310 DMG MORI used machine for sale

This 12-axis DMG MORI Multisprint 36 multi-spindle turning machine was manufactured in 2019. Ideal for complex turning operations, it offers precision and efficiency. If you are looking to get high-quality turning capabilities, consider the DMG MORI Multisprint 36 machine we have for sale. Contact us for more information.

x-travel:560 mm y-travel:560 mm z-travel:660 mm control:Celos Siemens 840D SL Operate ERGOline Multitouch turning speeds:20 - 20.000 1/min spindle drive:25/ 35 kW max. torque on the spindle:86 / 130 tool taper:HSK-A63 Number of tool station:60 diameter of tools max.:70 mm Tool diameter with no neighbouring tools:170 mm tool length - max.:450 mm weight of tools max.:12 kg numbers of pallets:2 Pallet dimension:400 x 400 mm max. workpiece diameter:630 mm workpiece height max.:900 mm table load:400 kg rapid travel x/y/z:60 m/min Feed x/y/z:60 m/min internal coolant system feed:70 bar weight of the machine ca.:8,5 t dimensions:3200 x 4800 x 2900 mm Renishaw probe (spindle):Vorbereitung / preparation only Horizontal machining center with Siemens - Celos control, full b-axis, tool magazine with 123 pos. HSK-A 63, coolant through spindle 40 bar. The machine has just received a new milling spind ...

GeneralTurning/milling center with turning length 1100 mm - mounting HSK-A 63 DIN 69893 - B-axis ±120 - Y-axis ±100 mm - 60-fold chain magazine - Absolute, direct path measuring systems in X-, Y- and Z-axis - Hydraulically movable tailstock with foot pedal - Double switch filter - Electric handwheel - DMG MORI IoT connector - Clamping pressure adjustment on the control - 5-axis simultaneous machining; Control: CELOS X with Siemens SINUMERIK ONE Working areaTurning diameter500 mmDistance between spindles1435 mmMax. Turning Length1100 mmMain drive 1Drive power (100% DC)14 kWDrive power (40% DC)17 kWSpeed range- 5000 rpmTorque (100% DC)275 NmMax. torque (40% DC)345 NmFloor space/WeightDimensions (L x W x H)5,77 x 2,33 x 2,51 mWeight approx.10000 KgTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-15000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% ...

turning diameter:356 mm turning length:705 mm control: CELOS M730 UM MAPPS swing dia.:742 mm standard turning diameter:275 mm travel -x axis:260 mm travel -y axis:100 ( ±50) mm travel -z axis:795 mm rapid travel - longitudinal/face:30 / 30 m/min Rapid travel B-axis (parts transfer subspindle):734 m/min Spindle 1 RPM:4000 1/min Spindle 1 Power:15/18,5/18,5 kW Spindle 1 Torque:409/505 /599 Nm Spindle 1 max. bar diameter:80 mm Spindle 2 RPM:4500 1/min Spindle 2 power:7,5/11 kW turret stations / rotary tool stations:20 / 20 BMT40 speed of driven tools:10000 1/min :3.7/5,5/5,5 kW torque rotary tools:14 / 24 Nm total power requirement:38 kVA weight of the machine ca.:6,3 t dimensions of the machine ca.:4 (9) x 2,1 x 2,2 m Parts catcher:Sp. 1 und Sp. 2 Spindle 1 Chuck:Kitagawa B 210 (250 mm) Spindle 2 Chuck:Kitagawa B 206 (160 mm) Tool presetter:Spindle 1 & 2 High precision Turning and Millin ...

turning diameter:670 mm turning length:1540 mm control:F31iB5 Celos Fanuc 35iB5 swing diameter max. over bed cover:700 mm Travel turret No.1 (milling spindle) x/y/z:495 / ± 150 / 1562(+164) mm Rotation B-axis:-30° / +210° Rapid traverse feeds turret 1 (milling head) x/y/z:40/40/40 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:20,2/18,8 kW Torque of milling spindle:120 / 44 Nm tool taper milling spindle:Coromant Capto C6 Tool magazine for milling spindle (turret 1):76 Tool change time tool/tool, milling spindle:1,25 s Spindle 1 RPM:3000 1/min Spindle 1 Power:36 / 30 / 25 kW C-axis spindle 1:0,001 ° Bar capacity spindle 1:102 mm Spindle 2 RPM:4000 1/min Spindle 2 power:26 / 22 / 15 kW C-axis spindle 2:0,001 ° Bar capacity spindle 2:80 mm dimensions of the machine ca.:7,8 x 3,6 x 2,9 m Linear scales on axis:X, Y programmable steady:KLU-A530 & SLU-X3.2 Spindle 1 ...

GeneralUniversal turning-/milling center; Control: SLIMline® Control SIEMENS 840D sl, w/o CELOS Working areaSwing diameter over guide ways500 mmTurning diameter400 mmMax. Turning Length1100 mmBar diameter max.65 mmWork spindle (left)Spindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)14 kWSpeed range- 5000 rpmDrive power (40% DC)17 kWBench speed485 rpmTorque (100% DC)275 NmMax. torque (40% DC)345 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% DC)8,8 kWDrive power (40% DC)10,5 kWTorque (100% DC)73 NmTorque (40% DC)90 NmSwivelling range+/- 120 degreelocking moment850 NmTool magazineType of magazineChain Number of tools30 Max. tool diameter78 mmMax. tool-Ø with free adjacent pockets125 mmFloor space/WeightDimensions (L x W x H)5,19 x 2,11 x 2,47 mWeight approx.11200 KgTechnologie cycle alternating spee ...

turning diameter: 100 mm turning length: 75 mm control: FANUC Oi-TF total power requirement: 15 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC vertical machining center Type: DMC 1035 V ECOLINE Manufacturer: DMG MORI Year: 2012 Control: Siemens Sinumerick 840D Total hours: 12,058 Spindle hours: 5,039 X: 1035 mm Y: 560 mm Z: 510 mm Working table: 1200 x 560 mm Tool magazine: 20 positions Max spindle speed: 8,000 rpm Chip conveyor Machine in good condition, fully functional, under power Find more here - / Contact us at -

x-travel: 650 mm y-travel: 520 mm z-travel: 475 mm control: Heidenhain TNC 530 tool adaptor: turning speeds: 15000 U/min spindle motor: 25/35 kW tool change unit: 30 pos. table surface area: 630 X 500 mm workpiece weight: 300 kg c-axis: 360 (0,001) ° A-Axis: -35 / +110 ° rapid traverse: 42 m/min feed: 10 m/min total power requirement: 31 kVA dimensions of the machine ca.: 3,3 x 2,2 x 2,78 m total wight: 7,5 t 5-Axis Machine ausgestattet mit: - CNC Control Hiedenhain TNC 530 / DMG ERGOLine - elektr. Handwheel - NC-Rotary / swivelling Table - Coolat - Vollkabine - ATC 30-fold - Renishaw Measuring - Chip Conveyor - 3D-Quick-Set The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 2100 mm y-travel: 2100 mm z-travel: 1250 mm spindle motor: 20 kW spindle turning speed range: 24000 U/min tool taper: HSK A 63 b-axis: -70 / +180 ° table diameter: 1700 mm table load: 8 t Feed speed: 60 / 40/ 40 m/min. rapid traverse: 60 / 40 / 40 m/min Control: Heidenhain iTNC 530 total power requirement: 89 kVA weight of the machine ca.: 41 t dimensions of the machine ca.: 9,8 x 7,5 x m - CNC Control Heidenhain iTNC 530 - Tool Changer 93-fold (HSK A 63) - Motor Spindle / Pick-Up Spindle approx 40900h Working Hours and 27100 Spindle Hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: DMG Mori Seiki Model: NEF 400 V3 Driven tools: 6 cross-driven tools Control System: Heidenhain Manual Plus Year of Manufacture: 2013 Find more here - / Contact us at -

CNC lathe Type: T1 Manufacturer: DMG MORI Year: 2023 Control: Siemens Sinumerik One + JobShop and ShopTurn Swing over bed: 550 mm Swing over support: 320 mm Max. turning diameter: 300 mm Diameter of clamping chucks – main spindle: 210 mm X: 232.5 mm Z: 410 mm Rapid traverse X/Z axes: 30/36 m/min Spindle nose: A2-6 Inner diam. of front bearing: 120 mm Spindle bore: 73 mm Max. diam. of machined bar: 65 mm Max. spindle speed: 4500 rpm Turret VDI: 12 positions Number of driven tool stations: 12 Max. speed: 5500 rpm Hydraulic tailstock Automatic tailstock travel range: 410 mm Tailstock sleeve taper: MK 4 Chip conveyor Machine weight: 3400 kg In very good condition, fully functional, under power Find more here - / Contact us at -

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm Control: SIEMENS 840D table - swivable +/-: +110 / -5 ° -C-axis table rotating: 360° tool piece magazine with: 16 Werkzeugplätzen weight of the machine ca.: 3.9 t dimensions of the machine ca.: 2.9 x 2.0 x 2.5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 750 mm y-travel: 620 mm z-travel: 520 mm Control: Manufacture: HEIDENHAIN TNC620 spindle turning speed range: 12000 U/min tool magazin:: 32 weight of the machine ca.: 7.8 t dimensions of the machine ca.: 4.4 x 3.2 x 2.97 m HEIDENHAIN TNC-426 Prepared for the 4th axis www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1.135 mm y-travel: 1.050 mm z-travel: 750 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 14.000 min/-1 power capacity - main spindel: 19 kW max. Torque: 100 Nm tool taper: HSK-A 63 table surface area: 1.400 x 1.050 mm max. table load: 2.500 kg max. workpiece sizes: 1.400 x 1.240 mm max. workpiece height: 750 mm tool magazin:: number of toolpositions: 30 pos. tool taper: HSK-A 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool length: 365 / 395 mm max. tool weight: 8,0 kg change-time chip to chip: 6,1 sec feeds:: feed speeds: max. 40.000 mm/min rapid traverse: 40 m/min Accelaration: 6 m/s² Feed force ( X / Y / Z ): 14 / 20 / 14 kN total power requirement: 44 kVA weight of the machine ca.: 14,4 t dimensions of the machine ca.: 6,0 x 5,0 x 3,3 m Documents: Chip conveyor: Coolantsystem: high pressure coolan ...

Manufacturer: DMG MORI Model: CTV 250 DF Year of Manufacture: 2019 Type of Machine : Power skiving machine / CNC Turning Center Max spindle speed: 6,000 rpm Secondary spindle speed: 7,000 rpm Machine weight: 7,000 kg Power supply: 400 V, 50 Hz, L1-L2-L3-N-PE phase Power consumption: 65 kVA Max current: 95 A Fuse: 100 A / 1.00 kA Max voltage: 440 V Control voltage: 230 V / 24 V Spare parts are available for sale separately Find more here - / Contact us at -

x-travel: 1135 mm y-travel: 1050 mm z-travel: 710 mm 0: dia 1240 x 690 mm control: Heidenhain TNC 640 : : 15000 min/-1 : 35 kW tool taper: SK 40 work table:: table surface area: 1050 x 860 mm max. table load: 2000 kg : : 30 pos. tool taper: SK 40 change-time chip to chip: 6 sec feeds:: : 40 m/min feed speeds: 40000 mm/min total power requirement: - kW weight of the machine ca.: 18 t dimensions of the machine ca.: 5,1 x 3,99 x 3,4 m 5-Axis Machine equipped with: - CNC Control Heidenhain TNC 640 - universal Milling Head (B-Axis +30/-130°) - NC- rotary Table dia 800mm (C-Axis) - BMF coolant and filtration system. - electr. Handwheel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm c-axis: 360 ° B-axis (table): -50 / + 110° mm turning speeds: 10.000 U/min spindle taper ISO: 40 DIN 69871 Control: Heidenhain TNC 620 total power requirement: 13 / 9 kW weight of the machine ca.: 4,5 t dimensions of the machine ca.: 6 x 3 x 3 m Options: - 30-pocket magazine with double gripper - Production package with Internal Coolant + chip conveyor - 360 L coolant tank - Blow-off air - Coolant gun - Electronic handwheel - HEIDENHAIN TS 649 infrared probe - Direct measurement system New motor spindle in 2022 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 356 mm turning length: 510 mm control: M 730 BM total power requirement: 40 kVA weight of the machine ca.: 6,6 t dimensions of the machine ca.: m CNC control: Mitsubishi 730 BM Main spindle: Speed: 5000 rpm Power: 15/11 kW (15% duty cycle / constant) Bar diameter: 65 mm Sub spindle: Speed: 6000 rpm Power: 11/7.5 kW (25% duty cycle / constant) Turret: 12 stations Tool spindle speed: 10000 rpm Power: 5.5/3.7 kW (5 minutes / constant) Y-axis travel: +/- 50 mm Equipment: Machine with gantry loader: Left-hand installation, 14-station storage, 20-pallet workpiece storage, Double gripper conveyor 3-jaw hydraulic KITAGAWA power chuck, 210 mm diameter High/low pressure chuck system for main and counter spindles MABEO high-pressure pump with 1.5 MPa filter unit Coolant gun Coolant sprayer on the chuck for main and counter spindles Coolant sprayer for the machine bed cladding Oil  ...

x-travel: 600 mm y-travel: 500 mm z-travel: 500 mm total power requirement: --- kW weight of the machine ca.: 9,6 t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 500 mm turning length: 1200 mm control: Siemens 840D greates pass round over bed: 700 mm Main spindle:: turning speed range - main spindle: 20 - 5000 min/-1 power capacity - main spindel: 25 /34 kW max. Torque: Nm C-Axis: 0,0001 ° spindle diameter: 67 mm milling spindle: milling spindle motor: 13 / 22 milling head speed: 12000 U/min b-axis: +/- 110 ° axis stroke:: x-axis: 450 mm y-axis: +/- 100 mm z-axis: 1300 mm feeds:: rapid traverse ( X / Y / Z ): 60 / 22,5 / 30 m/min feed power: 5,6 / 5,6 / 7,4 kN turret:: number of toolpositions: 24 pos. tool taper: Capto max. chucking diameter: 250 mm tail stock: tailstock quill taper MT: 5 tailstock adjustment: 1200 mm total power requirement: 65 kVA weight of the machine ca.: 8 t dimensions of the machine ca.: 6 x 2,7 x 2,1 m CNC - Turning and milling centre - 5 axes simultaneous - CNC control Siemens 840D SolutionLine w ...

x-travel: 1250 mm y-travel: 1000 mm z-travel: 1000 mm spindle taper: HSK-A 100 turning speed range: 10.000 U/min spindle drive: 28 kW Torque: 1240 Nm feed range: 0 - 12.000 mm/min rapid traverse: 60 m/min table surface area: 800 x 1000 mm workpiece weight: 1500 kg Control: Siemens 840D total power requirement: 80 kW weight of the machine ca.: 21 t dimensions of the machine ca.: 5,9 x 6,5 x 3,5 m 5-axis simultaneous machine equipped with: - CNC control Siemens 840D - 6-fold pallet station - Tool changer (HSK 100) - Coolant system with IKZ 40/80bar - Probe - tool breakage control The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC vertical machining center Type: ecoMill 600 V Manufacturer: DMG MORI Year: 2016 Control: Siemens SLIMline X: 600 mm Y: 560 mm Z: 510 mm Max spindle speed: 12000 rpm Table: 900 x 560 mm Max table load: 600 kg Tool magazine: 30 positions Machine weight: 5000 kg Tool and work probe Filtration Bürener Preparation for mist extraction Chip conveyor New spindle in 2025 Machine in good condition, fully functional, under power Find more here - / Contact us at -

x-travel: 400 mm y-travel: 400 mm z-travel: 375 mm total power requirement: --- kW weight of the machine ca.: 7,6 t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 400 mm turning length: 1100 mm control: Siemens Sinumerik 840D SL greates pass round over bed: 500 mm Swing dia. over traverse guideway: 370 mm Main spindle:: Max. rpm: 5000 min/-1 power capacity - main spindel: 17 / 25.5 kW max. Torque: 345 Nm spindle diameter in front bearing: 130 mm spindle bore: 67 mm chucking diameter: 325 mm spindle nose: A8 axis stroke:: x-axis: 750 mm y-axis: +/- 100 mm z-axis: 1200 mm feeds:: rapid traverse: 40 / 40 / 40 m/min Tailstock:: tailstock: 1200 mm taper of center: Mk 5 tension force: max. 8 kN milling head: b-axis: +/- 120 ° tool taper: HSK A 63 tool piece magazine with: 60 spindle turning speed - stepless: 12000 U/min spindle motor: 10,5 kW max. torque on the spindle: 90 Nm total power requirement: - kVA weight of the machine ca.: 9 t dimensions of the machine ca.: 4,6 x 2,5 x 2,82 m Equipped with: - Siemens 840D SlimLine / Cel ...

x-travel: 3.400 mm y-travel: 3.400 mm z-travel: 1.600 mm Control: CELOS 840D sl Op Siemens Main spindle:: max. spindle speed: 20 - 15.000 min/-1 power capacity - main spindel: 52 / 42 kW tool taper: HSK-A100 max. Torque: 404 / 280 Nm swivellable: B: -30° / +180 ° NC-Rotary table:: table diameter: 2.500 x 2.000 mm max. table load: 10.000 kg table speed: 5 min/-1 distance spindle center to table: hor.: 130 - 1.730 mm distance spindle center to table: vert.: 230 - 1.830 mm distance spindle nose and table: hor.: -1.500 - 1.900 mm distance spindle nose and table: vert.: -1.600 - 1.800 mm Tool-Presetter:: type: 5x Rad- / Wheel number of toolpositions: 303 pos. max. tool diameter: 110 mm max. tool-dia with free toolbox: 280 mm max. tool length: 900 mm max. tool weight: 45 kg tool changing time: 7,5 sec tool taper: HSK-A100 feeds:: rapid traverse: 60 / 30 / 40 m/min total power requirement ...

x-axis: 675 mm z-axis: 1530 mm y-axis: 300 mm control: CELOS ERGOline turning speed range - main spindle: 4000 min/-1 spindle passage: 91 mm spindle motor: 18,5 / 15 kW speed range - counter spindle: 4000 min/-1 : 76 tool length - max.: 400 mm tool diameter: 130 mm no. of tools in turret 1: 12 milling head speed: 12000 U/min milling spindle - taper: Capto C6 milling spindle drive: 22 kW total power requirement: 88 kVA total wight: 18,2 t dimensions of the machine ca.: - m Equipped with: - CELOS ERGOline CNC control - Main and counter spindle with 4000 rpm, 91 mm passage - Kitagawa 304 mm chuck - Milling spindle with Capto C6 and 12,000 rpm, 22 kW - 76-position tool changer - Counter spindle with tailstock function - Manual tool presetter - High-pressure coolant system / IKZ 70 bar - Coolant gun - Chip conveyor - Oil skimmer - Oil separator - Renishaw Power On: 17700h, Machining: 7200h  ...

turning diameter: 500 mm turning length: 800 mm control: Siemens 840D greates pass round over bed: 700 mm Main spindle:: turning speed range - main spindle: 20 - 5.000 min/-1 power capacity - main spindel: 25 / 34 kW max. Torque: 380 Nm C-Axis: 0,01 ° max. chucking diameter: 320 mm milling spindle: milling spindle motor: 22,5 milling head speed: 12000 U/min b-axis: +/- 110 ° tail stock: axis stroke:: x-axis: 480 mm y-axis: +/- 100 mm z-axis: 845 mm feeds:: rapid traverse ( X / Y / Z ): 60 / 22,5 / 30 m/min feed power: 5,6 / 5,6 / 7,4 kN switching time: 30°: 0,4 sec turret:: number of toolpositions: 24 pos. tool taper: HSK A 63 total power requirement: - kW weight of the machine ca.: 10 t NC - turning and milling center - CNC control Siemens 840D Ergo Pro - Milling head with B-axis - Y axis - Coolant system (through Spindle) 15bar with paper band filter - chip conveyor - Tailstoc ...

Machine Type: Turning Machine Model: Sprint 50 2T Manufacturer: DMG MORI Year of Manufacture: 2017 Specifications: - Spindle Speed (Max): - 1st Spindle: 7000 rpm - 2nd Spindle: 7000 rpm - Machine Weight: 9200 kg Electrical Specifications: - Power: 54 kVA - Current (Max): 135 A - Fuse Rating: 160 A - Voltage: - Main: 400 V ±10% - Auxiliary AC: 230 V - Auxiliary DC: 24 V - Frequency: 50 Hz Accessories/extras: CT-20D Hinge Belt chip extractor 2 pcs Sauter turret head Typ. Grip main spindle SPANNTOP mini 65 Grip counter spindle SPANNTOP mini 52 Unloading system Marposs TT30 tool setting system Artis CTM V6 tool wear and breakage monitoring system LNS Alpha 552 - 4 meter bar feeder Find more here - / Contact us at -

CNC vertical machining center Type: MCX 600 V Manufacturer: DMG MORI Year: 2017 X: 600 mm Y: 560 mm Z: 510 mm Max spindle speed: 12000 rpm Max workpiece high: 630 mm Max workpiece length: 900 mm Max workpiece width: 560 mm Max workpiece weight: 600 kg Machine weight: 4700 kg In very good condition, worked few hours, under power Find more here - / Contact us at -
