packing machines used for sale

For one of our customers in parquet production, we completed and commissioned a complete palletizing system including wrapper. The system ensures efficient, safe and fully automatic palletizing of the finished parquet packages – from stacking to transport securing with stretch film. With well thought-out conveyor technology, robust design and simple operation, the line offers maximum reliability in daily use.

Crate unpacker for 0.5 litre and 0.33 litre longneck glass bottles Manufacturer: Krones Model: Linapac II Bottle holder: 6x20 or 6x24 bottles Year of construction: 2005, Additional title: Unpacking machine for glass bottles, Performance approx.: 50000 bottles/h, Air consumption: 0,0002 m³ / bottle, Number of packing heads: 6 pc., Power: 24,5 kW, Voltage: 230/400 V, Frequency: 50 Hz, Length: 6160 mm, Width: 4120 mm, Height: 5033 mm, Weight: 2500 kg, Formats: 0.5 l glass bottle (D=68.5 mm H=270 mm; Ale / Longneck), 0.33 l glass bottle (D=61 mm H=238 mm; Ale / Longneck), Running direction: across, right -> left, Operation / Control: PLC, control box with touch panel, Position: free standing, Base construction: Square tube frame on spherical feet, Features: 1 basic machine (lifting mechanism, horizontal linear unit, gripper head carrier, movement axes), 2 gripper head sets (frame with 6 rin ...

Additional title: crate packer, Capacity for plastic crates: 500 cycles/h , Power: 11 kW active power/ 15 kVA apparent power, Voltage: 230/400 V ± 5 %, Frequency: 50 Hz ± 2 %, Length: 4170 mm, Width: 2550 mm, Height: 2650 mm, Weight: 4300 kg, Formats: Max. height: product: 360 mmm, plastic crate: 380 mm, cardbord box: 500 mm, Features: 2 heads à 20/24 bottles, construction with T-flange table quick hitch, only work with glas bottles, incl. filled crate inspector, Krones Checkmat

Pallet binder including protective grating to secure the danger zone of the work surface., Overall capacity of the palletising system approx.: 45000 bottles/h, Operating pressure: 5 bar, Power: 2,5 kW, Length: 2,45 m, Width: 0,9 m, Height: 2,9 m, Weight: 1500 kg, Material: tying material: PE cord

RICO-bottle packer, fully-automated, L-execution, for packing of 500 g yoghurt glasses., Additional title: Bottle packer, Capacity: 24 glasses/phase 500 g yoghurt glasses, Max. capacity: 550 phases/h, Power: 2,7 kW, Voltage: 3x230/400 V, Frequency: 50 Hz, Compressed air: 5 bar, consumption approx. 15 m³/h, Length: 2,35 m, Width: 2,15 m, Height: 2,30 m, Weight: 5000 kg

Further photo and video material can be sent on request. The orange painted components on the machine were recently renewed., Additional title: Keg-palletiser and depalletiser, Capacity approx: 240 Keg/h, Operation / Control: Siemens S7-300, Base construction: fixed on a plate with 12 bolts in the foundation, Features: gripping arms that can lift 2 Kegs or 1 empty pallet, control cabinet, ABB control monitor, safety fence (in consultation)

Pump station. Pre-run pumps for filling line, Keg line and for filtration, Euro-Hygia II Adapta-Super: Flow rate: 10 m3/h pump head - 55m, Euro-Hygia I Adapta-Super: Flow rate: 4 m3/h pump head - 45m, Operation / Control: Proleit V6, Material: Stainless steel, Base construction: Frame, Features: 3 Pumps; 3 flow meters; process measurement instruments

Additional title: Residual liquid, bottom, mouth, sidewall control, Capacity: 32000 bottles/h, Power: 3,6 kW, Voltage: 400 V, Frequency: 50/60 Hz, Compressed air: min. 6 - max. 10 bar, Length: 2,5 m, Width: 1 m, Height: 2,5 m, Weight: 1700 kg, Formats: Longneck-, Steini-, Vichy- 0,33 l bottles / 0,5 Longneck-, NRW- 0,5 l bottles, Running direction: right-left, Operation / Control: Heuft, Features: residual liquid, bottom, body, mouth, side wall

6 bottles are each enclosed and glued with solid cardboard sleeves. Two openings on the top provide a practical carrying option, while the large side surface offers space to advertise the brand and product. Formats currently in use: 6x0.33 litre Vichy, 6x0.33 litre Longneck. The machine can also be converted to other bottle sizes., Additional title: cardboard packer, Capacity: 36000 bottles/h, Power: 26 kW, Voltage: 420 / 230 V, Frequency: 50 Hz, Compressed air: 6 bar / 400l/min, Formats: 6x0.33 l Vichy bottle (internal carton-dimensions 709 x 181 mm), 6x0.33 l longneck bottle, Operation / Control: on-site control unit, ELAU: PacDrive C600

Industrial robot for the loading and unloading of pallets with filled and empty bottles in crates., Additional title: Pallet packing and unpacking, Capacity: 3000 Crates/h, Lifting load: 360 kg, Length: 2,20 m, Width: 1,40 m, Height: 2,60 m, Weight: 2400 kg, Formats: Euro-Pallet EUR1, Operation / Control: Hand-held programming device, Features: Clamp fixture; Maintenance-free AC servo-motors

Characteristics, Volume: 500 ml, Format: Prisma

Specifications Manufacturer Benhil Model 8312 Junior Year 1977 Condition Used Serial Number 312/57 Type of Machine Butter Packaging Machine Capacity ± 750 Kg/h Capacity (Units) up to 50 packages per minute Packaging Weight 250 gram Packaging Size 100 x 75 x 35 mm (German standard) Packaging type Bottom folding Motor power 2,2 kW Dimensions 300 x 170 x 200 cm Weight ± 1.275 kg Description Foil wrapping machine which can be used for packing products butter, lard, margarine, tvorog or cottage cheese into aluminium foil or parchment paper. This machine is in a reasonable mechanical and electrical condition (renewed by Schuy, auftr. nr: 13632-01). The format on the machine is Standard size: 250 gram, 100 x 75 x 35 mm, bottom folding. Capacity: up to 50 portions per minute. The butter is feed with an aluminium through with aluminium augers. Aluminium dosing station. T ...

Specifications Manufacturer Benhil Model 8311 Junior Condition Used Type of Machine Butter Packaging Machine Capacity ± 600 Kg/h Capacity (Units) up to 40 packages per minute Packaging Weight 250 gram Packaging Size 100 x 75 x 35 mm (German standard) Packaging type Bottom folding Motor power 1,5 kW Weight ± 840 kg Description Foil wrapping machine which can be used for packing products butter, lard, margarine, tvorog or cottage cheese into aluminium foil or parchment paper. The format on the machine is Standard size: 250 gram, 100 x 75 x 35 mm, bottom folding. Capacity: up to 40 portions per minute. The butter is feed with an aluminium through with aluminium augers. Aluminium dosing station. The machine is equiped with a later build on photocell on the paper infeed, to control the exact position of the print on the foil. Outfeed conveyor.

Packaging of bottles or similar shaped products into cardboard trays or shrink packs (depending on configuration). Ideal for use in beverage, food, or pharmaceutical production lines., Working principle: Tray packaging / outer packaging, Product dimensions: Adjustable depending on the format, Control system: Siemens S7 PLC, Compressed air: Required, approx. 6 bar

Used vacuum packaging machine made by TEPRO, type: PP-12S. New 2001. Technical specifications: - For vacuum sealing of trays in gas, - 4 molds (2 round and 2 rectangular), - Gas dosing, - MAX depth of tray 80mm, - Usable dimensions 750/720/1120mm, - Weight 250 kg, - Pump capacity 100 m3/hour. - Controller by MIXTER company.

Used flow pack packing machine made by UNIPAK, model: ASG-1. Very good condition.

Pieri brand film palletizer, model AVR-101-PEA. Bridge system with wraparound movable arm. Solid and automated structure. Brand: Pieri Model No.: AVR-101-PEA Type: Bridge with movable arm Total height: 2.5 m Automatic pallet wrapping machine

Complete weighing and clipping line, 2 lines available., Photos in the album are from production, the equipment is now available from our stock in Emmeloord. Professionally dismantled by STC, - Complete line, - Affeldt AVN112CW 10EVMD, - Affeldt AVN 955 T18 clipper no.2024-2008, - Platform for the weigher, - funnel, collection gate, - take away conveyor belt, - Complete line, - Affeldt AVN112CW 10EVMD, - Affeldt AVN 955 T18 clipper no. 2027-2011, - Platform for the weigher, - funnel, collection gate, - Extra equipment, - Electric cabin, - Bodijn feeding conveyor belt, - Flat conveyor belt for boxes, - A lot of spare parts (contact for more details)

Record PANDA flow-packer with automotion in-feed system., In stock now, more information soon.

More info soon

Tetra Pak Tetra Film Wrapper 66 (TFW 66), previously used for Tetra Brik 1.000 ml Slim cartons with a package pattern of 2x2. Film wrapping your carton packages gives you cost-effective product grouping & protection and then speeds up shelf replenishment for the retailer. This Tetra Film Wrapper 66 was running in combination with a Tetra Pak TBA/8 carton filler. Number of production hours: 9.268 hours. Package length of 90, package width of 47-59 and package height of 195-204. Conveyor width: B68. Conveyor infeed: 53. Conveyor speed in: 27 m/min. Feeding side: right hand. Outfeed: unit conv. 54 right hand. Power: 400/230 V - 50 Hz. Film used: Polyethene film, 1259180-0010. Drawing spec: 674967-0201. Control panel with GE Fanuc Series 90-30 PLC and separate Tetra Pak operation panel. The production capacity goes up to 7.000 packs per hour. Including all available manuals., Type of Machine ...

This Pattyn PI-3 case closing machine is used in packaging lines, after the fillers, for closing of the cases filled with product. In this case it was used in a Margarine / Butter factory. Case dimensions: max L 400 x W 300 x H (flaps up) 500 mm and min L 300 x W 200 x H (flaps up) 200 mm. The thermo sealing of the bag protects the product. The working sequence consist of 3 stations: Station 1) Thermo sealing of the PE bags (the air is removed out of the bag before sealing). Station 2) Closing of the short flaps of the case (the long flaps are brought down to the short flaps). Station 3) Closing of the long flaps-top of the case with self-adhesive tape. The 3-in-1 stations are on line in one unit framework with plexiglass interlocked doors. Output of the machine: up to 8 cases per minute. Power: 3 kW - 380 V - 50 Hz. Compressed air: 50 NL/cycle. Air pressure: 6 bar. Control panel with Si ...

This Pattyn Razim bag forming / case lining machine is used for all industries requiring american size of cases with PE film lining for the bulk packaging of semi-liquids, granulates and other products. In this case it was used in a Margarine / Butter factory. Case dimensions: max L 420 x W 300 x H (flaps up) 550 mm and min L 180 x W 170 x H (flaps up) 200 mm. This machines makes flat bottomed bags of gusseted lay flat tubing. Four sealheads under 45° seal the corners and are followed by horizontal seal- and cut off head. The sealed corners of the bag prevent the intrusion of the product into the corners. Easy taking out of the product without tearing off the film. Low cost bags from standard reels of gussted lay-flat tubing. 2 Reel positions on the machine. The bag is opened by means of specially developed snap suction technology and then inserted into a case. Anti-static ionisers. Inf ...

SAMMELHEFTER STITCHING MACHÄ°NE ST 100, 6 STATION OHNE UMSCHLAGSTATION

Dispensing system for capsule 16-fold with Packaging automation Abstract: The capsules are removed from the open form with the removal arm. On the removal arm, the presence of the parts is controlled. As soon as the removal arm reaches its end position in the robot the parts are turned with a 180° turning station. After the turning process, the capsules are stacked directly horizontally. A separate stack is formed for each cavity. Once the stacks have reached a number of 24 pieces, all of them are Stack ejected into a buffer. This buffer is driven by a vertical movement with a servo motor. As soon as all 16 stacks are in the buffer, it moves each level to the level of stacking table. Once a series has reached this level all 4 piles are pushed onto the table. From this table, the stacks are then moved by means of a 6-axis robot automatically packed into the boxes. S ...

bag length: bag width: work impulse: total power requirement: - kWweight of the machine ca.: 0,2 tdimensions of the machine ca.: - mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
