lathes used for sale (3,157)

2008 Spindle module replaced Circumferential diameter over bed 630 mm Circumferential diameter over support 370 mm Spindle through bore 105 mm the machine is delivered with a 250 mm manual chuck. Spindle speed range 1: 4 - 430 rpm. Spindle speed range 2: 430 - 2500 rpm. Main motor power: 18.5kw S6-40%

A precision lathe is offered: distance between centers: 1500mm, center height: 265mm, swing diameter over bed: 530mm, speed range: infinitely variable up to 2000rpm. Machine dimensions X/Y/Z: approx. 2700mm/850mm/1400mm, weight: approx. 2100kg. The brake has a problem. Inspection possible by appointment.

Main spindle: Technology: Motor spindle Speed: 4,000 rpm Power (max.): 29 kW Torque (max.): 250 Nm Bar Passage: 76 mm Sub-spindle: Technology: Motor spindle Speed: 5,000 rpm Power (max.): 29 kW Torque (max.): 250 Nm Ejector: Pneumatic Travel in Z: 800 mm Tool carrier I (X/Y/Z): Technology: 12-station turret Tool holder: VDI30 Tool drive: 5,000 rpm, 6.7 kW, 25 Nm Travel in X/Y/Z: 260/100/800 mm Rapid traverse in X/Y/Z: 30/12/30 m/min Tool carrier II (X/Z): Technology: 12-station turret Tool holder: VDI30 Tool drive: 5,000 rpm, 6.7 kW, 25 Nm Travel in X/Z: 210/800 mm Rapid traverse in X/Z: 30 m/min Equipment/accessories: Chip management: Chip conveyor Coolant management: IKZ system with paper belt filter and high pressure, 40 bar Raw material feed I: Robot interface prepared Raw Material Feed II: Bar Feeder Interface Prepared Finished part removal ...

Key data: 650 mm, 1500 mm

Double Spindle 5-Axis/7-Axis CNC Double Spindle Turning and Milling Center Okuma Multus U3000 1SW 1500 Year of construction 2021 OSP P300SA IGF-D CNC Controller Circumferential diameter over carriage 650 mm Turning diameter max. 1,500 mm Main spindle: Spindle bore 91 mm Spindle drive power 15/22 kW Spindle speeds max. 4,200 rpm. Chuck diameter 250 mm C-axis 0.0001° Sub-spindle: Spindle bore 91 mm Spindle drive power 15/22 kW Spindle speeds max. 4,200 rpm. Chuck diameter 250 mm C-axis 0.0001° Tool support: Single tool carrier in the work area Tools for turning (L) and milling (M) CAPTO C6 Tool Holder Milling spindle drive power 19/25 kW Milling spindle speeds 50 – 12,000 rpm. Tool magazine and automatic tool changer 80 tool magazine positions Axes/travels: Flat path X 645 mm Perpendicular travel (off-center) 250 mm Longitudinal travel Z 1,600 m ...

Key data: 500 mm, 1000 mm

Circumferential diameter over bed 500 mm, over support 290 mm Center width 1000 mm Speed range 1-3000 1/min, spindle nose bayonet Gr 8 Spindle bore 70 mm Tailstock quill MK 5 / stroke 160 mm incl. Control MTC K, Face Plate Fixed bezel with rolling heads Steel holder head system Multifix C with 1 cassette Coolant Setup

Key data: 330 mm, 850 mm, 190 mm

Circumferential diameter over bed / support 330 / 190 mm Center width 850 mm Bore 36 mm Speed range 60 - 2400 1/min Tailstock quill MK 3 / stroke 100 mm incl. accessories: 4-fold holder, chip back panel, T-slots in cross support Tightening tube for collets (New machine was designed according to DIN 8605)

Key data: 840 mm, 3000 mm, 490 mm

Circumferential. over bed 840 mm, over cross slide 490 mm Center width 3000 mm Speed range 10-1250 rpm, spindle nose DIN 55022 Gr. 11 Spindle bore 105 mm Feeds 0.060 - 1.4 mm // 0.024 - 0.518 mm Thread metric 1 - 224 mm Drive power 18.5 kW Quill path / cone 220 mm / MK 6 incl. Hardened and ground bed guides, electromagnetic brake of the main spindle mechanically driven upper support, rapid traverse longitudinal/transverse Multifix steel holder, fixed bezel 2-axis digital display,

CNC Lathe Manufacturer: Gildemeister Type twin 42 Year of manufacture 2005 Control Siemens 840D Turning length 210mm 2 X 12-fold turret all places are powered Engine A 83700 Spindle A 50809 Machine has a defect in the pick-up spindle, probably bearing With Breuning Profimat bar loading magazine

Key data: 660 mm, 3000 mm, 440 mm

Sine 330/3000 D Well-maintained conventional lathe without mounted lathe chuck but with standard accessories The construction follows the classic design however, is based on a heavy, one-piece cast machine bed. How in the case of heavy lathes here, too, the adhesion between the engine and spindle via a manual Multi-plate clutch. With integrated Features such as the removable bed bridge, rapid traverse and a Taper turning device. WORKSPACE Workpiece length 3000 mm Turning diameter over bed 660 mm Circumferential Ø over support 440 mm Turning diameter without bridge 900 mm Bridge length 320 mm Bed width 400 mm TRAVELS X-axis travel 368 mm Travel Z1 axis 230 mm Swivel range upper slide 45° MAIN SPINDLE Spindle speed 25 1/min - 1600 1/min Spindle bore 105 mm Spindle holder D1-8 RUSH COURSE Rapid traverse X-axis 2000 mm/min Rapid traverse Z-axis 4000 mm/min ...

Highlights − Linear actuator for maximum precision, dynamics and cost-effectiveness − 6 + 2 axes, 2 Y-axes as standard − 2 tools in use at the same time − Thanks to the conversion kit, the machine can be used as an adjustable spindle stick Technical description I-J10010 GILDEMEISTER SPRINT 20|8 linear CNC Swiss Automatic Lathe TECHNICAL DATA: MAIN SPINDLE Turning diameter max.: 20 (25 option) mm Stroke Z 1: 80 mm Max. speed: 10,000 rpm Nominal drive power: S1 3.7 kW SUB-SPINDLE Turning diameter max.: 20 (25 option) mm Stroke Z 2: 300 mm Max. speed: 10,000 rpm Nominal drive power S1: 3.7 kW CNC-CONTROLLED AXES Rapid traverse speed: 40 (30) m/min (Y1 only) Acceleration max. X1: 10 m/s2 Feed force (S1) axis Z1,Z2,X2,Y2: 250 daN Feed force (S1) axis Y1: 500 daN Linear axis feed force X1: 60 daN SLIDE 1 Stroke X 1: 50 mm Stroke Y 1: 350 mm 6 P ...

Highlights - CNC FANUC 32i - 6 linear axes - 2 programming channels - 2 electrospindles - C-axis standard for main spindle and sub-spindle - 25 Vehicle positions - 4 radial driven tools for slides 1 - 4 radial driven tools for slides 2 - Machining on the main spindle possible with 2 tools at the same time Technical description I-A1023 GILDEMEISTER SPRINT 20|8 CNC Swiss Automatic Lathe CNC CNC FANUC 32i TECHNICAL DATA MAIN SPINDLE Turning diameter max.: 20 mm Stroke Z1: 60 mm 180 (with option I-C1002) Max. speed: 10,000 rpm Nominal drive power S1: 2.2 kW SUB-SPINDLE Turning diameter max.: 20 mm Stroke X2: 220 mm Stroke Z2: 170 mm Max. speed: 10,000 rpm Nominal drive power S1: 1.5 kW CNC-CONTROLLED AXES Rapid traverse speed: 32 m/min Max. acceleration: 5 m/s2 Feed force (S1) axes Z1, Z2, X1, X2: 150 daN Feed force (S1) axis Y1: 370 daN Feed force  ...

Offered is a precision lead and feed screw lathe: Center distance: approx. 1000mm, center height: 180mm, swing diameter over bed: 360mm, spindle bore: 35mm, spindle mount: D1-3 Camlock, spindle taper: MK5 (MT5), speed steps: 12 speeds, speed range: approx. 40-1800rpm, longitudinal feeds: 0.05-0.7mm/rev, cross feeds: 0.02-0.4mm/rev, metric threads: 0.4-7.0mm, inch threads (Whitworth): 4-56threads/inch. Inspection possible by appointment.

turning diameter: 250 mmturning length: 600 mmcontrol: FANUC Series 31i-Model A total power requirement: 23 kWweight of the machine ca.: 7,7 tdimensions of the machine ca.: 2.880 x 2.130 x 1.990 mm mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Turning diameter: 200mm, Unrun diameter: 260mm, Turning height: 200mm, Spindle clearance: 30mm, Spindle speed: 7500rpm, Power: 10kW, Torque: 49Nm. Travel X/Z: 520mm/200mm, rapid traverse X/Z: 30m/min, tool positions: 14, tool holder: VDI 30, drive tool speed: 6000rpm. Machine dimensions X/Y/Z: approx. 2100mm/2100mm/2300mm, weight: approx. 3300kg, control: Siemens Sinumerik. The X-axis of the machine makes running noises. Documentation available. On-site inspection is possible.

Offered is a CNC vertical turning machine - pick-up system. Chuck diameter: approx. 160mm - 200mm, swing diameter: approx. 270mm, travels X/Z: approx. 500 - 600mm/approx. 160 - 200mm, max. spindle speed: 6000rpm, tool carrier: 12-station turret, drive system: Siemens SIMODRIVE 611, hydraulic unit: available, coolant system: including pumps and filter (One Eye Ind. magnetic filter installed), hinged belt chip conveyor. Inspection is possible by appointment.

2x2x2m 650 C and 1200 C PLC

A CNC flatbed lathe Optimum is available. Swing diameter over bed/slide: 280mm/170mm, center distance: 700mm, spindle bore: 27mm, speed: 4000rpm, travel X/Z: 165mm/660mm, feed X/Z: 2m/min/3m/min, tool stations: 4, quill stroke: 85mm. Machine dimensions X/Y/Z: approx. 2000mm/750mm/1550mm, weight: approx. 450kg, control: Siemens Sinumerik. Documentation available. An on-site inspection is possible.

Chuck flange, flange mount, lathe chuck flange, driving flange-Chuck flange: for three-jaw chucks, four-jaw chucks, face plates-Outer: Ø 193 mm-Inside: Ø 80 mm-Hole circle: Ø 105 mm-Dimension: Ø 193 x 75 mm-Weight: 4.1 kg

Change gear, change gears, gear-Number of teeth: 152 pieces-Module: 1.25 mm-for splined shaft: Ø 25 mm

Precision lathe, lathe, lead screw lathe, lead screw lathe -Manufacturer: VDF Heidenreich Harbeck, lead screw and feed screw lathe type 24R0 -Machine bed: hardened -Turning length: 1230 mm -Rotation diameter over bed: 500 -Turning diameter over support: 290 mm -Spindle bore: Ø 56 mm -Spindle speeds: 19 - 2000 rpm -Wedge bar chuck: Forkardt Ø 250 mm -Tailstock mount: MK4 -Drive: 5.5 kW -Accessories: 1x bezel, 7x Multifix tool holders, see photos -Dimensions: 1180/3050/H1345 mm -Weight: 1907 kg

Heavy lathe, turning machine, lathe, center and feed screw lathe, center and feed screw lathe -Manufacturer: Weisser, lead screw lathe type PF200 -Turning length: 1340 mm -Turning Ø over bed: 420 mm -Turning Ø over support: 240 mm -Spindle bore: Ø 41 mm -Spindle speeds: 31.5 - 1400 rpm -Three-jaw chuck: Röhm Ø 250 mm -Accessories: incl., see photos -Tailstock mount: MK4 -Drive motor: 2.5/3.5 kW -Dimensions: 2670/1000/H1230 mm -Weight: 1450 kg

Change gear, change gears, gear-Number of teeth: 141 pieces-Module: 1.25 mm-for splined shaft: Ø 25 mm

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø mm-Mounting: Hole shaft cone Ø 40-48 mm-Type designation: not available-Dimensions total Ø 180 x 85 mm-Weight: 6.8 kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø mm-Mounting: Hole shaft cone Ø 38-48 mm-Type designation: not available-Dimensions total Ø 180 x 85 mm-Weight: 7,3 kg

Lathe, turning machine, lead screw lathe, lead screw lathe -Handover: in the current condition as viewed -Condition: Gearbox makes noise (video) -Manufacturer: Colchester, Leadscrew and Feedscrew Lathe Type Triumph 2000 -Turning length: 1300 mm -Turning Ø over bed: 390 mm -Turning Ø over support: 240 mm -Spindle bore: Ø 55 mm -Spindle speeds: 22 - 2000 rpm -Three-jaw chuck: Ø 250 mm -Accessories: Tool holder/tools see photos -Tailstock mount: MK4 -Dimensions: 960/2435/H1640 mm -Weight: 1327 kg

Three-jaw chucks, three-jaw lathe chucks, power chucks-Chuck size: Ø 200 mm-Short taper: 6-Weight: 25 kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø 127 mm-Mounting: Hole shaft cone Ø 45-59 mm-Type name: 508x10-100x127 / 508x10-80x127-Dimensions total Ø 190 x 100 mm-Weight: 7.7 kg

Chuck flange, flange holder, lathe chuck flange, driving flange, intermediate flange, lathe chuck face plate, mounting flange -Feed flange: mounting flange -Outside: Ø 160 mm -Recess: Ø 130 mm -Hole: Ø 25 mm -Bolt circle: Ø 139 x 10 mm -Dimensions: Ø 160 x 40 mm -Weight: 2.6 kg

Upper support, upper slide, dovetail guide, tool slide, cross table, spindle drive for upper support -Spindle drive: for upper support -Trapezoidal spindle: Ø 20 mm -Dimensions: see photos -Dimensions total: 450/155/H110 mm -Weight: 5.4 kg

Grinding wheel holder, standard flanges, special flanges, grinding wheel flange-Grinding wheel holder: Holder: Ø mm-Mounting: Hole shaft cone Ø 38-49 mm-Type designation: not available-Dimensions total Ø 180 x 85 mm-Weight: 6.6 kg
