boring mills and machining centers used for sale (3,016)

Control system Heidenhain TNC 415 Spindle diameter 130 mm Tapered hollow spindle ISO 50 Spindle speed range 10 to 1500 rpm Table transverse (X): 3500 mm Rolling headstock stand for (Y): 2000 mm Longitudinal displacement rack (W): 1250 mm Eject working spindle (Z): 800 mm Table load 12 000 kg Machine weight: 36 000 kg

BKOZ 900x1400 spindle taper MK IV sleeve stroke 250mm table size 900x1400mm longitudinal 1000mm cross 750mm vertical movement by the head of main spindle 600mm spindle speeds 28-1400 Upm spindle feeds 0,02-0,8mm/U scales wreaths for all directions of motion hydr. clamping system coolant system sep. control cabinet Motor: 230/380V 50HZ 8KW dimensions base: 3.300 x 2.400mm height: 2.500mm weight: 7.500 kg

MIKROMAT Model / type:BKoE 630x1000 Technical data: > Mikromat BKoE 630 x 1000 > table clamping surface 1000 x 630 mm > longitudinal travel of the table 710 mm > cross travel of the table 700 mm > travel of headstock 630 mm > spindle stroke 200 mm > distance between spindle nose and table 20-850 mm

VR 4A/1250 Producer Mas Max. drilling diameter 50 mm Max. vertical arm adjustment 750 mm Taper in spindle 4 Morse Main motor output 4 kW Dimensions l x w x h 2250x1055x2970 mm Machine weight 2700 kg

SW BA W06-22Year of manuf. : 2020 Control : Siemens 840 Dsl Speed : 17500 rpmMovement X/Y/Z : 600/630/510 mmTool holder : HSK 63 ____________Description:In General:Year of manufacture:2020Control system:Siemens 840 DslTravel range X/Y/Z:600/630/510Spindle centre distance:600 mmRapid traverse X/Y/Z:120 m/minSpindles (2 pieces):Technology:Motorised spindlesSpeed:17,500 rpmPower:35 NmTorque:80 NmTool holder:HSK 63Swivel mount:Technology:A-axis or U-axis with counter bearingDrive:Direct drive (torque motors)Clamping bridge:Technology:Clamping bridges, each with 2 NC rotary tablesDrive:Direct drive (torque motors)Table diameter:Ø 340 mmMax. table load:2 x 90 kgMax. fixture dimensions:2x Ø 600 x 400 mmTool magazin:Technology:Chain magazineTool changer:Pick-upNumber of stations:2 x 72Max. tool diameter:80 mmMax. tool length:425 mmEquipment:Position measurement systems:Direct on all axes ...

SW BA W06-22Year of manuf. : 2020 Control : Siemens 840 Dsl Speed : 17500 rpmMovement X/Y/Z : 600/630/510 mmTool holder : HSK 63 ____________Description:In General:Year of manufacture:2020Control system:Siemens 840 DslTravel range X/Y/Z:600/630/510Spindle centre distance:600 mmRapid traverse X/Y/Z:120 m/minSpindles (2 pieces):Technology:Motorised spindlesSpeed:17,500 rpmPower:35 NmTorque:80 NmTool holder:HSK 63Swivel mount:Technology:A-axis or U-axis with counter bearingDrive:Direct drive (torque motors)Clamping bridge:Technology:Clamping bridges, each with 2 NC rotary tablesDrive:Direct drive (torque motors)Table diameter:Ø 340 mmMax. table load:2 x 90 kgMax. fixture dimensions:2x Ø 600 x 400 mmTool magazin:Technology:Chain magazineTool changer:Pick-upNumber of stations:2 x 72Max. tool diameter:80 mmMax. tool length:425 mmEquipment:Position measurement systems:Direct on all axes ...

Year of construction: 2004 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 630 Y-axis travel mm: 500 Z-axis travel mm: 500 Worktable Table dimensions mm: 800x500 Max. workpiece weight kg: 500 Spindle Spindle speed rpm: 10000 Spindle drive power kW: 9/13 (40/100%ED) Cooling Cooling through the Spindle Center bar: 15 Tank capacity: 750 Tool system Tool holder: SK 40 Tool magazine slots: 24 Equipment Electronic Handwheel Chip conveyor Internal cooling lubricant supply Operating mode 4 blowing air through spindle center selectable via M-function Measuring probe Machine running times Under power: 34476 Spindle Working: 8909 Rated power kVA: 32 Basic machine dimensions / weight Length mm: 2800 Width mm: 2700 Height mm: 2700 Weight kg: 4500

Travel X/Y/Z: 560mm/410mm/460mm, Tool positions: 30, Tool interface: CAT40/BT40, Spindle speed: 8000rpm, Spindle power: 10HP, Spindle diameter: 70mm, Rapid traverse: 30m/min, Table dimensions X/Y: 605mm/380mm, Max. table load: 250kg, Number of pallets: 2. Machine dimensions X/Y: approx. 3050mm/2900mm, Weight: approx. 5000kg, Control: Fanuc. Documentation available. An on-site inspection is possible.

bore capacity in steel (diameter):55 mmarm length:1600 mmtotal power requirement:4 kWweight of the machine ca.:5,5 tdimensions of the machine ca.:2800 x 980 x 3000 mm

arm length:1600 mmweight of the machine ca.:5,5 tdimensions of the machine ca.:2800 x 980 x 3000 mm

Year of Manufacture: 2015Machine No.: 12300000163Control SystemHeidenhain iTNC 530 HSCI (3D path control)Travel PathsX: 2,700 mmY: 2,700 mmZ: 1,600 mmB-axis: controlled universal swivel milling headC-axis: NC rotary table Ø 2,200 mm5-axis simultaneous machiningSpindleMotor spindle SK50Speed: 20–12,000 min⁻¹Power: 44 kW (40% duty cycle) / 32 kW (100% duty cycle)Tool holder: SK50 according to DIN 69871Tool Changer63-slot wheel magazineDouble gripperEquipmentIKZ 40 barChip conveyorElectronic handwheelRotating viewing windowMinimum quantity lubrication (MQL)Coolant through spindleCoolant tank 980 lMold making packageActive chatter suppression (ACC)Adaptive feed control (AFC)Oil/emulsion mist separatorSmartkey packageAdditional safety viewing windows (Visiport)Operating mode 4 (process observation)

Machine No.: 11720001123ControlHeidenhain iTNC 530 HSCI (3D path control)Travel PathsX: 1,850 mmY: 2,100 mmZ: 1,250 mmB-axis: controlled universal swivel milling headC-axis: NC rotary table Ø 1,700 mm5-axis simultaneous machiningSpindleMotor spindle SK50Speed: 20–12,000 min⁻¹Power: 44 kW (40% duty cycle) / 32 kW (100% duty cycle)Torque: 288 / 187 NmTool holder: SK50 according to DIN 69871Tool Changer60-fold chain magazineDouble gripperEquipmentIKZ 40 barChip conveyorTool measurement system Blum Laser NT HybridHeidenhain TS 640 infrared probeElectronic handwheelMinimum quantity lubrication (MQL)Oil/emulsion mist separatorCoolant through spindleCoolant tank 980 lRotating viewing window3D quickSETMachine Protection Control (MPC)Adaptive Feed Control (AFC)ATC (Application Tuning Cycle)DMG MORI NetServiceDMG MORI SMARTkeyDocumentation and electrical schematic (German)

Technical data (XYZ): X 980 mm / Y 630 mm / Z 630 mm Control: HEIDENHAIN iTNC 530 Miscellaneous: 32-tool changer, 24,000 rpm, HSK63/BT40/CAT40, rotary table, swivel head, internal coolant supply, chip conveyor.

Year of construction: 2015 CNC controller: Heidenhain TNC 640 Axes X-axis travel mm: 850 Y-axis travel mm: 520 Z-axis travel mm: 475 Feed rates m/min: 42 Rapid traverse m/min: 42 Acceleration in the axes m/s2: 5 Worktable Table dimensions mm: 1100x570 Maximum workpiece size (D x H) mm: H=800mm Max. workpiece weight kg: 1000 Spindle Spindle speed rpm: 14000 Spindle drive power kW: 20,3/14,5 (40/100%ED) Cooling Cooling through the Spindle Center bar: 20 Tank capacity: 600 Tool system Tool holder: SK 40 Tool magazine slots: 20 With free neighboring places mm: 130 With occupied neighboring places mm: 80 Max. Tool Length mm: 300 Chip-to-chip time s: 5.7 Equipment Electronic Handwheel Chip conveyor Infrared probe Internal cooling lubricant supply Rinsing gun Operating mode 4 blowing air through spindle center selectable via M-function Direct m ...

ALZMETALL AB4/SV Column Drilling Machine For sale is a used ALZMETALL pillar drilling machine type AB4/SV from 1995. The machine is suitable for professional drilling work in the workshop, production, metal processing, maintenance and mechanical engineering. Thanks to its robust design, it is also suitable for regular industrial use. Product data Manufacturer: ALZMETALL Model No.: AB4/SV Product Type: Column Drilling Machine/Column Drilling Machine Year of Make: 1995 Spindle holder: MK4 Operating voltage: 400 V Rated current: 10 A Fuse: 16 A gG Version: stationary stand-alone machine Condition: used The ALZMETALL AB4/SV is suitable for drilling, countersinking, reaming and similar machining work, among other things. Thanks to its solid design, the machine offers a stable basis for precise work on different workpieces. Signs of wear and tear due to age and use are  ...

Danube DR 32 High Speed Radial Drilling Machine High-precision and robust high-speed radial drilling machine, which is appreciated for its reliability in mechanical engineering and industrial production. Thanks to its swivelling boom, it allows the drill head to be positioned quickly and flexibly above the workpiece. Technical data Drilling capacity: Maximum 32 mm in steel. Tool holder: MK 4 (Morse taper). Speed range: Approx. 41 to 1,800 rpm Quill stroke: 190 mm to 200 mm. Projection: Flexibly adjustable from approx. 240 mm to 850 mm Table size: 1,200 x 600 mm Typical functions Tapping device: Integrated automatic for cutting threads (e.g. up to M26 in steel). Feeds: Automatic quill feed in several stages Coolant device: Integrated pump and coolant trough directly on the work table. "Everything from a single source: We will be happy to offer you suitable bank f ...

Danube DR 40 Z High Radial Drilling Machine The Donau DR 40 Z is a powerful, conventional high-speed radial drilling machine for trade and industry. It is characterized by its high flexibility and the swivel and extendable boom, which allows workpieces to be machined quickly and precisely. Technical data Drilling capacity: Up to 40 mm in steel and 50 mm in cast iron. Threading: Maximum M 33 in steel and M 45 in cast iron. Tool holder: MK 4 (Morse code 4). Spindle stroke: 200 mm. Projection: Variable from 320 mm to 1140 mm. Workpiece height: Maximum approx. 700 mm. Table size: 1200 x 750 mm. Speed range: 45 to 2240 rpm Feed rate: 0.075 to 0.6 m/min. Drive power: approx. 6 kW. Weight: Approx. 1.8 to 2.0 tons "Everything from a single source: We will be happy to offer you suitable bank financing for your project." komplett-konzept.leasingo.de More items - new an ...

Danube Danuflex-128 High Speed Radial Drilling Machine Manual high-speed radial drilling machine from the well-known German manufacturer DONAU Werkzeugmaschinen. This machine class is characterized by an extremely flexible, smooth-running swivel system and is used primarily in toolmaking, fixture construction and in individual and small series production. Technical data Tool holder: MK4 (Morse taper 4) Clamping table: 500 x 1055 mm Maximum projection: 1120 mm Spindle stroke: 160 mm Column diameter: Ø 150 mm Speed range: 45 – 2240 rpm (electrically switchable in steps) Feed range: 0.075 – 0.3 mm/rev Motor power: 1.5 / 2.2 kW Total weight: approx. 1,800 kg Additional equipment: Integrated threading device "Everything from a single source: We will be happy to offer you suitable bank financing for your project." komplett-konzept.leasingo.de More items - new an ...

Csepel RF50/1250 Radial Drilling Machine Robust and proven radial drilling machine of the quality manufacturer "Csepel" model RF50/1250. The machine is characterized by its solid construction and is ideal for locksmiths, workshops or demanding do-it-yourselfers. Technical data (according to nameplate): Manufacturer: Csepel (Budapest) Type: RF50/1250 Type of current: 3~ (three-phase current / 380 V) Frequency: 50 Hz Control voltage: 220 V Operating current: 10 A Required fuse: 16 A slow blow More items - new and used - can be found in our shop! International shipping costs on request!

Alzmetall AC 32 Turret Double Head In-Line Drilling Machine Extremely robust and rare double-head in-line drilling machine based on two Alzmetall AC 32 drill tops. This system is a high-quality industrial design designed for highly efficient series or step machining. Instead of simple spindles, this machine is equipped with two separate tool turrets. This enables fully automatic machining cycles (e.g. centering, drilling, countersinking, threading) without the need to manually retool tools. Technical data & equipment (per capita / total system): Manufacturer of drill tops: Alzmetall (Germany) Model: AC 32 (electronically controlled with digital display) Drilling capacity: max. 32 mm in steel Threading capacity: max. M 24 / M 30 Tool changer: 2x swivelling turret heads with several stations Machine table: Solid, ground cast iron table with T-slots for flexible constru ...

Foot switch, safety foot switch, foot pedal -Foot switch: Safety foot switch -Metal housing: with protective cover, die-cast aluminum -Number: 2x foot pedals available -Price: per piece -Dimensions: 270/140/H145 mm -Weight: 1.4 kg

A Deckel Maho CNC vertical machining center is available. Travel X/Y/Z: 1000mm/600mm/600mm, table dimensions X/Y: 1200mm/600mm, max. table load: 800kg, spindle speed: 8000rpm, power: 13kW/9kW, torque: 57Nm/83Nm, feed rate: 30m/min, rapid traverse: 30m/min, tool stations: 24, tool holder: SK40. Machine dimensions X/Y/Z: approx. 3200mm/2600mm/2700mm, weight: approx. 6500kg. Documentation available. An on-site inspection is possible.

x-travel: 650 mmy-travel: 650 mmz-travel: 650 mmControl: Siemens 840 D total power requirement: kWweight of the machine ca.: 12 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1800 mmy-travel: 1000 mmz-travel: 1200 mmControl: Siemens 840 C total power requirement: 20 kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1800 mmy-travel: 1000 mmz-travel: 1200 mmControl: Siemens 840 C total power requirement: 20 kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1800 mmy-travel: 1600 mmz-travel: 1400 mmControl: Siemens 840 C total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Working areaSwing diameter over guide ways680 mmSwing diameter over transverse guideway465 mmTurning diameter465 mmTransverse stroke300 mmLongitudinal stroke1050 mmClamping chuck diameter max.315 mmGeneralUniversal Turning Machines; Control: Siemens 840D SL Main drive 1Type of main driveAC Drive power (100% DC)22 kWDrive power (40% DC)33 kWSpeed range- 3250 rpmTorque (100% DC)420 NmWork spindleSpindle noseFlat flange Diametre of spindle nose220h5 mmSpindle bore102 mmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmFloor space/WeightDimensions (L x W x H)5,3 x 2,41 x 2,18 mWeight approx.7800 Kg3-jaw chuck Ø 250 mm3-jaw power clamping chuck Ø 250 mmClamping with balanced pressure for main spindleClamping with balanced pressure for main spindle (max. bar capacity D 76 mm/D 2,99 in) (option includes hydraulic hollow clamping attachment, VNK 170-77 type (PXP ...

Control Winmax Travel X/Y/Z: 1,067 x 610 x 610 mm Spindle speed 12,000 min-1 Tool magazine for 30 Wkz., SK 40 IKZ Chip conveyor Detachable handwheel

A Hurco CNC vertical machining center is available. Tool holder: SK50, travel X/Y/Z: 1270mm/660mm/610mm, max. table load: 1500kg, spindle speed: 8000rpm, tool stations: 30, rapid traverse: 30m/min. Machine dimensions X/Y/Z: approx. 4600mm/4600mm/3000mm, weight: approx. 9250kg. Documentation available. An on-site inspection is possible.

CNC Machining Center Matec 40 HV Control: Heidenhain iTNC 530 Year of Make: 2008 Internal machine no. 70 Travels: X-axis: 3,000 mm Y-axis: 800 mm Z-axis: 1,100 mm Horizontal Z-axis: 990 mm vertical NC swivel head infinitely variable: +/- 105 degrees Tool magazine: 40-fold Tool holder: SK50 Motor spindle: 8,000 rpm / 68kW Accessories: - Chip conveyors - Partition wall prepared - Electronic handwheel - Internal coolant supply 20 bar (paper belt filter 450 l) - Full work area cladding with roof - Rinsing gun - Oil-central lubrication - Oil mist extraction system - 3D probe with radio (Renishaw RMP60)
