peripheral equipment (e.g. heating, conveying, drying) used for sale

Year of construction 2000 Cutting System 30 x Checkered Knife Rotor diameter 248 mm, motor 18.5 Kw

Key data: 42 m²

Extraction system Filter system Spänex Model ADDITOR U Type II + III – VU – 15 – SBU 165 – S2 – 000 Order number 40132/93 Built in 1993 Filter area 42 m² Filter bag material needle felt, in very good condition Capacity 64,200 m³/h 5 chip collection containers each 165 litres Motor vibration With heat return air duct Fire Extinguishing Line With control cabinet With documentation and circuit diagram With fan 7.5 kW Pipe connection diameter on the fan 300 mm Dimensions of the extraction system Frame with container Overall height 2971 mm Overall width 980 mm Length of the extraction system approx. 3600 mm Plus add-on parts The plant has already been dismantled and Ready for loading from stock

Motor: 5.5kWSpeed: 300t/minSuction: Dia 25cmInlet: 30x 20cmWith mounting bracketWith control box

Plate rack with 3 uprightsHeight uprights: 5750mmWidth: 2250mmLength support arms:1850mmArm load: 700kgSupport arms available for 6 levels

Volume: 2000lGas: airMax pressure: 10.7 barMax temp: -15/55°C

curved conveyor beltbend 90°width carpet 500 mmtotal width 700 mmmin/max height 890/990 mmlength inner size 2800 mmengine 0.55 kW

In line panel rotatorMax. panel sizes: 5200 x 1350 mmMax. panel thickness: 60 mmWorking height: ca. 900 mm6 cycles/min

Length 6.04 m.Roll width 40 cmRoller diameter 75 mmBelt driveCenter distance of the rollers approx. 50 cmWorking height adjustable 85 - 95 cmElectrical cabinet not included

Workpiece dimensions up to approx. 5 m. length, 250 mm widthSliding blocks for possible loading with singulatorTransverse transport with 5 parallel driven belts, approx. 1.5 m in length, motor 0.37 kW Intermediate distance x 1m25 x 0m80 x 0m80 x 1m00 x4 perpendicular stop rollers4 non-driven feed rollers1 Interroll driven feed roller, built-in motor 0.37 kW, speed 0.20 m/sWorking height 70 cmElectrical cabinet not included

Conveyor for wet pieces in laquer lineLength: 3 m.Width: 1,3 m.Cleaning brush at the bottomMotorised feedworks

In line 90° panel turning devicePanels entering crosswise, turning them to lengthwiseFence side at the leftPanel sizes:-Width from 220 mm to 1000 mm-Length from 320 mm to 3200 mmThe panels are transported on a roller conveyor, they are taken by 2 clamping discs iin order to turn them freely without friction and are placed back on a roller conveyor bringing them to the next machineConsisting of: -First roller conveyor with inclined driven rollers, length 1500 mm and width 3000 mm, rollers are soft pvc covered, centers 150 mm, feedspeed adjustable from 20 to 80 m/min, power installed 1,1 kW-Clamping and turning device-Fixed fence-Second roller conveyor with inclined driven rollers, length 3000 mm and width 1500 mm, rollers are soft pvc covered, centers 150 mm, feedspeed adjustable from 20 to 80 m/min, power installed 1,1 kW

In line 90° panel turning device (or transport crosswise without turning)Panels entering lengthwise, turning them to crosswiseFence side at the leftPanel sizes:-Width from 220 mm to 1000 mm-Length from 320 mm to 3200 mmThe panels are transported on a roller conveyor, they are taken by 2 clamping discs iin order to turn them freely without friction and are placed back on a roller conveyor bringing them to the next machineConsisting of: -First roller conveyor with inclined driven rollers, length 3000 mm and width 1500 mm, rollers are soft pvc covered, centers 150 mm, feedspeed adjustable from 20 to 80 m/min, power installed 1,1 kW, additional roller coveyor aside in case of transport without turning-Adjustable fence-Clamping and turning device-Second roller conveyor with inclined driven rollers, length 1500 mm and width 3000 mm, rollers are soft pvc covered, centers 150 mm, feedspeed adju ...

RobotMaximum reach: 3195mmRated payload: 180kgMaximum payload: 230kgMaximum supplementary load, rotating column / link arm / arm: 300kg / 130kg / 150kgPose repeatability (ISO 9283): +-0,07mmNumber of axes: 5Mounting position: FloorFootprint: 754mm x 754mmWeight: 1017kgProtection rating (IEC 60529): IP65 Running hours: 1053hVacuumsystemDimensions: 1700mm x 900mm 350mmConstruction of 56 SCHMALZ cups dia 50 and 70mm with pushrod for loosen plateFESTO components for compressed air/vacuumEach cup separately controlled by FESTO controllerCommunication via Profibus

Suction diameter: 160 mm; Blow-out diameter: 160 mm; Volume flow: 2500 m³/h; Motor power: 2.2 kW; Weight: 50 kg; Very stable blower with steel impeller.

Suction diameter: 300 mm; Discharge diameter: 300 mm; Volume flow: 5400 m³/h; Motor power: 2.5 kW; Weight: 100 kg; Very stable blower with steel impeller.

Suction nozzle diameter: 300mm; Intake side: left; Nominal volume flow: 5083 m³/h; max. volume flow: 6000 m³; Frequency converter: yes; Volume flow monitoring: pressure differential indicator; Negative pressure: 2540 pa; Filter area: 31.6 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: db; Chip volume: 3 x 165l; Filter cleaning: motorized; Motor power: 7.5 kW; Machine length: 3940mm; Machine width: 1020 mm ; Machine height: 2250mm; Weight: 1300 kg;

Suction nozzle diameter: 1 x 200, 3 x 100mm; Nominal volume flow: 1760 m³/h; Residual dust content: 0.1 mg/m³; Chip collection volume: 240l; Filter cleaning: motorized; Motor power: 3 kW; Noise level: 78dB(A); Machine length: 1340 mm; Machine width: 900 mm; Machine height: 2170 mm; Weight: 178 kg; Clean exhaust air by separating dust in the cyclone separator and cartridge filter Effective cartridge filter with a large filter area, easy to remove for cleaning or changing Automatic filter cleaning for consistently high extraction performance Included

Suction nozzle diameter: 300mm; maximum volume flow: 6000 m³/h; Nominal volume flow: 5089 m³/h; Volume flow monitoring: pressure differential indicator; Filter area: 31.8 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 70 db; Scout bag volume: 480 l; Filter cleaning: mororic; Motor power: 7.5 kW; Extinguishing device: yes; Machine length: 3245 mm ; Machine width: 1030 mm; Machine height: 2595 mm; Weight: 780 kg; The Riedex vacuum dust collectors have been developed for the extraction of wood chips, wood dust and related substances, but also

Suction nozzle diameter: 250mm; maximum volume flow: 5000 m³/h; Nominal volume flow: 3534 m³/h; Volume flow monitoring: pressure differential indicator; Filter area: 25.4 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 70 db; Scout bag volume: 480 l; Filter cleaning: mororic; Motor power: 5.5 kW; Extinguishing device: yes; Machine length: 3510 mm ; Machine width: 880 mm; Machine height: 2545 mm; Weight: 850 kg; The Riedex vacuum dust collectors have been developed for the extraction of wood chips, wood dust and related substances, but also

Suction nozzle diameter: 200mm; maximum volume flow: 3200 m³/h; Nominal volume flow: 2262 m³/h; Volume flow monitoring: pressure differential indicator; Negative pressure: 2250 pa; Filter area: 16 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 65 db; Späh bag volume: 320 l; Filter cleaning: pneumatic, jet cleaning; Motor power: 4 kW; Machine length: 2340 mm; Machine width: 880 mm; Machine height: 2190 mm; Weight: 385 kg; The Riedex vacuum dust extractors have been developed for the extraction of wood chips, wood dust and related substances

Suction nozzle diameter: 160mm; maximum volume flow: 2000 m³/h; Nominal volume flow: 1448 m³/h; Volume flow monitoring: pressure differential indicator; Negative pressure: 3000 pa; Filter area: 10.5 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 64 db; Scout bag volume: 160 l; Filter cleaning: pneumatic; Motor power: 3 kW; Machine length: 1800 mm; Machine width: 820 mm; Machine height: 2220 mm; Weight: 320 kg; The Riedex vacuum dust collectors have been developed for the extraction of wood chips, wood dust and related substances, but also for

Suction nozzle diameter: 160mm; maximum volume flow: 2000 m³/h; Nominal volume flow: 1448 m³/h; Volume flow monitoring: pressure differential indicator; Negative pressure: 3000 pa; Filter area: 10.5 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 64 db; Scout bag volume: 160 l; Filter cleaning: mororic; Motor power: 3 kW; Machine length: 1800 mm; Machine width: 820 mm; Machine height: 2220 mm; Weight: 320 kg; The Riedex vacuum dust collectors have been developed for the extraction of wood chips, wood dust and related substances, but also for

Suction nozzle diameter: 200mm; maximum volume flow: 3200 m³/h; Nominal volume flow: 2262 m³/h; Volume flow monitoring: pressure differential indicator; Negative pressure: 2250 pa; Filter area: 16 m²; Residual dust content: less than 0.1 mg/m³; Sound pressure level: 65 db; Späh bag volume: 320 l; Filter cleaning: mororic; Motor power: 4 kW; Machine length: 2340 mm; Machine width: 880 mm; Machine height: 2190 mm; Weight: 385 kg; The Riedex vacuum dust collectors have been developed for the extraction of wood chips, wood dust and related substances, but also for

Motor power: 1 kW; Filter area: 2500mm x 1600mm; Exhaust nozzle: 300mm; Current consumption: 2.3 A; Weight: approx. 120 kg;

Suction nozzle diameter: 150 mm; Volume flow: 3000 m³/h; Negative pressure: 3500Pa; Air speed: 47m/s; Bulking bag volume: 2 x 0.1426m³; Filter area: 5m²; Filter cleaning: manual; Motor power: 1.5 kW; Dimensions: Weight:

Suction nozzle diameter: 200 mm / 2 x 100 mm; Nominal volume flow: 1900 m³/h; Scout bag volume: 1 x 110 l; Filter cleaning: manual; Motor power: 1.5 kW; Machine height: 1000 x 500 x 2100 mm (L x W x H); Weight: 39 kg; For milling, planing and sawdust (not suitable for dust)180Â rotatable extraction unit enables extraction guidance from below or aboveStable metal fan wheel as standard with high-quality chassis for better stability and easy manoeuvringQuick release fasteners for filter and chip bagFine filter bag double
