lathes used for sale (3,058)

The positions of the rotating tools are: T01-02-03-04 / T22-23 / T34-35 - equipped with Iemca Boss 332E/32 new in 2006 - lot of collets / guide bushes - MSC-501 Control - the machine has always worked with oil.

Center distance 5,000mm Height of the tips 600mm 105mm bar passage carriage equipped with grinding Machine in very good condition

Center distance 11,000 mm Turning diameter 730 mm Drill height 500 mm turnable on the bench 1050 mm Motor power 22 kW

• Height of centers 750 mm • Distance between centers 5000 mm • Diameter on the bench 1500 mm • Diameter on the carriage 1050 mm • Main engine power 75 Hp • Baruffaldi BA 300 4-position automatic turret • CNC ECS 2400 • Hydraulic chuck • Max. permissible weight between the tips without steady rests kg. 15000 • Max. permissible weight on the platform, cantilevered, with centre of gravity at 300 mm: kg. 3800

:::TECHNICAL SPECIFICATIONS::: CNC Model: Mazatrol Spindle nose: ASA 6 Spindle power: 22Kw Number of main spindle speeds: 5000 Turning Diameter: 540mm Self-centering diameter: 210mm Bar Passage: 51mm Turning length: 1018mm Number of tools: 40 Spindle power: 7.5Kw Number of spindle speeds: 6000 X-axis travel: 530mm Y-axis travel: +- 70mm Z-axis travel: 1065mm Adjustable B-axis travel: 1065° Fast feeds for linear axes X Y Z: 30m/min Tailstock: yes Steerer stroke: 140mm Chip conveyor: belt Presetting: yes :::D DIMENSIONS AND WEIGHT::: Length: 3500mm Width: 2100mm Height: 2500mm Weight: 5700Kg

:::TECHNICAL SPECIFICATIONS::: CNC Model: Mitsubishi Main spindle power: 7Kw Main spindle bar passage: 36mm Headstock Stroke (Z1): 165mm Main spindle speed: 4000 Fixed headstock: yes Number of linear axes: 5 Number of fixed tool slots for tool plate: 5 + 5 Number of live tool slots for tool holder: 4 X1 Axis Travel: 185mm Y1 axis travel: 490mm Fast feeds for linear axes X Y Z: 30m/min Sub-spindle: yes Number of counter-spindle speeds: 4000 Counter spindle power: 3.5Kw Bar Passage: 32mm Counter spindle X stroke : 293mm Z stroke sub-spindle : 295mm Number of motorized rear tools: 4 Refrigerant used: emulsion Model and brand bar loader: Iemca Boss 545 E Chip conveyor: belt :::D DIMENSIONS AND WEIGHT::: Length: 2420mm Width: 1500mm Height: 1935mm Weight: 3800Kg

:::TECHNICAL SPECIFICATIONS::: CNC Model: Siemens CNC Version: 840 D Main spindle power: 11Kw Main spindle bar passage: 38mm Headstock Stroke (Z1): 320mm Number of main spindle speeds: 8000 Number of linear axes: 8 Number of fixed tool slots for tool plate: 5 Number of live tool slots for tool holder: 4 Fast feeds linear axes X Y Z: 32m/min High refrigerant pressure: yes Number-turrets-sled-tool-holders: 1 number-of-tool-places-first-sled-turret-sled: 10 Motorized-first-sled-turret-number: 10 tool-holder-type-first-turret-slide: VDI 30 travel-x-axis-first-turret-slide: 140mm travel-y-axis-first-turret-slide: + - 50mm Sub-spindle: yes Number of counter-spindle revolutions: 8000 Counter spindle power: 11Kw Bar Passage: 38mm Z stroke sub-spindle : 320mm Number of fixed rear tools: 4 Refrigerant used: neat oil Model a ...

Mazak QTN 350M x 1200 Motorized Lathe :::TECHNICAL SPECIFICATIONS::: CNC Model: Mazatrol CNC Version: FUSION 640 T NEXUS Main spindle nose: ASA 8 Main spindle power: 22Kw Main spindle bar passage: 76mm Turning diameter: 420mm Turning length: 1173mm Number of main spindle speeds: 3300 Number of tool turrets: 1 Number of tool positions for the first turret: 12 Number of Motorized First Turret: 12 First turret X-axis travel: 260mm First turret Z-axis travel: 1240mm Presetting: yes :::D DIMENSIONS AND WEIGHT::: Length: 3450mm Width: 2050mm Height: 2000mm Weight: 7500Kg

Tsugami BU20 Swiss-type lathe :::TECHNICAL SPECIFICATIONS::: CNC Model: Fanuc CNC Version: 16i - TB Main spindle power: 3.7Kw Main spindle bar passage: 20mm Headstock Stroke (Z1): 170mm Number of main spindle speeds: 8000 Number of linear axes: 7 Number of fixed tool slots for tool plate: 4 Number of live tool slots for tool plate: 3 Sub-spindle: yes Number of counter-spindle revolutions: 8000 Bar Passage: 20mm Number of fixed rear tools: 6 + 6 Refrigerant used: neat oil Chip conveyor: belt Machine equipment: the machine is supplied without bar loader :::D DIMENSIONS AND WEIGHT::: Length: 2712mm Width: 1401mm Height: 1728mm Weight: 3500Kg

12 position upper turret (6 are driven) -10 positionlower turret (5 are driven) - sub spindle - 2 x C axis - equipped with Lns Sprint S2 bar loader with front magazine, fixed and driven tool holders, manuals - Fanuc 18T Control

Gildemeister GMC20 ONE, Options / Accessories, - 5 Cross-slides pos. 1;2;3;4;5, - 2 Radial slides pos. 6 for cutting and rear-working operations, - 1 C-axis for the pick up spindle, - Pneumatic work-piece unloading chute for pos. 6, - Work-piece conveyor belt, - Swarf conveyor, worm type, - 5x Frontal tool spindle, fix, - Pick- up spindle in pos. 6, - High pressure coolant device 70l / 50bar, Country of origin: Italy, Control: Siemens 840D, Number of spindles: 6, Max bar diameter [mm]: 25, Spindle speed [rpm]: 6.000, Spindle motor [kW]: 9,1, Z - travel [mm]: 70 / 140, Total power requirement [kVA]: 98, Weight of the machine ca. [kg]: 9.800, Auto bar loader: Cucchi Giovanni DBM.625

6 spindle bar automatic Gildemeister GS20, compound slide with drive in pos. 1, compound slide with drive in pos. 2, compound slide in pos. 4, compound slide in pos. 5, 4x axial spindle (pos. 1, 2, 4, 5), rotating milling device in pos. 3, pick-up spindle pos. 6, swing rear machining arm drive in pos. 3, swing rear machining arm drive in pos. 6, swarf coneveyor, worm type, set of tool holders, set of cams, Number of spindles: 6, Max bar diameter [mm]: 20, Max bar feed [mm]: 100, Spindle speed [rpm]: 214 - 5.168, Spindle motor [kW]: 11, Weight of the machine ca. [kg]: 5.000, Auto bar loader: Pietro Cucchi

Number of spindles: 6, Max bar diameter [mm]: 20, Spindle speed [rpm]: 500 - 6.000, Weight of the machine ca. [kg]: 5.000, Auto bar loader: Iemca SIR 25 P 33

NC sliding headstock lathe Star SE 16 FMB Minimag bar loader high pressure coolant pump, Control: Fanuc 21i-TB

Control: Siemens 840D Solution line, Auto bar loader: Top Automazioni XF 375

Gildemeister GM 16-6AC, 4x compound slide - Pos.1; Pos.2; Pos.4; Pos.5, 4x indipenden feed - Pos.1; Pos.2; Pos.4; Pos.5, threading device, 1x threading spindle, pick-up spindle, broaching device, set of cams, set of collets, bar-loader Cucchi Giovanni (YOM 2004), Working hours: 13.600

- spindle drum locking by means of a triad of HIRTH-type rings, - central lubrication system, - spindle stop attachment for main spindles, - cross drill device pos. 4, - 6 indipendent frontal slides, - 4 compound slides in pos. 1, 2, 4, 5, - 2 radial slides in pos. 3, 6, - double slide in pos. 6, - pick-up spindle pos. 6, - pick-up spindle stop attachment pos. 6, - conveyor belt for finished parts, - chip conveyor, hinged belt type, - high pressure coolant system, - removable coolant fluid tank, - bar stock reel for bar length 3 m, - various camms, - various gears, Number of spindles: 6, Max bar diameter [mm]: 32, Spindle speed [rpm]: 250 - 4.250 (250 - 3.350), Spindles interaxis [mm]: 276, Max bar feed [mm]: 125, Weight of the machine ca. [kg]: 9.500

- spindle drum locking by means of a triad of HIRTH-type rings, - central lubrication system, - spindle stop attachment for main spindles, - 2x spindle positioning attachment (pos. 6 + 7), - 8 indipendent frontal slides, - 4 compound slides in pos. 1, 2, 5, 6, - 4 radial slides in pos. 3, 4, 7, 8, - double slide in pos. 8, - 2x pick-up spindle (pos. 4 + 8), - 2x pick-up spindle stop attachment (pos. 4 + 8), - threading attachment, - chip conveyor, hinged belt type, - high pressure coolant system, - removable coolant fluid tank, - bar stock reel for bar length 3 m, - various camms, - various gears, - electrical preparation for auto bar loader, Number of spindles: 8, Max bar diameter [mm]: 32, Spindle speed [rpm]: 270 - 3.750 (270 - 3.200), Spindles interaxis [mm]: 360, Max bar feed [mm]: 125, Weight of the machine ca. [kg]: 11.500

Loader applicable to all types of CNC lathes, with fixed or sliding head. The TS560 series automatic loaders are characterized by a very silent operation and a large capacity bar magazine. They can be connected to automatic and CNC lathes, with fixed and sliding headstock, and to any machine working the bar (transfer, cutting-off machines, presses, etc.) even with special profiles; they are particularly suitable where large quantities are required. The TS 560 P loaders are equipped with a magazine with 4 eclipsable overlapping shelves (max. Capacity 1800 mm.), L max [mm]: 3.300

CNC swiss type lathe Traub TNL 32-7, - Model TNL32/TNL32K, - Controller TX8i-s, - Main spindle max. diameter 32 mm, with C-axis, - Counter spindle including parts discharge, - Top revolver X/Y/Z/H-axis: 10 tools dual drive, - Bottom revolver X/Y/Z/H-axis: 9 tools same drive; counter spindle independent drive, - Conveyor belt for finished parts with gripper, - Coolant pump 3 bar, - Coolant pump 8 bar, - Swarf conveyor, hinged belt type H=1000 mm, - Linear encoder X-axis for revolver top/bottom, - Fabric filtration for coolant: grade of filtration ca. 30-40 µm, - High pressure coolant pump 20 bar, - CO2 fire fight system Kraft & Bauer, - Auto bar loader FMB LSK 38, max. bar length 3,2 m, Machine worked only with cutting oil, Country of origin: Germany, Control: TX8i-s, Operating hours: 55.000 | 36.000, Max bar dia. [mm]: 32, Spindle speed [rpm]: 8.000, Spindle stock stroke [mm]: 305, Weig ...

Gildemeister GM20, Country of origin: Italy, Operating hours: 0, Number of spindles: 6, Max bar diameter [mm]: 20, Auto bar loader: Cucchi Giovanni alternative IMG Easy load

multi spindle bar automatic, Mori Say 8/42 - YOM 2006, CONFIGURATION, - HIRTH coupling for drum locking, - 8 front slides and 8 radial slides, - 4 Compond slides in stations 1, 2, 5, 6, - CUCCHI Pietro bar loader (2007), - Bundle for CUCCHI BLT BUNDLE bar loader (2018), - Pick-up spindle, hydraulic in pos. 8, - preparation for oil fume extraction

- neu aufgebaut, neue Elektrik in 2018, - Schnecken-Späneförderer, - Ölnebelabsaugeinrichtung, - Kühlmittelfilter, selbstreinigend, - Doppelschlitten in Lage 6 zum Abstechen und Rückseitenbearbeitung, - Polygondreh- und Gewindefräseinrichtung Lage 4, - CNC-Kreuzschlitten AUTOR in Lage 5, - Abgreifspindel, hydraulisch in Lage 6, - Transportband für Fertigteile, - Stangenlader Iemca PRA

8-spindle lathe, Number of spindles: 8

Gildemeister G20, 6-Spindel-Portal-Drehautomat, GILDEMEISTER 20, Maschine komplett überholt, Elektrik - neu, PLC – neu, Mechanik - generalüberholt -, Geometrieprotokoll – wie Neumaschine –, CE – Konformitätserklärung, einschl. elektrische Standardausrüstung, Grundausstattung der Maschine:, 1 Tippbetrieb zum Einrichten, 1 automatische Zentralschmiereinrichtung, 1 Kühlmitteleinrichtung einschl. Pumpe und Antrieb, Behältervolumen ca. 650 L, 1 Werkzeugspindelführungsblock, 1 Antriebsgruppe für rotierende Werkzeugspindeln einschl. Gewindeschneidgetriebe für jede Werkzeugspindelposition wahlweise:, - a) Gegenläufig zum Schnellbohren, - b) Synchronlaufend, - c) Zum Gewindeschneiden bzw. Reiben, 2 Planschlitten mit unabhängigen Planvorschub, 4 Kreuzschlitten mit unabhängigem Plan- und, (Längsvorschub als Option) + 1 Maschinen-, leuchte, 1 Paar Wechselräder für Spindeldreh ...

Schütte 32 multi-spindle lathe, completely rebuilt by GWM-Tech, Fanuc AC motors, FANUC motors for threading, PLC, pick-up spindle chuck, bar loader Cucchi Pietro

!bargain price!

Number of spindles: 6, Max bar diameter [mm]: 25, Spindle speed [rpm]: 4.250, Weight of the machine ca. [kg]: 7.150, Auto bar loader: Cucchi BLT Multi F-6

3 slides 3 revolvers with 12 positions each driven main and subspindle 2 C-axis Y axis, workpiece unloading device, high pressure coolant system with paper filter chip conveyor, Control: Fanuc 310i, Country of origin: Italy, Operating hours: 34.000 | 22.900, Number of spindles: 2, Number of linear axis + C axis: 8+2, Max bar diameter [mm]: 65, Spindle speed [rpm]: 5.000, Spindle motor [kW]: 20, Auto bar loader: Iemca Master 880 P/R, Machine weight approx. [kg]: 9.000

Mori Say TM626 AC, 5 axial slides, 4 cross slides, double slide pos. 6, pickup spindle, swarf conveyor with vibrating filter device, high pressure coolant system, set of tool holders, auto bar loader L = 3 m, Country of origin: Czech Republic, Number of spindles: 6, Max bar diameter [mm]: 26, Spindle speed [rpm]: 500 - 6.000, Spindle motor [kW]: 20, Total power requirement [kVA]: 40, Weight of the machine ca. [kg]: 5.500, Auto bar loader: Iemca PRA 52/32 P
