basic foodstuffs and animal feeds machines used for sale (505)

Stock#: U2466-1 Used stainless steel round vibrating screen by Allgaier (D) model D1200. Screen has working diameter 1200 mm. Single deck and cleaning deck with rubber balls. Central feeding inlet has diameter 200 mm. Side wall outlet has connection 145 mm. Central discharge of final product has diameter 200 mm. Screen is driven by two vibrating motors, each: 0,75 kW, 1000 rpm, 220-240/380-415 V, 50 Hz, kN 11,1 Ex design. Machine is mounted on stainless supporting frame. Additional equipment: - gravity feed metal detector by Cassel (D) model Shark 2, on stainless steel supporting frame - carbon steel construction frame with discharge stainless steel pipe and butterfly valve.

For sale: Homogeniser Alva Laval SHL25 capacity 2850-7800 L/H 250 bar

Manufacturer: INOTEC - overhauled Type: WT97-SH Power: 2 kW Weight: approx. 480 kg Length x width x height: 998 x 850 x 1740 mm - Calibers from 17 to 46 mm - Infinitely adjustable speed from 0.25 m/s to 0.8 m/s Request a quote iNTER-WiBA Sp.J. Ul. Krakowska 263 PL 43-305 Bielsko-Biala VAT number: PL547-17-47-669 tel. 0048 33 812 58 60

Cooling aggregat ZCH -3 - NEW External dimensions: L 1300 x W 750 x H 1250 mm Weight: 190 kg Request a quote iNTER-WiBA Sp.J. Ul. Krakowska 263 PL 43-305 Bielsko-Biała Identyfikator VAT: PL547-17-47-669 tel. 0048/33 812 58 60 Faksu. 0048/33 812 58 36

Stock# U2453 Used stainless steel contact parts ribbon mixer by Yanagiya (JP). Mixing chamber has internal dimensions: L 598 mm x W 500 mm x D 550 mm. Total volume of mixing chamber 145 l. Working volume approx 100 l. Side walls have welded atmospheric stainless steel jacket, which has bottom discharge outlet with valve. Mixer has mixing shaft with bolted stainless steel ribbon, belt driven by el motor 1.5 kW, 1420 rpm, 380 V, 50 Hz. Discharge of chamber by tilt, via manually operated wheel. Mixer is mounted on mobile carbon steel base and is equipped with local control panel. Shipping dimensions: L 145 cm x W 95 cm x H 160 cm x weight about 800 kg.

Stock# U2452 Used stainless steel two decks tumbling screen by Allgeier-Werke Gmbh & Co KG (Germany) model TSM 950/3. Body and contact parts made of stainless steel. Machine has 2 decks with diameter 950mm and has cleaning rubber balls on 2 deck. Central top inlet and 3 side outlets. Machine is driven by ele. motor with power 1.5 kW, 1430 rpm 220/380 volts, 50 Hz. Screen is mounted on carbon steel based. The set with machine includes a third deck with balls without a screen.

Stock# U2448-3 Used Jehmlich (Germany) model Rekord BT turbo/cage mill designed in carbon steel. Mill has rotor with diameter 320 mm and insert with screen. Insert has outside diameter 380 mm. Top feeding, via carbon steel hopper. Bottom discharge outlet. Mill is belt driven by an explosion-proof electric motor with a power of 18.5 kW, 2930 rpm, 400 V, 50 Hz. Mill is mounted on carbon steel frame.

Stock# U2448-2 Used pin mill by Jehmlich (Germany) model Rekord D, designed in carbon steel. Mill body made of cast iron. Unit has milling discs with a diameter of 610 mm made of carbon steel. Mill has one fixed and one rotating milling disc driven by a belts driven with an ex proof electric motor with a power of 22kW, 2940 rpm, 380 V, 50 Hz. Machine is equipped with a carbon steel feeding hopper and bottom unloading. Whole thing is mounted on a frame made of carbon steel. The set includes a spare set of milling discs and pins. Not included technical documentation.

Stock# U2448-1 Used pin mill by Jehmlich (Germany) model Rekord D, designed in carbon steel. Mill body made of cast iron. Unit has milling discs with a diameter of 610 mm made of carbon steel. Mill has one fixed and one rotating milling disc driven by a belts driven with an ex proof electric motor with a power of 22 kW, 2945 rpm, 380 V, 50 Hz. Machine is equipped with a carbon steel feeding hopper and bottom unloading. The set includes a stainless steel hopper tank mounted on 4 carbon steel legs and a belt conveyor with a polyurethane fabric/plastic belt with a working width of 245 mm and a length of 3800 mm, conveyor construction is made of carbon steel and mounted on legs. The belt is driven by a gearbox with a ratio of i=15, an ex proof electric motor with a power of 1,1 kW, 1415 rpm, 380 V, 50 Hz. Whole thing is mounted on a frame made of carbon steel. Also includes a spare set of ...

Manufacturer: BIZERBA Type: FK 23 Band Saw BIZERBA Type FK 23 Cutting and portioning of fresh meat with or without bone as well as cutting of long bones, poultry and fish Cutting height 251 mm Cutting thickness 10-190 mm Saw blade speed 17 m/sec Dustbin System for clamping and releasing the saw blade Height-adjustable saw table Protection class IP 55 Voltage 400 V 50 Hz Request a quote iNTER-WiBA Sp.J. Ul. Krakowska 263 PL 43-305 Bielsko-Biala VAT number: PL547-17-47-669 tel. 0048 33 812 58 60

Stock# U2435-1 Used stainless steel ribbon mixer made by Consumasz (Poland) type M-01 with total volume 1100 l and working volume 850 l. Mixing chamber has internal dimensions: L 1990 mm W 830 mm x D 1175 mm. Mixer is feeded from the top via cylindrical sifter type PC-400, driven by gearbox and el motor 4 kW, 1445 rpm, 220/380 V, 50 hz, or directly through inlet 205 mm x 205 mm. Mixer has single shaft equipped with welded double ribbons. Shaft is driven via gearbox and el motor 15 kW, 1460 rpm, 380 V, 50 hz. Gearbox reduction i= 36,9. Working rotation of shaft up to 39 rpm. Mixer has side wall inspection manway with dimensions 540 mm x 365 mm, and bolted stainless steel lid. Central bottom discharge outlet has diameter 200 mm and is equipped with manually operated valve. Product is droped into the hopper of discharge screw conveyor with screw diameter 200 mm and working length 1000 m ...

Stock# U2423-2 Used stainless steel conical nauta type powder mixer by Pharming type HV 600 (CZ). Cone has diameter 1440 mm x height 1855 mm. Total volume of tank about 1300 l, working volume up to 600 l. Total height 2770 mm. Standard mixing screw is top driven by el. motor 3 kW, 965 rpm, 230-400 V, 50 hz, and supported by bottom pintle bearing. Arm rotation - 2 rpm. Screw rotation - 60 rpm. Discharge via bottom rotary slide outlet valve, operated manually. Mixer is mounted on 3 lugs with carbon steel supports. Included technical documentation. Shipping dimensions: length 277 cm x diameter 180 cm x weight 600 kg. Machine had been working in food industry.

Stock # U2423-1 Used stainless steel conical nauta type powder mixer by Pharming type HV 1000 (CZ). Cone has diameter 1550 mm x height 2200 mm. Total volume of tank about 1700 l, working volume up to 1000 l. Total height 324 cm. Standard mixing screw is top driven by el. motor 3 kW, 970 rpm, 230-400 V, 50 hz, and supported by bottom pintle bearing. Arm rotation - 2 rpm. Screw rotation - 60 rpm. Discharge via bottom rotary slide outlet valve, operated manually. Mixer is mounted on 3 lugs with carbon steel supports. Included technical documentation. Shipping dimensions: length 330 cm x diameter 170 cm x weight approx 1000 kg. Machine had been working in food industry.

Stock number: U2395-3 Used vertical stainless steel silos for powders with total volume about 6000 l. Tank has internal diameter 180 cm x length of straight side of wall 144 cm. Silos has conical bottom, equipped with vibrating discharge outlet driven by el vibrating motor and pneumatically operated valve. Diameter of discharge 200 mm. Silos had been mounted on cylindrical support. Feeding inlet via top located connection to pneumatic conveyer. Silos has side wall rectangular connection for dust filter with dimensions 570 mm x 490 mm. There is a inspection manway with bolted lid with diameter 500 mm. Last time used in food industry.

Stock# UG6345 Unused atmospheric cabinet dryer by Airflow Premier Industrial Oven (UK). Chamber construction mild steel. Inside dimensions of drying chamber: W 3250 mm x D 1850 mm x H 2050 mm. Working temperature range up to 60C. Dryer is equipped with 2.2 kW centrifugal fan, whch can give air circullation up to 4.2 air change per minute. Heating - electric - 15 x el heaters each with power 3 kW. Outside dimensions: W 3500 mm x H 2900 mm x D 2200 mm. Machine has local control panel.

Stock number U2387-1 Used mixing station for liquids. Station consist of vertical stainless steel mixing tank with total volume 1300 l. Internal diameter 1170 mm x length of straight side of wall 1140 mm. Bottom elipsoidal, with central discharge outlet. Tank is mounted on three stainless steel legs, on tension cells. On side walls there are welded four baffles. Mixing is provided by homogenizing agitator by IKA (DE) model Turrax UTC TMP 150 / 2KT, driven directly by 11 kW, 2915 rpm, 380/660 V, 50 hz. Length of the shaft 900 mm x diameter of mixing die 150 mm. Agitator is mounted on stainless steel supporting frame. Discharge from tank is provided by sinusoidal stainless steel contact parts pump by Masosine Process Pumps model SP 25, working on pressure up to 15 bar. Working rotation up to 600 rpm. Pump is driven by 2.2 kW, 1400 rpm, 220-380 V, 50 hz. Working rotation of drive up to 2 ...

stainless steel process tank capacity 0.25 m3 heating jacket thermal insulation stirrer for dense masses

CUTTING GATE FOR DICER RÜHLE typ SR 1- used Cutting gate sizes to the choice /optional/ : 6 and 24 mm Request a quote iNTER-WiBA Sp.J. Ul. Krakowska 263 PL 43-305 Bielsko-Biala VAT id: PL547-17-47-669 tel. 0048/33 812 58 60 Fax. 0048/33 812 58 36 abc.inter-wiba.com.pl info@inter-wiba.com.pl

Extruder for food products. producer: model: MU A14342 machine performance: 1200 kg/h year: 2017

Stock# U2284 Used stainless steel paddle mixer for continous work by Gloucester Material Handling Ltd (UK) with total volume 2700 l. Internal diameter of mixing chamber 1100 mm x 2840 mm length. Top feeding inlet has dimensions: 300 mm x 300 mm. Bottom front outlet has dimensions 300 mm x 440 mm. Mixer is equipped with stainless steel mixing shaft with welded 21 paddles. Front and back walls are bolted. Front wall is equipped with mechanical sealing of shaft. Back wall has standard sealing of shaft. Mixer had been running with electric motor 55 kW, 1500 rpm - but motor is not included. Mixer is equipped with gearbox and new mechanical sealing. No control panel included. Technical drawings of mixer and shaft are included. Mixer had been running in food production with reported output about 8-12 tons per hour. Machine is mounted on 6 stainless steel legs.

Stock# U2310 Used stainless steel two-stage piston homogenizer manufactured by Tetra Pak (Sweden) model Tetra Alex 20. Capacity up to 5000 l/h at 160 bar pressure. Number of pistons: 3. Piston diameter: 50 mm. Piston material: stainless steel. Main drive: ABB electric motor 30 kW, 400 V, 50 Hz, 1475 rpm, IP55. Hydraulic drive: 0.25 kW, 400 V, 50 Hz, 1410 rpm, IP55. Cooling water requirements: 130 l/h. Stainless steel covers included. Weight: 1355 kg.

Producer: H & K Model: CIP system Capacity: 1500 l Year of construction: 1983 The tank is equipped with a liquid manometer.

POWER ELECTRONICS ASSY - CONTROL BOARD FOR FILLING MACHINE VEMAG TYPE 134 ROBBY II - / PC 880 / ARTICLE NUMBER VEMAG: 871.371-004 871.380-002-574733-5LP210695 871.360-102 - 871.360-002 072.999-005 875.821-005 - 871.821-105 871.370-004 - 871.370-701 Request a quote iNTER-WiBA Sp.J. UL. Krakowska 263 PL 43-305 Bielsko-BiaÅ?a USt-IdNr.: PL547-17-47-669 Tel. 0048/33 812 58 60 fax. 0048/33 812 58 36

Height 1350 Width 1700 mm Length 700 mm Voltage Electrical: 400V 50Hz 3N Main material Stainlees Steel Chamber dimentions 500 mm

MANUFACTURER: Niro Atomizer CAPACITY: 1.183 Kg/h, , APPLICATION: Milk powder and whey powder production. MACHINE COMES WITH: External vibro fluid bed dryer, Niro F35 atomizer, powder cyclones, bag filters, air pre heating economizer unit, air heating unit with steam heat exchangers, vibro sieve powder calibration unit, air ventilators, air locks, rotary valves and many accesories...
