paper converting: carton gluers used for sale (67)

Reference ID: PP-56409 Category: Folder Gluer Manufacturer: Jagenberg Model: Diana 165-4 Year Built: 1999 Color: - Impression: - Working Hours: - Speed: - Max. Size: 1650 mm Min. Size: - Condition: Good Location: Europe Availability: Immediately Machine Description: Automatic feeder unit Extended folding and transfer section Press/delivery section Conveyor-type delivery Linear rail-based manual adjustment elements Top control panel / operator panel Safety equipment (protective guards, emergency stop, etc.) Gluing line (glue application infrastructure available)

Reference ID: PP-56048 Category: Folder Gluer Manufacturer: Bobst Model: DOMINO 145 II Matic Year Built: 1996 Condition: Good Location: Europe Availability: Immediately Price: 85.000€ LOT Key Features & Equipment • Longitudinal seam configuration • Automatic bottom system (3-point) • 4/6-point gluing capability • Cold glue system by Valco (Year 2019) with 5 nozzles • Hot melt gluing system by hhs-Xmelt (Year 2017) with 3 nozzles • Integrated handle applicator • CoroPack 125 Bobst included (Year 1996) – electronics renewed

Format range: max. 1000 mm, min. 56 mm Equipment: Longitudinal seam, folding bottom, double edge, 4-point gluing, new servo overhaul folding with program memory, electronic Nordson top gluer with 2 application heads, Disc underglue on the left, feeder with vibrator and tooth gauge, Belt pre-crusher right, left up to max. 30 mm, additional central transport, folding floor module A2 with additional upper and lower centre transport, additional central transport in folding station, pneumatic kicker, counter, digital position indicators, Bobst CUBE control, camera monitoring, remote control, small box device, pneumatic, extended press belt. Overhaul 2026: cleaned, checked, painted and with new feeder and transport belts.

Format range: Box length: 80-535 mm Box width: 50-400 mm Equipment: motorized right turn / back dust margin, laser counter, speed infinitely adjustable via potentiometer. Packing scheme: 1–4 rows / layers, results in 16 possibilities. Overhaul 2025: cleaned, checked, painted, new belts. Machine can be viewed by appointment while running.

Bobst Domino 145 II Matic, Year 1996, Longitudinal seam, Automatic floor (3-point), 4/6-Punktklebung, Cold glue system from Valco Year 2019 with 5x nozzles, Hot melt adhesive system by hhs-Xmelt year 2017 with 3x nozzles, Handle dispenser, CoroPack 125 Bobst is included, year 1996 - electronic is new.

Format range: max. 1100 mm, min. 66 mm. Equipment: Longitudinal seam, folding bottom, double edge, 4+6 point gluing, electronic HHS X-tend top gluer, 8 channel with 6 application heads, equipped with the following additional modules for quality assurance: code reader / disc glue control / / pinball ejector control, disc bottom glue unit left, feeder with vibrator, tooth gauge and vacuum, cutting alignment right and left after the feeder, pre-crushing module, electronic servo overhaul folding with program memory, radio remote control, digital Position indicators, motorized format adjustment, fully automatic format setting with box storage, pump-up glue unit, Central transport in the folding, 2x motorized tool holders that can be raised, pressing device after folding, flipper ejector, kicker, counter, camera monitoring of the transfer station, 2x box aligner on the press belt, exte ...

HEIDELBERG DIANA SMART 115, Manufacturer: HEIDELBERG, Year of construction: 2018, - 2018, - Folding Carton Line, - longitudinal seam carton:, - max. 1150 x 600 mm, - min. 75 x 55 mm, - min. 45 x 55 mm (with small carton device), - Fold-bottom carton:, - max. 1150 x 600 mm, - min. 146 x 80 mm, - 4-point erecting carton:, - max. 1150 x 680 mm, - min. 120 x 110 mm, - 6-point erecting carton:, - max. 1150 x 630 mm, - min. 250 x 130 mm, - with BELKHOFF control system, - Rolling and drying tunnel, - TÜNKERS EAS 480 output station, right, 2019, - in production, - Available: immediately, - Located in: Germany

Format range: max. 940 mm, min. 50 mm Equipment: Longitudinal seam, folding bottom, double edge, electronic top gluing unit HHS X-pect, 8 channel with 3 application heads, disc underglue unit left, Pre-crusher right and left, kicker, counter, vibrator on the feeder, digital Position indicators, threading station, lower center feed in folding, pneumatic, intermittent press belt, cleaned, tested.

Format range: Max. sheet size opened: 2300 x 1000 mm Min. sheet size opened: 380 x 160 mm Min. sheet size folded: 185 x 130 mm Equipment: Longitudinal seam, folding bottom, double margin, 4 + 6 point gluing, electronic glue mill HHS XTS-E16 cold glue system, BJ. 2023 with 8 application heads, counters, fully automatic format setting, boxflow control with Touchscreen display, extended pressing station, ACE feeder with vacuum, material: Corrugated board with corrugated A, B, C, E, F, FE, EE, BE, BC, solid board: 800–1500 g/m², Maximum mechanical speed: 250 m/min, Bahmüller Retrofits 2025, including fully automatic SMB COR-Flex bundling machine. The machine is in very good condition and can be used by arrangement in production.

Format range: max. 1350 mm, min. 45 mm. Equipment: Longitudinal seam, folding bottom, double edge, 4-point gluing, electronic top gluing unit HHS X-tend, 8 channel with 4 application heads, high pressure, disc underglue unit left, Feeder with vacuum and vibrator, cutting alignment right and left, primary crusher right and left, kicker, counter, digital position indicators, add-on module for Folding bottom and 4 point, motorized center feed top/bottom in folding, Press rollers after folding, servo overhaul folding with touch screen, Camera monitoring of the deposit, cutting alignment on the press belt, extended, pneumatic press belt, cleaned, tested and painted in 2023.

Bahmüller Turbox BJD 2100, Max. Size: 2100x1200 mm, Min. Size: 380x160 mm, Longitudinal seam bonding, Automatic floor, 4-6 point bonding, Solid board: 800-1500 g/m², Hebklwexni D Eevy Aefn, Corrugated: N,F,E,B,C,A,EE,EB,BC etc.

Box format: Length: 100 mm - 400 mm Width: 50 mm - 320 mm Equipment: Standard, right-hand delivery, box material: 200-700 g/m², Box types: normal folding boxes, folding bottom boxes, 4-point erecting boxes, 6-point erecting boxes. Machine can be viewed by appointment while running.

Folder Gluer, ACE MACHINERY Model SIGNATURE 110N 46CS, Manufacture date: 1998, - Max Carton Width: 1.100 mm, - HHS Gluing device type KFE-KPE9, cold glue, The machine was mainly used for gluing shoe boxes and was modified/adapted, for this purpose to perform longitudinal seams and double longitudinal seams.

Automatic Folder-Gluer ETERNA EFOLD 1100 ELITE Year of 2021 ETERNA - A Bobst Group Company - Lateral alignment at the feeder (both sides) - Tools and fixtures for 4-point and 6-point gluing - ERO gluing system (cold glue), year of manufacture 2020 - Pre-breaker Technical details: Gram weight: 200-800 g/m² Total power requirement: 35 kVA, Grammage: 200-800 g/m2, Total power requirement: 35 kVA

Format range: max. 680 mm, min. 126 mm. Equipment: Longitudinal seam, folding bottom, double edge, electronic top gluer HHS, 4 channel with 2 application heads, double disc top glue, disc bottom gluer left, Bobst CUBE control, vibrator, primary crusher right and left, kicker, counter, digital position indicators, additional center transport at the top / bottom of the Folding station, folding floor module, pneumatic, intermittent press belt. Overhaul 2025: cleaned, checked, painted, new feeder and transport belts.

Format range: max. 1650 mm, min. 275 mm Equipment: Longitudinal seam, folding bottom, double edge, 4-point gluing, Baumer HHS electronic glue mill with 4 application heads, Disc underglue unit on the left, electronic overhaul folding, Feeder with vacuum, cycle feeder, primary crusher left, motor-driven upper transport stations, kickers, counters, digital position indicators, extended folding station, motorized Threading station, Jagenberg DBS 01 control, fully automatic Format setting Jagset II, 3 x alignment on the press belt, pneumatic, intermittent press belt. Overhaul 2023: cleaned, checked, painted and equipped with new feeder and transport belts

Lamina crash-lock gluer year: Specifications: Max thickness: 4mm for crash lock boxes 6mm for standard boxes Minimum thickness: 1mm corrugated flute type: E, B, C, Corrugated flute type: E, B, C

Diana Jagenberg 115-3 year:1990 -straightline -lockbottom -4 corners -6 corners -vibrator -football -counter -pre breaker without electronic glue system

Window patch machine Heiber & Schroeder, Year 1986, Model: WP 1

ANTER 800, year 2002 – serial Nº 576/632, straightline boxes, lockbottom boxes, 4 corner boxes, Max. size: 800mm; min. size: 106mm, Max. length box: 650mm, min. Length box: 60mm, Material: cardboard from 200gr/m2 up to 600gr/m2, Speed: Up to 350m/min., Cold glueing unit PAFRA with 2 guns, Semiautomatic packer VESTAPACK year 2001, nº 507

Format range: max.: 450 x 450 mm min. 100 x 100 mm Equipment: 1 mold shaft, electronic nozzle gluing system HHS C 421 with 2 application heads, approx. 800 operating hours, max. 6,600 boxes / hour.

Format range: max. 1100 mm Equipment: Longitudinal seam, folding bottom, double edge, 4+6 dot gluing, feeder with suction belt and vibrator, electronic servo overhaul folding with touch screen and job memory, Accufeed (cutting orientation right / left after the feeder), primary crusher right and left with additional central transport top/bottom, disc bottom gluer on the left, electronic upper gluer ERO, 8 channel with 4 application heads, radio remote control, extension module A2 with lower upper central transport, Central transport at the top / bottom in folding, pressing device left/right, digital position indicators, pneumatic kicker, cutting alignment and video monitoring on the press belt, pneumatic, extended press belt.

Format range: max. 680 mm min. 126 mm Equipment: Longitudinal seam, disc underglue unit left, Vibrator & dental gauge on the feeder, Bobst CUBE control, primary crusher right and left, kicker, counter, fully automatic format setting with program memory, pneumatic, intermittent press belt. Overhauled 2022: cleaned, checked, painted, new jetty and Transport belts.

Automatic Folder-Gluing Machine Manufacturer: Eterna Type: Efold 1100 Elite Year of Make: 2021 For microcorrugated cardboard and cartons Carton: 200-800 g/m² Corrugated cardboard: N/E/F flute Belt speed: 320 m/min (420 m/min as an option) Jogging speed: 20m/min. Main motor: 11kW Overall length: 12.7 x 2.6 m Total weight: 7 tons. Max. cutting width: 1100 mm Incl. ERO-TE high-pressure gluing system for folding carton gluers 4 cold glue nozzles

Format range: max. 750mm, min. 66mm. Equipment: Longitudinal seam, folding bottom, double edge, motorized format adjustment, electronic top gluer Robatec, 8 channel with 6 application heads, feeder with vibrator and self-drive, vacuum at the feeder, dental gauge, quick feeder belt adjustment, video surveillance at the handover, cutting alignment according to the feeder right and left, HHS Xtend² quality assurance system with code reader pane underglue control, disc subglue unit left with fully automatic HHS pump-up glue unit and Level control, mechanical disc top gluing unit with 2 stations, Pre-crusher right and left, kicker, counter, Bobst CUBE control, digital Position indicators, motorized additional station for folding tool, middle station in folding, additional upper middle station in folding, pressing device right/left after folding, rejection by Bobst flipper in the trans ...

Printed circuit board 734 QI (PCB) / control PC with integrated touch display on the insert, for Bobst Alpina 110 II matic. PCB Printed circuit boards 734 QI / control PC with integrated touch display on the feeder, for Bobst Alpina 110 II matic. Manufacturer numbers and replacement numbers: BSA07230000BW / BSA07230000BT / BSA07340000TH

Control Card / Plug-in Circuit / PCB Board for Bobst Alpina 110 II matic. Control card / plug-in circuit / PCB board for Bobst Alpina 110 II matic. BSA0701239601

Control Techniques Undrive M701 frequency inverter, with 5.5kW power. For Bobst Alpina 110 II matic. Control Techniques Undrive M701 frequency inverter, with 5.5 kW output. For Bobst Alpina 110 II matic.

Bobst Cube / monitor with control unit for transfer station, Bobst Alpina 110 II matic. Used and tested. Bobst cube / monitor with control unit for transfer station, Bobst Alpina 100 II matic. Used and tested. BSA07320000TG / H12P+P50S1

well-preserved banding machine by Karl Tränklein, 55cm working width. Cleaned and tested
