boring mills and machining centers used for sale (3,202)

CONTROLS  CNC controls WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 1040 mm  Y-axis travel: 510 mm  Z-axis travel: 640 mmTABLE  table surface (left-right): 1460 mmSPINDLE / HEAD  spindle revolutions (max): 7000 /minTOOL MAGAZINE  number of positions: 24 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 Hz

CONTROLS  CNC controls HELLER UNI-PRO CNC 90 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 1250 mm  Y-axis travel: 1000 mm  Z-axis travel: 1250 mmTABLE  table surface (left-right): 1000 mm  table surface (front-back): 800 mmSPINDLE / HEAD  tool fixture: ISO SK 50 AUTOMATIC WORKLOAD EQUIPMENT  store type: pallet changer   number of store positions: 2 DIMENSIONS / WEIGHTS  total weight approx.: 26500 kgATTACHMENTS  European CE standards: yes Machine in very good condition. DismantledStill available for sale:HELLER MCP-H 250 HS 1997DECKEL MAHO FP5-80 1994HELLER MCP-H 200 1998

CONTROLS  CNC continuous-path control 3D MILLPLUS IT V600 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 500 mm  Y-axis travel: 450 mm  Z-axis travel: 400 mmTABLE  table surface (left-right): 700 mm  table surface (front-back): 500 mm  workpiece load (max): 500 kgSPINDLE / HEAD  spindle revolutions (min): 20 /min  spindle revolutions (max): 10000 /min  tool fixture: ISO SK 40   drive power: 13 kWAXIS DRIVES  traverse velocity X (max): 24000 mm/min  traverse velocity Y (max): 24000 mm/min  traverse velocity Z (max): 24000 mm/minTOOL MAGAZINE  number of positions: 30   tool diameter max.: 80 mm  - with free neighbour positions: 130 mm  tool length max.: 300 mm  tool weight max.: 6 kg  tool changing time: 8 sATTACHMENTS  European CE standards: yes No cooling system; the machine is connected to a central c ...

CONTROLS  CNC controls SIEMENS SOLUTION LINE WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 600 mm  Y-axis travel: 560 mm  Z-axis travel: 510 mmTABLE  table surface (left-right): 900 mm  table surface (front-back): 560 mm  workpiece load (max): 600 kgSPINDLE / HEAD  spindle revolutions (min): 20 /min  spindle revolutions (max): 12000 /min  tool fixture: ISO SK 40   drive power S6 40%: 13 kW  drive power S1 100%: 9 kW  spindle torque S6 40%: 82 Nm  spindle torque S1 100%: 54 NmAXIS DRIVES  traverse velocity X (max): 20000 mm/min  traverse velocity Y (max): 20000 mm/min  traverse velocity Z (max): 20000 mm/min  rapid traverse X: 30000 mm/min  rapid traverse Y: 30000 mm/min  rapid traverse Z: 30000 mm/minTOOL MAGAZINE  number of positions: 30   tool diameter max.: 80 mm  - with free neighbour position ...

CONTROLS  CNC controls HELLER UNI-PRO CNC 90 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 800 mm  Y-axis travel: 800 mm  Z-axis travel: 710 mmTABLE  table surface (left-right): 630 mm  table surface (front-back): 500 mmSPINDLE / HEAD  spindle revolutions (max): 12000 /minAUTOMATIC WORKLOAD EQUIPMENT  store type: pallet changer   number of store positions: 2 ATTACHMENTS  chip conveyor: yes   European CE standards: yes Machine in production, under powerStill available for sale:HELLER MCS-H 400 2001DECKEL MAHO FP5-80 1994HELLER MCP-H 200 1998

CONTROLS  CNC controls GRUNDIG DIALOG 12 WORKING RANGE -CUBIC-  X-axis travel: 800 mm  Y-axis travel: 550 mm  Z-axis travel: 500 mmSPINDLE / HEAD  spindle revolutions (max): 5000 /min  tool fixture: ISO SK 40 DIMENSIONS / WEIGHTS  total weight approx.: 4500 kgThe machine needs a new control card (price €2,000).

CONTROLS  CNC controls HEIDENHAIN ITNC 530 BASIC DESIGN  basic design: moving column WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 3000 mm  Y-axis travel: 1000 mm  Z-axis travel: 1100 mmTABLE  table surface (left-right): 3000 mm  table surface (front-back): 1035 mmSPINDLE / HEAD  tool fixture: HSK A63 TOOL MAGAZINE  tool manipulator: change gripper ELECTRICAL SPECIFICATIONS  mains power supply: 60 kVA  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 14000 mm  space requirements -front/back-: 3760 mm  total height: 3770 mm  total weight approx.: 24000 kgATTACHMENTS  tool breakage detector: yes   zero-point workholding system: yes   chip conveyor: yes   band filtration unit: yes   closed cabin: yes   European CE standards: yes

CONTROLS  CNC controls FANUC 310 IS WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 600 mm  Y-axis travel: 410 mm  Z-axis travel: 460 mm  rotating range A-axis from: -30 °  rotating range A-axis up to: 120 °TABLE  clamping surface diameter: 350 mmSPINDLE / HEAD  spindle revolutions (max): 12000 /min  drive power: 18 kWAXIS DRIVES  rapid traverse: 4800 mm/minTOOL MAGAZINE  number of positions: 30 DIMENSIONS / WEIGHTS  space requirements -left/right-: 3000 mm  space requirements -front/back-: 2400 mm  total height: 1980 mm  total weight approx.: 7500 kgOperating hours: 35`000hInklusieve: Vices see picture

CONTROLS  CNC controls FANUC 18 MB WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   .. among of them simultaneous CNC axes: 3   X-axis travel: 900 mm  Y-axis travel: 800 mm  Z-axis travel: 980 mm  rotating range B-axis from: 0 °  rotating range B-axis up to: 360 °TABLE  table surface (left-right): 630 mm  table surface (front-back): 630 mm  workpiece load (max): 1200 kgSPINDLE / HEAD  spindle type: horizontal   spindle revolutions (max): 10000 /minAXIS DRIVES  rapid traverse: 50000 mm/minTOOL MAGAZINE  number of positions: 140 AUTOMATIC WORKLOAD EQUIPMENT  store type: table changer   number of store positions: 2 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 19000 kgATTACHMENTS  chip conveyor: yes   coolant unit: yes   band filtration unit: yes   ...

CONTROLS  CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 1300 mm  Y-axis travel: 1200 mm  Z-axis travel: 1100 mmTABLE  table surface (left-right): 800 mm  table surface (front-back): 800 mm  workpiece load (max): 2000 kgSPINDLE / HEAD  spindle revolutions (max): 0 /min  spindle revolutions (max): 6000 /min  tool fixture: ISO BT 50 AXIS DRIVES  rapid traverse: 42000 mm/minTOOL MAGAZINE  number of positions: 60 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 7400 mm  space requirements -front/back-: 4300 mm  total height: 3750 mm  total weight approx.: 23500 kgATTACHMENTS  chip conveyor: yes   coolant unit: yes   band filtration unit: yes   through spindle coolant attachment: yes   closed cab ...

CONTROLS  CNC controls SIEMENS 840 D WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   .. among of them simultaneous CNC axes: 3   X-axis travel: 1000 mm  Y-axis travel: 800 mm  Z-axis travel: 1100 mmSPINDLE / HEAD  tool fixture: HSK E100 AUTOMATIC WORKLOAD EQUIPMENT  number of store positions: 4 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 6800 mm  space requirements -front/back-: 3000 mm  total height: 3200 mm  total weight approx.: 20000 kg

CONTROLS  CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 600 mm  Y-axis travel: 450 mm  Z-axis travel: 450 mm  rotating range B-axis from: -115 °  rotating range B-axis up to: 30 °  rotating range C-axis from: 0 °  rotating range C-axis up to: 360 °TABLE  clamping surface diameter: 450 mm  workpiece load (max): 200 kgSPINDLE / HEAD  spindle revolutions (max): 20000 /minAXIS DRIVES  rapid traverse X: 22000 mm/minTOOL MAGAZINE  number of positions: 220 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 4400 mm  space requirements -front/back-: 3400 mm  total height: 2700 mm  total weight approx.: 8000 kgATTACHMENTS  digital display: yes   chip conveyor: yes   coolant unit: yes   band filtra ...

The REIDEN RX14 Machining Center, constructed in 2014 and installed in 2015, offers advanced manufacturing capabilities with the HEIDENHAIN TNC640 CNC controller. It features extensive axis travel (X: 1,800 mm, Y: 1,800 mm, Z: 1,210 mm, A: -15° to +105°) and a rapid traverse of 40 m/min. The spindle delivers 15,000 rpm with a power of 63/73 kW for efficient processing. The worktable, measuring ø1,400 x 1,200 mm, supports up to 5,000 kg. Equipped with a 92-slot HSK-A100 tool magazine, it includes numerous enhancements like an electronic handwheel, chip conveyor, and collision monitoring. A precise, reliable machine for demanding applications.

CONTROLS  CNC controls SIEMENS 840 D SL WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 210 mm  Y-axis travel: 270 mm  Z-axis travel: 360 mmSPINDLE / HEAD  spindle revolutions (max): 40000 /min  tool fixture: HSK A40 TOOL MAGAZINE  number of positions: 64 AUTOMATIC WORKLOAD EQUIPMENT  workpiece manipulator: articulated robot   number of store positions: 32 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 9000 kgATTACHMENTS  chip conveyor: yes   coolant unit: yes   band filtration unit: yes   closed cabin: yes Operating hours: Spindle 1: 4050 h, Spindle 2: 11,114 hInternal cooling 70 barFanuc Automation Robot M-10IAIntegrated workpiece changing deviceKnoll coolant tank Knol KF 400/900

CONTROLS  CNC controls SIEMENS 840D SL 4.8 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 210 mm  Y-axis travel: 270 mm  Z-axis travel: 360 mmSPINDLE / HEAD  spindle revolutions (max): 40000 /min  tool fixture: HSK A40 TOOL MAGAZINE  number of positions: 72 AUTOMATIC WORKLOAD EQUIPMENT  workpiece manipulator: articulated robot   number of store positions: 36 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 8500 mm  space requirements -front/back-: 2500 mm  total weight approx.: 6000 kgATTACHMENTS  central lubrication system: yes   chip conveyor: yes   coolant unit: yes   through spindle coolant attachment: yes   European CE standards: yes -Siemens tool management with retooling-Fanuc Automation Robot M-10IA-Operating hours: 7,200  ...

CONTROLS  CNC controls ROEDERS WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   .. among of them simultaneous CNC axes: 3   X-axis travel: 500 mm  Y-axis travel: 450 mm  Z-axis travel: 300 mmSPINDLE / HEAD  spindle revolutions (max): 42000 /min  tool fixture: HSK A40 TOOL MAGAZINE  number of positions: 40 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 3500 mm  space requirements -front/back-: 3000 mm  total height: 2750 mm  total weight approx.: 9500 kgATTACHMENTS  zero-point workholding system: yes   central lubrication system: yes   closed cabin: yes   European CE standards: yes Equipment:- Renishauw OMP400- Megatool base clamping plate- Control update 2022Special features:- Hydrostatic X, Y & Z axes- Coordinate grinding package- Kraft&Bauer CO2 ...

CONTROLS  CNC controls HEIDENHAIN MILL PLUS WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 5   X-axis travel: 500 mm  Y-axis travel: 420 mm  Z-axis travel: 380 mmSPINDLE / HEAD  spindle revolutions (max): 18000 /min  tool fixture: HSK A63 AXIS DRIVES  feed velocity (max): 20000 mm/min  rapid traverse: 50000 mm/minTOOL MAGAZINE  number of positions: 60 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 2500 mm  space requirements -front/back-: 2600 mm  total height: 2440 mm  total weight approx.: 6000 kgATTACHMENTS  zero-point workholding system: yes   chip conveyor: yes   coolant unit: yes   band filtration unit: yes   through spindle coolant attachment: yes   closed cabin: yes   European CE standards: yes Total spindle hours: 38800 hours.machin ...

CONTROLS  CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 750 mm  Y-axis travel: 500 mm  Z-axis travel: 600 mmTABLE  table surface (left-right): 1000 mmSPINDLE / HEAD  spindle revolutions (max): 10000 /min  tool fixture: ISO SK 40 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 6000 mm  space requirements -front/back-: 4500 mm  total height: 2800 mm  total weight approx.: 8000 kgPendulum machining unit2 x 750 mmMachine in very good and well-maintained conditionOnly used for machining aluminum or plasticFeatures:- Various tool holders- 3R clamping system on each side (see photo)- Work area light

CONTROLS  CNC controls SIEMENS 840 D WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 4   X-axis travel: 550 mm  Y-axis travel: 320 mm  Z-axis travel: 360 mmTABLE  table surface (left-right): 820 mm  workpiece load (max): 500 kgSPINDLE / HEAD  spindle revolutions (max): 24000 /min  tool fixture: HSK A50 AXIS DRIVES  rapid traverse: 75000 mm/minTOOL MAGAZINE  number of positions: 24 AUTOMATIC WORKLOAD EQUIPMENT  workpiece manipulator: articulated robot   store type: table changer   number of store positions: 2 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 7700 kgATTACHMENTS  guideway covers: yes   central lubrication system: yes   chip conveyor: yes   coolant unit: yes   closed cabin: yes   European CE standards: yes - Shuttle table machine- Knoll (KSS)  ...

Pensulum holder for ER25 collets

WORKING RANGE -CUBIC-  X-axis travel: 1270 mm  Y-axis travel: 660 mm  Z-axis travel: 635 mmSPINDLE / HEAD  spindle revolutions (max): 7500 /minBASIC FUNCTIONS  number of spindles: 1   number of turrets: 0   live positions: yes   number of c-axes: 0   number of y-axes: 1   number of b-axes: 0 ATTACHMENTS  chip conveyor: yes WORKING RANGE TURNING  swing diameter (max): 635 mm  worpiece length max.: 1372 mm  workpiece weight max.: 1814 kgMAIN SPINDLE  spindle revolutions (min): 0.001 /min  spindle revolutions (max): 7500 /minX/Z SLIDE  Z-axis travel: 635 mm  X-axis travel: 1270 mm  Y-axis travel: 660 mmTOOL MAGAZINE  tool diameter max.: 178 mm  tool length max.: 406 mm  tool weight max.: 13.6 kg

CONTROLS  CNC controls HEIDENHAIN TNC 426 WORKING RANGE -CUBIC-  number of processing axes (excl parallel axes): 3   X-axis travel: 500 mm  Y-axis travel: 350 mm  Z-axis travel: 610 mmTABLE  table surface (left-right): 920 mm  table surface (front-back): 380 mmSPINDLE / HEAD  spindle revolutions (min): 50 /min  spindle revolutions (max): 18000 /min  tool fixture: ISO SK 30 TOOL MAGAZINE  number of positions: 24 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 2000 mm  space requirements -front/back-: 1700 mm  total height: 3000 mm  total weight approx.: 3200 kgATTACHMENTS  chip conveyor: no   coolant unit: yes   through spindle coolant attachment: no   closed cabin: yes   European CE standards: yes Machine in TOP condition- Power ON :    about 37000 h- Spindle hour ...
