other packaging machinery used for sale

Fully automatic stretch winding machine Spinny S2300 with electromechanical nider holder Pallet dimensions: L 1200 x W 800 x H 2600 mm Maximum weight: 1000 kg Hourly rate: approx. 20 pal./hour (depending on pallet height and type of winding) Conveying height: 500 mm Technical specifications: • Winding cycle, programmable via the electronic control panel and SIEMENS S7-1200, KTP700 Control Panel • Control SIEMENS PLC S7 1200 SAFE and HMI KTP700 • 15 freely programmable winding programs • Turntable stop in the end position • Conveying height: 500 mm • Usable width of roller conveyor: 1000 mm • Photocell for autom. Pallet height detection • Clamp for attaching the film to the pallet load • Automatic film cutting system at the end of the wrapping cycle • Frequency converter for adjusting the turntable speed 5 ...

Herbert Gemini weigh price labeller from 2003. Weighing range: - Max weight: 4 kg - Min weight: 0,1 kg Weight precision: 0,002 kg Labelheight: - Applicator no 1: 150mm - Applicator no 2: 400mm Packs per minute range: - Minimum speed: 1 per minute - Maximum speed: 100 per minute Conveyor width: 225mm Year of production: 2003 Serial number: 20251005 Condition: good Dimensions: - Checkweigher: 1.600mm x 750mm & 1.750mm (LxW&H) - Labeller & printer: 1.800mm x 1.000mm & 2.100mm (LxW&H)

SF WeighStation checkweigher. Double rejects for both under- & overweight weighins. Conveyor width: 600mm Year of production: 2014 Serial number: SF 589314.738 Dimensions: 2.850mm x 1.200mm & 1.800mm (LxW&H)

Loma 6000 checkweigher. Push reject for over- and underweight weighins Maximum weight: 6 kg per product Weight precision: 0,6 gram Speed: 250 products per minute Finish: 304 stainless steel Conveyor width: 140mm Year of production: 1999 Serial number: ACW-40540-010733 Condition: good Dimensions: 1.800mm x 900mm & 1.100mm (LxW&H)

Thermo Ramsey Accustar checkweigher. Maximum product weight: 4 kg Weight precision: 1 gram Speed: 90 metres per minute Conveyor width: 225mm Year of production: 2003 Serial number: 5512 Condition: good Dimensions: 1.650mm x 1.000mm & 1.850mm (LxW&H)

Liebel Wäge- und Sortiertechnik USS – 4 checkweigher from 2002. Weighing range: - Max weight: 750 gram - Min weight: 50 gram Weight precision: 1 gram Speed: 120 packs per minute Conveyor width: 200mm Year of production: 2002 Serial number: 02003 Condition: good Dimensions: 1.300mm x 750mm & 1.650mm (LxW&H)

K.S. Automatik elevator from 2006. Conveyor width: 160mm Year of production: 2006 Serial number: 7 Condition: good Dimensions: 1.300mm x 600mm & 1.300mm (LxW&H)

Load: 40 kg Additional load: 20 kg, Type: RP40, Description: Reis Robotics, Year built: 2003, Capacity: 7 Pallets / hour, Dimensions: approx. 3.000x6.000x4.000mm, Connection: electrical 400VAC, 50Hz, 35A, Control panel: Touchscreen, Colour: Red, Repeat precision: + / - 0,3 mm, Number of axes: 5

3M-Matic 800a-E Type 29600 (5799) Carton sealing machine for lid and bottom closure with adhesive tape, side belt belt drive system, carton format range in mm length 150 - ~, width 115 – 550, height 120 – 625, manual carton size adjustment, maximum carton weight approx. 38 kg, roll discharge with a length of approx. 1200 mm, drive laterally, electrical connection 380V/50Hz/3PH/1.4A, 260W, machine in mobile version on rollers, output up to 40 cartons per minute

Empty bottle inspector with inspection of: - Inlet inspection with rejection - Bottom inspection with foil detection - RGB sealing surface inspection - HF + infrared residual liquid inspection - Dual sidewall inspection - Side neck finish/thread inspection - foil detection in the side wall modules Setting of test bottle requirements and processing via RFID., Additional title: empty bottle control, Capacity: 40000 bo/h, Power: 1,6 kW, Current: 7 A, Voltage: 230 V, Frequency: 50 / 60 Hz, Formats: White and brown bottles; 0.33 litre longneck, 0.5 litre NRW and Euro, Running direction: left -> right, Features: Camera system, Two discharge systems for separating dirty and damaged bottles, remote maintenance module, software licence, self-monitoring system

Pallet film wrapper, Additional title: Pallet film wrapper, Max. capacity: 55 pal/h at max. 1600 mm height (standard height 2300 mm), Rotation speed max.: 20 rpm, Power: 4 kW, Current: 7,5 A, Voltage: 400 V, Frequency: 50 Hz, Weight: 1500 kg, Formats: Pallets with 1200 x 800 mm (max. 1200 x 1200 mm, min. 600 x 800 mm), Running direction: right -> left, Operation / Control: On-site control box, Material: Black steel painted, Position: free-standing, Base construction: Frame construction bolted to the floor, Features: Satellite winder with integrated cover sheet dispenser, Powerstretch film pre-stretching system S:C:S:P, clamping system Genesis, protective grille and muting system, safety barriers, pneumatic hold-down device, 2 roller conveyors in the winding area

Single-end bottle washer. Factory overhauled in 2005., Additional title: one end machine, Nominal capacity: 6700 bo/h, Control range: 7370 bo/h, Number of bottle cells: 1620 pcs., Number of bottle cells per row: 10 pcs., Length: 7790 mm, Width: 3450 mm, Height: 2950 mm, Weight: 20000 kg, Machine partitioning: Chain division 150 mm, cell division 110 mm, Operation / Control: Siemens S 5, Material: Stainless steel, Position: Free-standing on spherical feet, Base construction: Housing in one-piece block design, Features: Bottle insertion and removal finger system, chemical dosing stations with dosing pumps, format parts for inlet and outlet

Repacking line for 0.5 litre glass bottles, consisting of three machines: 1. depalletising: Pallets with full modular crates are loaded and unstacked here, and empty crates are stacked and moved out. 2. repacking machine: This is where modular boxes of 20 are unpacked, 4-carrier cartons are unfolded and loaded/packed with bottles. 3. packer/palletiser Here, the 4-pack carrier cartons are packed into quill boxes, stacked on pallets and moved out of the system., Additional title: combined repacking system with palletizing, Capacity approx.: 200 crates/h, Formats: Bottle crate (400 x 300 mm) on Euro pallet (1200 x 800 mm), Running direction: right -> left, Operation / Control: on-site control unit / Siemens PLC, Position: free standing, Base construction: Square tube construction bolted to the floor, Features: depalletizing, unpacking, bottle transport, crate transport, carton unfolding, pa ...

Additional title: Roboband / Logomatic, Capacity: 150 paletts / h, Power: 5,5 kW, Current: 10 A, Voltage: 400 Volt, Frequency: 50 Hz, Weight: 1700 kg

Bottle washing machine Nagema GM Arcade Year of construction 1993 Output 23,000 bph, Additional title: Single-ended machine, Capacity: 21000 bo/h, Bottles each row: 16 bo/row, Length: 8,64 m, Width: 4,47 m, Height: 1,92 m, Weight: 17900 kg, Formats: 0,5 l NRW-Bottle, Features: Heated by steam; smoke suction; insertion sieves; caustic settling tank , Periphery: S5 controll (HMI Lauer)

Federspiel Maschinenbau GmbH & Kuka Roboter GmbH; Kuka Roboter:Type: KR 210-2 2000, Year of manufacture: 2007, Weight: 1276 kg, Load capacity: 210 kg, 6 axes, Driven by AC servo motors, Other: IP65,

Combined de-capper for screw tops and crown caps. Combined unscrewer and uncorker. Equipped with 2 unscrewing and one uncorking hoods. The machine is operated with 2 hoods installed at the same time, which corresponds to 4 unscrewing/decorking heads. Velocity of the crate conveyor: 0,6 m/s., Capacity: 40000 bo/h, Pneum. working pressure: 10 bar, Power: 11 kW, Current: 25 A, Voltage: 230/400V, 24V control voltage, Frequency: 50 Hz, Length: 2900 mm, Width: 1260 mm, Height: 2000 mm, Formats: 0,5 l NRW, 0,5 l Euro, 0,33 l Steinie, screw caps and crown caps, Operation / Control: Simatic S7, Features: 2 Hoods with 2 heads each for screw tops,1 hood with 2 heads for crown caps, crate transport conveyor, crate lock with initiator, limit switch, cork detection, hydraulics, light barriers, hydraulic valve, door switch, compressed air connection, control cabinet

Additional title: high pressure spraying, Capacity: 1800 cr/h, Formats: 20 bottle crates (NRW 0,5 l, Euro 0,5 l, Steinie 0,33 l) , Operation / Control: semiautomatic with switch cabinet panel, Features: crate turner incl. shard collection container

Carbon dioxide laser for label marking. Supports high line speeds. Laser-optimised fonts for high-speed marking, including standard fonts and Unicode.Labels can also be marked with graphics (.bmp, .plt, .dxf formats). Over 60 different types of barcodes can be printed on labels, as well as traceability codes and serialisation data. Operation via graphical user interface. Extraction of smoke and dirt by Domino DPX 1500 and DPX 3500., Additional title: label marking, Capacity: 40000 Fl/h, Wavelength laser: 10 µm, Ambient temprature: 40 °C, Air humidity: 90 % RH non condensing, Power: 1,05 kW, Voltage: 90 - 264 V, Frequency: 47 - 63 Hz, Features: control touch panel, extraction systems DPX 1500 and DPX 3500

Palletization including pallet loader and unloader, pallet magazine, banding machine, pallet labeling, Capacity: 150 Pallet/h, Features: Pallet loader and unloader: Nagema PA; Year of construction: 1993; Capacity: 1700 crates/h; Dimensions: Length: 3 m, width: 2 m, height: 3 m Weight: 1.6 tons Banding machine:Athena Roboband 2VH; Year of construction: 2004Capacity: 150 pallets/h; Pallet dimensions: 1.2 m x 0.8 m; Logopac Logomatic 915/T; Year of construction: 2014; Capacity: 150 pallets/h

Capacity of filling line: 5000 bo/h, Features: switch cabinet with control panel, 24 capping heads

Technical data turn table wrapping line with top sheet despenser for fully automatic, watertight packaging of palletised goodsManufacturer UNITECH S.r.l., Via Buscaglia, 10 - 27029 VIGEVANO, ItaliaTyp UNIWRAP 200 AEYear of construction 2007Throughput capacity approx. 30 pallets per hourConnected load 7,5 kWWeight 3,700 kgStretch films, roll diameter 300 mmRoll height 500 up to 750 mmCore diameter 76 mmFilm thickness 15 to 35 micron Roll weight 25 kg Top cover PE film, roll diameter 250 mmCore diameter 76 mm PE film roll width max. 1,700 mmPE film thickness 60 to 100 micronPLC Siemens Simatic S7-200PLC panel Siemens OP 77AInstallation dimensions Wrappinmg unit 3,400 x 3,100 x 3,900 mm (l x w x h)Dimensions roller conveyor 10,000 x 1,150 x 570 mm (l x w x h)Descreption:The Uniwrap 200 AE is a robust build stretch wrapping machine made of high quality components delivering reliability in t ...

REF-2650 PILLAR UNIFOILER-U 1kW INDUCTION CAP SEALER Manufacturer: PILLAR TECHNOLOGIES Model: UNIFOILER-U (U5R1002000000) Year: 2008 Induction sealing machine for sealing the foil inside the caps of bottles, jars, etc. Air-cooled Stainless steel design Portable cart with casters Power: 1 kW Voltage: 240 V/8 A/50-60 Hz/1PH Foil seal diameter: max. 120mm Room temperature: max. 40 °C Overall dimensions (mm): 900 x 560 x 1,700 (LxWxH) Sealing head: 126 x 51 mm Adjustable height

Deblister machine Manufacturer: RBP Bauer GmbH Type RBP Model D 3600 Year of construction 2002

A semi-automatic Siat pallet wrapping machine is available. Turntable diameter: 1500mm, max. wrapping height: 2500mm, load capacity: 2000kg, machine dimensions X/Y/Z: approx. 3800mm/1500mm/2400mm. Including a supply of wrapping film. Documentation available. On-site inspection is possible.

A line for packing and palletizing bags of products such as salt or fertilizer is available. It includes specialized machines for the precise filling, packaging and stacking of bags on pallets for shipping. The system is designed for continuous operation. 1) Palletizing robot for the bags, max. pallet dimensions X/Y: 1300mm/900mm, loading height including pallet: 700mm-1500mm, max. loading weight: 1500kg, max. loading capacity: 500-600 bags/h, recommended loading capacity: 450-550 bags/h. 2) Big bag filling station Aventus FIBC EGF 1, big bag weight: 500kg, 600kg, 1000kg, max. big bag height: 1400mm, max. big bag width: 1000mm, max. big bag depth: 1000mm, loop length: 250mm, filling support diameter: 400mm, filling support height: 500mm, max. bag sag: 250mm, accuracy: +/-1g per 1kg. 3) Stretch-Hood-System Aventus KL Stretch-Hood, max. loading width: 900mm, max. loading length: 1300mm, ma ...

An automatic stretch-banding machine Keiner Skinetta is available. Cycle output: 32/min, max. film width: 300mm, max. insertion width: 380mm, max. insertion length: 360mm, max. insertion height: 290mm, packaging materials: PE/PP/PVC. Machine dimensions X/Y/Z: approx. 3200mm/1000mm/2100mm, weight: approx. 500kg, control: Siemens Simatic S5-100U. Documentation available. On-site inspection is possible.

A comprehensive package of spare parts from Tetra Pak is available. Machines: Tetra Pak packaging systems and related equipment. Spare parts: Sleeve for pipe connections, cone ID6xD6mm aluminum, cutting ring 6mm, spacers, spring 1.00x12.00x50.0mm 1. 4310, screw M5x12, sealing ring 8x14mm, O-ring 15x2mm, retaining ring DIN 471, valve spring, bearing 6001-2RS, plain bearing bush 10x12x15mm, hose connector 6mm, seal EPDM, connection nipple R1/8, guide bush 20mm, plastic sealing cap, insulating washer 22x3mm, clamping element and others. Documentation available.

Here is an entire packaging line sold in very good used condition Ilapack Carrera 500PC flowpack machine, speed up to 35 to 60 cycles/min. TANGO automatic tap Fully automatic price labeller with weighing function Espera ES 5011. Labeling: Top and bottom, label dispensing if weight fits Mettler Toledo Checkweigher Turntable

Tightening banding machine with shrink tunnel Manufacturer: Kiener Type ASK 450 Kiener Tightening Banding Machine Auto Skinetta 450 with hinge chain belt and shrink tunnel with bar chain belt and hot air gun on the side and from above. Siemens Control Film width 40-450 mm single lane Foil thickness 25-60 My Thickness tolerance +/- 10% Roll diameter up to film width 200 mm Outer diameter approx. 300 mm Up to film width 600 mm Outer diameter approx. 250 mm
