grinding machines used for sale (2,199)

Key data: 762 mm, 3048 mm, 813 mm

Minakuchi CNC Cylindrical Roll Grinder Year of Manufacture: 1990 Control: Fanuc Series O-GC (parameters need reloading) Technical Specifications: • Max. Swing: 32” (813 mm) • Distance Between Centers: 120” (3048 mm) • Max. Grinding Diameter: 30” (762 mm) • Grinding Wheel Size: 24” x 1.968” x 10” • Max. Grinding Wheel Width: 1.968” • Spindle Speeds: 1410 / 1530 RPM • Grinding Wheel Motor Power: 30 HP • Workpiece Weight Capacity: 20,000 lbs (approx. 9,070 kg) • Machine Weight: Approx. 30,000 lbs (13,600 kg) Equipped With: • Fanuc Series O-GC CNC Control • Remote hand wheel • Control Panel with Jog / Auto / Handle Modes • Spindle inching, feed hold, emergency stop, ZRN • Taper and crowning grinding capability • Wheel head motor • Work head & tailstock • Work rest supports • Extra wheel hub • I. ...

Key data: 585 mm, 4064 mm

JARBE Universal Cylindrical Grinder Year: 1981 Technical Specifications & Features: • Swing Over Table: 23″ Distance between centers 160” • Hydraulic Table Traverse • Swiveling Table for Taper Grinding • Universal Workhead • Universal Wheelhead • Grinding Wheel Capacity: 20″ • Includes 2 Workrests • Equipped with Coolant System • Electrics: 440 Volt

Key data: 318 mm, 648 mm

Key data: 500 mm, 1500 mm

CNC Universal Cylindrical Grinder TSCHUDIN TL-155U Center height mm.250 Center distance mm.1500 Machine dimensions mm.5840x3400x2300 Weight Kg.7500 Year 1996 CE

Key data: 3000 mm, 850 mm

Crankshaft Grinder BERCO RTM 425 Center height mm.425 Max swing mm.850 Center distance mm.3000 Wheel flanges Rests Machine dimensions mm.7100 x2350 Weight approx Kg 9000 Perfect working condition

Fritz Studer Series 152 favorit CNC Grinding Machine Year: 2021 Linear Axes: Max. Travel X = 285 mm, Max. Travel Speed X= 10,000 mm/min, Max. Travel Z= 1,150 mm, Max. Travel Speed Z= 20,000 mm/min; Spindle drive: Max. Spindle Power= 9 kW, Max. Number Of Revolutions= 2'810 /min, Max. Grinding Wheel Diameter= 508 mm, Max. Grinding Wheel Width= 80 mm; Swiveling Axes: Swiveling Range B= 210 Degrees, Swiveling Range C= Full; Workpiece Data: Workpiece Length= 1,030 mm, Workpiece Diameter= 349 mm, Max. Workpiece Weight= 120 kg, Distance Between Centers= 1,000 mm, Center Height= 175mm, Includes Keys, Fanuc Series oi-TD Controller, Also Includes Cyclotron Products Chip Conveyor and Filter, MistBuster 500 Mist Collector, and Hammond Transformer, 480v

ELB SURFACE GRINDER 460x2440mm CNC Dresser

VOUMARD CNC 300 S/N: 300030 Used - Excellent Year: 2007 DESCRIPTION: Machine type: BU 1000 T L7400 Was recently removed from power due to routine upgrades and was making good parts with full functionality. Siemens 840D CNC Control. Manuals included. Has grinding capability for: Internal diameters External diameters Front faces Back faces Internal tapers External tapers Profiles Drive spigots Face keyways Cams Bilobes and trilobes Internal threads External threads Bearing tracks Located at our warehouse in Preston, Idaho. We care about the machines we sell and want all of them to enjoy continued productive and profitable service for our remarkable customers. Included specifications are gathered from various sources such as firsthand inspection, owner or operator interviews, manuals, and OEM research. All machinery specifications, condition and detail ...

Danobat RTM-2500 CNC X600 CNC Surface Grinder Grinding Length: 100" Grinding Width: 28" Table Length Dimension: 98.43" Table Width Dimension: 19.690" -Grinding Wheel- Grinding Wheel Diameter: 20" Grinding Wheel Width: 4" Grinding Wheel Bore: 8" -Wheel Head- Angle Adjustment: 0 DEG Wheel Head Motor: 20 HP Wheel Head Speed: 1,200 RPM -EQUIPPED WITH- Fagor 8055 CNC Control Magnetic Swarf Conveyor

Minakuchi NWT-300 CNC Cylindrical (ROLL) Grinder, I.D. Spindle, Fanuc O-GC, 30HP, New 1990 Machine Overall Capacity: 32" x 120" Swing: 32" Distance Between Centers: 120" Max. Swing over Table: 32" Max. Grinding Diameter: 30" Max. Work Piece Weight: 20000 LBS. Estimate at 32" x 120" Grinding Wheel: 24" x 1.968" x 10" Max. Grinding Wheel Width: 1.968" Spindle Speed: 1410/1530 RPM Spindle Wheel Motor: 30 HP Machine Weight: 30000 Lbs. Approximately Equipped with: Control: Fanuc Series O-GC (Parameters need to be reloaded) Fanuc Remote Hand Wheel Machine control functions: Coolant On/Off Switches, MODE: Off/Auto/Jog/Handle/Zero, Over Ride: 0-150%, Buttons: PRC, HIX, Spindle Inching, OTR on/off Switch, Cycle Start, Spindle Off, RT, Return, Feed Hold, Grind Off, ZRN, Emergency Stop Button Taper or Crowning Grinding Wheel Head Motor Work Head Work Rest Supports Extra W ...

Naxos CNC Multi-Axis Cylindrical Grinder Year: 1987/2013 Max. swing: 630mm Max. distance workhead face to tailstock face: 4850mm Max. travel for Z axis: 5000mm Max. grinding distance for main wheel: 4520mm X axis infeed travel for both headstocks: 720mm Approx. weight between centers: 4000kg Power requirements: 460/3/60 This machine was completely remanufactured to new specifications in 2013 and installed in 2014. It was stripped down to the bare casting, table/base/wheel heads/work head and tailstock and the second z axis ways were fit and rescrapped. New electrical cabinet with all new wiring to the machine and new all components, hydraulic lines, air lines and new cable carriers were added. New Marathon 60HP motors for both grinding wheel heads. (The drives in the cabinet are set for 40 Hp) The spindle drives in the cabinet are Yakawa built in the USA along with the workh ...

WALDRICH SEIGEN WST IV H80 X 12000 ROLL GRINDER YEAR: 1981 / INSTALLED 1982 MAXIMUM GRINDING DIAMETER: 78” ( 1981.2 mm) WITH 32” (812.8 mm) DIAMETER WHEEL MAX DIAMETER CAPABILITY: 2500mm DISTANCE BETWEEN CENTERS: 472.40” (12000mm) MAXIMUM WORKPIECE WEIGHT: 176000 lbs. (80t) WHEEL OD MAXIMUM: 32.00” WHEEL WIDTH MAXIMUM: 4.00” WHEEL ID: 12.00” WHEEL SPINDLE POWER: 27 - 59/59 HP WHEEL DRESSER: BED MOUNTED ROLL WHEELHEAD TRAVEL: 25.60” TABLE TRAVEL: (WHEEL HEAD TRAVEL) 488.40”( 12405 mm) TABLE SPEED: (WHEELHEAD SPEED) 157.5 in/min (4000 mm/min) WHEEL SPINDLE SPEED: 450 - 1800 RPM Infinitely Variable WORKHEAD POWER: 1.9 - 59/59 HP WORKHEAD SPEED: .5 - 300 RPM WAYS: CAST IRON FULL HYDROSTATIC SLUDGE CONVEYOR: NONE COOLANT: YES FILTRATION SYSTEM: COMBINATION 2 CARTRIDGE AND FABRIC FILTER WAY COVERS: METAL TELESCOPIC POWER 3PHASE / 50-60 Hz / 200 - 50 ...

grinding diameter max.:3-220 mmregulating wheel width:500 mmmax. width of grinding wheel:500 mmweight of the machine ca.:16 t.dimensions of the machine ca.:12 x 10 x 8 m.grinding wheel diam. min/max.:420-610 grinding wheel diameter - width-internal grin:304,8 x 500 mmRegulatin wheel diameter min/max.:300-350 mmThe machine is currently designed for plunge grinding JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times.The grinding process with JUPITERWhen centerless grinding, there are two grinding processes: the through gr ...

: neu : 2026 : 050162 : Mai 2026, Zwischenverkauf : Taiwan : 69400 €: 1311.66 €: 800 mm: 610 mm: 800 x 400 mm: 800 x 400 mm: 810 mm: 5 - 25 m/min: 0.74 kW: 10 kVA kW: 3540 mm: 2080 mm: 2100 mm: 2900 kg: 980 mm: 350 kg: 355 x 50 x 127 mm: 0,001 mm: 500 - 1.800 U/min: 3,75 kW: 1.1 kW10.4", graphic NC control on a swivel arm with touchscreen for:Operating mode selectionCycle selection and program creationSurface grindingCross grindingPlunge grindingDressing with automatic compensationSemi-automatic balancing in the machineAutomatic spindle speed for constant surface speedSpindle load visualizationUnbalance controlGraphical status monitoringAlarm listaut. vertical feedservo drive for grinding wheel feed and table cross feedhardened slide ways in all 3 axes with needle rollerselectro-magnetic chuckcoolant equiptment with aut. paper filter and magnetic separatorautom. dressing attachme ...

Auction-ID: A1-42601-110

grinding diameter:5-55 mmgrinding length:500 mmtotal power requirement:44 kW-- Intended use and general information --Fully automated external and surface grinding of synchronous ringsCentre height: 200 mmGrinding length: 500 mmGrinding wheel arrangement: right, 30° angled Grinding wheel dimensions: 600 x 30 x 203.2 mmDrive power: 7 kW X/Z axis drive: ball screw Travel speed: 0.01 - 10,000 mm/min. Resolution: 1 µm Concentricity of workpiece spindle: < 1 µmWorkpiece changing system: Fanuc robot Control: Siemens Sinumerik 840-DMachine weight: 7,000 kgCentre height: 200 mmGrinding length: 500 mm

grinding diameter:200 mmgrinding length:320 mmtotal power requirement:3,5 kWweight of the machine ca.:9 tspace required L x W X H:5,28 x 4,5 x 2,4 mmax. wheel dia.:200 mmSpindle drives Arena SiemensFor Worm grinding we have not module, but pitch. Pitch is freely programmable from 0.001 to big value i.e. 500mm

: neu : ca. 6 Monate ab Auftragse : 162050 €: 3062.75 €: 1200 mm: 730 mm: 1200 x 600 mm: 1200 x 600 mm: 1300 mm: 5 - 30 m/min: 0-2250 mm/min: 0,001-32 mm: 685 mm: 560 mm: 0-675 mm/min: 500-2200 1/min: 11 kW: 5.5 kW: 3.1 kW: 3.1 kW: 4790 mm: 3207 mm: 2305 mm: 8100 kg: 1150 kg: 1600 kg: 405 x 75 x 127 mm: 0,0001 mmiSurface control with Touch screen for 3 axes fully automatic surface and plunge grinding system10.4” TFT high resolution color control to ensure ease of operationRough increment, finish increment, spark out (0-9 times), and automatic grinding cycleCycle interrupt, flip over for part inspection &, final dimensions setWheelhead will rise up to end, start or reference positionnd table parks at left or right side after cycle is completedDisplay accuracy 0.0001mmI/O diagnosis &, alarm displayMax. table speed (X axis) 30 m/minIntegrated machine-body temperature controlDoub ...

Auction-ID: A1-43179-650

max. grinding diameter:160 mmstations:2 sanding width:30 mmtotal power requirement:0,37 kWweight of the machine ca.:100 kgdimensions of the machine ca.:520 x 520 x 1160 mm

no. of working stations:1 Stücktool adaptor:1650 W revolutions per minute:2990 U/mintotal power requirement:380V, 2,7 Aweight of the machine ca.:33 kg

no. of working stations:1 Stücktool adaptor:1650 W revolutions per minute:2990 U/mintotal power requirement:380V, 2,7 Aweight of the machine ca.:33 kg

Auction-ID: A1-42601-109

Auction-ID: A1-42601-104

working width:1400 mmWorkpiece thickness max.: 80 mmwork height max.:1000 mmFeed speed:4m/min I Stufe, 8 II Stuf m/min.Required air-pressure:max. 5 barvoltage:50 Hz, 380 Vworkpiece length:320 mmworkpiece thickness min.:1 mmweight of the machine ca.:3500 kgDocuments:vorhanden

workpiece length:350 mmwork piece width:150 mmdiameter:Tellerradius 200 mmtool taper:M32 x 1,5 spindle diameter:32 mmgrinding width:max.450 mmturning speeds:3385 U/minwork table::Höhe 1000 mmworkpiece height max.:100 mmtotal power requirement:1,1 kWweight of the machine ca.:300 kgdimensions of the machine ca.:700 x 800 x 1170 mm

table diameter:520 x 22 mmtable - swivable:45 Gradtotal power requirement:1,6 kWweight of the machine ca.:130 kgdimensions of the machine ca.:520 x 520 x 1200 mmmit SchleifzylinderZubehör: 4 ( Aluzylinder) Werkzeuge zur Aufnahme von SchleifmittelnØ 50, 70 , 90, 120 mm x 223 mmneuer Motor

sanding belt length:max. 470 mmworkpiece dia.:600 mmtable - swivable:0 - 6 Gradtaper:Reitstock Morse 2 turning speed range::1260 - 3100 U/mintable movement:längs 470 mmtool taper:schwenkbar 0-6 °, 90° dre total power requirement:0,4 kWweight of the machine ca.:950 kgdimensions of the machine ca.:1100 x 1100 x 1500 mmDocuments:vorhanden

max. grinding diameter:50 mmgrinding length:250 mmworkpiece length:300 mmtotal power requirement:0,7 kWweight of the machine ca.:330 kgdimensions of the machine ca.:1000 x 1000 x 1400 mm

grinding length:600 mmgrinding width:250 mmworkpiece height:380 mm:Sinumerik max. dia. of grinding wheel:300 mmweight:4000 kgtotal power requirement:12,5 kWgrinding wheels:Ø 400 mmmax. width of grinding wheel:100 mmgrinding wheel hole diameter:127 mmturning speeds:470 - 12030 1/minx-axis:600 mmy-axis:300 mmz-axis:250 mmgrinding range:450 x 200 mmdistance spindle nose and table:500 mmtable load:250 kgdimensions of the machine ca.:2600 x 2100 x 2400 mmswitchgear cabinet:1300 x 800 x 2000 mmhydraulical unit::450 x 350 x 500 mmDocuments:vorhanden
