extruders used for sale (455)

Key data: 150 mm

Berstorff Strainer Extrusion Line Consisting of: Extruder Supplier Berstorff Type GE 150KSx16D Year of construction 2007 Pins: 12 Pins per level: 8 Condition: good Weight approx. 10000 kg Screen change: hydraulic, bladder accumulator 20lt / 300Bar D = 200mm Gear pump Supplier: Maag Pump Systems Type: extrex® 110-5 RV Volume 716 cm³ / rev Year of construction 2013 Condition: good Heaters Supplier: Regloplas Type P140 Year of construction various Number 5 pcs. Cooling bath Cooling medium Water above, 2 rows below with 4 fans each Year of construction 2006 Condition: good Dimensions 9m Weight approx. 500 kg Especially 8 fans Installation tape Year of construction 2006 Condition: good Weight about 300 kg

Key data: 2 mm

CPP 7 ply , Testline, can also be used for smaller special productions. Film width max = 650 mm, Output max. = 200 kg/h Nozzle width = 800mm 5 Extruders: 2x Ø 60mm, melt pumps available 70 kg/h each 3x Ø 38mm 19 kg/h each Output: 200 kg/h Weight range: 50-700 μm, Hopper and pneumatic conveying option! Cloeren Feedblock EDBBCAA EBBCDCA ACEDEBA Cooling roller unit with 3 rollers Rewinder diameter max = 300 mm

Barwell MR400 Top Load Ram Extruder

Collin 3 zone Extruder 150degC max temperature with transformer

1 x Buss PR200? Ko-Kneader, supplied fully refurbished by Buss in 1995, G130 gearbox, 11 L/D ratio, with 340kW dc motor and controls. Including oil heater and TCU 2t/hr output. Spare screw and barrel segments.

Iddon Cold Feed Extruder. 2.5" screw dia. 10/1 LD Ratio. Motor Size 20.4/5.5 HP

Francis Shaw 90mm coldfeed rubber extruder.Year: 1992. Machine No.4846Vented. Side power roller feed,L/D ratio 20:1,H series David Brown gearbox,Thrige Scott 63kW, 2000rpm DC variable speed motor.Machine fully overhauled, cleaned/painted and fitted with NEW electrical control panel. With provision for 5 x TCU's.

Fong Kee (Taiwan) Year of manufacture 2016 Double Head (125mm screw) Accumulator type continue extrusion machine Machine In production Product type 160 Liter Float Dimensions 1188mm x 875mm x 407mm net weight 9kgs gross weight 17kgs estimate production rate 30/32pcs per hour Mold dimensions 1300mm x 1260mm x 860mm

The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3000 mmy-travel: 2500 mmz-travel: 1000 mmControl: Siemens type: Sinumerik 840 DFeed: 5-30.000 mm/minTable area: 2000x2170 mmtable load: 1500 Kg/m²T-slots: 22 H9distance between uprigths: 2500 mmspindle turning speed range: 6000 U/minspindle drive: 36 kWspindle taper: HSK 100Tool changer: 30 Rotary table: 2000 mmspeeds: 250 U/minturning diameter: 2500 mmtable load: 10 tTorque: 33000 Nmtotal power requirement: kWweight of the machine ca.: 45 tdimensions of the machine ca.: 8x6,4x4,4 mGentry gantry milling machine with carousel rotary tableHead change stationTool changerThe tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories ...

The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Conical twin screw extruder CINCINNATI TITAN92-APC Motor: 91.6 kW (DC drive) Max. screw speed: 22.0 rpm Gearbox equipped with central lubrication Cylinder with air cooling and 5 cylinder heating zones Cylinder degassing via vacuum unit with vacuum filter Original screws for u-PVC window profile molybdenum coated Active screw temperature control with separate heating/cooling unit Original cylinder standard nitrided Horizontal dosing conveyor incl. material hopper Tool Zones: 12 x 3-ph 5pin CEE 5.5 kW 1 x 3-ph 5pin CEE 5.5 kW for adapter 13 x TC Type J 16 mm Tuchel C70B 3-pin 4m Dimensions (l x w x h): 5,672 x 1,484 x 2,500 mm, weight: 6,500 kg Condition: good, fully functional

Key data: 20 mm, 25

single-screw laboratory extruder Collin E 20 M Output capacity: max. 5 kg/h (depending on material and processing conditions) Screw diameter: 20 mm, L/D = 25 Screw suitable for processing PE/PP (condition: excellent) Heating capacity cylinder: up to 300 C incl. mass pressure and temperature sensor Incl. motorized lifting device for the height adjustment of the processing unit incl. material funnel incl. clamping flange for nozzle attachment Total connected load: 17 kW Dimensions (L x W x H): 1,450 x 800 x 1,900 mm Weight: 300 kg Note: including complete documentation Condition: used, function-tested

Reduction and transfer case for conical twin screw extruder Cincinnati Titan 58 Manufacturer: Eisenbeiss on behalf of Cincinnati Extrusiontechnik General overhaul included: • Checking the sprockets for damage with a special camera • New sealing of the drive and output shaft • New shaft bearing • New oil filling • Repainting Condition: overhauled, fully functional

5 layer die head, without extruder and cooling ring Manufacturer: Reifenhäuser Year of manufacture: 2018 Nozzles: 350mm diameter Capacity: 420 kg/h Product examples: Collation Shrink: 16%/14%/40%/14%/16% Standard packaging film 16%/16%/36%/16%/16% Laminating films : 14%/22%/28%/22%/14% The following extruders were mounted: 60/60/90/60/60

Key data: 50 mm

We offer you a EREMA extruder for sale, which has been fully refurbished in-house. It is an INTAREMA® 605K, the machine is completely mechanically and electrically reconditioned by us before delivery, all components that do not meet our criteria are exchanged for original EREMA spare parts. The machine is designed for a throughput of up to 90kg per hour and is suitable for LDPE. If you are interested in this machine, please contact us! Tags: EREMA, UMAC, refurbished, pelletizer, extruder, regranulating machine,

STEIN Maschinenbau Profile Guillotine PT1-200 For glazing beads, small profiles, main profiles and technical profiles Max. cutting width: 190 mm, max. cutting height: 120 mm Extrusion speed: up to max. 10 m/min Blade length: 600 mm Length accuracy: +/- 2 mm Knife stroke: 180 mm Cutting speed infinitely variable Pneumatic quick-change device for knives Hold-down device pneumatic Knives are preheated: 80ºC - 160ºC Cycle time: 1.5 to 4 sec. adjustable on the display Infeed side: unit for applying a protective film to the profile Control: Compact PLC Siemens S7-613C Dimensions: Height: approx. 1,900 mm, extrusion height: 1,100 mm (+/- 50 mm height adjustment) Footprint: approx. 1,450 x 800 mm (without inlet and outlet tunnel) Condition: very good, ready for use

Cincinnati Titan92-APC Tapered Twin Screw Extruder Year of Make: 1996 incl. volumetric dosing unit for masterbatch Wittmann Dosimax Manual screen changer BD Plast Installed between extruder adapter and pelletizing head Alternatively available: Gneuss Screen Changer Granulating head Cincinnati GK120 works in the hot knock-off method including adapter and funnel Circular vibrating screen IFE US 400 x 1000 FV – LM445T Year of manufacture: 2018 for the separation of particles that are not bound in the granules with particle size < 1.8 mm Vertical granule cooler Knorr GK-600-PVC Year of manufacture: 2018 Cooling volume: approx. 190 litres Mounted on a walk-on steel platform incl. cyclone separator, complete supply and outlet pipes and blower Big-Bag Filling Station incl. material transport and material weighing SBB weighing technology Condition: fully functio ...

GREINER double-strand calibration table getCAL 11.2-5P/4Z - DUAL A (2008) Clamping table (L / W / H): 2 x 11,170 / 2 x 380 / 940 – 1,040 mm Rail spacing: 2 x 320 mm Center Distance Dual: 500 mm Clamping width (max.): 400 mm Height adjustment: 100 mm Side adjustment: (+/-) 15 mm Longitudinal adjustment: 750 mm Tilt adjustment: (+/-) 10 mm 5 vacuum pumps á 4.6 kW incl. 50 ABA 1/2'' vacuum connections 4 cyclone pumps á 1.1 kW Dimensions (L x W x H): 11,200 x 1,580 x 1,200 mm incl. calibration & water tanks GREINER Double Strand Fume/Saw Combination getCOM 30/9-235-S/500 (YOC 2008) Max. profile dimensions (W x H): 235 x 140 (per side) Contact length tracks: 2 x 2,300 mm Number of cleats: 2 x 55 pcs. Lug width: 235 mm (per side) Pull-off force max.: 30 kN (per side) Pull-off speed: 0.5 - 10 m/min Extrusion height adjustable via machine feet: 1,040 – 1,140 mm Saw ...

CINCINNATI PROTON 45-30G Attention: Machine in left-hand version Screw diameter: 45 mm, L/D = 30 Grooved catchment zone Motor (DC drive): 65 kW Screw speed: max. 320 rpm Tool zones: 4+1 for adapters Melt pressure & temperature sensor included EXcPRO-NT control incl. CAN bus for data communication Air conditioner for control cabinet Cylinder in bimetal design – condition: very good Screw with few operating hours – condition: very good Without material funnel & without adapter

Key data: 60 mm, 25

Blown Film Extrusion Line: Manufacturer: Reifenhäuser / Troisdorf Type: S 100.060 Connection: 220 / 380 Volt Total connected load: approx. 100 amps Film thickness range: 30 - 80 microns max. winding width: 1200 mm Material: LDPE Extruder: Type: S60 Power: 7 to 28 kw Screw diameter: 60mm Screw length: 25D Max. output capacity: 50 kg/h Drive: Elektra Faurndau GmbH Granulate feed via vacuum conveyor Die head: rotating Type: BSR 100 - 250 mm Die insert: 150 mm and 200 mm diameter Heating capacity: 11.2 kW Cooling ring: Cooling ring inserts: 150mm and 200mm diameter Air volume control, lip adjustment Flattening and pull off device: Adjustable side boards for foil flattening Side gusset insertion device Pull-off rollers Winder: 2 digits - tandem wrapper manual winding shaft insertion device Winding System: Tangential Winder pneumatic roller lifter Max ...

The Macchi 3 layer Film Blowing Machine PLASTEX model is a compact line for a top quality film production with a range up to 350 kg/h and a film width of 1.650 mm. This production line of 3 layer co-extrusion blown film extruder produced by MACCHI can be used for the production of a wide range of general packaging films as it allows to achieve a high output and a significant level of productivity and flexibility.

Winder : Bandera Model W 400/1 Contact winder / surfacewinder Roll diameter max: 1200mm Roller width: 1200mm Roll width max: 1100mm Speed: max. 55m/min Longitudinal cutting device 2 or multi-lane Side Slitting Device Automatic roll change Cross-cutting device Role magazine Calibration device Reifenhäuser Low-friction rollers motor adjustment Adjustment range: for 500-1100mm laying width takeoff unit: Type TPE-1200 Side gusset insertion device Drive: 4-pole 4kW with axial fan Electric cabinet

Winder : Bandera Model W 400/1 Contact winder / surfacewinder Roll diameter max: 1200mm Roller width: 1200mm Roll width max: 1100mm Speed: max. 55m/min Longitudinal cutting device 2 or multi-lane Side Slitting Device Automatic roll change Cross-cutting device Role magazine Calibration device Low-friction rollers motor adjustment Adjustment range: for 500-1100mm laying width takeoff unit: Type TPE-1200 Side gusset insertion device Drive: 4-pole 4kW with axial fan Electric cabinet

Blown film line especially for PP processing length: 6,300 mm width: 2,500 mm height: 4,200 mm Weight: 3.700 kg blowing capacity: 65 kg/hod. Film Thicknes: 0.015 – 0.1mm film width: 250 – 650mm Die- diameter 65 mm Winding speed: 5 – 60m/min. Power consumption: 72 kW

Key data: 140 mm

We offer you an EREMA extruder that has been completely remanufactured in-house for sale. It is an EREMA 1514T, the machine is completely mechanically and electrically prepared by us before delivery, all components that do not meet our criteria are replaced with original EREMA spare parts. The machine is designed for a throughput of up to 1100kg per hour and is suitable for PE as well as PP. If you are interested in this machine, please do not hesitate to contact us!

Key data: 140 mm

We offer you an EREMA extruder that has been completely remanufactured in-house for sale. It is an EREMA INTAREMA® 1714 TVEplus®, the machine is completely mechanically and electrically prepared by us before delivery, all components that do not meet our criteria are exchanged for original EREMA spare parts. The machine is designed for a throughput of up to 1200kg per hour and is suitable for PE as well as PP. If you are interested in this machine, please do not hesitate to contact us!

The extrusion line is a COEX cast film line. Processing of thermoplastics in a processing range of 150-300°C. Possible layer structures: - Monofilms - 3- layer (A-B+C-A) - 5- layer (A-B-C-B-A) Plant data: Total system output max. 2230 kg/h Extruder A: 90/33 L/D max. 330kg/h Extruder B.: 135/33 L/D max. 950kg/h Extruder C.: 135/33 L/D max. 950kg/h Film width NET: 1600 - 2110mm; Center cut for 2 bobsleighs possible (2x 800 – 2x 1055mm) Thickness: 25-580μm Production speed 10 - 150m/min Roll width 2500 mm roll weight 2000kg Additional components (quality): non-contact thickness gauge for automatic nozzle with automatic cross profile control on both sides Corona pretreatment (max. 12000W) Optical surface inspection system incl. defect marking in open and pass-through light Ancillary equipment: Dryer 1 – 4 with 4500 liters volume ; Heating capacity 48kw dryer 5 ...

The original part is a main and KO extruder from Kuhne built in 2006, the system was extended in 2010 by an additional extruder from the SML (coating unit). Plant description: COEX cast film line with additional coating unit. The main plant is equipped with a co- and a main extruder. The coating unit with a main extruder. Processing of thermoplastics in a processing range of 90-300°C. The system can be operated with the following combinations: • Main unit (CoEx system) with coating unit • Main unit (CoEx system) without coating unit • Only coating unit with unwinding unit for carrier film For operation in the various combinations, the corresponding additional units are switched on or off. Possible layer structures: Main plant: - Monofilm with release film if required - 3-layer film (A-B-A) with release film if required Coating: - Monofilm on carrier material if req ...

This Krauss Maffei KME 75-36 R AC single screw extruder was manufactured in 2008. It features a KM-GM 750 control integration with meter weight and mass throughput control, and a capacity of up to 750 kg/h granulate. The machine includes a connection for INDEX wall thickness measurement and is equipped with a EURO socket CEE 32 A - 6 H / 250 V. Contact us for more information about this machine.
