Horizontal Processing Centers used for sale (29)

Key data: 730 mm, 730 mm, 850 mm

Basic machine data Used 4-axis horizontal machining center from MORI SEIKI Make: MORI SEIKI Type: NH5000 DCG Year of Make: 2011 Condition: Mint Control: Name: FANUC 32iA MAPPS Travels: x-travel: 730 mm // y-travel: 730 mm // z-travel: 850 mm Technical data: • Spindle: max. 14000 rpm • HSK A-63 Tool Holder • 60-fold tool changer • Feed speed: 50 m/min • Rapid traverse: 50 m/min • B-axis indexing: 360° • 2 pallets • Pallet dimensions: 500 mm x 500 mm • Max. workpiece size: 800 mm x 1000 mm • 680 l IKZ • Chip conveyor The machine is in mint condition. Machine has only 5203 PGM hours Prior sale is reserved. No liability is assumed for the technical information provided here. The legal provisions apply.

x-travel: 650 mmy-travel: 650 mmz-travel: 680 mmNumber of working hours: 55.000 htool taper: HSK 63 turning spindle: 85 spindle turning speed range: 20.000 U/minChain-type tool magazine: 60 positionsChip conveyorPallet changerCoolant filtration systemHigh-pressure coolant through the spindleThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The machine is in good technical condition, after prior agreement it is possible to test it. Spindle completely overhauled summer 2023 Ball screw replaced in Z axis in 2020. Feeds: X axis 850 mm Y axis 700 mm Z axis 750 mm Working feed 1-24000 Positioning accuracy +/- 0.005 Rapid feed – 48m/min all axes. Distance spindle face – front of table 150-900 mm Distance spindle axis – pallet surface 50-750 mm Pallet – 500 x 500 Spindle alfaP22/8000 Motor power (continuous/15') – 11/15/18.5 Spindle speed – 8000 rpm Base speed – 8000 rpm Tool clamping force – 1000 N Max. torque (15') 29.2 Nm Orientation built-in sensor Taper ISO 40, taper 7/24 Power transmission – synchronizing belt and pulley Cooling through the spindle – 70 kg/cm2, max flow 20 L/min, pump power 3.7 KW Magazine for 60 tools – chain – be careful, the catalogue incorrectly states 40.

x-travel: 1200 mmy-travel: 950 mmz-travel: 1200 mmB-axis travel: 0 – 360°A-axis travel: +45° to -90°Tool holder spindle: HSK 100Torque spindle: 200 mmSpindle speed: 15,000 rpmChain-type tool magazine: 60 positionsPallet changerChip conveyorHigh-pressure coolant through the spindleCoolant filtration systemThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 620 mm, 800 mm, 650 mm

Horizontal BAZ LID MAHO DMC 60H Linear with 2-fold pallet changer and 180 magazine locations Year of Make: 2009 Control: Sinumerik 840D Technical data: Spindle speed: 0-18,000 min-1 Drive power: 35KW Torque: Spindle mount: HSK 63 Number of magazine slots: 180 pieces Number of pallets: 2 Pallet size: 500x500mm Travels: X-axis: 630mm Y-axis: 800mm Z-axis: 650mm C-axis: 0.001° All axes have linear actuators Accessories: -Coolant system -Chip conveyor Machine was regularly serviced Video available on request.

control: FANUC 16 MA-Pro 3 Number of axles: 4 St.x-travel: 900 mmy-travel: 800 mmz-travel: 970 mmb-axis: 0.001 °size of pallet: 630 x 630 mmtool piece magazine with: 244 milling spindle: HSK100 spindle turning speed - stepless: -12000 U/minchip conveyor: kWmisc. accessories: weight of the machine ca.: 20 tdimensions of the machine ca.: 6.5 x 3 x 3 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control Siemens 840D powerline Travel X/Y/Z 630/630/630 mm 2-fold pallet changer Speed 10000 1/min Knoll coolant system with paper belt filter Tool holder: SK40 Tool magazine 80 spaces

CONTROLS  CNC controls OKUMA OSP-P300MA WORKING RANGE -CUBIC-  X-axis travel: 560 mm  Y-axis travel: 560 mm  Z-axis travel: 625 mmSPINDLE / HEAD  spindle revolutions (max): 15000 /minX/Z SLIDE  number of tool positions (total): 12   number of live positions: 12   - rotation speeds (max): 5000 /min  - drive power: 5.5 kWTOOL MAGAZINE  number of positions: 146 AUTOMATIC WORKLOAD EQUIPMENT  number of store positions: 2   Workpiece diameter max.: 600 mm  worpiece length max.: 900 mm  pallet length: 400 mm  pallet width: 400 mm  number of pallets: 2 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzATTACHMENTS  chip conveyor: yes   coolant unit: yes   through s ...

Inv. Num. : 8589 Type: CWK 400D Dynamic Producer: Heckert Created: 2002 Parameters: Control system: Siemens Sinumerik 840D Work table length: 400 mm Work table width: 400 mm Maximum table load (uniform): 400 kg Spindle drive power: 19 kW Number of axes: 4 pieces Tool magazine: 120 pieces Minimum spindle speed: 50 1/min Maximum spindle speed: 15000 1/min X-axis travel: 650 mm Y-axis travel: 650 mm Travel travel Z-axis: 650 mm Cone: HSK A63 Max. tool length: 350 mm Max. tool weight: 10 kg Machine height: 2600 mm Machine length: 8500 mm Machine width: 4500 mm Machine weight: 12000 kg Equipment: 2 pallets 4th axis – rotary table Chip conveyor KNOLL 450 K – 1/250 Emulsion Filtration KNOLL 210/1350 Oil mist extraction

CONTROLS  CNC controls MAZAK PC FUSION 640 M WORKING RANGE -CUBIC-  X-axis travel: 1700 mm  Y-axis travel: 1400 mm  Z-axis travel: 1400 mmTABLE  - positioning/indexing: 360000 °SPINDLE / HEAD  spindle revolutions (max): 10000 /min  drive power: 37 kWTOOL MAGAZINE  number of positions: 120 AUTOMATIC WORKLOAD EQUIPMENT  store type: pallet changer   number of store positions: 6   pallet length: 1000 mm  pallet width: 1000 mm  number of pallets: 6 A high-quality Mazak FH 10800 is available for sale, equipped with a 6-fold pallet storage system, ideal for automated machining processes and high production output. The machine is in very good condition and is available immediately. With a large travel range, powerful spindle and extensive equipment, this horiz ...

Inv. Num. : 8429 Type: Bluestar 6 Producer: HÜLLER-HILLE Created: 2006 Parameters: Work table length: 630 mm Work table width: 630 mm X-axis travel: 700 mm Y-axis travel: 630 mm Travel Z axis: 700 mm Max. tool diameter: 150 mm Max. tool weight: 10 kg

control: FANUC Professional 6 Number of axles: 4 St.x-travel: 900 mmy-travel: 900 mmz-travel: 1020 mmb-axis: 0.001 °size of pallet: 630 x 630 mmtool piece magazine with: 136 milling spindle: HSK100 spindle turning speed - stepless: 10000 U/mintype of pallet-changer: FASTEMS FPC1500 chip conveyor: kWmisc. accessories: weight of the machine ca.: 20 tdimensions of the machine ca.: 10 x 5 x 3.5 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8330 Type: HR 8A Producer: MITSUI-SEIKI Generated: Parameters: Control system: FANUC Work table length: 1295 mm Work table width: 1295 mm Maximum table load (uniform): 3992 kg X-axis travel: 1800 mm Y-axis travel: 1500 mm Travel distances Z-axis: 1200 mm Machine height: 5500 mm Machine length: 12000 mm Machine width: 9200 mm Machine weight: 45000 kg

control: FANUC 310 is-A Number of axles: 4 St.x-travel: 730 mmy-travel: 730 mmz-travel: 650 mmb-axis: 0.001 °size of pallet: 500x500 mmtool piece magazine with: 60 milling spindle: HSK63 spindle turning speed - stepless: 50-12000 U/minchip conveyor: kWmisc. accessories: weight of the machine ca.: 10 tdimensions of the machine ca.: 3.0 x 5.0 x 3.0 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

:::TECHNICAL SPECIFICATIONS::: CNC Model: Fanuc CNC Version: Professional L Tool holder: HSK 50 Spindle power: 15Kw Number of spindle speeds: 8000 Number of tools: 22 X-axis travel: 400mm Y-axis travel: 400mm Z-axis travel: 400mm Fast feeds linear axes X Y Z: 60m/min Guides: roller Pallet type: continuous Maximum allowable load: 400Kg High refrigerant pressure: yes External tank system with filter: yes Chip conveyor: belt Other technical data: Table diameter 400 mm with single cube THE MACHINE HAS NO PALLET CHANGER AND 'WITH A SINGLE ROTARY TABLE VERY PRECISE AND FAST MACHINE :::D DIMENSIONS AND WEIGHT::: Length: 3200mm Width: 1280mm Weight: 5000Kg

control: FANUC 18i MB Number of axles: 4 St.x-travel: 710 mmy-travel: 610 mmz-travel: 650 mmb-axis: 0.001 °size of pallet: 500x500 mmtool piece magazine with: 60 milling spindle: BT40 spindle turning speed - stepless: 15000 U/minchip conveyor: kWmisc. accessories: weight of the machine ca.: 15 tdimensions of the machine ca.: 5.1 x 3.7 x 3.1 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8264 Type: MA-400HA Producer: OKUMA Created: 2008 Parameters: Work table length: 400 mm Work table width: 400 mm Maximum spindle speed: 8000 1/min X-axis travel: 560 mm Y-axis travel: 610 mm Z-axis travel: 625 mm

x-travel: 600 mmy-travel: 580 mmz-travel: 580 mmcontrol: SEICOS 16M B-axis (table): 360 x 1° mmfeed X/Y/Z/-axis: 1 - 50.000 mm/minrapid traverse X/Y/Z: 50,00 m/minturning speed range - stepless: 35 - 12.000 Nmspindle drive: 22,00 kWmax. torque on the spindle: 236 tool taper: BT40 toolpiece magazine: chain magazine: 61 Stücksize of pallet: 2x 400x400 mmmax. workpiece diameter: 630 mmworkpiece height max.: 680 mmworkpiece weight max.: 400 kgtotal power requirement: 30,00 kWweight of the machine ca.: 12,00 tdimensions of the machine ca.: 4,00 x 3,50 x H3,00 mWith SEICOS S16M control unit, coolant system, chip conveyor, electron. handwheel, dust exhauster.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 7815 Type: HEC 800 Producer: Starrag Heckert Created: 2008 Parameters: Switch-on hours: 46529 h Hours: 19542 h Work table length: 800 mm Work table width: 800 mm Maximum workpiece weight: 2000 kg Spindle drive power: 28 kW X-axis travel: 1450 mm Y-axis travel: 1100 mm Travel distances Z-axis: 1300 mm Cone: SK 50 Machine length: 8300 mm Machine width: 5500 mm Machine weight: 27000 kg

Dimensions (L,W): 1000 x 800 mmFor sale are 51 machine pallets for Burkhard and Weber MCR 120The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 7814 Type: CWK 800 Producer: Starrag Heckert Created: 2004 Parameters: Control system: Siemens Sinumeric Switch-on hours: 60035 h Hours: 31689 h Work table length: 800 mm Work table width: 800 mm Maximum workpiece weight: 1500 kg Spindle power: 28 kW Machine length: 6330 mm Machine width: 5760 mm Machine weight: 18100 kg In 2021 repairs: Replacement of linear guides and ball screws on the X, Y and Z axes Spindle replacement and ATC cabling Machine geometry ATC Function Test

x-travel: 1020 mmy-travel: 610 mmz-travel: 600 mmtool piece magazine with: 48 Plätzenspindle turning speed - stepless: 15000 U/minControl: Manufacture: FANUC 18iMB total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 7300 mm, 1000 mm, 650 mm

- Swivel angle A-axis: 0-90° freely programmable - C-axis swivel angle 0-355° freely programmable - Max. machining length without frontal machining: 7300mm - Max. machining length with front machining: 6980mm - Tool changer with 10 places, as well as a saw blade holder - 9 Material tensioner - Tool holder SK30 - 2-layer machining

x-travel: 1250 mm mmy-travel: 1000 mm mmz-travel: 600 mm mmControl: total power requirement: 25 Kw kWweight of the machine ca.: tdimensions of the machine ca.: mBrand TosMachine no F641Type SPEEDtecCNC Brand SiemensCNC Type Sinumerik 840DYear of make 2009X 1.250 mmY 1.000 mmZ 600 mmIntake HSK 100Engine power 25 kWSpeed 12000 RPMTool changer Number of pallets 4Outgoing ram Including manuals Speed maximum 12.000 RPMMaximum pallet load 4.000 kgChip transport Tool magazine positions: 2x 40 , HSK 1004 tables, 1x 1.000 x 1.250mm / 3x 1.000 x 1.000mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine-Details Stock-No. 1105-04009 Type of machine Machining Center - Horizontal Make MORI SEIKI Type MH 50 Year of manufacture 1993 Type of control CNC Storage location FRANKREICH Country of origin Japan Delivery time stock Freight basis ex. location Technical details X-Travel 710 mm Y-Travel 600 mm Z-Travel 600/730 mm FANUC 16 M control power capacity - milling spindle 22 kW Spindle Turning Speed - Stepless 13000 1/min numbers of tools in magazin 120 BT 50 size of pallet 500 x 500 mm max. workpiece diameter on pallets 580 mm workpiece height max. 740 mm B-axis (table) 360000° X/Y/Z -STEPLESS feeds 24 mm/min Rapid Travel X/Y/Z 24000 mm/min total power requirement 35 kVA weight of the machine ca. 17 t dimensions of the machine ca. 3.9 x 3.4 x 2.6 m Accessories Chip conveyor Additional information NICE MACHINE - 2 pallets 500 X 500 360000° PALLET IND ...

x-travel: 700 mmy-travel: 700 mmz-travel: 700 mmtotal power requirement: 68 kWweight of the machine ca.: 10500 kgdimensions of the machine ca.: 4300x2400x2600 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 1010 mm, 800 mm, 1010 mm

Inv. Num. : 6942 Type: H63 Producer: ZPS Created: 2005 Parameters: Control system: Siemens Work table length: 800 mm Work table width: 630 mm X-axis travel: 1010 mm Y-axis travel: 800 mm Z-axis travel: 1010 mm

Key data: 400 mm, 700 mm, 400 mm

Inv. Num. : 6723 Type: BA400-2 Producer: SW Created: 2004 Parameters: Control system: Siemens - Sinumerik 840D Maximum spindle speed: 17500 1/min Tool magazine: 120 pieces X-axis travel: 400 mm Y-axis travel: 700 mm Z-axis travel: 400 mm Cone: HSK63 Equipment: IKZ High Pressure Pump Filtration Knoll Preparation for 5 axis

Horizontal machining center Kafo HVC 500 :::SPECIFICATIONS::: CNC Model: Fanuc CNC version: 18i MB Tool connection: BT 50 Spindle power: 25Kw Number of spindle revolutions: 10000 Number of tools: 60 X Shaft Stroke: 720mm Y Axis Stroke: 650mm Z Axis Stroke: 650mm Rapid feeds linear axes X Y Z: 48m/min Pallet size: 500x500mm Pallet type: indexed Pallet degrees: 0.001 Maximum load allowed: 800Kg High cooling pressure: yes Pressure value: 20bar System with external tank with filter: yes Chip evacuator: carpet :::D IMENSIONS AND WEIGHT::: Length: 4035mm Width: 5170mm Height: 3000mm Weight: 13000Kg
