67 KEYENCE used machine for sale

Manufacturer: Keyence Model: Agilista 3200W Input Voltage: 100-240V AC, 50/60Hz Power Consumption: 750 VA Certification: CE Find more here - / Contact us at -

The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The following components make up the full WM-3000 series kit:PositionModel/ArticleDescriptionOrigin1WM-3000Coordinate Measuring System (Main Head) Japan 2WM-S1Camera Stand (Kamerastativ) —3—Laptop with Measuring Software —4WM-8C1Battery Charger (Akkuladegerät) China 5WM-B1Battery (Messstab Akku) China 6—Training Fee for WM series —7WM-V30DService Package —8OP-88032Mouse, German User Manual, and WM accessories Find more here - / Contact us at -

Manufacturer: Keyence Model: IM-8000 Type: Image Dimension Measurement System Software Version: B-13.0.0.28-11.07-20.07.09.01 / A2.05-A1.27-A3.03-9B.06-9B.06-02.01-03.02 Sensor: 20-megapixel CMOS Stage Size: 300 x 200 mm Measurement Capacity: Up to 300 features in a single measurement cycle Condition: Used, fully functional Find more here - / Contact us at -

Manufacturer: Keyence Model: IM 8020 Year of Manufacture: 2023 Find more here - / Contact us at -

Manufacturer:Keyence Model: IM6025 Year of Manufacture: 2016 Find more here - / Contact us at -

Manufacturer: Keyence Model: WM 3000 Year of Manufacture: 2020 Type of Machine : 3D coordinate measuring system The device has already been upgraded to Windows 11 Measurement Specifications - Maximum Measuring Range (W x D x H) 10000 x 3500 x 5000 mm - Guaranteed Accuracy Range (W x D x H) 3000 x 1500 x 1500 mm - Measuring Accuracy +/- (28 + 5L/1000) micrometers - Repeatability +/- 10 micrometers Minimum Display Resolution - Distance Resolution 0.001 mm - Angle Resolution 0.001 degrees Camera Unit Rotation - Theta Rotation (Pan) +/- 90 degrees - Tilt Rotation +/- 30 degrees Connectivity - External Input Voltage-free input, 2 inputs - Bluetooth Bluetooth 5 - USB USB 3.0 - Infrared Communication 945 nm Power Supply - Power Supply Type Supplied via dedicated power supply unit - Rated Voltage DC 24 V - Power Consumption 1.7 A Environmental Conditions - Operating Temperature + ...

The operating times are specified with 1387 h. However, this is the time that the printer was connected to the network. The pure printing time is 40 h The printer was serviced regularly until last year in March 2022. Technical data Model AGILISTA-3200W Printing material AR-M2 (transparent printing material), AR-H1 (heat-resistant printing material), AR-G1L (silicone rubber [low hardness]), AR-G1H (silicone rubber [high hardness]) Support material AR-S1 (water soluble support material) Installation space 297 × 210 × 200 mm (A4 size × 200 mm) Resolution 635 × 400 dpi Layer thickness High resolution AR-M2: 15 µm Normal resolution AR-M2: 20µm AR-H1: 20µm AR-G1L/H: 30µm Power supply Supply voltage 100 to 240 VAC, 50/60 Hz Power consumption Max. 750 VA Interface Ethernet 10BASE-T / 100BASE-TX Operation Interactive color touch panel Software Name Mode ...

This KEYENCE IM-7030T was manufactured in 2018. It features a digital measuring projector with a 300x200 mm measuring field, light probe, and height probe. Accessories include a control unit, AC power cable, mouse, keyboard, and a user manual in German. Consider the opportunity to buy this KEYENCE IM-7030T optical measurement machine. Contact us for more information.

This KEYENCE IM-7030T optical measurement machine was manufactured in 2020. It features a digital measuring projector with a 300 x 300 mm measuring field, height probe, and photograph sensor. Accessories include a flat stylus, AC power cable, and a control unit. A mouse, keyboard, and a German user manual are also provided. Contact us for more information about this machine.

Measuring range: X24, Y 18, Z 10 mm weight of the machine ca.: 35 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8001 Type: IM6120 Producer: KEYENCE Created: 2014 Parameters: Axis X: 100 mm Axis Z: 30 mm Measuring range: 200 x 100/125 x 25 mm Weight: 36 kg

Keyence Digital Measuring Projector ? Model XM-1600 General: Digital measuring projector with a high resolution image measurement system and very easy operation. Place the part on the stage and measure by pressing a button. Supports automated measurements of up to 300 dimensions within seconds. Measuring Head / Control Unit: ·Sensor: Monochrome CMOS 1 inch, 20 megapixels ·Display: 12.1 inch LCD monitor (WXGA 1280 x 800) ·Lens: Double telecentric lens Measuring Field and Measuring Range: ·Standard measuring field: approx. 100 mm diameter ·Precision mode measuring field: approx. 25 x 25 mm Measurement Accuracy and Repeatability: ·Display resolution: 0.1 micrometer ·Repeatability (standard, without stage movement): approx. plus minus 1 micrometer ·Precision mode (without stage movement): approx. plus minus 0.5 micrometer Stage / Travel Axes: ·XY measuring stage: motorized ·Z axis ...

An inkjet-based industrial PolyJet/material jetting 3D printer Keyence for photopolymers is available. Build volume dimensions X/Y/Z: 297mm/210mm/200mm, resolution: 635dpi/400dpi, XY resolution: 63.5µm/40µm, layer thickness range: 15µm-30µm, machine dimensions X/Y/Z: approx. 950mm/700mm/1400mm, weight: approx. 200kg. Documentation available. An on-site inspection is possible.

Camera-based code readers, uEye camera, industrial camera, high-performance camera -Manufacturer: Keyence, Industrial camera, 16x speed, 5-megapixel camera (B/W) -Type: CA-H500MX -Dimensions: 115/70/H60 mm -Weight: 0.4 kg

Proximity switch, proximity sensor, proximity sensor -Manufacturer: Keyence, proximity switch proximity sensor unused original packaging -Type: EM-030P -Number: 2x encoder available -Price per piece -Dimensions packaging: 110/105/H25 mm -Weight: 0.1 kg/pcs

Fiber optic measuring amplifier, fiber optic sensor, fiber optic sensor with digital sensor -Outputs: 2 -Connector: M-8 -Expansion unit: PNP -Weight: 0.2 kg

Fiber optic measuring amplifier, fiber optic sensor, fiber optic sensor with digital sensor -Output: 1 -Connector: M-8 -Expansion unit: PNP -Weight: 0.2 kg

Fiber optic amplifier, fiber optic sensor -Manufacturer: Keyennce -Type: FS-V31CP -Weight: 0.2 kg

Fiber optic measuring amplifier, fiber optic sensor, fiber optic sensor with digital sensor -Output: 1 -Connector: M-8 -Expansion unit: PNP -Weight: 0.2 kg

Measuring amplifier, power supply module, point-type measuring amplifier, ionizer, static eliminator, static eliminator -Manufacturer: Keyence, Static Eliminator Stabilizer -Type: SJ-M300 -Dimensions: 130/70/H35 mm -Weight: 0.1 kg

Fiber optic measuring amplifier, fiber optic sensor, fiber optic sensor with digital sensor -Output: 1 -Expansion unit: PNP -Weight: 0.2 kg

Image processing system, central unit, high-end image processing, image processing controller, camera controller -Manufacturer: Keyence, Image processing system, Image processing controller -Type: XG-X2800 -Expansion module: CA-E200L (see photos) -Submission/Price: complete -Dimensions: 200/155/H175 mm -Total weight: 2.5 kg

Marking laser, control unit, full-spectrum sensor, sensor -Manufacturer: Keyence, full-spectrum sensor, unused, original packaging -Type: LR-W500C -Voltage: 10-30V DC -Cardboard dimensions: 180/110/H650 mm -Weight: 0.2 kg

Camera-based code readers, uEye camera, industrial camera, high-performance camera -Manufacturer: Keyence, Industrial camera 16x high-speed line scan camera with 4096 pixels -Type: CA-HLO4MX -Dimensions: 110/50/H70 mm -Weight: 0.4 kg

Sensor Module, Incremental Encoder, Encoder Relay Unit, Encoder Unit -Manufacturer: Keyence, Encoder Unit -Type: CA-EN100U -Dimensions: 130/55/H30 mm -Weight: 0.1 kg

Measuring amplifier, power supply module, measuring amplifier point design -Manufacturer: Keyence, Measuring amplifier point version -Type: SJ-M300 -Dimensions: 130/50/H75 mm -Weight: 0.2 kg

Fiber optic measuring amplifier, fiber optic sensor, fiber optic amplifier -Manufacturer: Keyence, fiber optic amplifier with accessories -Type: FS-N41C -Voltage: 10...30 V DC -Transport dimensions: 120/120/H30 mm -Weight: 0.1 kg

Measuring amplifier, power supply module, measuring amplifier point design -Manufacturer: Keyence, Measuring amplifier point version -Type: SJ-M300 -Discharge rod: Type SJ-M030G -Number: 3x measuring amplifiers available -Price: per piece -Transport dimensions: 250/180/H80 mm -Weight: 0.9 kg/pc.

Image processing system, central unit, high-end image processing, image processing controller, camera controller -Manufacturer: Keyence, image processing system image processing controller -Type: XG-X1500 -Extension modules: -DC40E / -NEC20E see photos -Shipping/Price: complete -Dimensions: 180/150/H175 mm -Total weight: 2.5 kg
