other metal working machines used for sale (11,592)

Powder curing furnaces in various sizes, gas or electric 1 Inner dimension length 1500 - 6,500 [mm] 2 Inner dimensions width 1700 - 1,900 [mm] 3 Inner dimensions height 2,000 [mm] 4 Steel profile substructure 5 walls Galvanized sheets 1mm on both sides, RAL on the outside 6 Insulation walls, ceiling rock wool 150mm 75Kg/m² 7 Floor furnace gets 2 entry rails for tray trolleys (optionally with conveyor technology) 8 Temperature 220°C 9 fans 1 - 2 pcs. 2600 - 15,000 [m³/h] 10 electric motors 1 - 2 pcs 1.1 - 6 [kW] , 1450 [rpm], 3 F, 50 [Hz] 11 Thermal power 14 - 99 [kW] 12 hinged or sliding doors on one or both sides 2 - 4 pcs insulated with rock wool 150mm 75Kg/m² Heating Indirectly via Thermoblock 13 Thermoblock Stainless Steel INOX AISI 316 Heating Electric or Gas Heat-Resistant Fans and Heat-Resistant Bearings, Thermoblock Has Overheating Protection

The continuous system consists of the following components: Chemical pre-treatment by spraying Dryer Powder coating system Powder curing furnace Conveyor technology (cycle method) Electrical control Overall length: 30,000 mm Overall depth: 4,300 mm Width: 6,500 mm Workpiece weight (max.): 100 kg Temperature: 220 °C Heat output: 80,000 W Workpiece width (max.): 800 mm Workpiece height (max.): 1,200 mm Workpiece length (max.): 2,500 mm Insulating material: Mineral wool 75 kg/m³ Insulating thickness: 150 mm

Powder furnace el. or gas Powder curing furnace 6,500 x 1,900 x 2,000 mm 1 Inner dimension length 6,500 mm 2 Inner dimensions width 1,900 mm 3 Internal dimensions height 2,000 mm 4 Substructure 1 set of steel profile 5 walls 1 set of galvanized sheets 1mm on both sides, RAL on the outside 6 Insulation walls, ceiling 1 set of rock wool 150mm 75Kg/m² 7 Bottom furnace gets 2 entry rails for tray wagons 8 Temperature 220°C 9 fans 2 pcs. 2x 7,500 = 15,000 m³/h 10 electric motors 2 pcs 2x 3 kW , 1450 rpm, 3 F, 50 Hz 11 Thermal power 110 kW 12 hinged doors on one side 2 pcs insulated with rock wool 150mm 75Kg/m² Heating Indirectly via Thermoblock 13 Thermoblock 1 set stainless steel INOX AISI 316 heater electric heat-resistant fans and heat-resistant bearings, thermoblock has overheating protection 14 burners 1 pc stove is electrically heated 15 Exhaust air 1 pc device fo ...

1. Powder curing furnace 1,500 x 1,200 x 1,750 mm 2. Powder Coating Booth -KG DUO-01 3. Wagner powder coating plant, – Prima Sprint – 1. Powder curing furnace 1,500 x 1,200 x 1,750 mm 1 Inner dimension length 1,500 mm 2 Inner dimensions width 1,200 mm 3 Internal dimensions height 1,750 mm 4 Outer dimensions incl. thermoblock length 2,250 mm 5 Outer dimensions incl. thermoblock width 1,815 mm 6 External dimensions incl. thermoblock height 2,006 mm, 2,296 mm incl. exhaust pipe 7 Substructure 1 set of steel profile 8 walls 1 set of galvanized sheets 1mm on both sides, RAL on the outside 9 insulation walls, ceiling 1 set of rock wool 150 mm, floor is insulated with 50 mm 10 Floor Furnace Gets 2 Entry Rails for Tray Wagons 11 Temperature 220°C 12 fans 1 pc. 2,600 m³/h 13 electric motors 1 pc 1.1 kW , 1450 rpm, 3 F, 50 Hz 14 Thermal power 14 kW 15 hinged doors, single ...

1.Powder curing furnace 2,000 x 1,900 x 2,000mm 1 Inner dimension length 2,000 mm 2 Inner dimensions width 1,900 mm 3 Inner dimension height 2,000 mm 4 Outer dimensions incl. thermoblock length 2,300 mm 5 Outer dimensions incl. thermoblock width 2,300 mm 6 Outer dimensions incl. thermoblock height 2,700 mm 7 Substructure 1 set of steel profile 50 x 50 mm 8 walls 1 set of double-sided galvanized sheets 1mm, outside RAL 5005 9 Insulation walls, ceiling 1 set of rock wool 150mm 75Kg/m² 10 floor stove gets 2 entry rails for tray wagons 11 Temperature 220°C 12 fans 1 pc. 6,000 m³/h 13 electric motors 1 pc 1.1 kW , 1450 rpm, 3 F, 50 Hz 14 Thermal output 36 kW = 30,960 kcal/hour 15 wing doors on one side 2 pcs insulated with rock wool 150mm 70Kg/m² Heating Indirectly via thermoblock Thermoblock 1 set stainless steel INOX AISI 316 heat-resistant fans and heat-resistant bea ...

Powder coating system for large parts Example:(all sizes can be changed individually) Space requirement: 30 x 15 meters Part size: L= 6,200mm W= 2,300mm H= 2,000mm Cleaning booth walk-in incl. spray wreath automatic 1 Dimensions of the cabin Length 9,000 mm Width 4,500 mm Height 3,400 mm 2 Mass of tanks Length 1,200 mm Width 850 mm Height 1,000 mm 2 Dimensions of the cabin complete Length 9,140 mm including tanks width 5,580 mm Height 4,200 mm Coating booth walk-in, manual coating Lmmuapd8S 1 Dimensions cabin length 9,000 mm Width 4,500 mm Height 3,400 mm 2 Dimensions of the cabin including extraction Length 10,125 mm Width 4,500 mm Height 3,400 mm Powder curing furnace 1 Inner dimension length 6,500 mm 2 Inner dimensions width 2,500 mm 3 Internal dimensions height 2,950 mm 4 Outer dimensions incl. thermoblock length 7,600 mm 5 Outer dimensions inc ...

.1.1. Powder Coating Booth, Open Spray Stand The overspray during powdering is absorbed by the extraction unit. The powder spray stand is delivered on rollers and is therefore mobile. - The extraction system is equipped with a 60 L powder container (rollable). - As a 1st stage, there are 4 filters in the extractor. - Above the cab is the absolute filter. 1 Dimensions of the powder stand width 2,450 mm Depth 2,350 mm Height 2,700 mm 2 fans 1 pc. 6,000 m³/h Electric motor 3.0 kW 3 Filters Φ 325x800 4 pcs Type Filter Cartridges 4 Electromagnetic Valves 2 pcs 1" "Turbo" Italy 5 absolute filters 1 pc. type pocket filter 2.1.2. Powder curing furnace Mzlxwbat 1 Inner dimension length 4,000 mm 2 Inner dimensions width 1,500 mm 3 Inner dimensions height 2,200 mm 4 Outer dimensions incl. thermoblock length 5,250 mm 5 Outer dimensions incl. thermoblock width 2,050 mm ...

Powder coating plant oven, cabin, etc. Powder Coating Booth Open Spray Stand Dimensions of powder level Width 2,000 mm Depth 2,100 mm Height 2,200 mm Fan 1 pc. 6000 m³/h Power 3 kW (electric motor) Filter 4 type filter cartridges (à ⌀325 x 600 [mm]) Electromagnetic valves 2 Pcs. 1" "Turbo" Italy Absolute filter 1 pc. type bag filter Powder Pistol Wagner "Prima Sprint" Mains Standard 230 VAC Frequency 50 – 60 Hz Input compressed air 6-8 bar Output compressed air 0.05 – 5.5 Nm³/hr. Powder curing furnace Inner dimension length 3,225 mm Inner dimension width 1,400 mm Inner dimensions height 2,000 mm Insulation rock wool 150mm [75 Kg/m³] Temperature max. 220°C Fans 1 pc. 4,500 m³/h Electric Motors 1 pc 1.5 kW, 1450 rpm, 3 F, 50 Hz Thermal power 39 kW Doors on both sides 2 pcs. Manual, insulated with rock wool 150mm 70Kg/m³ Heati ...

2.1.1. Walk-in cleaning booth, pre-treatment for steel and aluminium The cleaning booth is designed for automatic cleaning. Spraying can be done at medium pressure. There are 7 different spray tanks in the cabin. The part sizes are max. L= 6,000mm, W= 2,000mm, H= 2,300mm. 1 Dimensions of the cab length 6,500 mm Width 3,000 mm Height 3,600 mm 2 dimensions of the pre-treatment complete Length 6,600 mm Width 4,640 mm Debpm0Nom Height 4,300 mm 2.1.1.1. 1. Degreasing/Neutral Pickling Process Heated bowl, 50-55°C, time = 3-6 minutes, draining time = 80 seconds 2.1.1.2. 2. Process Acid Mineral Pickling Heated bowl, 50-55°C, time = 3-6 minutes, draining time = 80 seconds 2.1.1.3. 3. Rinsing Process 1 in this chamber rinsing is done at ambient temperature, time = 0.75-1.5 minutes, draining time = 1 minute 2.1.1.4. 4. Rinsing Process 2 in this chamber is rinsed at ambient tem ...

Powder curing furnace 4,500 x 1,900 x 2,000 mm electric 1 Inner dimension length 4,500 mm 2 Inner dimensions width 1,900 mm 3 Internal dimensions height 2,000 mm 4 Substructure 1 set of steel profile 5 walls 1 set of galvanized sheets 1mm on both sides, RAL on the outside 6 Insulation walls, ceiling 1 set of rock wool 150mm 75Kg/m² 7 Bottom furnace gets 2 entry rails for tray wagons 8 Temperature 220°C 9 fans 2 pcs. 2x 5,700 = 11,400 m³/h 10 electric motors 2 pcs 2x 2.2 kW , 1450 rpm, 3 F, 50 Hz 11 Thermal power 74 kW 12 hinged doors on one side 2 pcs insulated with rock wool 150mm 75Kg/m² Heating Indirectly via Thermoblock 13 Thermoblock 1 set stainless steel INOX AISI 316 heater electric heat-resistant fans and heat-resistant bearings, thermoblock has overheating protection 14 burners 1 pc stove is electrically heated 15 Exhaust air 1 pc device for exhaust air ...

Powder curing furnace 3,500 x 1,900 x 2,000 mm gas operation 1 Inner dimension length 3,500 mm 2 Inner dimensions width 1,900 mm 3 Internal dimensions height 2,000 mm 4 Substructure 1 set of steel profile 5 walls 1 set of galvanized sheets 1mm on both sides, RAL on the outside 6 Insulation walls, ceiling 1 set of rock wool 150mm 75Kg/m² 7 Bottom furnace gets 2 entry rails for tray wagons 8 Temperature 220°C 9 fans 1 pc. 7,500 m³/h 10 electric motors 1 pc 3 kW , 1450 rpm, 3 F, 50 Hz 11 Thermal output 58 kW = 49,880 kcal/hour 12 hinged doors on one side 2 pcs insulated with rock wool 150mm 75Kg/m² Heating Indirectly via Thermoblock 13 Thermoblock 1 set of stainless steel INOX with heat-resistant fans and heat-resistant bearings, thermoblock has overheating protection 14 burners 1 pc. stove is heated by gas burner. 15 Exhaust air 1 pc device for exhaust air pipe, m ...

Powder curing furnace 3,500 x 1,900 x 2,000 mm electric 1 Inner dimension length 3,500 mm 2 Inner dimensions width 1,900 mm 3 Internal dimensions height 2,000 mm 4 Substructure 1 set of steel profile 5 walls 1 set of galvanized sheets 1mm on both sides, RAL on the outside 6 Insulation walls, ceiling 1 set of rock wool 150mm 75Kg/m² 7 Bottom furnace gets 2 entry rails for tray wagons 8 Temperature 220°C 9 fans 1 pc. 7,500 m³/h 10 electric motors 1 pc 3 kW , 1450 rpm, 3 F, 50 Hz 11 Thermal power 58 kW 12 hinged doors on one side 2 pcs insulated with rock wool 150mm 75Kg/m² Heating Indirectly via Thermoblock 13 Thermoblock 1 set stainless steel INOX AISI 316 heater electric heat-resistant fans and heat-resistant bearings, thermoblock has overheating protection 14 burners 1 pc stove is electrically heated 15 Exhaust air 1 pc device for exhaust air pipe, manual flap ...

Powder curing furnace 2,000 x 1,900 x 2,000 mm 1 Inner dimension length 2,000 mm 2 Inner dimensions width 1,900 mm 3 Internal dimensions height 2,000 mm 4 Substructure 1 set of steel profile 5 walls 1 set of galvanized sheets 1mm on both sides, RAL on the outside 6 Insulation walls, ceiling 1 set of rock wool 150mm 75Kg/m² 7 Bottom furnace gets 2 entry rails for tray wagons 8 Temperature 220°C 9 fans 1 pc. 5,700 m³/h 10 electric motors 1 pc 2.2 kW , 1450 rpm, 3 F, 50 Hz 11 Thermal output 33 kW = 28,380 kcal/hour 12 hinged doors on one side 2 pcs insulated with rock wool 100mm 75Kg/m² Heating Indirectly via Thermoblock 13 Thermoblock 1 set of stainless steel INOX with heat-resistant fans and heat-resistant bearings, thermoblock has overheating protection 14 burners 1 pc stove is operated with gas burner 15 Exhaust air 1 pc device for exhaust air pipe, manual fla ...

Powder curing furnace 2,000 x 1,900 x 2,000 mm 1 Inner dimension length 2,000 mm 2 Inner dimensions width 1,900 mm 3 Internal dimensions height 2,000 mm 4 Substructure 1 set of steel profile 5 walls 1 set of galvanized sheets 1mm on both sides, RAL on the outside 6 Insulation walls, ceiling 1 set of rock wool 150mm 75Kg/m² 7 Bottom furnace gets 2 entry rails for tray wagons 8 Temperature 220°C 9 fans 1 pc. 5,700 m³/h 10 electric motors 1 pc 2.2 kW , 1450 rpm, 3 F, 50 Hz 11 Thermal power 33 kW 12 hinged doors on one side 2 pcs insulated with rock wool 100mm 75Kg/m² Heating Indirectly via Thermoblock 13 Thermoblock 1 set of stainless steel INOX with heat-resistant fans and heat-resistant bearings, thermoblock has overheating protection 14 burners 1 pc oven is electrically operated 15 Exhaust air 1 pc device for exhaust air pipe, manual flap guide

Open Spray Stand 2x2,1x2,2 The overspray during powdering is absorbed by the extraction unit. The powder spray stand is delivered on rollers and is therefore mobile. - The extraction system is equipped with a 60 L powder container (rollable). - As a 1st stage, there are 4 filters in the extractor. - Above the cab is the absolute filter. 1. Dimensions of the powder stand width 2,000 mm Depth 2,100 mm Height 2,200 mm 2. Fan 1 pc. 6,000 m³/h Electric motor 3.0 kW 3. Filter Φ 325x600 4 pcs Type Filter Cartridges 4. Electromagnetic valves 2 pcs. 1" "Turbo" Italy 5. Absolute filter 1 pc. type bag filter

Powder coating system for large parts Example:(all sizes can be changed individually) Space requirement: 30 x 15 meters Part size: L= 6,200mm W= 2,300mm H= 2,000mm Cleaning booth walk-in incl. spray wreath automatic 1 Dimensions of the cabin Length 9,000 mm Width 4,500 mm Height 3,400 mm 2 Dimensions of the tanks Length 1,200 mm Width 850 mm Height 1,000 mm 2 Dimensions of the cabin complete Length 9,140 mm including tanks width 5,580 mm Height 4,200 mm Coating booth walk-in, manual coating 1 Dimensions cabin length 9,000 mm Width 4,500 mm Height 3,400 mm 2 Dimensions of the cabin including extraction Length 10,125 mm Width 4,500 mm Height 3,400 mm Powder curing furnace 1 Inner dimension length 6,500 mm 2 Inner dimensions width 2,500 mm 3 Internal dimensions height 2,950 mm 4 Outer dimensions incl. thermoblock length 7,600 mm 5 Ou ...

4 pieces diode laser system, Limo Diocut 1300 – used - : Price per piece from location: 1.950.-€ (net)! Manufacturer: LIMO (Lisotchenko micro-optics) Type: Diocut 1300 Year of Make: 2013 400V, AC +/- 10% 50/60 Hz I < 16A, 3 phase, + N + PE Condition: good, Available: immediately Location: Frankenberg camp / Saxony

x-travel: 4500 mmy-travel: 630 mmz-travel: 630 mmcontrol: Siemens type: 810 M Tool changer: 40 Pos.spindle taper: ISO: 40 spindle turning speed range: 20-7100 U/mintable surface area: 5100x680 mmspindle drive: 38 kWT-slot - width: 18 mmchip conveyor: total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Piller HD Supply System WSD 21H+1000 Litre Tank Specifications: Designation: WSD 21 H Year of Make: 2019 HD pump: Hammelmann Max. operating pressure: 780 bar Max. flow rate: 38 l/min Power HD pump: 55kW Max.water temperature: 40 degrees Operating voltage: 3x400V/50Hz Connected load: 80kVA Total current consumption:115A Curb weight: 2300kg Operating Weight: 3300kg Dimensions LxWxH: 3240x1200x2800mm Control: Siemens Comfort Panel KP400 Location of the machines: 76661 Philippsburg The machines can be viewed on site at any time. They are in our warehouse and work perfectly. You can make an appointment for a viewing at any time before bidding on +49 (0) 72 55 / 39 73 337. We would love to hear from you

Scope of delivery: 1. Chemical pre-treatment by spraying (in cycle process) 2. Dryer 3. Powder coating system 4. Powder curing furnace 5. Conveying technology, semi-automatic Ue3Zjkdi72 6. Electrical control Hall/ Parking space Floor area of the system max. 12,000 x 6,500 mm Industrial flooring hall floor Workpiece sizes Max. part dimensions L= 500mm, H= 1,500mm, W= 500mm Steel parts range Conveyor P&F chain conveyor in cycle method, semi-automatic Pretreatment Chemical Energy supply Electricity On-site power (max. 88 kW) Gas On-site performance Compressed Air On-Site Performance Water On-site service Calculation Type of system Cycle system Conveying speed 3.2 meters/min Length per cycle L = 1,600 mm Time for clock movement: Tm = 1.6 meters : 3.2 meters/min = 0.5 minutes Time for clock stop: Ts = 8.5-12 minutes Total time for clock Tt = Tm + Ts  ...

workpiece length: 400 mmwork piece width: 400 mmworkpiece height: 100 mmtotal power requirement: ? kWweight of the machine ca.: 0,2 tdimensions of the machine ca.: 0,70,71,6 mNo. 5006Filing machine ERHARDT + SPIESS / H&KWorking area: Table 400 x 400Drive: ?2 hold-down devicesFile guideAdjustable stroke rate 75-300 min-1Space requirement approx. 650 x 650 x (+500) x 1600 mmWeight approx. 200 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

tool taper: 54 x SK 50 worktool system: 27 x System TUL Kelch Packing: 1200800350 mmShipping weight: ? kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

weight max. in kg: 2680 kgstroke: 4 tfork length: mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

amount: 1 STKweight: 5 kgrange L-W-H: 380 x 340 x 220 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Used, technically overhauled reinforcing steel bending machine. Rotation of the bending plate 5/7.5/10/15 Power requirement 3.15/3.65 KW 2 footswitches with emergency stop function. Bending capacity max. 1 piece 45mm D. Reinforcing steel or 3 bars 28mm D. The control system is upgraded to Siemens Touch Display CC. Latest standard. 1 set of standard bending tool.

coolant capacity: 50-250 m3l/hHeadroom: 20 moperating pressure: 2 barvoltage: 380 V / 50 Hzmotor speed: 950 U/minMotor Capacity: 4 kWweight: 420 kgnormal priming centrifugal pump,Housing and impeller made of stainless steel,Flange connections,Fabr. no. 22/00-125616The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

1 piece of used, technically overhauled reinforcing steel shears. The scissors work electromechanically. The engine was remounted. V-belt renewed. Machine painted. Cut is triggered by means of a footswitch on the front. Max. cutting capacity: 1 piece 32mm. D. Reinforcing steel bars. Connected load: 3KW/400V/16A

CNC Portal Flame Cutting Machine Manufacturer: Microstep Type: MasterCut-AM 9001.20 Year of Make: 2011 CNC control: iMSNC with integrated network card Working area: 2,000 x 9,000 mm Extraction table 1 oxy-fuel burner Cutting thickness up to 150 mm 1 plasma marking unit Kjellberg Laser pointer Technical data in detail: 1x oxy-fuel burner (1 x fully automatic) 1x plasma marking unit (fully automatic) Kjellberg Finsterwalde MicroStep® CNC machine control iMSNC with integrated network card LCD operator units on the gantry Laser pointer with automatic offset transmission Parameter database iMSNC control / Windows® "AsperWin-Basic" programming system, for programming directly on the machine control system Module Macro Library "AsperWin Select" Module NC Simulator "AsperWin NC-Sim" Module "Plasma Marking" (for graining) via plasma source Module "THC" / Automati ...

Year: 2006 Jahrmodule range: ab 0,5 mmtravel -x axis: 1800 mmtravel -y axis: 200 mmtravel -z axis: 650 mmControl: Technical Details:• Max. Rotary table Workpiece diameter = 5 bis 400mm• Max. Rotary table load = 180kg• Axis X= 1800mm Y=200mm Z=650mm• Tailstock measuring range = 20 bis 900mm• Modul range from 0,5mm• Max. Rack length = 1200mm• 6x Probe changer inkl. 6x SP600M probe plates• Machine temperature compensation• Machine air damping• Build in 2006• Accessories such as, driver, reference ball etc. as shown• Jaw chuck D=250mm with inside and outside jawsThe following software modules are included:• TMain – Programm Management• TStylus – Stylus Management• TCali – Stylus Calibration• TAmo – Axis Workpiece Alignment• TGear – Spur and helical gear measurement• TShaft – Software for Dimension for form, position elementes, diameters,lenght ...

turning diameter: . mmturning length: . mmcontrol: . turning diameter: . mmturning length: . mmswing diameter over bed slide: . mmtotal power requirement: . kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
