Multi-spindle turn automatics used for sale (30)

Schütte SF51 6-spindle bar machine Suitable for complex turning operations in metalworking The Schütte SF 51 is a proven, cam-controlled 6-spindle bar machine with 51 mm spindle passage, ideal for the efficient series production of turned parts. These robust machines feature an electronic cam switch that provides high process stability and flexibility in turning, drilling, and tapping. The machine is appreciated for its stability and flexibility in the production of demanding workpieces Manufacturer: Schütte Type: SF 51 Cam-controlled multi-spindle bar machine Number of spindles: 6 main spindles Control: Conventional Spindle passage: 51 mm Feed max. 125 mm Turning length max. 102 mm Drilling depth max. 102 mm Tapping device Chip conveyor 6-fold loading magazine Voltage: 400 V Year of Make: 2004 Dismantling and removal by buyers Dismantling also possibl ...

Schütte SF51 6-spindle bar machine Suitable for complex turning operations in metalworking The Schütte SF 51 is a proven, cam-controlled 6-spindle bar machine with 51 mm spindle passage, ideal for the efficient series production of turned parts. These robust machines feature an electronic cam switch that provides high process stability and flexibility in turning, drilling, and tapping. The machine is appreciated for its stability and flexibility in the production of demanding workpieces Manufacturer: Schütte Type: SF 51 Cam-controlled multi-spindle bar machine Number of spindles: 6 main spindles Control: Conventional Spindle passage: 51 mm Feed max. 125 mm Turning length max. 102 mm Drilling depth max. 102 mm Tapping device Chip conveyor 6-fold loading magazine Voltage: 400 V Year of Make: 1979 Dismantling and removal by buyers Dismantling also possibl ...

Number of spindles 8 Max. bar feed in one station: 130 mm Max. bar feed in two stations: 260 mm Max. stroke radial slide: 52 mm Radial slide adjustment: +- 12 mm Max. stroke axial slide: 72 mm Max. stroke tool spindles: 106 mm Adjustment of tool spindles: +- 10 mm Main spindle speed: 500 - 4,000 1/min Piece time: 2 - 80 s Number of tool positions: 18 Weight: 12,600 kg

X-axis travel mm: 260 Z-axis travel mm: 590 B-axis travel mm: 624 Turning length mm: 515 Max. turning diameter mm: ø: 366 Swing over bed mm: ø: 923.8 Swing over cross-slide mm: 755 Bar work capacity mm: 52 Upper turret Number of tool slots St .: 16 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5/5.5/3.7 (3min/5min/cont) Indexing time s: 0.25 Main spindle Speed spindle rpm: 6.000 Drive power spindle kW: 11/7.5 Spindle bore mm: 61 Chuck type: Hollow Chuck (6") Manufacturer: KITAGAWA Spindle nose: JIS A2-5 Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 11/7.5 Spindle bore mm: 43 Chuck type: Hollow Chuck (6") Manufacturer: KITAGAWA Coolant system Tank capacity liter: 235 Equipment Chip conveyor Signal lamp High pressure pump Chuck foot switch (double) for main and counter spindle Interface for ...

6 spindles Tapping Cross drilling Thread Rollers Milling apparatus a lot of accessories Feed motor (spindles) defective! with bar feeder IEMCA PRA 40/32 P

Fully functional Index Lathe Location of the machines: 76661 Philippsburg The machines can be viewed on site at any time. They are in our warehouse and work perfectly. You can make an appointment for a viewing at any time before bidding on +49 (0) 72 55 / 39 73 337. We would love to hear from you.

4x compound slide - Pos.1; Pos.2; Pos.4; Pos.5 4x indipenden feed - Pos.1; Pos.2; Pos.4; Pos.5 threading device 1x threading spindle pick-up spindle broaching device set of cams set of collets bar-loader Cucchi Giovanni (YOM 2004)

• Siemens 840 C controller • Location I + III + IV + VI: Longitudinal and transverse slide • Position II + V: CNC slide and longitudinal slide Bvxhlj3gi3 • Advance position VI • Interceptor Position VI • KS system (emulsion) • Loading magazine Cucchi model Multi-6 156C15, YOC 2015, • Ruez hinge belt conveyor in the machine bed • Hinge conveyor Knoll 280 S-1/40 ID 26565 (outside) • Electrostatic separator ISI RON/A 2500A, ID 26295 • Without further accessories / tools • CUCCHI BLT Model Multi -6 YOM 2015

Codice: 0222 - AI

various accessories / spare parts for Tornos AS 14

8-spindle rotary machine Built in 1989; serie 25 Refurbished in 2012 • New electrics • New bearings • Guided tours • CNC cross slide in position 7 • Spindle stop setup • Material rod guide • Chip conveyor • Pick-up spindle position 8 • Calibration device • Various tool holders • Various curves
