Processing Centers used for sale (284)

BAZ Heckert CWK 800 BJ 1999

CNC machining center Emco, type VMC 600, built in 1998 incl. handwheel + 3 vices with clamping device

Key data: 850 mm, 510 mm, 510 mm

General Manufacturer: Spinner Type: VC 850 Year of Make: 2022 Control: Siemens 840DE ShopMill Travel X/Y/Z: X 850 mm Y 510 mm Z 510 mm Working spindle Spindle speed: 18,000 rpm Tool holder: HSK63 Tool changer: 32-fold Voltage Operating voltage: 3x400V +/-10% Power frequency: 50Hz (+/-2%) Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Direct measuring systems in X/Y/Z Multifunction handheld operator Chip conveyor Preparation of standard probes

Key data: 850 mm, 510 mm, 510 mm

General Manufacturer: Spinner Type: VC 850 Year of Make: 2021 Control: Siemens 840DE ShopMill Travel X/Y/Z: X 850 mm Y 510 mm Z 510 mm Working spindle Spindle speed: 18,000 rpm Tool holder: HSK63 Tool changer: 32-fold Voltage Operating voltage: 3x400V +/-10% Power frequency: 50Hz (+/-2%) Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Direct measuring systems in X/Y/Z Multifunction handheld operator Chip conveyor Preparation of standard probes

BAZ Hurco VMX 40 built in 2001

Key data: 3850 mm, 350 mm, 280 mm

3-axis machining centre with automatic tool change for aluminium or PVC profiles Max. travel X-axis: 3,850 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Windows control with USB ports Speed infinitely variable up to 22,000 rpm Boc Hqjyqyaqoa R H Towi Hand-held control unit Minimum quantity spraying Tool changer with 2 magazines (a total of 10 places plus angle head) Tensioner detection and clamp displacement 2 light barrier areas and 2 material stops, thus pendulum operation possible A total of 8 material tensioners Spindle in good condition, spindle pull-in force: 12 kN Weight: approx. 2,000 kg

BAZ lid Maho DMF 250 linear BJ 2002 BAZ Cover Maho DMC 63 H BJ 2002

Table: 450 x 500 mm 60 Way Tool Changer IKZ Breakage control lasers 5 axes Further technical information on request

3 pcs double spindle machining centers SW BA422 built 2015/2014/2014 - 4-axis version Workspace x-axis 400 mm y-axis (tool change position) 500 (775) mm z-axis 425 mm Spindle spacing 400 mm Double swivel beam (Q-axis) 0 – 180° with NC rotary axes and counter bearings ----- Number of spindles 2 Spindle speeds up to 17,500 1/min Power 40/ 100% ED 2x 35/26 KW / 80 Nm ----- Feed/rapid traverse x/ y/ z 55/ 70/ 70 m/min Tool magazine 2 x 60 tool positions Tool holder HSK 63 Max. tool diameter 80 / 160 mm Max. tool length 300 mm Max. tool weight 10 kg Installation area L x W x H approx. 7.0 x 4.0 x 4.38 m Machine weight approx. 18,000 kg Transport weight approx.  ...

Cincinatti Machining Center, 2 Available: Arrow/Milacron 500, built in 1995 & 2000 Technical data: Travel (X / Y / Z) 510 mm / 510 mm / 510 mm Work table (L × W) 700 × 520 mm Maximum table load / workpiece weight approx. 350 kg evenly distributed Tool changer (tool magazine) 21 tool positions Spindle holder / tool holder SK 40 Spindle speed (min–max) 60 – 6000 rpm (sometimes specified for newer variants up to 8000 rpm) Machine weight approx. 3050 kg (≈ 3 t) Dimensions approx. 2000 × 2650 × 2700 mm (L × W × H) Number of axles 3-axis CNC

Key data: 630 mm, 1100 mm, 600 mm

Clamping area: Ø700 x 500 mm Rapid traverse X/Y/Z: 60/60/56 m/min Milling spindle Max. spindle speed: 18,000 rpm SK-40 Other equipment Air on the workpiece Cooling by the spindle, 70 bar Renishaw RMP 600 Probe F) Tool tip control 5-axis simultaneous machining Tool radius compensation – 5-axis simultaneous Drilling cycle with torque-dependent chip breaking G00 slope constant Synch. Threading Cylinder interpolation EIA Dynamic Compensation 2 (included 1) KNOLL Coolant System KF200/1250 Paper Belt Filter 70 bar high-pressure pumoe KNOLL Chip Conveyor 640-S-1

2 x BAZ DMG DMU 60T BJ 2000/2002

Vertical machining center Travel x/ y/ z = 1020/ 600/ 500 mm Table size 1250 x 600 mm max. workpiece weight 800 kg Tool magazine 32 Tool positions HSK 63 Rapid traverse 70 m/min CNC control Heidenhain iTNC 530 Chip conveyor Coolant system

General Manufacturer: Hermle Type: C 40 U Year of Make: 2005 Control: Heidenhain TNC 430 Travels: X 850 mm, Y 700 mm, Z 500 mm B swivel axis Working spindle Speed: 28,000 rpm Tool/movement Tool changer: 38-speed Tool holder: HSK63A Dimensions and weight Weight: 10,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included Spindle coolers IKZ high-pressure system 80 bar Blum Laser Measurement Workpiece probes Electric Handwheel HR410 Chip conveyor Oil mist extraction

Key data: 762 , 508 , 508

HAAS UMC-750SS Machining Center TECHNICAL FEATURES: Year: 2019 Number of continuous axes: 5 X-axis stroke: 762 [mm] Y-axis travel: 508 [mm] Z-axis travel: 508 [mm] C-axis angular travel: 360 [°] Table dimensions: Ø630 x 500 [mm] Maximum weight Tabletop Allowance: 300 [Kg] B-axis angular travel: +110 [°] / 350 [°] Pin Attachment: CT 40 Maximum speed Spindle: 15000 [rpm] Spindle power: 22.4 [kW] Number of tool magazine stations: 40 Capacity of the garden tray: 284 [l] Number of hours in operation: 5277 [h] EQUIPMENT INCLUDED: x1 Center-Spindle Watering x1 High Pressure Coolant Pump 21 [bar] x1 RENISHAW Wireless Coin Probe x1 Calibration Sphere x1 RENISHAW Tool Probe x1 HAAS Oil Mist Vacuum x1 HAAS offset crank x1 HENNIG Chip Conveyor Type 101435 Machine visible under tension for testing at our premises, by appointment. Price excl. VAT on request,  ...

3-axis machining centre with automatic tool changer for aluminium or PVC profiles Max. travel X-axis: 3,850 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 280 mm Control E 550 Speed infinitely variable up to 21,000 rpm Manual control unit Minimum quantity spraying Automatic tool change with magazine (4 places plus angle head) Tensioner detection and clamp displacement 4 pneumatic material clamps light barrier Weight: approx. 2,000 kg

General Manufacturer: Chiron Type: DZ 28 P five axis Year of manufacture: 2023 Control: Siemens Sinumerik 840D SL Travels: X 1,200 mm Y 1,100 mm Z 800 mm Rapid traverse: X 120 m/min Y 75 m/min Z 75 m/min Axle acceleration: X 1.0 g Y 0.8 g Z 1.5 g Main spindle drive Speed: up to 20,000 rpm 2-axis torque swivel device 2 x face plates diameter: 479 mm Swivel axis as A-axis Swivel angle: ± 120° Swivel radius: 700 mm Bridge dimension: max. 2,400 mm Repeatability: ± 5" Speed: 42 1/min NC rotary table as C-axis Clamping force: 25 kN +/- 15 % per clamping segment Repeatability: ± 5" Speed: 100 1/min Loading and unloading station for tools Tool Stations: 2 x 36 Tool shank: HSK-A 63 DIN 69893 Tool diameter: max. 78 mm Tool diameter with free adjacent spaces: max. 160 mm Tool length: max. 450 mm Tool weight: max. 10 kg Tool change time: approx. 0.9 s Ma ...

Key data: 762 mm, 460 mm, 460 mm

Vertical machining center Okuma MB-46UAE Year of Make: 2004 Control OSP U100M Machinery ▪ Spindle – speed 8000 rpm. ▪ High-speed machining (Hi-Cut) ▪ Spindle load monitor (load monitoring) ▪ Thread milling (Herical-Cut) ▪ Workpiece zero points 50 pieces ▪ 200 Tool Corrections ▪ Manuals available (documentation) ▪ Tool changer with 32 positions ▪ Internal coolant supply Technical details ▪ Travel X-axis (column right-left): 762 mm ▪ Travel Z-axis: (table forward-backward): 460 mm ▪ Y-axis travel (spindle up-down): 460 mm ▪ Distance table surface to spindle nose: 150~610 mm Table ▪ Table size: 1000 x 460 mm ▪ Distance from the floor to the table surface: 800 mm ▪ Max. load capacity: 700 kg Spindle ▪ Spindle speed: 8,000 rpm ▪ Number of gears: infinitely variable ▪ Front bearing diameter: 70 mm ▪ Spindle: 11/7.5 kW � ...

5-axis machining centre with tool changer for aluminium or PVC profiles Max. machining length: 9,000 mm Y-axis travel: 1150 mm Travel Z-axis: 715 mm Swivel angle A-axis: 0° - 180° Angle C-axis: 0° - 180° Max. speed 24,000 rpm Spindle power: 21 kW Tool changer with 13 standard and 7 special tools Minimum quantity spraying Tensioner detection and automatic displacement 12 pneumatic material tensioners Pendulum operation through two light barrier areas Manual control panel Loading is included in the price Weight: approx. 8,500 kg

4-axis machining centre with 8-fold tool changer for aluminium or PVC profiles Max. machining length: 3,100 mm Y-axis travel: 850 mm Travel Z-axis: 650 mm Swivel angle A-axis: 0° - 180° Max. speed 21,000 rpm Weight: approx. 3,000 kg Windows 7 Operating System Minimum Quantity Spraying Tensioner detection and automatic displacement 6 pneumatic material clamps 2 material stops Loading is included in the price

Key data: 1050 mm, 560 mm, 460 mm

incl. Robojob Mill-Assist Manufacturer: Okuma Type: Genos M 560-V-e Travels: X: 1050 mm, Y: 560 mm, Z: 460 mm Table size 1300 x 560 mm Maximum table load: 900 kg Tool Stations 32 Control: Okuma OSP-P 300Ma-e (NC-controlled) Serial number: 0712-101084 Year of manufacture: 2018 Accessories: Chip conveyor High pressure pump 15 bar, Internal cooling pneum. Peeping tom loading door, Automation: Robojob Mill-Assist Essential Robot interface Length probe Renischaw

Key data: 1050 mm, 560 mm, 460 mm

Table size 1300 x 560 mm Tool Stations 32 Control: Okuma OSP-P 20 M Serial Number: 155968 Year of manufacture: 2011, retrofitted 2022 Accessories: Chip conveyor 4th axis, 0-point clamping plate 1 hinged quill

Key data: 2000 mm, 500 mm, 550 mm

Specifications: Manufacturer: Chiron Type: Mill 2000 high speed Control: Heidenhain TNC 530 Year of Make: 2013 Travels: X 2,000, Y 500, Z 550 mm Working spindle Speed: 12,000 rpm Start table Dimensions L/W: 2,600 x 550 mm Table load: 1,000 kg Tool/movement Tool holder: SK40 Tool changer: 40-fold Measuring system: direct X/Y/Z Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Conveyor Preparation FK7 Loading automatically "opening and closing" Tub flushing

Manufacturer: Burkhardt + Weber BW Model: MC 120 Year of Make: 1999 Condition: Used Control: Siemens Sinumerik 840C Pallet sizes: 4 pieces 1000 x 1000 mm, 2 pieces 1250 x 1000 mm, 13 pieces 1600 x 1000 mm Pallet system length: 47000 mm Clamping area: 630 x 800 mm Table load: 1500 kg Spindle taper: DIN 50 Spindle speed: 6000 rpm Engine power: 37 kW B-axis travel: 360° Tool magazine: 144 positions Fuel tank capacity: 230 l Spindle bearing and spindle housing overhauled 09/2024.

Switch-on hours 51800 h Program running hours 15100 h Specifications: Speed, max.: 12,000 rpm Power: 77 kVA Weight, approx.: 18,100 kg
