other machinery for waste disposal and recycling used for sale

Jöst feed channel Type: FUF Dim: length 2800 mm - width 1200 mm, Drive with two vibration motors of 3 kW each

Technical data of the bale opener line for RDF. MSW, paper, cardboard:Manufacturer Cross Wrap Oy Ltd, Siilinjärvi, FinlandType BO 4000 Year of manufacture 2015Quantity of opened bales 674 piecesOperating time only 3 days, exclusively by running in the entire line during new installationOpening time approx. 45 seconds per baleBale dimensions (W x H x L) 1100 x 1100 x 1400 - 1900 mmMax. Bale weight 2,000 kgConveying height of the system 1,400 mmMax. Conveying width of the system 1,200 mmMaterial to be opened RDF/MSWAvailability of the line 98%Noise level of the bale opener line 85 dB(A)Total connected load 37 kWRated current 125 AOperating display SIEMENS SIMATIC HMI TouchControl SIEMENS S7 ET200SInstallation dimensions 8,463 x 2,890 x 3,960 mm (l x w x h)Scope of delivery:Feed conveyor 3,500 x 1,200 x 1,400 mm Feed conveyor to opener 1,500 x 1,200 x 1,400 mmBale opener (gripper with knif ...

Technical data Feed hopper with hydraulic moving floor and bag opener:Manufacturer BRT HARTNER GmbHType HP5-3035Year of construction 2015Hopper volume 30 m³ Drive line 17.5 kWDimensions in current state 13,200 x 3,050 x 4,350 mm (l x w x h)Condition of the machine:The feed hopper with bag opener was in use at a large recycling company, where waste in bags was tipped into the hopper with wheel loaders and the bags were opened via the bag opener and the waste was conveyed in doses for further processing. The system worked perfectly until it was dismantled and was replaced by a larger system with a higher throughput capacity. The machine is in good working condition. On request, various spare parts can be purchased for a separate, additional fee. The buyer would have to dismantle the elevation for removal, as the machine is otherwise too high.Comments:The machine is currently being overhau ...

Technical data for the bale loosening drum:Manufacturer not knownType of bale loosening drumYear of manufacture not knownDimensions of the drum 6000 x 3000 mm (l x d)Height of the welded-in helix 300 mmDimensions of the drum frame 4900 x 3400 x 2200 mm (L x W x H)Drive power 2 x 4 kWFunctional description:The bale loosening drum was fed with pressed paper bales from which the binding wire had previously been removed. The pressed and compact bale is broken up and loosened by the baffle plates welded into the drum parallel to the conveying direction. The helix, which is welded in with an incline to the conveying direction, transports the loosened material further to the drum outlet. Here it falls through a hopper onto a conveyor belt for further processing.Scope of delivery:Bale loosening drumFrame with drive and roller bearings for the bale loosening drumComments:Documentation (operating  ...

Technical data IFE cascade screens (vibrating waste screens):Manufacturer IFE Aufbereitungstechnik GmbH, AustriaType SM 2400 x 5000 F - UW30Year of construction 2009Drive motor 22 kWRated current 43 AScreen dimensions overall 5,000 x 2,400 mm (l x w)Dimensions of individual sieve segment 950 x 800 x 130 mm (l x w x d)Screen hole grid 150 x 125 mmLength of screen fingers (steel tubes in front of the screen segments) 400 mmSwing width max. 18.5 mmWeight approx. 6,600 kgPossible applications:The waste screen is suitable for use in plants for sorting household waste, commercial and industrial waste, paper and cardboard, scrap metal and electrical waste. Blockage-free screening with the most difficult feed materials, with high throughput capacity, no pigtail formation with oversize particles, loosened oversize particle discharge over the entire screen width and no downtimes for screen cleanin ...

Technical data feeding conveyor belt:Manufacturer BollegraafTyp HBT 1216/2000 18000Year of construction 2015Driving motor 5,5 kWLength feeding conveyor 18,000 mmGrade 0°Effecting width 2,000 mmHeight of side wall feeding conv. 500 mmTransport dimensions 18,000 x 3,200 (2,830 mm without motor and gear) x 1,200 mm l x w x hWeight approx. 13 tComments:Inspections are possible after agreement. We will not assume liability for the given technical data and possible errors.

We offer you a used PET bottle crusher of the manufacturer BOREMA, type R-1200 F, year of construction 2013, for residual emptying, deaeration and pre-compaction of the fed PET bottles, from 0.3 up to 2.5 l content. The machine has a chassis and can be moved into and out of the feed chute of your baler. The machine has a throughput capacity of approx. 85,000 bottles/h, corresponding to approx. 3t/h.We have the following technical information:Manufacturer: BOREMA Umwelttecjhnik AGType: R-1200 F (with trolley for retracting and extending)Year of manufacture: 2013Drive power: 11 kWConnected load: 15 kWRated current: 32 ABack-up fuse: 40 AType of construction: Continuous systemFunction: Double rotor press systemRotor pretension pneumatic: approx. 16tOverload protection: by anti-blocking systemInput material: PET disposable and returnable empty bottles 0.3 to 2.5 L capacityInput material: HDP ...

Technical data PaperSpike 2 G:Manufacturer Grumbach und Petermann GmbHType 2500Year of construction 2019Dimensions accelerator belt 3,000 x 2,980 x 600 mm (l x w x h)Weight 1,100 kgDimensions PaperSpike sorting unit 2,480 x 2,982 x 1,805 mm (l x w x h)Weight 3,100 kgDimensions PaperSpike 2G complete 5,450 x 3,480 x 1,805 mm (l x w x h)Weight 4,600 kgDimensions paper discharge conveyor 3,400 x 1,200 x 650 mm (l x w x h)Weight 400 kgElectrical equipment of the entire system:Voltage 380 - 420 VConnected load 9.5 kWCurrent consumption 20.34 AOperating principle:The material is fed in as dry and thin a layer as possible, preferably a monolayer, evenly over the entire width on the accelerator belt.The sorting roller with the spikes pulls the mixed paper from the chute, while cardboard boxes are impaled and held by the spikes. Material (paper) with low stiffness (newspapers, magazines, brochur ...

fire: JCB, model: JS150LC, Year of construction: 2006

fire: Liebherr, model: A944B HD, Speed at max. torque: 2000 rpm, Operating hours: 20,000 hours, Year of construction: 2005

A Cushion Pack cardboard shredder is available. Cutting width: 420mm, max. inlet height: 20mm, shredding capacity: approx. 6m³-9m³/h, working height: 890mm, feed speed: 14m/min, motor power: 3kW. Machine dimensions X/Y/Z: approx. 1100mm/750mm/800mm, weight: approx. 250kg. Including suction unit. Documentation available. On-site inspection is possible.

Manufacturer: Buhler Model: SORTEX E PolyVision Year of Manufacture: 2018 Type of Machine: Optical sorting line Sorting Capabilities: - Capable of separating materials by color, including black and polymers. - Detects and partially ejects aluminum based on color recognition. Included Components: - Operator platform - Water chiller (~3.5 kW) for cooling - Flake feeding system with fan-assisted delivery - Suction system for good flakes with transfer to a packing cyclone - Cyclone/bunker unit with big bag frame and pneumatic cylinders - Separate suction and cyclone system for rejected (bad) flakes Performance: - Proven throughput of 1 to 1.3 tons per hour with sufficiently clean flake input Additional Applications: - Suitable for sorting berries and other small-sized items Technical Specifications Dimensions (Service Access - Including Vibrator): - Width: 2651 mm (104.8 in) - ...

fire: Sennebogen, model: 835 Series E, wheels, Cab adjustment: E270 hydraulically elevating, This power: Cummins, 224 kW, Service weight: approx. 46 t., Operating hours: 11000 hours, Bucket: K18, Year of construction: 2017

AGICOM recycling machines: JMC 407 alligator shears The most used alligator scissors from Mc Intyre Mechanically adjustable hold-down device Machine on casters Ideal for shredding automotive scrap, transmission housings, cylinder heads and iron parts Machine in stock

CROSSED MIXING SYSTEM FOR PLASTIC MATERIALS, The system includes n.2 x 20.000 lt. vertical mixers which fill each other through the endless screw conveyor., for each mixer :, total height approx 6.950 mm including transmission group, max diam. 2.380 mm.(standard transport), constructed in painted electro-welded carbon steel., inner auger diam.350 mm., lower hopper with safety grid and sampling shutter, complete with anti-dust cover, mm.600×500, pulley and belt transmission, protected by carters, inspection doors with safety limits, cleaning hinged door with on bottom of cone for complete discharging, with safety opening, bottom discharging pipe on the other mixershopper with pneumatic valves, side discharging pipe to big bag with valve mm.at 2.700 mm from ground with pneumatic valves, electric min/max level indicator, paddle type, N.1 loading hopper with horizontal conveying screw to on ...

Conveyor belt SBM Austria Brand: SBM Austria A.A length = 9,000 mm Belt width: 800 mm Drive: Drum motor 4 kW

Brand: Jwell Cutting width: 1440 mm Capacity: up to 6mm thick Geared motor: 7.5 hp (5.5 kW) Type: Mechanical Guillotine

average output 500 kg/h depending on materials and moisture content,, including : LOADING BELT, 1,4 Kw drive 7,0 mt.lomg x 0,9 mt.wide constructed in sturdy painted steel structure,, side walls,, PVC belt AGGLOMERATOR, 1000 mm. diam.steel barrel with infeed 115 kW, Hp 150 main engine, side door for inspection and knives replacement, replaceable inner lining 400 mm high grease lubricating system for engine bearings oil lubricating station for hub bearings, through automatic pump with oil pressure indicator bearing cooling system through circulating water, 0,75 kW oleodynamic power station electrovalve for closing/opening unloading door Hp 3,0 steam vacuum drive control switchboard and panel appx dimensions: L 3.470 mm.x W 1.500 mm. bent steel structure, electric motor DIAGONAL AUGER, 1,5 Hp drive diam +/-150 mm. – width +/- 1000 mm. – length +/- 1500 mm. – bolted upper cover, de-pre ...

WISSMATEC Scraper Chain Conveyor

Paglierani conveyor belt 5 meters long with smooth belt and gear motor. Ideal for production lines. Brand: Paglierani Dimensions: 5 x 0.60 m Band Type: Plain Geared motor: 0.75 hp (0.55 kW) Robust metal structure

Clarifying Decanter with 2 gear drives, continuously operating horizontal solid-wall centrifuge, used for the dewatering of municipal and industrial waste water sludge. The frame is of open design with gravity discharge of the clarified phase. Rotating parts manufactured in stainless steel 1.4462 (DUPLEX steel with addition of Molybdenum which secures good resistance against pitting corrosion and intergranular corrosion). Diameter: 300 / 157 mm. Max bowl speed: 4.500 rpm. Solids: 2,5 kg/dm3. Min / Max temperature: 5 - 80 °C. Comparative capacity: 20.000 ltr/h. g-force (z): max 3.400 g. Motor bowl drive (15 kW) + motor scroll drive (2,2 kW). Special lifting tools for maintenance, Operation manual / spare parts manual in German language. Decanter was maintained by GEA Wesfalia., Type of Machine: Decanter, Diameter: 300 / 157 mm, Bowl speed: 4.500 rpm, Solids: 2,5 kg/dm3, Temperature: Min  ...

Year of construction 2018, with Volvo TAD 754 GE 260 kw engine, 3730 h, with screening plant, oversize grain recirculation, magnetic separator, hyd. foldable side belt for pre-screening

Swiss Combi belt dryer system, manufacture year 2013, Capacity 88 m2, Incl. storage container with 8 m³ filling volume with double screw discharge, Distribution screws for applying the dryer cake to the dryer belt, 3 heat exchanger units on the surface of the dryer, Extraction fan with 110 kW drive, Chimney approx. 10 m height, Discharge screw system with layer doubling (Swiss Combi system), Complete electrical switchgear (Siemens S7) with operating terminal (Win CC), Additional equipment:, Incl. belt washing system, Incl. fire extinguishing device and spark detection, Heat exchanger units (new) between boiler and dryer with pumps,, Pipes, insulation, etc., 1 completely new conveyor belt is included in the scope of delivery., Full specificatins in pdf

Technical specification, CBR A3, FEATURE VALUE, POWER 5.5 KW, CABLE DIMENSIONS 1-120mm, CUTTING SPEED 25 meters/min, LENGTH 1240mm, WIDTH 780mm, HEIGHT 1330mm, WEIGHT 480kg, cable stripping machine, CBR A3 cable stripping machine is specially designed to remove the outer insulating material from cables of all sizes, allowing the conductive material inside to be easily removed. This series offers excellent performance on steel armored cables (SWA), double steel armored cables, steel tapes, PVC coated cables, lead coated cables, thick rubber coated cables, nylon coated cables, low grade cables, TT cables and more. Specially machined blades with unique design enable cutting and stripping of cables of any length for a long period of time without the blades becoming blunt. All electrical and electronic components of CBR A3 series are Siemens brand. Our products are manufactured and certified  ...

3M7 FULLY AUTOMATIC SCREENCHANGER, for 130-160 mm diam. extruders, sliding net screening system, hydraulic pack, used machine offered AS IS WHERE IS, availability: immediate

DRAINING AUGER, construction in aisi 304 stainless steel,, case diameter (U-shape) 380 mm, total length 4.500mm,, internal stainless steel spiral diam. 230mm,, drainage with stainless steel perforated plate L=3.500 mm,, nr.6 hinged side doors,, gear motor power 2.2 kw, installed power - used power in work: about 60-65% : 2.2

CROSSED MIXING SYSTEM FOR PLASTIC MATERIALS, The system includes n.2 x 30.000 lt. (or bespoke) vertical mixers which fill each other through the endless screw conveyor., for each mixer :, total height approx 7.750 mm including transmission group, max diam. 3.000 mm.(exceptional transport), constructed in painted electro-welded carbon steel., inner auger diam.350 mm., lower hopper with safety grid and sampling shutter, complete with anti-dust cover, mm.600×500, pulley and belt transmission, protected by carters, inspection doors with safety limits, cleaning hinged door with on bottom of cone for complete discharging, with safety opening, bottom discharging pipe on the other mixershopper with pneumatic valves, side discharging pipe to big bag with valve mm.at 2.700 mm from ground with pneumatic valves, electric min/max level indicator, paddle type, N.1 loading hopper with conveying screw  ...
