boring mills and machining centers used for sale (3,252)

Why manufacture small parts on large, expensive CNC machining centers when it does a small CNC machine for a fraction of the price as fast and true to size ? Brass, copper , steel, stainless steel and many other materials can be processed . See information and seek non-binding offer or view a demonstration at our premises , personalized with your material and your record !; ready for operation

Equipment / Product data of the CNC-Fraesen Type High-Z/TRex series / Type 1224 Drive: 3 buerstenlose brand stepper motors with 4.5 amperes. Pushing through long and up to 120mm high materials possible, as no belt drive is in the way at the end of the X axis! linear guides on all axes of HIWIN / THK ! Multiple ball-bearing ball thread spindles on all axes, brand edging! speed speed max. 12,000 mm/min Working speed max. approx. 8,000 mm/min Technical platform X/Y: 0.005mm (1/10 step); Z: 0.0025mm reverse clearance maximum approx. +/- 10 microns (0.010 mm) Point repeatability: approx. 0.01 mm clamping area 2800 x 1340 mm travel distances: X=2400mm; Y=1200mm; Z= 130 mm contactsensors / reference switches / limit switches on all axes Double secured emergency trigger energy chains for clean cable flush Total mass with motors : LxWxH approx. 3070 x 1800 x 1420 mm Fraesmotor holder Euroneck  ...

Equiptment / product data CNC-milling machine type High-Z/TRex series / 1224 Drive: 3 brushless brand stepping engines with 4,5 ampere. Possibility of sliding through long and up to 120mm high materials, no belt drive at the ende of the X axis! Linear guide on all axis by HIWIN / THK ! Multiple ball-bearing ball-screw spindle on all axes, proprietary brand! Rapid traverse max. ca. 12.000 mm/min Operating speed max. ca. 8.000 mm/min Technical definition X/Y : 0,005mm (1/10 Schritt); Z: 0,0025mm Backlash maximal ca. +/- 10µm (0,010 mm) Repeat accuracy: ca. 0,01 mm Clampin surface of grooven panel / T-slot table 2800 x 1340 mm Travels: X=2400mm; Y=1200mm; Z= 130 mm Non-contact reed sensors / reference switches / limit switches on all axes Double secured emergency-stop button Energy chains for a clean cable routing Total dimensions with engines : LxBxH ca. 3070 x 1800 x 1420 mm Mill ...

Dauerbohrleistung in St 60: 35 mm standard ALB ear power: 40 mm thread cutting performance: M 30 spindle: MK 4 feed adjustable: 20-400 mm / min drilling depth programmable: 175 mm projection: 300 mm spindle/table: 70-830 mm surface: 550 x 400 mm column diameter: 120 mm total height: 1,980 mm weight: 450 kg motor pole shift bar: 1.5 / 3.0 kW spindle speeds continuously variable range: 120-2,500 rpm spindle speeds stepless area B: 60-1,200 RPM

Dauerbohrleistung in St 60: 18 mm standard ALB ear performance: 20 mm thread cutting performance: M 12 spindle: MK 2 drilling depth: 100 mm projection: 225 mm from spindle/table: 55 up 880 mm table area: 450 x 315 mm column diameter: 90 mm overall height: 1,745 mm weight: 170 kg frequency-controlled three-phase motor: 1.5 kW spindle speeds continuously variable range: 100 - 2,000 rpm range: 200 - 4,000 min-1 digital display for speed as standard.

Dauerbohrleistung in St 60: 15 mm standard ALB ear performance: 18 mm thread cutting performance: M 8 spindle: MK 2 drilling depth: 80 mm projection: 180 mm spindle speeds of stepless 200 - 4,000 rpm spindle speeds threads 200-700 rpm distance spindle/table: up to 380 mm tabletop: 250 x 220 mm column diameter: 65 mm total height: 910 mm weight: 80 kg three-phase motor frequency controlled: 1,1 kW with full thread cutting device and programmable digital display

Spindle: MK 3 Dauerbohrleistung: 25 mm standard ALB ear performance: 30 mm of thread cutting performance: M 20 depth: 125 mm projection: distance 260 mm spindle/table: 90 to 840 mm table surface: 500 x 365 mm column diameter: 110 mm overall height: 1,855 mm weight: 250 kg motor pole shift bar: 0.8/1.5 kW spindle speeds continuously variable range: 80 - 1440 min-1 range: 180 - 3,200 RPM digital display for speed as standard.

Drilling capacity: 40 mm tool holder: MK 4 speed (spindle): 90-1455 K rpm projection: 320 mm drilling table swivel: +/-50° distance spindle to table maximum: 590 mm distance spindle to base plate: 1155 mm column diameter: 120 mm table size: 505 x 425 mm worktop base plate: 360 x 370 mm motor power: 1.0 / 1.5 kW machine dimensions (W x D x H): 500 x 930 x 1870 mm weight approx.: 450 kg Accessories: - Chuck Dorn MK 4 / B 18 - coolant system - digital speed display - keyless drill Chuck 1-16 mm / B 18 - reduction sleeve MK 4 / 3, MK 4 / 2, MK 3 / 1 - halogen lamp - automatic tool ejector - protective cover

Table clamping surface: 2 x 350 x 300 mm traverse path x/y/z: 700/300/250 mm spindle retainer: BT 30 ISA kl. / gr. Table/spindle distance: 450 mm spindle speeds: 6-6000 rpm number of tool stations: 10 pieces feeds: 5-10000 mm / min rapid traverse: x & y/z 25/20 m / min spindle drive: 3,1/4,1 kW Electr. Supply: 400 V kW weight: 2600 kg

Drilling capacity in steel/GG: 50/60 mm spindle retainer: 5 MK projection: 400 mm table size: 700 x 600 mm Quill stroke: 275 mm spindle speeds: 32-1030 rpm feeds: 4: 0.1 ? 0.4 mm drive motor: 380 V, 2.2/3.7 kW space: 700 x 1200 x 2700 mm weight: 1240 kg

Drilling capacity in steel/GG: 23 mm spindle retainer: 2 MK projection: 300 mm table size: 300 x 300 mm Quill stroke: 100 mm spindle speeds: 190-1500 rpm drive motor: 380 V, 0.5/0.75 kW space: 410 x 670 x 1950 mm weight: 180 kg

New machine editing by: wood, plastic, PVC, Fiberglass, Plexiglas, non-ferrous metals such as aluminum, brass, etc. Technical data: Auflöstung: 0,0018 mm X-Y-Z of precision trapezoidal thread spindles 12 x 3 mm All drive spindles are without triple play ball bearings Table size: 506 mm x 320 mm Traverse paths: x 215 mm, y 375 mm, z approx. 90 mm Passage about 78 mm Prices and further sizes on request

conventional ´ traditional Tischbohrwerk, work spindle diameter 85 mm Traverse paths x 1000 mm, y 1000 mm, z 900 mm, ISO 40,. Clamping area table 1000 x 1120 mm with position indicator

Thread cutting capacity: M 3 - M 12 Speed: 400 rpm Air demand: 750 l/min Pressure: 6 - 7 bar Extension: 950 mm Standard accessories: Parallel arm Air motor 6 pcs safety slip couplings of your choice guide column with mounting flange Radial boom Maintenance Pneumatic oil for initial filling

Stand drilling machine in row arrangement, used Gang drilling machine, used Type: BT 6.52 Manufacturer / make: Steinel Built/ new in: 1978 Drilling capacity / drilling capacity: 6 mm in St 60 Spindle cone/ spindle taper: MK 1 Drilling spindle discharge / distance center drill spindle to column: 204 mm Drilling stroke/ way of spindle: 90 mm Table clamping area/ table size: 800 x 390 mm Column diameter/ diam. of coulmn: 60 mm Drilling spindle speeds / speeds of drilling spindle: 1400 / 2800 / 5600 per min/ per minute Total connection value / rated power: 0.25 kW each => 1 kW Weight / weight: approx. 0.4 t

Radial drilling machine, used radial drilling m/c, used Type: BR 56 x 1600 Manufacturer/ make: WMW Year built/ year of make: 1965 Extension/ length of arm: 300...1600 mm Ma. Drilling radius / max. drill. Radius: 1800 mm Drilling capacity at boring: 56 mm ( St 60 ) Drilling capacity at boring: 80 mm ( GGL 20 ) Thread cutting/ thread cutting: max. 65 mm ( St 36 ) 76 mm ( GGL 20 ) Drilling depth/ drilling depth: 400 mm Tool holder / taper in spindle: MK 5 Removal spindle head to base plate/ distance Spindle head to base: max. 1600 mm Base plate/ base: 1700 x 1000 mm Speed range/ range of speeds: 14..1800 rpm Feed: 0.0315 .. 1.6 mm/U// mm per round Connection value: 7.13kW Weight: about 4.5 t

Thread cutting power M 2 - M8 Speed: 700 rpm, luf requirement: 750 l/min, pressure 6 - 7 bar, working range extension: 300 - 1900 mm, Afbau parallel arm: stable arm structure made of hard aluminium profile (38x29) Weight: 23 kg, adapter holder: TCS 1 B - incl. 6 safety slip couplings according to your choice year: 2009

Thread cutting: M3 - M27 Speed: 70/220 rpm Working radius: 300 - 1900 mm Construction parallel arm: Stable arm structure made of hard aluminium profile (58x40) Weight: 39 kg Zubehoer: 6 slip couplings of your choice

Thread cutting of M 4 - M 22 Working radius 300 - 1900 mm Speed: 120/300 rpm Air demand/pressure: 950 l/min 6-7 bar Construction parallel arm: Stable arm structure made of hard aluminium profile (58 x 40) Weight: 39 kg incl. 6 safety slip couplings of your choice

Thread cutting: M 3 - M 16 Speed: 300 rpm Working radius: 200 - 1900 mm Air requirement/pressure 950 l/min 6 - 7 bar Construction parallel arm: Stable arm structure made of hard aluminium profile (38 x 29) Adapter recording TCS 2 B Weight: 27 kg incl. 6 slip couplings

Thread cutting of M 3 - M 12 - Speed: 400 rpm. Air demand/pressure: 750 l/min. 6-7 bar Working range (extension) 300 - 1900 mm Construction parallel arm: Stable arm structure made of hard aluminium profile (38 x 29) Weight: 23 kg Adapter recording: TCS 1B incl. 6 TCS1B safety slip couplings of your choice

Specification: Column

Mikron HSM 400 is a high-precision, high-speed machining center STEP TEC spindle, type HVC140-SB-10-15/42-3F-HSK-E40Spindle hours: 26897 hManufacturer: Step-Tec AG (Switzerland)Spindle type: HVC140-SB-10-15/42-3F-HSK-E40Tool interface: HSK-E40Maximum spindle speed: 42,000 rpmPower: 13 kW (40% duty cycle), 10 kW (100% duty cycle)Torque: 4.25 Nm (40% duty cycle), 3.2 Nm (100% duty cycle)Lubrication: oil-air lubrication systemAxis Drives and DynamicsDrive system: AC servo motors with ball screw drivesFeed rate (X/Y/Z): 0 – 40 m/minAcceleration (X/Y/Z): 1 g (10 m/s²)Rotary Axis PerformanceB-axis speed: up to 54,000 °/minC-axis speed: up to 90,000 °/minTool SystemTool interface: HSK-E40Tool magazine capacities: 18 / 36 / 68 tools depending on configurationTool change time: approx. 10 secondsChip-to-chip time: approx. 12.5 secondsPallet and Clamping SystemErowa UPC pallet system: 320 ×  ...

Year of construction: 2016 CNC controller: FANUC Professional 5 Axes X-axis travel mm: 550 Y-axis travel mm: 1000 Z-axis travel mm: 500 C-axis degrees: 360 (continuous rotation) / rotary encoder A-axis degrees: 150 (+30 120º) rotary encoder Feed rates m/min: X:32; Y,Z:40 Rapid traverse m/min: X,A,C:48; Y,Y:50; A,C:18 Worktable Table dimensions mm: 500 Maximum workpiece size (D x H) mm: 650x500 Max. workpiece weight kg: 350 Spindle Spindle speed rpm: 14000 Tool system Tool holder: HSK-A63 Tool magazine slots: 323 Tool changer: Pinza doble Max. Tool Diameter 70 With occupied neighboring places mm: 140 Max. Tool Length mm: 300 Max tool weight kg: 8 Equipment Electronic Handwheel Chip conveyor Measuring probe Machine running times Under power: 63813h Spindle Working: 30592h Basic machine dimensions / weight Length mm: 3550 Width mm: 2900  ...

Manufacturer QUASER Model MV204IIU / 10 Year 12/2002 CNC HEIDENHAIN ITNC530 3 work tables / pallets Table 1 Size Ø280 mm. Table 2 Size Ø 500 mm. Table 3 Size 600×400 mm. Weight allowed on table 265 kg Min-max distance on table 150-760 mm. Axles Travels (X/Y/Z) 700/590/480 mm Tilting head movement range (A-axis) ±110º Axis Positioning A 0.001º Table Rotation (C-Axis) 360º C-Axis Positioning 0.001º Fast Forward Axles (X/Y/Z) 32,000 mm/min Maximum Working Advance (X/Y/Z) 15,000 mm./min. Head Head Speed 10,000 r.p.m. BT-40 Head Cone Main engine power 15/33 kW Par 192/189 Nm. Charger Tools No. of Positions in Tool Loader 32 RANDOM tool change system Maximum tool length 280 mm. Maximum tool weight 7 kg Other Equipment Chip Evacuator INCLUDED Internal cooling 20 bar INCLUDED Coolant tank capacity 280 l. Refrigeration electrical cabinet INCLUDED Clea ...

Manufacturer DMG Model DMU 50 eVo linear Year 2008 3D CNC control HEIDENHAIN iTNC 530 Table NC Rotary Table INCLUDED Table surface 500×380 mm. Maximum weight on table 500 kg Table rotation (C-axis) 0.001º (±360º) Oscillation field (B-axis) 108º Direct Measurement System INCLUDED Routes and advances Longitudinal travel (X-axis) 500 mm Cross travel (Y-axis) 450 mm Vertical travel (Z-axis): 400 mm X-axis fast feed 80,000 mm/min Fast forward Y-axis, Z 50,000 mm/min Fast forward B, C axes 18,000 mm/min Number of Controlled Axles 5 Head Head speed 18,000 r.p.m. BT-40 Head Cone Main Motor Power 30 kW Equipment Automatic tool loader INCLUDED No. of positions in tool loader 30 Internal cooling 40 Bar INCLUDED Coolant tank with paper filter INCLUDED Chip Evacuator INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel Others Total installed power 52 kVA Machin ...
