milling machines used for sale (2,497)

Vertical machining center FANUC Robodrill Alpha T14iA ISO30 14 tools 8000 RPM X 500 Y 380 Z 300 CNC Fanuc 16iM The machine is visible in our warehouse in Gussago BS. Mimu Machine Tools Gussago BS Italy The machining center is a machine tool equipped with numerical control capable of performing multiple mechanical operations with a single set-up on multiple surfaces of the same work piece. It is generally equipped with several axles of motion and a automatic tool exchange system and sometimes multiple pallets, X axis: 500, Y axis: 380, Z axis: 300, CNC type: Fanuc

Vertical machining center FANUC Robodrill Alpha T21iC 2002 ISO30 14 tools 8000 RPM X 500 Y 380 Z 300 CNC Fanuc 16iM The machine can be inspected in our warehouse in Gussago BS. Mimu Machine Tools Gussago BS Italy The machining center is a machine tool equipped with numerical control capable of performing multiple mechanical operations with a single set-up on multiple surfaces of the same workpiece. It is generally equipped with several axles of motion and a automatic tool exchange system and sometimes multiple pallets, X axis: 500, Y axis: 380, Z axis: 300, CNC type: Fanuc

Ex-Cell-O XG620, Excello XG 620, Siemens CNC overhauled 2011, docs available, ball groove milling for constant velocity joints, This machine can be inspected in our warehouse in Gussago BS Italy (Milan Area)

MECOF CUTTER MOD. CR15 NC ECS 2301 4 AXES 1 mt BOARD.

X axis travel 5000mm Y axis travel 2500mm Z axis travel 1500mm C axis automatic head cnc rotary table CNC Heidenhain 530 machine in excellent conditions.

Technical data of the FPT Pragma M40 mobile column milling machine used: Longitudinal travel: 4000 mm Vertical travel: 1600 mm Transversal travel: 1200 mm Working feeds: 0-15000 mm/min Fast feed: 30000 mm/min Maximum thrust on axes (X,Y,Z): 2000 from N Spindle motor power (continuous service S1): 28 kW 38 hp Spindle motor power (intermittent service S6-60%): 35 kW 47,6 hp Constant torque spindle speed range: 0-312.5 g/min Spindle speed range at constant power. 312.5-5000 rpm Maximum spindle torque (continuous service S1): 856 Nm Maximum spindle torque (intermittent service S6-60%): 1070 Nm Supply voltage: 50Hz Current consumption: 119,2A Total installed power: 65 kW 88,4hp

Basic features: X axis travel: 6.000 mm Y axis travel: 900 mm Z axis travel (vertical travel): 2000 mm automatic head index 2,5° spindle speed 3.300 rpm spindle taper ISO 50 stolle floor: 7000x1500 mm - nr. 6 T-slots rotary table B axis 360 positions - 5 ton load capacity CNC Heidenhain TNC 426 chip conveyor ATC 60 Total power: 60 kW - 380 V machine in excellent conditions, ready to work. NB: The aforementioned technical data, taken from the manufacturer's technical data sheet, are to be considered non-binding and subject to change without notice.

X-axis: 4500 mm Y-axis: 2500 mm Z-axis: 1000 mm Year: 1986 Voltage: 380 V Power: 80 kW Weight: 63000 kg Size: 9500x9800x6100(h) mm

5 axis machininng center (milling/turning from bar) multitasking Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 ? 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters mi ...

Table length: 10.800 mm Table width: 1.000 mm Table height: 200 mm Load capacity: 10 t/m Power motor spindle: 22 Kw Max. speed of turning: 1.700 rpm X Axis travel: 7.000 mm Vertical axis travel: 2.000 mm RAM travel: 1.000 mm Total installed power: 60 Kw Rapid feed rate: 15 mt/min CNC ECS 4801 Chip conveyor

MODEL: VERSAMATIC 400 TYPE: TV-MO SERIAL NUMBER: VS4 166 YEAR OF BUILD: 1995 CNC: HEIDENHAIN

5 axis machininng center (milling/turning from bar) multitasking Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 ? 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters mi ...

This 5-axis Mazak Variaxis i-500 was manufactured in 2019, featuring a spindle speed of up to 12,000 rpm and a tool magazine capacity of 30 tools. It supports workpieces up to Ø500 mm by 350 mm and has a table load capacity of 300 kg. Consider the opportunity to buy this Mazak Variaxis i-500 universal machining centre. Contact us for more information about this machine.

This 5-axis DMG MORI HSC 70 linear was manufactured in 2014. It features impressive travel dimensions of 650 mm in X, 600 mm in Y, and 380 mm in Z. The machine is equipped with a spindle speed of up to 18,000 rpm and a tool magazine with 30 positions. If you are looking to get high-quality machining capabilities, consider the DMG MORI HSC 70 linear universal machining centre we have for sale. Contact us for further details.

This 5-axis DMG ULTRASONIC 50-5 Linear was manufactured in 2010. It features a traverse range of 500 mm in the X-axis, 450 mm in the Y-axis, and 400 mm in the Z-axis. The machine is equipped with a USB 1818 hybrid spindle, offering speeds from 200 to 18,000 rpm for both ultrasonic hard machining and milling. If you are looking to get high-quality machining capabilities, consider the DMG ULTRASONIC 50-5 Linear universal machining centre we have for sale. Contact us for further details.

This 5-axis HNK HPM 30M gantry milling machine was manufactured in 2014. Ideal for complex and precise milling tasks, it offers enhanced flexibility and accuracy. Consider the opportunity to buy this HNK HPM 30M gantry milling machine. Contact us for more information about this machine.

This 3-axis Optimum Optimill F150 was manufactured in 2017 and features a Siemens Sinumerik 828D control system, a vertical spindle type SK40 with a speed range of 10-10,000 rpm, and a carousel tool changer with a 16-tool capacity. It supports a maximum table load of 350 kg and includes a screw-type chip conveyor. If you are looking to get high-quality milling capabilities, consider the Optimum Optimill F150 machine we have for sale. Contact us for more information.

This Okuma MCR-A5C30x65 gantry milling machine was manufactured in 2013. It features a robust 100 mm spindle, capable of speeds up to 4000 min⁻¹, and accommodates a maximum workpiece size of 2540 mm by 5540 mm. The machine supports a hefty 30,000 kg on its 2500 × 6300 mm table. Ideal for heavy-duty milling with a rapid feed rate of 20,000 mm/min. Contact us for more information about this machine.

This 3-axis Hyundai SPT-V30TD was manufactured in 2001. It features a spindle speed of 8,000 rpm, table dimensions of 600 x 380 mm, and a maximum table load of 200 kg. Ideal for milling applications, it offers X, Y, and Z travels of 500 mm, 300 mm, and 300 mm respectively. Consider the opportunity to buy this Hyundai SPT-V30TD vertical machining centre. Contact us for more information about this machine.

This 3-axis Datron M8A was manufactured in 2013. It features an impressive X-axis travel of 1020 mm, Y-axis travel of 700 mm, and Z-axis travel of 240 mm. The machine is equipped with a high-speed spindle capable of reaching 40,000 rpm and has a tool magazine with 18 positions. If you are looking to get high-quality machining capabilities, consider the Datron M8A vertical machining centre we have for sale. Contact us for further details.

This 5-axis RASOMA EBZ 200-500 was manufactured in 2018, featuring a robust 16,000 kg weight and comprehensive dimensions of 10800 × 2700 × 3100 mm. It includes a high-performance tool spindle with a 7.5 kW Siemens motor, capable of speeds up to 2000 rpm, and advanced cooling and hydraulic systems ensuring efficient operation. If you are looking to get high-quality milling capabilities consider the RASOMA EBZ 200-500 machine we have for sale. Contact us for more information about this machine.

This Okuma MA-500HA was manufactured in 2004. A robust horizontal machining centre, it features a spacious X-axis travel of 700mm, Y-axis of 900mm, and Z-axis of 980mm. It includes a high-speed spindle capable of 20000 RPM and an efficient through coolant pump. For more information about this horizontal machining centre, please reach out to us.

This 3s HAAS VF-5/40 vertical machining centre was manufactured in 2023. It features an impressive X-Axis travel of 1270 mm, Y-Axis travel of 660 mm, and Z-Axis travel of 635 mm, making it suitable for various machining tasks. With a spindle speed of 8100 rpm and a tool changer capacity of 20/24+1 stations, consider the opportunity to buy this HAAS VF5/40 vertical machining centre. Contact us for further details.

Worktable size 710x710 mm, including cabinet with various accessories

Incl. peripherals and documents Dismantled for transport Video available!
