distance between slides : 1000 mm, Shut height : 775 mm , Ram size front to back :1200 mm, Bolster size front to back :1200 mm, Air pressure : 7-9 MPA , Height of instruments : 450 min., Die-holder front to back dimensions: 1400 mm, Height above floor level: 7270 mm, Hammer dimensions : 4400x10420x2700 mm, Weight (less anvil block): 73.5 ton, Weight of anvil block : 203.8 tons.

Nominal mass of falling parts, taking into account the mass of the upper stamp (500 kg.), Kg. 5000 Actual mass of falling parts without top stamp, kg. 5030 Effective kinetic energy of falling parts at full successive impacts, kgc m 12500 The greatest working stroke of a woman, mm. 1300 The smallest height of dies without shanks, mm. 400 Distance between guides in the light, mm. 800 The length of the woman in the direction perpendicular to the front of the hammer, mm. 1180 Steam (air) pressure before entering the cylinder, atm. 7-9 Nominal mass of the upper die, kg 500 The largest mass of the upper die, kg. 1500 The highest permissible steam temperature, ⁰C 200 weight 145-148ton, weight of anvil block 75+22 ton.

Standard Equipment's Chrome Coated Cylinder Boiled Steel Body Pressure indicator Pressure Adjustment User guide 2 Years Warranty CE

Press capacity: max. 45 t Pull force: max. 45 t Counter force in pressing position: max. 17 t Stroke of the punch: 175 mm Filling height: max. 140 mm Deduction: max. 85 mm Compression distance: max. 55 mm Top pressing: max. 15 mm Stroke rate: 9 – 26 min.-1 Motor: 7,4 kW Approx: 3000x1200x1800 mm Net weight: about 6000 kg

Nominal force: 4000 tons Slider's undershoot to BDC: 10 mm Slider stroke: 630 mm Frequency of continuous strokes per min: 10 The highest frequency of single strokes per min: 7 Closed height: 1180 mm Adjustment of closed height: 200 mm Slider's dimensions: -From left to right: 5000 mm -From front to back: 2000 mm Dimensions of the plate of the die: -From left to right: 5000 mm -From front to back: 2000 mm Capacity of the main drive: 250 kW Overall dimensions: -From left to right: 7640 mm -From front to back: 5980 mm -Height above floor level: 10490 mm

press is after overhaul: full function complete mechanical parts, pneumatic and control system. The press has a new pneumatic clutch, the original was electromagnetic clutch as old system. Press capacity: max. 45 t Pull force: max. 45 t Counter force in pressing position: max. 17 t Stroke of the punch: 175 mm Filling height: max. 140 mm Deduction: max. 85 mm Compression distance: max. 55 mm Top pressing: max. 15 mm Stroke rate: 9 – 26 min.-1 Motor: 7,4 kW Approx: 3000x1200x1800 mm Net weight: about 5000 kg

Capacity: 2500 ton Slider stroke: 190 mm Size of a working course of slider before its extreme bottom position corresponding nominal capacity: 4.5 mm Number of slider courses per minute: 20 Maximum distance between table and slider (in lower position of slider): 800 mm Distance adjustment between table and slider: 20 mm Table overall dimensions: - from front to rear: 1400 mm - from left to right: 1250 mm Thickness of a under-forginig plate: 230 mm Hole diameter in a table: 125 mm The size of a slider in front - back: 900 mm Lower eliminator stroke length: 190 mm force of the bottom pusher: 75 ton Distance between railings: 950 mm Course of a pusher in a slider: 15 mm Capacity of a pusher in a slider: 25 ton Admissible number of starts per minute: 10 Machine overall dimensions - length: 3910 mm - width: 3920 mm - height: 6220 mm Press weight: 97715 kg

effort 250 ton stroke 315 mm slide adjustment 160 mm distance slide- table 800 mm die height 555 slide 620x950 mm table 800x1180 mm 28 kW Total weight 25t

Max. diameter of initial blank: 30 mm Blank length: -Min.: 120 mm -Max.: 300 mm Max. diameter of upset flange: 60 mm Upset slide nominal force: 2500 kN Max. force on clamping slide with dies closed: 2500 kN Stroke: -Movable die: 100 mm -Upset slide (full): 220 mm -Die closing: 140 mm Slide strokes per minute: 45 Machine overall dimensions: -Length: 6050 mm -Width: 4600 mm -Height: 2260 mm Machine weight: 24680 kg

Capacity , ton: 800 Stroke, mm: 320 Strokes/min: 20 Shut height, mm: 900 Bed to ram adjustment stroke, mm: 320 Bed dimensions, mm: 2500x1600 Main drive motor power, kW: 75 Overall dimensions, mm: 4220x3500x8356 Weight, ton: 96,6

(side-front moving table) Nominal force: 1000 ton Slide stroke: 400 mm Continuous slide strokes per 1 min: 20 Single slide strokes per 1 min: 16 Shut height: 1060 mm Slide adjustment: 320 mm Table dimensions: 3150x1800 mm Slide dim., front-back: 1700 mm Window H 1500 x W 1900 mm Hydro pneumatic cushion in table clamping force at P = 0.42 MPa (P = 4.2 kg / cm2), kN 2000 ejection force P = 0.45 MPa (P = 4.5 kg / cm2), kN 200 Main-drive electric motor power: 132 kW DIMENSIONS: 5150x4700x11400 H floor7830 mm WEIGHT:193 ton

Equipment Description Used Indirect Extrusion Press • Brand / Model: SMS Hasenclever 28 / 31.5 MN McKechinstrang” • Type: Horizontal indirect extrusion system for non-ferrous billets • Drive: Mechanical main unit with hydraulic auxiliaries • Country of Origin: Germany • Current Status: Dismantled and available for dispatch • Serial No. / Year of Manufacture: [To be confirmed] 2. Key Technical Specifications Parameter Value Main Piston Force 25.07 MN Total Press Force with Coupling 31.23 MN Max Stroke 3,070 mm Working Stroke 2,825 mm Ram Speed at 28 MN 0–64 mm/sec Ram Speed at 31.5 MN 0–57 mm/sec Billet Diameter Range Ø 230–355 mm Billet Length (cold) 320–1,320 mm Receiver Heating System Resistance; max 63 kW / 375 °C Shear Force 0.64 MN Profile Ejector Force 0.31 MN Actuation Differential Cylinders Ø 280/200 3. Included Components • B ...

Ajax 1,000 Ton Straight Side Mechanical Forging Press S/N 4410 10” Stroke 33” Shut Height 36” x 36” Bed 80 Strokes Per Minute Partially Rebuilt Ajax 1,000 Ton Straight Side Mechanical Forging Press S/N 4621 10” Stroke 32” Shut Height 36” x 32” Bed 80 Strokes Per Minute Bolsters are included. Both presses are in working condition and under power.

6500ton Open Die Forging Press HJ / Seonam (Korea) Design: Eastern European Corporation Installation: 2006/2008 Press Type: Four column push down Oil hydraulic system Nominal force (static working pressure of 320 bar): 5,000 Tons Up-setting force (static working pressure of 420 bar): 6500 Tons Daylight: 5,200 mm Stroke of Movable cross head: 2,700 mm Main Ram dia. (Center cylinder): 1 set - ￠950 mm Side Ram dia. (Side cylinder): 2 sets - ￠750 mm Return cylinder Ram dia: 2 sets - ￠300 mm Moving Table Width: 2,600×Length 6,600 mm Moving Table stroke (center to both side 2,750mm): 5,500 mm Approaching speed: 300 mm/sec Main cylinder Forging speed (2,200 tons/ 320 bar): 163 mm/sec All cylinder Forging speed (5,000 tons/ 320 bar): 73 mm/sec Up-setting Forging speed (6,500 tons/ 420 bar): 10 mm/sec Return speed: 270 mm/sec Hydraulic Main pump: 12 sets  ...

VORONEZH K8544 Hot Forging press YEAR : 1980 / 2008 OVERHAUL AND INSTALLED FORCE : 2500ton RAM STROKE : 350 mm RAM SIZE : 1120X1070 mm TABLE OVERALL SIZE : 1400X1200 mm NUMBER OF STROKES IN CONTINUOUS MODE : 60 NUMBER OF STROKES IN MANUAL MODE : 26 SHUT HEIGHT : 890 mm STROKE OF UPPER KNOCK OUT : 60 mm STOROKE OF LOWER KNOCK OUT : 70 mm MAIN MOTOR : 132KW (CHANGED TO HYUDAI HEAVY Y2012) PRESS OVERALL DIMENSION : 5380X4680X6400 mm HYDRAULIC BOLSTER NEW IN 2007 CONDITION : VERY GOOD WORKING CONDITIONS Trimming press available

2000 Ton Sumitomo Hot Forging Press line Year 2006 Stroke 350 mm (13.78") Strokes per min 75 Shut height 850 mm (33.47") SlideAdj. 7 mm (.27") Ram size 1200 mm LR X 1300 mm FB Bed size 1320 mm LR X 1300 mm FB 4 stage transfer system Slide knockout Bottom knockout Scrap System Dual Die Changer Extra Die Shoes Billet Heater and Billet Saw Also Available This line was used by HONDA to make transmission gears, It takes a billet, cuts it to size, heats it to 1300 C then the press hits it 4 times. It can determine good from bad parts, the bad parts get sent to a quench tank, the good parts get sent into a cool down conveyor that you can pick the parts up by hand at the end. The entire system was ran by one operator.

(2) Asahi Sunac THP500-6 horizontal forging press (heading machine) Year: 2008 First stroke: 24 mm Second stroke: 50 mm Kickout power: 150 kN Open height: 625 mm Closed height: 425 mm Die (WxL): 500x490 mm Punch (WxL): 250x350 mm Ram stroke: 200 mm Forging force: 5000 kN Cycling time: 6.5 sec Crank speed: 60 RPM Machine weight: 28 t

IHI Transfer Press Model SL4-1600-450-220. With NC Feeder, Transfer System including Robots. New : 1984 Capacity : 1600 ton Stroke : 850mm Die height :1400mm Slide Adjustment : 500mm No. of Stroke : 16R.P.M Bolster Area : 4500 x 2200mm Clutch working Air Pressure : 4.5kg/cm2

: neu : ca. 12 Wochen ab Auftrags : Türkei : 7000 €: 135.1 €: 80 to: fix : 250 mm: 1040 mm: 200x120 mm: 5 mm/s: 10 mm/s: 1810 mm: 750 mm: 2100 mm: 835 kgsteel welded framestop at any positionpressure manometersafety valve against overloading2 V-blockstable height adjustabletable up-down movement attachmentcontrol by operating leveraccording to CE regulations user manual in GERMAN and ENGLISHThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
