CNC Turning Machines used for sale (562)

Key data: 324 mm, 600 mm

Control: HEIDENHAIN CNC Pilot 4290 Max. spindle speed: 5,000 1/min C-axis Max. bar passage: 65 mm Travel: X= 260, Z= 630 mm 12-station turret (all driven, max. 4,500 rpm) Tailstock Tailstock stroke: 580 mm Chip conveyor Dimensions LxWxH: 3500 x 2440 x 2100 mm (without chip conveyor) Weight: 6,000 kg Switch-on hours: 32,600 h Spindle hours: 7,600 h

CNC lathe for turning and machining metal parts. CNC control: Fanuc 16 T AAMax. turning diameter: 165 mmTurning length: 100 – 340 mmDiameter above bed: 220 mmMain spindle speed: 50 – 5,000 rpmMain spindle power: 5.5 / 7.5 kWMain spindle bar passing: 65 mmSub-spindle speed: 50 – 5,000 rpmSub-spindle power: 3.7 / 5.5 kWSub-spindle bar passage: 42 mmC-axis: 0.001° Turrets: 2Tool positions: 2 × 16Motorized tools: 2 × 16 positionsStrokes: X 175 mm / Z 240 – 680 mmTotal power: 41 kVADimensions (mm): 3,500 × 2,800 × 2,000Weight (kg): 5,500 Auction-ID: A1-47716-237

Key data: 290 mm, 450 mm, 5000 1/min

Control: EPL Country of origin: Germany Spindle passage: Ø65 mm Tool turret: 12-fold driven places Tool holder: VDI 40 Speed tools: 3000 rpm Weight: approx. 4,700 kg + 600kg control cabinet Chip conveyor: BMF Bürener Maschinenfabrik Bar feeder: GIOVANNI CUCCHI, type DB 70 Tools for an extra charge There are a total of 6 machines with bar feeder (price per machine with loader) Dcjwvey N Tdzeu Nu Ieg There is 1 machine without loader available (€ 8.500,-)

Working parameters: Tip height 260 mm; Ø allowed above the bench 530 mm; Ø allowed above the cross slide 315 mm; distance between points 1000 mm; bench width 350 mmEquipment included: GE Fanuc Series 0i Mate-TC control; 3-jaw chuck; tool turret; tooling set, jaws and accessories visible in the tank; visible SMART-TURN / PINACHO documentationPower: 7.5 kWYear & Manufacturer: 2008, PINACHO / METOSANotes: Serial No. 55217; spindle bore 80 mm; spindle nose DIN 55027; spindle taper CM5; spindle speed 0 to 2500 rpm; X/Z fast feed approx. 5 m/min; Sheath tailstock approx. Ø72 mm, stroke approx. 180 mm, CM5 morse taper; Machine with visible signs of use, dirt and shavings. Dimensions (mm): 3000 × 1600 × 1800Weight (kg): 1800 Auction-ID: A1-47716-2

The machine is in good technical condition, after prior agreement it is possible to test it. with the Siemens Shopturn system, including the feeder, the machine is fully equipped. BASIC PARAMETERS Working space max. turning Ø: ≈ 410–500 mm max. length: 800 mm distance between spindles: approx. 1020 mm swing diameter above the bed: ~700 mm realistic: ideal for shafts, flanges, bodies up to ~800 mm Travels (axes) X: ~480 mm Y: 100 mm Z: ~800–845 mm B axis: 110 (5-axis machining) C axis: 360 (indexing + interpolation) this makes it a full-fledged turn-mill (not a classic lathe) Spindles main spindle speed: ~5000 rpm power: ~25–34 kW passage: approx. 76–87 mm counter spindle speed: ~6000 rpm milling spindle (main difference compared to a classic lathe) speed: up to 12,000 – 20,000 rpm power: ~19–22 kW taper: HSK-A63 or Capto C6 allows: milling drilling tapping 5-axis simultane ...

CNC Control: GE FANUC Series 16i-TNumber of axes: 2 (with sub-spindle)Main spindle: ASA 5 nose, max. bar passage 42 mm, power 11 kW, max. speed 6,000 rpmMax. rotation diameter: 519.2 mmMax. turning diameter: 308 mmX/Z axis strokes: 189.2 / 406 mmTurret: VDI 30 bidirectional, 16 positions (16 motorized)Sub-spindle: ASA 5 nose, max. bar passage 42 mm, power 7.5 kW, max. speed 6,000 rpmIncluded equipment: parts catcher, motorized tools and stationary tools (depending on seller)Weight (kg): 5071Year & Manufacturer: 2001 – HARDINGE Auction-ID: A1-47716-257

Key data: 350 mm, 650 mm, 3500 1/min

CNC Teach-in Lathe COLCHESTER Alpha 1350 XT Travel X: 245 mm Numerical Command FANUC Between points: 650 mm Maxi turning diameter: Ø 350 mm Spindle diameter: Ø 41 mm Max Rotation: 3500 RPM Turret: 8 tools VDI 30 Year of construction: 2006 Spindle motor: 5,5 kW 3 speed ranges Centralized lubrication pump Delivered with 2 3-jaws chuck Ø 160 mm Delivered with some tool holders (see photos) Voltage: 380 V Dimensions (L x W x H): 2500 x 2000 x 1900 mm Weight: approx 2 T Machine in very good condition

Manufacturer: HARDINGEYear: 2005Type: CNC Motorized Tool Lathe with C-AxisNumerical Control: FANUC 21i-TBBar Capacity: Ø 51 mmMax. Turning Circle: Ø 310 mmMax. Turning Length: 470 mmChuck: Ø 200 mm (8\")Bed Inclination: 45°Spindle: 50–5,000 rpm – 18.5 kW (max) / 11 kW (continuous)Turret: 12 stations, all motorable positionsMotorized implements: 4,000–5,000 rpm – 3.7 kWFast feeds: X/Z 19 / 24 m/minAccuracy: ±0.005 mmIncluded equipment: Programmable C-axis (0.001°), IEMCA Boss 545 bar feederWeight (kg): approx. 4200 Auction-ID: A1-47716-272

Used lathe with numerical control HEIDENHEIM PLUS Basic parameters: Diameter: 490 mm, Length 1000 mm Max. diameter over cross slide 280 mm Bed width: 350 mm Spindle bore 65 mm Main motor 12/16 kW Max. speed 2500 /min Feed range 0.01 - 3 mm/rev. Quill stroke 160 mm Quill bore 70 mm Dimensions 2800 x 1800 x 1400 mm Weight 3.2 tons

Manufacturer: SOTOS VOJUS (VOJUS a.s.)Year: 2001Type: CNC lathe with automatic cycleNumerical control: Siemens Sinumerik 840D ShopTurnMax. turning diameter: Ø 630 mmDiameter above dragger: Ø 420 mmMax. turning length: 3,000 mmSpindle: up to 2,500 rpm – passage Ø 110 mmFast feeds: longitudinal 10 m/min – transverse 5 m/minInstalled power: approx. 26 kWEquipment: Multifix tool holder, 1 bezel, coolantDimensions (mm): 3000 × 1800 × 1790Weight (kg): approx. 4500Remarks: High-capacity CNC lathe for long workpieces. Serial number included in the description. Auction-ID: A1-47716-220

The machine is in good technical condition, after prior agreement it is possible to test it. with a bar seller, 65 mm draw tube passage, Sauter revolver, driven tools, hydraulic tailstock, it is after GO, new draw cylinder for clamping tools, still connected in operation, including draw tube inserts, tool holder, etc.,

CNC Control: NUM Teach-InMax. diameter above the bed: 380 mmMax. diameter above the carriage: 200 mmDistance between tips: 750 mmMax. turning length: 600 mmStrokes X × Z: 180 × 610 mmSpindle type: A2-6\"Spindle power: 11 kWRotational speeds: 0–3000 rpmMax. bar diameter: 62 mmTailstock: Morse code N°4, Ø sheath 60 mm, stroke 175 mmPower supply: 400 V / 50 HzIncluded equipment: touch screen on carriage, LCD control screen, AMESTRA Ø 200 mm 3-jaw chuck, set of hard jaws, AMESTRA type B turret, 5 AMESTRA quick-change tool holders, CM4 rotating tailstock, coolant tray with automatically controlled pump, lighting, 4 feetDimensions (mm): 1950 × 1320 × 1820Weight (kg): 2000Year: 2000Manufacturer: CAZENEUVE Auction-ID: A1-47716-268

Inv. Num. : 9102 Type: Hi-TECH 230 BL YMC Producer: Hwacheon Created: 2019 Parameters: Control system: FANUC Hours: 6623 h Maximum turning length: 584 mm Maximum turning diameter: 400 mm Maximum turning diameter over bed: 750 mm Maximum spindle speed: 3500 1/min Weight: 6650 kg

Lot composed of: CNC Tower Biglia BV 315 Y Mitsubishi CNC Y-axis COMAC / BRC automated parts loading/unloading system Motorized circular transfer table Conveyor for the evacuation of machined parts Hydraulic power unit with filtration Machine data: Manufacturer: BIGLIA Model: BV 315 Y Serial No.: 9266 Year of manufacture: 2007 Weight: 6,220 kg Posting working time: 22,057 h Automation data: Manufacturer: COMAC Type: BOX 126-24 Serial No.: 50807 Year of manufacture: 2007 Additional manufacturer: BRC Automazione Industriale Type: NTB BV 160 Serial No.: MT06 0810 Year of manufacture: 2007 Auction-ID: A1-47716-9

Control Siemens C 200 – 4D Turning diameter: 100 mm Turning length 280 mm 8-fold revolver with applied revolver Wkzg. 6-fold revolver with applied revolver Wkzg. Spindle speed 6000 min-1 Max. bar passage 60 mm Rear drilling unit for 5 stations Chip conveyor Knoll Coolant system

CNC lathe for turning and machining metal parts. CNC control: Fanuc 16 T AAMax. turning diameter: 165 mmTurning length: 100 – 340 mmDiameter above bed: 220 mmMain spindle speed: 50 – 5,000 rpmMain spindle power: 5.5 / 7.5 kWMain spindle bar passing: 65 mmSub-spindle speed: 50 – 5,000 rpmCounter-spindle power: 3.7 / 5.5 kWCounter-spindle bar passage: 42 mmC-axis: 0.001°Turrets: 2Tool positions: 2 × 16Motorized tools: 2 × 16 positionsStrokes: X 175 mm / Z 240 – 680 mmTotal power: 41 kVADimensions (mm): 3,500 × 2,800 × 2,000Weight (kg): 5,500Serial No.: 1105-02957 Auction-ID: A1-47716-238

General Manufacturer: Spinner Type: Microturn LT Year of construction: 2024 Control: Siemens One Travels: X 600 mm Z 350 mm Y +/- 50 mm Switch-on hours: 4,587 h Work spindle hybrid bearing Speed: 10,000 rpm Tool/movement Tool holder: BMT45 with Y-axis Tool turret: 12-speed Condition Condition: Used Functional: tested and fully functional Other equipment and accessories included: High-precision motor spindle with a circular shape deviation and 1um Power Chuck Röhm KFD-HS 125 Power Chuck SMW Autoblok BH-D 165-46-3-A05 Various owners and AGW High-pressure system 70 bar including fine filter Chip conveyor Spindle coolers

Maximum passage diameter: 310 mm Maximum turning diameter: 190 mm Standard turning diameter: 170 mm Maximum turning length: 235 mm Bar passage: 65 mm Spindle speed: 50 to 5,000 rpm Spindle power: 22 kW / 18.5 kW Spindle nose: JIS A2-6 Spindle Bore: 73 mm Axis C: Indexation 0.001° Turrets: 2 independent turrets Tool capacity: 32 positions (16 per turret) Motorized tools: 16 positions per turret Motorized Tool Speed: 6,000 RPM Power with motorized tools: 5.5 / 2.2 kW Indexing time: 0.2 s X-axis: 140 mm Y-axis: ± 50 mm Z-axis: 700 / 690 mm B-axis: 775 mm Fast Advances: 18 m/min CNC Control: MSX 501 MAPPS II (Fanuc 30i) Weight: 6,600 kg Dimensions: 3,700 x 2,100 x 2,000 mm Equipment: Bar feeder included Auction-ID: A1-47716-15

CNC lathe BIGLIA B750 YS TECHNICAL FEATURES: Year: 2015 NC Type: FANUC series 32i-B Maximum diameter Rotation: 680 [mm] X-axis travel: 305 [mm] Y-axis travel: 140 [mm] Z-axis travel: 860 [mm] X-axis fast feed speed: 18000 [mm/min] Z-axis fast feed speed: 24000 [mm/min] Y-axis fast feed speed: 7500 [mm/min] Spindle Nose: ASA 8" Maximum diameter in bar: 80 [mm] Spindle Bore: 91 [mm] Maximum speed Spindle: 3500 [rpm] C-axis indexing accuracy: 0.001 [°] Spindle power: 22 [kW] Spindle torque: 700 [Nm] Counter Spindle Nose: ASA 5" Sub-spindle bore diameter: 55 [mm] Counter-spindle stroke: 895 [mm] Maximum speed Spindle: 5000 [RPM] C-axis sub-spindle indexing accuracy: 0.001 [°] Sub-spindle power: 25 [kW] Spindle torque: 159 [Nm] Max. section Tool holders: 25 x 25 [mm] Number of turret stations: 16 Turret Index Time: 0.3 [s/pos] Number of powered turret statio ...

CNC lathe for metal part turning operations. Numerical control: Fanuc 18TAxes: 3-axisTurret: 12 fixed positions + 6 rotating positionsChuck: Ø 200 mm (possibility of mounting clamps in the spindle)Distance between tips: 350 mmSpindle speed: 4,000 rpmSpindle passage: 51 mm Auction-ID: A1-47716-249

The machine is in good technical condition, after prior agreement it is possible to test it. Fanuc i Series, Dmax320mm, X175 Z330, 5,000rpm, 12 tool positions, Tool measuring system, Part catcher, 4 jaw inserts,, Clamping pliers, many accessories

Manufacturer: YAMAZAKI MAZAKModel: Quick Turn 20Year: 1997CNC Machine: Mazatrol T PlusAxes: 2 Axes (X, Z)Capacities:Max. diameter above bed: Ø 300 mmDistance between points: 446 mmX-axis stroke: 180 mmSpindle:Bore: 61 mmMax. speed: 4500 rpmMotor power: 15 kWTurret: 8 positionsDimensions per machine: 2660 x 1520 x 1879 mmUnit weight: approx. 4170 kg (total batch weight approx. 8340 kg)Condition: used Auction-ID: A1-47716-261

The machine is in good technical condition, after prior agreement it is possible to test it. approx. 3000 hours of TRIPS 550X400

CNC Control: FANUC 18i-TNumber of Axes: 5 (Twin-Spindle Configuration)Main Spindle: PresentSub-Spindle: Turrets: 2 Turrets with MotorizedTools Configuration: Combined Turning and MillingWeight (kg): Approx. 9000Year & Manufacturer: 2004 – HARDINGE Auction-ID: A1-47716-259

The machine is in good technical condition, after prior agreement it is possible to test it. ideal machine for complete machining in one clamping (turning + milling). Equipment and parameters: - main spindle + counter spindle (complete machining from both sides) milling spindle with B axis Mazatrol SmoothG control 36-position tool magazine Capto C6 / PSC63 internal cooling large number of accessories (jaws, clamps, holders, etc.) a functional postprocessor for SolidCAM is included in the sale significant time and cost savings when introducing the machine into production

CNC Control: FANUC Series 18-TNumber of axes: 3 (including C-axis)Maximum machining diameter: 200 mmDistance between tips: 300 mmMax. spindle speed: 3,000 rpmSpindle power: approx. 17.5 kWTurret: 12 fixed positions + 6 rotating positionsChuck: Ø 200 mmSpindle: direct collet mounting possibleWeight (kg): approx. 4200Year & Manufacturer: 1993 – HARDINGE Auction-ID: A1-47716-255

Inv. Num. : 9089 Type: CT 40/1000 Producer: Gildemeister Created: 1991 Parameters: Maximum turning length: 1000 mm Maximum turning diameter over bed: 400 mm Maximum turning diameter over support: 225 mm Spindle diameter: 56 mm Weight: 3200 kg Equipment: Chip conveyor Tailstock Spare parts Shovel Powered tools

CNC control: MSX-850 IIINumber of axes: 2Strokes: X = 260 mm, Z = 590 mmSpindle speed: 50 – 5000 rpmPower: 15 kWBar capacity: Ø 65 mmSpindle bore: 73 mm Turret: 12 stations (BMT)Max turning diameter: 356 mmMax turning length: 510 mmChip conveyor: yes235L high-pressure pump: yes Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-47716-204

Inv. Num. : 9085 Type: KMX XL 32 Producer: Manurhin Created: 2003 Parameters: Maximum turning length: 330 mm Max. turning diameter: 33 mm Length: 3850 mm Width: 2000 mm Height: 2100 mm Weight: 6000 kg

2-axis CNC lathe with HAAS CNC Manufacturer: HAAS Model: HL-2 Year: 1997 Serial Number: 61212 Max turning diameter: 508 mm Max turning length: 610 mm Spindle Bore: 76.2 mm Max spindle speed: 3750 rpm Turret: 10 positions CNC Control: HAAS CNC Power supply: 360 / 480 V – 3 phases – 50/60 Hz Dimensions approx. (L x W x H): 3200 x 1778 x 1778 mm Weight approx.: 4082 kg Auction-ID: A1-47716-263

video available

Maximum rotation diameter: 760 mm Maximum turning diameter: 550 mm Maximum turning height: 600 mm Chuck: 15 inches X-axis: 325 mm Z-axis: 625 mm Axis C: Indexation 0.001° Spindle speed: 2,000 RPM Spindle power: 22 kW Spindle nose: A2-11 Type of training: By belt Turret: 12 stations (BMT75) Motorized tool speed: 3,000 rpm Power of motorized tools: 7.5 / 5.5 kW Tool dimensions: 32 x 32 mm Bore bar diameter: Ø 50 mm Fast Forwards: 20 / 18 m/min CNC Control: Fanuc 32i Model B Weight: 8,500 kg Floor dimensions: 2,010 x 3,212 mm Auction-ID: A1-47716-17

Control Siemens 828D - ShopTurn Rotary diameter. [mm] 405 Turning length [mm] 956 Main spindle: Lining SAMCHULLY HS-12 (12 inches) Spindle speed (max.) 3,000 rpm Spindle nose A2-8 Motor power (Cont./Max) 18.5 kW / 26 kW Max. turning Ø x turning length 405 mm x 956 mm Tool carrier (X/Z): Number of tool positions 12x BMT65 Max. milling Ø 433 mm Travel (X/Z) 245 mm / 1,040 mm Rapid traverse (X/Z) 24 m/min / 30 m/min Tailstock: Quill Ø 110 mm Quill stroke 100 mm Equipment/accessories: Control SIEMENS 828D - ShopTurn Bed construction 45° inclined bed (cast from one piece) Additional equipment Tool Probe (Tool Setter, swivel) Collision protection turret with Hirth serration Weight 5,600 kg (according to configuration nameplate) Chip Management Chip Conveyor Electrical connection 380 V / 3PH. PE / 50/60 Hz / 42 kVA

Working parameters:Max. turning diameter 325 mmMax. turning length 400 mmSpindle speed 30 – 4,500 rpmX-axis strokes 215 mm / Z-axis 420 mmEquipment included:12-station turret VDI 40Hydraulic chuck 3 jaws Ø 204 mmTailstock CM4Tool holder with motorized toolsCoolantBar loaderYear & Manufacturer: Year 2000Manufacturer HYUNDAI Auction-ID: A1-47716-266

Lathe M. Ernault Sorma Cholet 550

CNC lathe for turning and machining metal parts. CNC control: Traub TX 8Max. turning circle: 275 mmMax. turning length: 450 mmBar pass: 65 mmChuck diameter: 210 / 250 mmBench inclination: 40°Spindle speed: 0 – 4,000 rpmSpindle nose: A2-6Spindle motor power: 11 / 18.5 kWC-axis: 0.001° with hydraulic brakeTurret: 12 positions VDI 30Motorized tools: 4,000 rpm – 4.4 kWFast feeds: X 15 m/min / Z 20 m/min Auction-ID: A1-47716-241

Lathe Mori Seiki SL25

CNC Control: SIEMENS 810 DNumber of axes: 3Max. turning diameter: 325 mmMax. turning length: 400 mmMax. passage over the bed: 500 mm X/Z axis strokes: 215 / 420 mmSpindle speed: 30 – 4,500 rpmSpindle bore: 52 mmSpindle power: 15 kWTurret: 12 VDI 40 positions with motorized toolsChuck: 3-jaw hydraulic Ø 204 mmTailstock: present, CM4 taperTailstock sleeve stroke: 130 mm, Ø 80 mmIncluded equipment: coolant, bar feederWeight (kg): approx. 4500Year & Manufacturer: 2000 – HYUNDAI Auction-ID: A1-47716-253

Main spindle: Technology: Motor spindle Speed: 4,000 rpm Power (max.): 29 kW Torque (max.): 250 Nm Bar Passage: 76 mm Sub-spindle: Technology: Motor spindle Speed: 5,000 rpm Power (max.): 29 kW Torque (max.): 250 Nm Ejector: Pneumatic Travel in Z: 800 mm Tool carrier I (X/Y/Z): Technology: 12-station turret Tool holder: VDI30 Tool drive: 5,000 rpm, 6.7 kW, 25 Nm Travel in X/Y/Z: 260/100/800 mm Rapid traverse in X/Y/Z: 30/12/30 m/min Tool carrier II (X/Z): Technology: 12-station turret Tool holder: VDI30 Tool drive: 5,000 rpm, 6.7 kW, 25 Nm Travel in X/Z: 210/800 mm Rapid traverse in X/Z: 30 m/min Equipment/accessories: Chip management: Chip conveyor Coolant management: IKZ system with paper belt filter and high pressure, 40 bar Raw material feed I: Robot interface prepared Raw Material Feed II: Bar Feeder Interface Prepared Finished part removal ...

Lot composed of: DMG MORI CLX 450 CNC Lathe DMG MORI CNC Main spindle Counter-spindle Motorized tool turret Rear chip conveyor Integrated lubrication and filtration unit Manufacturer's plate data: Manufacturer: DMG MORI Model: CLX 450 Serial number: 0031001193C Year of Manufacture: 2019 Maximum spindle speed: 4,000 RPM Apparent power: 39 kVA Power supply: 400 V Frequency: 50/60 Hz Maximum current: 56 A Weight: 6,400 kg Meters read: Hours on : 14,108 hours Operating hours: 4,366 hours Auction-ID: A1-47716-3

Inv. Num. : 9065 Type: GLS 200 Producer: GOODWAY Created: 2016 Parameters: Control System: FANUC Series Oi-TF Switch-on hours: 15380 h Hours: 7757 h Max. turning length: 300 mm Grinding diameter: 350 mm Maximum turning diameter over bed: 500 mm Maximum turning diameter over support: 380 mm Maximum spindle speed: 4500 1/min Spindle passage: 65 mm Number of tool head positions: 12 Weight: 3200 kg Equipment: Chuck Tool probe Bar Feeder Grips

CNC Control: SIEMENS 840 DNumber of axes: 2Max. turning diameter: 420 mmMax. turning length: 1000 mmX/Z axis strokes: 200 / 1000 mmSpindle bore: 82 mmSpindle speed: 0 – 3,000 rpmSpindle motor power: 14.5 kWTurret: VDI 40, 12 stationsChuck: Autoblok Ø 250 mmTailstock: Chip Conveyor: PresentRemarks: Machine in good working order.Weight (kg): approx. 5500Year & Manufacturer: 2001 – MENTI Auction-ID: A1-47716-254

Inv. Num. : 9057 Type: CTX 310 Producer: DMG MORI Created: 2004 Parameters: Control system: SINUMERIK 840 D Maximum turning length: 450 mm Max. turning diameter: 200 mm Maximum turning diameter over bed: 330 mm Maximum turning diameter over support: 260 mm Maximum length of travel in the X-axis: 160 mm Maximum feed in the Z-axis: 450 mm Maximum spindle speed: 6000 1/min Weight: 3950 kg

Capabilities: Maximum turning diameter: 420 mm (standard 290 mm) Maximum turning length (Z-axis): 635 mm Bar passage: 65 mm Spindle Bore: 79 mm Spindle: Rotational speed: 25 to 5,000 rpm Power: 21 kW (100%) / 28 kW (40%) 3-jaw hydraulic chuck (Ø approx. 200–250 mm) Turret & tooling: Sauter Turret VDI 30 (DIN 69880) Capacity: 12 stations Motorized substations C-axis (pin indexing) CNC Control: Heidenhain Turn Plus Electrical data: Power supply: 400 V / 3~ / 50 Hz Installed effective power: 44 kVA Current rating: 64 A Protection: 80 A Auxiliary voltage: 230 V Control voltage: 24 V DC Auction-ID: A1-47716-262

Inv. Num. : 9056 Type: SPRY 40 CNC-D Producer: ZPS Created: 1994, GO 2016 Parameters: Control system: Siemens Sinumeric 840D Maximum turning length: 300 mm Max. turning diameter: 110 mm Maximum main spindle power: 10 kW Spindle bore: 50 mm Max. rod diameter: 40 mm Weight: 2400 kg Equipment: Duplomatic tool head with rotary tools 3 meter pole holder

AC power supply 220 V, 3PH, 50/60 Hz; control voltage AC 110 V / DC 24 V; rated current 75 A; installed power 35 kVA; spindle speed up to 6000 rpm; ASA A2#5 spindle nose; 53 mm spindle passage; 12-tool VDI turret; Tool dimensions 25 x 25 mm; boring bar Ø 40 mm; strokes X 242 mm / Z 440 mm; fast feeds X 20 m/min, Z 25 m/min; 11 kW spindle motor; X-axis motors 1.4 kW / Z axis 2.8 kW; lubricating tank capacity 100 L; Max turning Ø 350 mm; Max turning length 425 mm Auction-ID: A1-47716-12

Key data: 500 mm, 1000 mm, 2500 1/min

Lathe Voest Alpine Steinel WNC 500 S x 1000 Turning diameter 500 mm Turning length: 1000 mm Control system Sinumerik 810 T-GA 2 2 stage gearbox i = 4 Power: 37 KW at 100% ED Max. torque during turning: 1450 Nm Tailstock manual with clamping and coupling Speed max 2500 rpm Electronic handwheel For milling: Hydraulically swivelling servo motor with 720 Nm and max. 18.5 rpm 12-speed disc turret with driven tools max. 3000 rpm at 4 kw Tool holder VDI 40 Many VDI 40 tool holders for internal and external machining as well as driven tools, incl. some tools - e.g. internal turning steels otherwise without tools!

Manufacturer: GILDEMEISTERModel: CTX 400 Series 2Year: 1998German-made 2-axis CNC lathe, robust and precise, suitable for turning single parts and small to medium series.CNC : HEIDENHAIN TURN PLUSAxes: 2 axes (X, Z)Turning capacities:Diameter above bed: Ø 570 mmDiameter above carriage: Ø 420 mmX-axis stroke: 220 mmZ-axis stroke: 635 mmSpindle:Bore: 79 mmChuck diameter: Ø 250 mmSpindle speed: 25 – 5000 rpmMotor power: 21 kWFast feeds:X-axis: 20 m/minZ-axis: 24 m/minTurret: 12 positions VDI 30Equipment: automatic tailstock (Ø 80 mm), chip conveyor, parts collectorCountry of origin: GermanyCondition: used Auction-ID: A1-47716-232

DMG MORI NRX 2000™ CNC Lathe TECHNICAL FEATURES: Year: 2017 NC Type: MITSUBISHI M730UM Maximum diameter Machinable: 150 [mm] X-axis travel: 100 [mm] Z-axis travel: 220 [mm] X1 Axis Fast Feed Speed: 30000 [mm/min] Fast feed speed X2 axis: 30000 [mm/min] Z1 axis fast feed speed: 30000 [mm/min] Z2 axis fast feed speed: 30000 [mm/min] Spindle Nose: JIS A2-5 Maximum length Machinable Spindle 1: 100 [mm] Maximum length Machinable Spindle 2: 100 [mm] Maximum speed Spindle 1: 6000 [rpm] Maximum speed Spindle 2: 6000 [RPM] Turret Turning Tool Power 1: 1.5 [kW] Turret 2 rotating tool power: 1.2 [kW] Number of posts - Turret 1 : 10 Maximum speed Rotating Tools - Turret 1: 10000 [RPM] Number of posts - Turret 2: 10 Maximum speed Rotating Tools - Turret 2: 10000 [RPM] Installed power: 38 [kVA] Supply voltage: 400 [V] Working time: 12270 [h] Weight: 5700 [Kg] EQUIPMEN ...

Manufacturer: DMG GILDEMEISTERYear: 2008Type: CNC lathe with motorized tools with C and Y axesNumerical control: Heidenhain iT PlusMax. turning diameter: 400 mmMax. turning length: 600 mmDistance between tips: 615 mmMain spindle: 20–6,000 rpm – 16 kW – max. torque 155 NmBar capacity: Ø 52 mm – spindle bore 61 mmC-axis: 0.001° resolution Turret: 12 positions – 12 motorized tools (5,000 rpm, 3.7 kW)Strokes: X 160 mm / Z 450 mm / Y ±32 mmFast feeds: X 60 m/min – Z 45 m/minAttachments: Chip conveyor, 12 bar HP coolant, workpiece catcher, fixed tool holders (5), motorized tool holders (3), hydraulic systemDimensions (mm): 8000 × 3000 × 2700Weight (kg): approx. 4500Remarks: Machine in good condition, powered on. Serial number included in the description. Auction-ID: A1-47716-212
