milling machines used for sale (2,381)

Indexing faceplate Hand operated Maualy operated Plate diameter 500mm T-Slot 19 mm Weight 185 kg

Tool Milling Machine Cover FP4MK 2203 Travel XYZ: 500-400-400 mm Spindle mount: ISO 40 Spindle speeds: 50-2500 Universal Rotary Table 2038 incl. Angle Counter VRZ560 Active Digital Display 3 Axes Heidenhain TNC113 Hydraulic drawbar for DIN 2080 Quill with 90 mm stroke Coolant system Incl. vice Weight approx. 1700 kg Year of construction approx. 1992

- KOSMO 3 indexing head Sk-50, 0,02 Degrees, 1195 Nm- Spindle extention L = 600 mm with 2000 Rpm- 3D Measuring probe MP60- ATC Chain 60 Positions- Coolant system 1320 L with 4,8 Bar- Rotary indexing table  2000 x 1600 x 15 ton- V-Axis (in feed) 1500 mm- Rotation 3 U/Min- HeidenHein RON 700 encoder for Table rotation- Ram size 500 x 500 with 56 kW- Chip conveyor

Key data: 4230 mm, 2100 mm, 850 mm

X-axis: 4,230 mm Y-axis: 2,100 mm Z-axis: 850 mm CNC control: Heidenhain TNC 530 Spindle mount: ISO 50 Spindle speed: 6,000 rpm Tool changer: 30 places Table dimensions: 4,000 x 1,650 mm Stand spacing: 2,300 mm Equipped with: - Angle milling head - Touch probe button - Inner spindle cooling - Double chip conveyors - Cooling system -Operating instructions Country of origin: Taiwan Machine LxWxH: 9,000 x 3,500 x 4,000 mm +/- Machine weight: 30,000 kg

Key data: 3000 mm, 2000 mm, 1150 mm

X-axis: 3,000 mm Y-axis: 2,000 mm Z-axis: 1,150 mm Table dimensions: 2,800 x 1,500 mm Spindle mount: ISO 50 Spindle speed: 30 - 6,000 rpm Tool changer: 50 places CNC Control: OSP7000M Stand spacing: 2,050 mm Equipped with: - Angle milling head - Touch probe button - Double chip conveyors (recently renewed) - Cooling plant (recently renewed) -Operating instructions Country of origin: Japan Machine LxWxH: 9,000 x 3,500 x 3,500 mm +/- Machine weight: 27,500 kg

Key data: 1000 mm, 500 mm, 530 mm

Like new: X-axis: 1,000 mm Y-axis: 500 mm Z-axis: 530 mm Table dimensions: 406 x 1,372 mm Spindle mount: BT 40 Spindle speeds: 1 - 8,000 rpm Control: Fagor Equipped with: - Coolant system -Operating instructions Country of origin: Taiwan Engine power: 10 hp Machine LxWxH: 2,900 x 2,280 x 2,550 mm Machine weight: 3,100 kg

- Y Travel with head 180 = 3700- Y from floorplate to spindle middle = 4200 mm- Chain ATC Tool changer 80 positions- Rotary table 1500 x 1500 with V-Axis 1500 mm- Table load 15.000 Kg- Optional Box table 3500 x 1000 x 1000 mm- Under power - Spindle hours 9300 H

- Head Pick up Station- CNC Indexing Micro Head 0.001 Gr- Spindle extionsion- Internal coolant system- ATC Chain Tool changer 60 Positions- Under power

CNC Floor Milling Machine for Bed CNC control Heidenhain iTNC 530 Controlled NC table 1600 x 1600 mm Table dimensions 5500 x 2600 mm Travel X-axis 8000 mm Y-axis travel 2100 mm Travel Z-axis 1300 mm Travel W-axis 1000 mm C-axis swivel of the milling head body by 360° A-axis swivel of the milling head by 180° Spindle speed 36 - 6,000 rpm Spindle motor 42 / 30 kW Spindle holder DIN 69871-SK 50 Tools in Tool Magazine 48 If you have any questions about the machine, please do not hesitate to contact us by phone or e-mail. Feel free to check out our other ads for a full overview of our stock.

- Double guideway two box way construction- Head changer for Multi-Face machining off larger compontents- ATC tool changer for Horizontal and vertical milling head swivabel- Distance table spindle nose    213 - 1093 mm- Distance table spindle center  130 -  ...mm- Indexing Horizontal head 5 Degrees x 72 positions- HeidenHain iTNC530 with HR410 handwheel- Spindle torq 1018 Nm ISO50 - Universal Huron type milling head

- Seperate coolant and frequency converter- Last service & Test Log in 2018- Run out in 1 uM

- Z Axis 1100 mm- X Axis 1310 mm- C Axsi Endles- Working range stage 1: 4000 - 8500 mm- Working range stage 2: 4000 - 11.500 mm

Duplex milling are two machines located one opposite the other which can work seperately or as single machine, workpiece can be machined with 2 simultaneous spindles.- Production increase of up to 50% in relation to conventional solutions, i.e. individual milling machines- Improvements in part precision, by managing to do the machining of the part in one single setup, in most of the cases- One sole operator can control the DUPLEX milling machines- Reduced space and investment requirement comparing with two single machines- Fast investment amortisation due to the high productivity- Duplex solution admits different configurations: single working area, pendulum working areasFor machining excavator arms / boom like, CAT, Caterpillar, Komatsu, Hitachi, Hyundai, Doosan, Case, Bobcat, JCB, Kobelco, Liebherr, Kubota, Takeuchi, Volvo

- Universal head (U-25)- Coolant system- Hydraulic tool clamping

- FP Model ideal for variety of application Medium-Large size Components- Floor type milling boring machine- High dynamics with speeds of 35M/Min- INA linear guiding system - Hydro mechanical clamping slides- Orthogonal milling head for machining at any desired angle- Y Travel = 2600 + 500 head upright = 3100 mm stroke in Y Axis

- Chip conveyor- Laser tool setter- Portal Handwheel- Full A/B-Automatic head- High pressure coolant

- Aiptek ATC 30 positions- Automatic head 2.5 x 2.5 Gr- Central lubrication- Machine housing with front doors- Large tool package

ATC Chain 40 positonsMax. tool size  Ø 125 x 400 mmMachine prepared for rotary table Chip conveyorCentral lubricationStroke with vertical head rotated 3300 mm

- Chip conveyor- High preessure coolant 25 Bar- ATC chain 60 posiions- Optional Magnet table clamping system- Auto index head 1 Gr.

- Chip conveyor- Double doors front side- Chain Tool chnager 30 positions- Central lubrication- IKZ 16 Bar and 2,2 kW Flow 16L/Min- Tool blocking power 1968 daN- Full set books and 1e owner machine

Producent INTOS Zebrak Tjechië Type FNGJ 20 Chalkboard afmeting breedte x lengte 400 x 256 mm Longitudinal Plaatsing X=as 450 mm Dwarsverplaatsing Y=as 300 mm Verticaleverplaatsing Z=as 350 mm Spindle opname SK 40 DIN 2080 Spindle toerental 50 -2500 rpm. Aantal toerentallen 18 Sheet voeding X-Y as 8-400 mm/min. Sheet voeding Z as 4-200 mm/min. Rapid traverse X-Y as 2400 mm/min. Rapid traverse Z as 1200 mm/min. Electrified capacity 2.2 kW Afmetingen L x W x H 1735 x 1475 x 1660 mm Weight 1660 kg Standaard toebehoren Koelmiddel inrichting Heidenhain uitlezing met taster

Key data: 5000 mm, 3100 mm, 1200 mm

Machine Type: CNC Gantry Milling Machine Make CORREA Type Rapid 50 Year of manufacture 2004 Heidenhain control type Table dimensions (mm) 5000 x 2000 mm X-way (mm) 5000 mm Y-way (mm) 3100 mm Z-way (mm) 1200 mm Table load max. 15 ton Speeds of (rpm) max. 18,000 Tool holder HSK 63 Total power(KW) 20/27 Length (mm) 15000 Width (mm) 6200 Height (mm) 6000 Weight 65 ton

Make: Tos Machine No: F641 Type SPEEDtec CNC brand Siemens CNC type Sinumerik 840D Year of construction 2009 X 1,250 mm Y 1,000 mm Z 600 mm Mounting HSK 100 Motor power 25 kW Speed 12000 RPM Tool Changer Number of pallets 4 Outgoing Aries Including manuals Maximum speed 12,000 RPM Maximum pallet load 4,000 kg Chip transport Magazine slots: 2x 40 , HSK 100 4 tables, 1x 1,000 x 1,250mm / 3x 1,000 x 1,000mm

Key data: 6000 mm, 2000 mm, 3000 mm

Machine Type: CNC Travelling Column Milling Machine Make ZAYER Type KCU6000 Year of construction 1992 Control type Heidenhain TNC 415 X-way (mm) 6,000 Y-off (mm) 2,000 Z-off (mm) 3,000 Speeds from (rpm) 20 - 1,800 Tool holder BT50 Feed longitudinal (mm/rev) 5 - 5000 mm/min Feed Transverse (mm/U) 5- 5000 mm/min. Vertical feed rate (mm/rev) 5- 5000 mm/min. Rapid traverse 10,000 mm/min. Total power(KW) 34 Length (mm) 11,000 Width (mm) 2,500 Height (mm) 7,000 Weight 31.000 kg Information 'Juaristi MG6' rotary table: 1500 x 1200 mm With coolant pump Cooling system: 2.5 bar Tool cooling: 15 bar

Key data: 4300 mm, 1200 mm, 1050 mm

Brand: Anayak Engine No: F607 Type HVM-5000 CNC brand Heidenhain CNC Type TNC-426 Year of manufacture 1997 Table length 5,000 mm Table width 1,000 mm X 4,300 mm Y 1,200 mm Z 1,050 mm Tool Changer 40 Probes Milling head B as gestuurd Huron Milling Head Pivot BT 50 CNC controlled milling head Index after 2.5 ° Number of axes 4 Cooling by spindle Conveyor Machine weight +- 35000 kg Movable column

Key data: 6300 mm, 1800 mm, 2500 mm

Brand: Anayak Engine No: F712 Type HVM 7000-MG CNC brand Heidenhain CNC type iTNC 530 Year of manufacture 2005 Table length 3,300 mm Table width 1,200 mm Maximum table load 15,000 & 28,000 X 6,300 mm Y 1,800 mm Z 2,500 mm Holder SK 50 Speed 60 - 3,000 RPM CNC controlled milling head Index after 2.5 ° Controlled rotary table 360 ° - 2,000 x 3,000 mm Cooling by spindle Conveyor Turn on the spindle 37/51 Kw Max. workpiece weight 28,000 kg Machine weight 65,000 kg

Key data: 3600 mm, 1250 mm, 1600 mm

Brand: Kiheung Machine No: F668 Type KNC-U1000 CNC brand Heidenhain CNC type TNC 426 Year of construction 2002 Table length 4,100 mm Table width 1,050 mm Maximum table load 8,000 kg X 3,600 mm Y 1,250 mm Z 1,600 mm Holder BT50 Fast 10,000 m/min Speed 0 - 4,000 RPM Movable table Huron Milling Head CNC controlled milling head Conveyor Machine size (LxWxH) 11,000 x 5,000 x 3,800 mm Machine weight 28000 kg Magazine slots: 30 Spindle drive motor: 29 Kw Equipped with 4th axle. Table diameter: 630 mm Ø Load: 900 kg
