boring mills and machining centers used for sale (3,201)

Dauerbohrleistung in St 60: 18 mm standard ALB ear performance: 20 mm thread cutting performance: M 12 spindle: MK 2 drilling depth: 100 mm projection: 225 mm from spindle/table: 55 up 880 mm table area: 450 x 315 mm column diameter: 90 mm overall height: 1,745 mm weight: 170 kg frequency-controlled three-phase motor: 1.5 kW spindle speeds continuously variable range: 100 - 2,000 rpm range: 200 - 4,000 min-1 digital display for speed as standard.

Dauerbohrleistung in St 60: 15 mm standard ALB ear performance: 18 mm thread cutting performance: M 8 spindle: MK 2 drilling depth: 80 mm projection: 180 mm spindle speeds of stepless 200 - 4,000 rpm spindle speeds threads 200-700 rpm distance spindle/table: up to 380 mm tabletop: 250 x 220 mm column diameter: 65 mm total height: 910 mm weight: 80 kg three-phase motor frequency controlled: 1,1 kW with full thread cutting device and programmable digital display

Spindle: MK 3 Dauerbohrleistung: 25 mm standard ALB ear performance: 30 mm of thread cutting performance: M 20 depth: 125 mm projection: distance 260 mm spindle/table: 90 to 840 mm table surface: 500 x 365 mm column diameter: 110 mm overall height: 1,855 mm weight: 250 kg motor pole shift bar: 0.8/1.5 kW spindle speeds continuously variable range: 80 - 1440 min-1 range: 180 - 3,200 RPM digital display for speed as standard.

Drilling capacity: 40 mm tool holder: MK 4 speed (spindle): 90-1455 K rpm projection: 320 mm drilling table swivel: +/-50° distance spindle to table maximum: 590 mm distance spindle to base plate: 1155 mm column diameter: 120 mm table size: 505 x 425 mm worktop base plate: 360 x 370 mm motor power: 1.0 / 1.5 kW machine dimensions (W x D x H): 500 x 930 x 1870 mm weight approx.: 450 kg Accessories: - Chuck Dorn MK 4 / B 18 - coolant system - digital speed display - keyless drill Chuck 1-16 mm / B 18 - reduction sleeve MK 4 / 3, MK 4 / 2, MK 3 / 1 - halogen lamp - automatic tool ejector - protective cover

Table clamping surface: 2 x 350 x 300 mm traverse path x/y/z: 700/300/250 mm spindle retainer: BT 30 ISA kl. / gr. Table/spindle distance: 450 mm spindle speeds: 6-6000 rpm number of tool stations: 10 pieces feeds: 5-10000 mm / min rapid traverse: x & y/z 25/20 m / min spindle drive: 3,1/4,1 kW Electr. Supply: 400 V kW weight: 2600 kg

Drilling capacity in steel/GG: 50/60 mm spindle retainer: 5 MK projection: 400 mm table size: 700 x 600 mm Quill stroke: 275 mm spindle speeds: 32-1030 rpm feeds: 4: 0.1 ? 0.4 mm drive motor: 380 V, 2.2/3.7 kW space: 700 x 1200 x 2700 mm weight: 1240 kg

Drilling capacity in steel/GG: 23 mm spindle retainer: 2 MK projection: 300 mm table size: 300 x 300 mm Quill stroke: 100 mm spindle speeds: 190-1500 rpm drive motor: 380 V, 0.5/0.75 kW space: 410 x 670 x 1950 mm weight: 180 kg

New machine editing by: wood, plastic, PVC, Fiberglass, Plexiglas, non-ferrous metals such as aluminum, brass, etc. Technical data: Auflöstung: 0,0018 mm X-Y-Z of precision trapezoidal thread spindles 12 x 3 mm All drive spindles are without triple play ball bearings Table size: 506 mm x 320 mm Traverse paths: x 215 mm, y 375 mm, z approx. 90 mm Passage about 78 mm Prices and further sizes on request

conventional ´ traditional Tischbohrwerk, work spindle diameter 85 mm Traverse paths x 1000 mm, y 1000 mm, z 900 mm, ISO 40,. Clamping area table 1000 x 1120 mm with position indicator

Thread cutting capacity: M 3 - M 12 Speed: 400 rpm Air demand: 750 l/min Pressure: 6 - 7 bar Extension: 950 mm Standard accessories: Parallel arm Air motor 6 pcs safety slip couplings of your choice guide column with mounting flange Radial boom Maintenance Pneumatic oil for initial filling

Stand drilling machine in row arrangement, used Gang drilling machine, used Type: BT 6.52 Manufacturer / make: Steinel Built/ new in: 1978 Drilling capacity / drilling capacity: 6 mm in St 60 Spindle cone/ spindle taper: MK 1 Drilling spindle discharge / distance center drill spindle to column: 204 mm Drilling stroke/ way of spindle: 90 mm Table clamping area/ table size: 800 x 390 mm Column diameter/ diam. of coulmn: 60 mm Drilling spindle speeds / speeds of drilling spindle: 1400 / 2800 / 5600 per min/ per minute Total connection value / rated power: 0.25 kW each => 1 kW Weight / weight: approx. 0.4 t

Radial drilling machine, used radial drilling m/c, used Type: BR 56 x 1600 Manufacturer/ make: WMW Year built/ year of make: 1965 Extension/ length of arm: 300...1600 mm Ma. Drilling radius / max. drill. Radius: 1800 mm Drilling capacity at boring: 56 mm ( St 60 ) Drilling capacity at boring: 80 mm ( GGL 20 ) Thread cutting/ thread cutting: max. 65 mm ( St 36 ) 76 mm ( GGL 20 ) Drilling depth/ drilling depth: 400 mm Tool holder / taper in spindle: MK 5 Removal spindle head to base plate/ distance Spindle head to base: max. 1600 mm Base plate/ base: 1700 x 1000 mm Speed range/ range of speeds: 14..1800 rpm Feed: 0.0315 .. 1.6 mm/U// mm per round Connection value: 7.13kW Weight: about 4.5 t

Thread cutting power M 2 - M8 Speed: 700 rpm, luf requirement: 750 l/min, pressure 6 - 7 bar, working range extension: 300 - 1900 mm, Afbau parallel arm: stable arm structure made of hard aluminium profile (38x29) Weight: 23 kg, adapter holder: TCS 1 B - incl. 6 safety slip couplings according to your choice year: 2009

Thread cutting: M3 - M27 Speed: 70/220 rpm Working radius: 300 - 1900 mm Construction parallel arm: Stable arm structure made of hard aluminium profile (58x40) Weight: 39 kg Zubehoer: 6 slip couplings of your choice

Thread cutting of M 4 - M 22 Working radius 300 - 1900 mm Speed: 120/300 rpm Air demand/pressure: 950 l/min 6-7 bar Construction parallel arm: Stable arm structure made of hard aluminium profile (58 x 40) Weight: 39 kg incl. 6 safety slip couplings of your choice

Thread cutting: M 3 - M 16 Speed: 300 rpm Working radius: 200 - 1900 mm Air requirement/pressure 950 l/min 6 - 7 bar Construction parallel arm: Stable arm structure made of hard aluminium profile (38 x 29) Adapter recording TCS 2 B Weight: 27 kg incl. 6 slip couplings

Thread cutting of M 3 - M 12 - Speed: 400 rpm. Air demand/pressure: 750 l/min. 6-7 bar Working range (extension) 300 - 1900 mm Construction parallel arm: Stable arm structure made of hard aluminium profile (38 x 29) Weight: 23 kg Adapter recording: TCS 1B incl. 6 TCS1B safety slip couplings of your choice

Manufacturer DMG Model DMU 160P Year 2002 CNC HEIDENHAIN iTNC-530 Table Dimensions of the Work Table 1,500 x 1,250 mm. Maximum weight allowed on table 4,000 kg. Table Rotation (C-Axis) 0.001º (Continuous) Routes and advances Longitudinal course (X-axis) 1,600 mm. Cross Span (Y-Axis) 1,250 mm Vertical course (Z Axis) 1,000 mm. Horizontal Automatic Swivel Head / Vertical (A-axis) 0.001º (continuous) Fast Axis Feed 60,000 mm/min SK-40 Spindle Cone DIN 69871 Speed range 20-18,000 rpm Main Motor Power 28 kW Equipment Automatic tool loader INCLUDED Positions in tool loader 60 Coolant tank capacity 200 l. HEIDENHAIN optical rulers INCLUDED Chip conveyor INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel 3D-Rot INCLUDED Measuring probe piece HEIDENHAIN TS-631 M function for coolant Internal/external INCLUDED Prepared for internal cooling INCLUDED Mode 4 op ...

Manufacturer HERMLE Model C40 U Dynamic Year 2006 CNC control HEIDENHAIN iTNC 530 Table Table surface Ø 800 mm. Tilting rotary table INCLUDED Maximum weight on table 1400 kg Table rotation (C-axis) 0.001º (±360º) Oscillation field (B-axis) +25 / -110 º Direct Measurement System INCLUDED Maximum part diameter 840 mm. Routes and advances Strokes (X/Y/Z) 850/700/500 mm X, Y, Z axis fast feed 60,000 mm/min Head Head speed 18,000 r.p.m. SK 40 Head Cone DIN 69871 Main motor power 15 W Main torque 130 Nm Equipment Automatic tool loader INCLUDED No. of positions in tool loader 38 Internal cooling 80 Bar INCLUDED Tank with paper filter 200 l. INCLUDED Active cooling control cabinet INCLUDED Infrared measurement probe part M&H INCLUDED Blum Laser Probe Measurement Tool INCLUDED Chip evacuator INCLUDED Cleaning gun with pump 2 bar 40 l/min INCLUDED 3D Quick ...

FEATURES: • Longitudinal travel 1020 mm • Cross travel Y 510 mm • Vertical travel Z 575 mm • SIEMENS CNC Type • Table length 1200 mm • Table width 500 mm • Max. Authorized weight 800 kg • Number of tools 30 • ISO 40 spindle taper • Max spindle speed 8000 rpm • Spindle motor power 15 kW • Length x width x height 3275 × 2948 × 2996 • Weight 7500 kg

Manufacturer KONDIA Model A-6 Year 2015 CNC HEIDENHAIN TNC 530 HSCI Table Table surface 800 x 400 mm. Number of T-Slots 3 T-slots (width, distance) 18.125 mm. Table-floor distance 885 mm. Table distance – spindle nose (min/max) 140 / 650 mm. Maximum weight allowed on table 450 kg. Routes and advances Longitudinal travel (X) 600 mm. Cross travel (Y) 410 mm. Vertical travel (Z) 500 mm. Fast forward X/Y/Z axes 30,000 mm./min. Head Spindle taper ISO 40 DIN 69871 Maximum spindle speed 12,000 rpm Spindle power 10 / 17 kW Autoloader Tools Chain Type Random Change Warehouse Positions 20 Maximum tool width with adjacent free positionsq 135 mm. Maximum tool width without adjacent free positionsq 85 mm. Maximum tool length 250 mm. Maximum tool weight 6 kg Equipment Internal cooling 20 BAR INCLUDED Chip evacuator INCLUDED Water gun cleaning parts INC ...

Manufacturer DMG-MORI Model DMF 260 Year 2011 CNC SIEMENS SINUMERIC 840D Table Table surface 2,900 x 700 mm. Maximum weight on table 2,150 kg. Routes and advances Longitudinal (X-axis) 2,600 mm Transverse (Y-axis) 700 mm Vertical (Z-axis) 700 mm Fast forward of the axes (X,Y,Z) 40 m/min Working progress of the axes (X,Y,Z) 40 m/min Axle acceleration 4 m/s2 Head Revolutions 14,000 mm/min SK 40 Head Cone DIN 69872 Main engine power 18.4 / 14 kW Automatic tool loader No. of Charger Tools 30 Maximum tool length 300 mm Maximum tool weight 6 kg. Maximum tool diameter with adjacent free positions 130 mm Maximum tool diameter without adjacent free positions 80 mm Equipment Refrigeration 40 Bar / 600 l. INCLUDED Longitudinal chip evacuator INCLUDED Coolant cleaning gun INCLUDED Portable steering wheel INCLUDED Direct Measurement System INCLUDED Machine hours  ...

CHEVALIER QP2040-L CNC Machining CenterTechnical SpecificationsManufacturer: Falcon Machine Tools / ChevalierType: QP2040-LMachine Type: Vertical CNC Machining CenterTable Size: 1,200 × 510 mmMaximum Table Load: 600 kgSpindle Speed: 8,000 RPMMachine Weight: 6,000 kg

Mikron HSM 400 is a high-precision, high-speed machining center STEP TEC spindle, type HVC140-SB-10-15/42-3F-HSK-E40Spindle hours: 26897 hManufacturer: Step-Tec AG (Switzerland)Spindle type: HVC140-SB-10-15/42-3F-HSK-E40Tool interface: HSK-E40Maximum spindle speed: 42,000 rpmPower: 13 kW (40% duty cycle), 10 kW (100% duty cycle)Torque: 4.25 Nm (40% duty cycle), 3.2 Nm (100% duty cycle)Lubrication: oil-air lubrication systemAxis Drives and DynamicsDrive system: AC servo motors with ball screw drivesFeed rate (X/Y/Z): 0 – 40 m/minAcceleration (X/Y/Z): 1 g (10 m/s²)Rotary Axis PerformanceB-axis speed: up to 54,000 °/minC-axis speed: up to 90,000 °/minTool SystemTool interface: HSK-E40Tool magazine capacities: 18 / 36 / 68 tools depending on configurationTool change time: approx. 10 secondsChip-to-chip time: approx. 12.5 secondsPallet and Clamping SystemErowa UPC pallet system: 320 ×  ...

Introducing the CNC Machining Center with FANUC Control System, designed for precision and efficiency in industrial applications. This machine features an extensive axis travel of 1700 mm (X-axis), 750 mm (Y-axis), and 700 mm (Z-axis), accommodating a wide variety of machining tasks. The robust spindle operates at 12,000 rpm, ensuring high-speed performance with a BT50 tool holder and a 24-slot tool magazine for versatility and reduced downtime. The large worktable supports complex operations, and the included 4th axis enhances multi-dimensional machining capabilities. This equipment is maintained in excellent condition, ready to meet the demands of modern manufacturing environments. Available now for immediate shipping to enhance your production facility.

Manufacturer DMG Model DMC 100U duoBlock® Year 2007 CNC control HEIDENHAIN iTNC 530 Routes and advances Strokes (X/Y/Z) 1,000/1,000/1,000 mm. Fast forward axes (X/Y/Z) 60,000 mm./min. Max. working advance axes (X/Y/Z) 10,000 mm./min. NC rotary table Pallet changer for 2 pallets INCLUDED 2 Pallets INCLUDED Quick change system INCLUDED Pallet dimensions 1,000x800mm Maximum weight on pallet changer 1500 kg Table rotation (C-axis) 0.001º (Continuous) Table rotation speed 10.3 r.p.m. Head Horizontal Automatic Swivel Head / Vertical (A-axis) 0.001º (continuous) Head Cone HSK 63 Main Motor Power 26.9 kW Engine revolutions 24,000 rpm Automatic Tool Loader Type Loader Tools Horizontal Chain Tool warehouse positions. 120 Additional equipment Internal Cooling 80 Bar INCLUDED Compact cooling system INCLUDED Coolant tank with paper filer INCLUDED Chip Evacuator IN ...

Specification: Column

Manufacturer QUASER Model MV204IIU / 10 Year 12/2002 CNC HEIDENHAIN ITNC530 3 work tables / pallets Table 1 Size Ø280 mm. Table 2 Size Ø 500 mm. Table 3 Size 600×400 mm. Weight allowed on table 265 kg Min-max distance on table 150-760 mm. Axles Travels (X/Y/Z) 700/590/480 mm Tilting head movement range (A-axis) ±110º Axis Positioning A 0.001º Table Rotation (C-Axis) 360º C-Axis Positioning 0.001º Fast Forward Axles (X/Y/Z) 32,000 mm/min Maximum Working Advance (X/Y/Z) 15,000 mm./min. Head Head Speed 10,000 r.p.m. BT-40 Head Cone Main engine power 15/33 kW Par 192/189 Nm. Charger Tools No. of Positions in Tool Loader 32 RANDOM tool change system Maximum tool length 280 mm. Maximum tool weight 7 kg Other Equipment Chip Evacuator INCLUDED Internal cooling 20 bar INCLUDED Coolant tank capacity 280 l. Refrigeration electrical cabinet INCLUDED Clea ...

Manufacturer DMG Model DMU 50 eVo linear Year 2008 3D CNC control HEIDENHAIN iTNC 530 Table NC Rotary Table INCLUDED Table surface 500×380 mm. Maximum weight on table 500 kg Table rotation (C-axis) 0.001º (±360º) Oscillation field (B-axis) 108º Direct Measurement System INCLUDED Routes and advances Longitudinal travel (X-axis) 500 mm Cross travel (Y-axis) 450 mm Vertical travel (Z-axis): 400 mm X-axis fast feed 80,000 mm/min Fast forward Y-axis, Z 50,000 mm/min Fast forward B, C axes 18,000 mm/min Number of Controlled Axles 5 Head Head speed 18,000 r.p.m. BT-40 Head Cone Main Motor Power 30 kW Equipment Automatic tool loader INCLUDED No. of positions in tool loader 30 Internal cooling 40 Bar INCLUDED Coolant tank with paper filter INCLUDED Chip Evacuator INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel Others Total installed power 52 kVA Machin ...
