Machining Center - Univ. MATEC 30 HV

CONTROLS
  CNC controls HEIDENHAIN ITNC 530

BASIC DESIGN
  basic design: moving column

WORKING RANGE -CUBIC-
  number of processing axes (excl parallel axes): 5
  X-axis travel: 3000 mm
  Y-axis travel: 1000 mm
  Z-axis travel: 1100 mm

TABLE
  table surface (left-right): 3000 mm
  table surface (front-back): 1035 mm

SPINDLE / HEAD
  tool fixture: HSK A63

TOOL MAGAZINE
  tool manipulator: change gripper

ELECTRICAL SPECIFICATIONS
  mains power supply: 60 kVA
  mains voltage: 400 V
  mains frequency: 50 Hz

DIMENSIONS / WEIGHTS
  space requirements -left/right-: 14000 mm
  space requirements -front/back-: 3760 mm
  total height: 3770 mm
  total weight approx.: 24000 kg

ATTACHMENTS
  tool breakage detector: yes
  zero-point workholding system: yes
  chip conveyor: yes
  band filtration unit: yes
  closed cabin: yes
  European CE standards: yes



seller offer No. resale 57593
