Plasma Cutting Equipment used for sale (15)

MicroStep SPL-PA plasma cutting system with extraction and compressor technology Manufacturer: MicroStep Group Model No.: SPL-PA 4501.15+S50 Machine Type: CNC Plasma Cutting Machine CNC Control: iMSNC Construction: Portal design with linear guides Extraction system: Donaldson Torit DCE Electrical connection extraction system: 400 volts Motor power extraction system: 7.5 kW Compressed Air Generation: Screw Compressor Compressor manufacturer: Kaeser Compressor model: TA 8 CE marking: available Location: Waltenhofen, Germany Dismantling and loading by sellers included

This machine is multi-purpose and can drill/punch/mark and cut plasma. See photo for all diameter heads and cutting thicknesses max. Auction-ID: A3-43547-16100

CUTTING SPEED: 0 to 12500mm/min, depending on the type of process and the power source MAXIMUM TRAVEL SPEED: 35000mm/min REPEATABILITY: 0.025mm POSITIONING ACCURACY: 0.05mm RAILS: High precision 20mm Agma10 helical inverted racks protected against dirt and impacts, 25mm linear bearings installed on machined surfaces. MOTORS / GEARBOXES: Simultaneous motor drives on each side of the rails, pneumatic clutch of the racks with linear bearings, ultra-precise helical planetary gearboxes for smooth movement CNC CONTROLLER: Edge Pro CNC Controller, Sercos III Windows base, 380mm glass touch screen 2 USB ports and network connection Phoenix Software MAXIMUM TABLE CAPACITY: Material thickness 120mm, changeable MOTORIZED STATIONS: 2 max. OXY COUPAGE STATIONS: 3 max. AUTOMATIC HEIGHT CONTROLLER: Machitech's automatic height controller uses arc voltage sampling to trac ...

Rated power: 9.2 KVA; Rated current: 14 A; No-load voltage: 256 V; Output current adjustment: 20-60 ; Rated output voltage: 104 V; Max cutting thickness: 20 mm; Cyclic duration factor: 60%; Efficiency: 70%; Insulation grade: F; Protection grade: IP21; Arc-start: Contact; 6094 Auction-ID: A1-47513-350

Rated power: 5.5 kVA; Rated current: 25 A; No load voltage: 243 V; Output current: 20-40 A; Rated output voltage: 96 V; Cyclic duration factor: 40%; Efficiency: 70%; Insulation grade: F; Protection grade: IP21; Arc-start: Contact; 6095 Auction-ID: A1-47513-348

Rated Input Voltage: 1P AC380V ±15% 50/60Hz Rated Input Current: 14A Rated input power: 9.2 KVA Open circuit voltage: 256V Output Current Setting: 20-60A Rated Output Voltage: 104V Cyclic Duration Factor: 60% Efficiency: 70% Insulation class: F Protection class: IP21 Arc discharge by contact Auction-ID: A1-40265-125

Swift-Cut PRO 2500 MK5 CNC table with Hypertherm plasma cutter.This machine has very low mileage – only 238 hours of operation, with approximately one month of use.Ideal for a CNC workshop, manufacturing company, or for a quick production start-up. For more information, see the attached PDF file Auction-ID: A7-40834-9

Box size 400x245x305mm; 15A/86V - 40A/96V; IP21S; digital display; Auction-ID: A1-47513-334

Rated power: 19 kVA; Rated current: 29 A; No-load voltage: 280 V; Output current adjustment: 30-120 A; Rated output voltage: 128 V; Max cutting thickness: 45 mm; Cyclic duration factor: 60%; Efficiency: 80%; Insulation grade: F; Protection grade: IP21; Arc-start: Contact 6093 Auction-ID: A1-47513-352

Box size 400x245x305mm; 15A/86V - 40A/96V; IP21S; digital display; Auction-ID: A1-47513-335

Compressed Air Plasma Cutting Machine Brand: Stahlfest Type: SFPC130 Maximum cutting thickness: max. cutting thickness 45 mm Connection: 380 volts adjustable current: 30-120 A Start: Equipped with: Pilot Arc duty cycle: 60% duty cycle (120 A) Technology: IGBT Technology Protection: circuit breaker Additional function: Plug for CNC control Including: plasma torch, accessories and protective cover Not included: power cable and 380 volt plug Condition: Unused and in the original packaging Auction-ID: A3-43544-640

Auction-ID: A3-43544-20162

Extraction system KAPPA, type: MYKRON M 16Serial number: 00M16.0055Year of construction: 2000Motor power: 15 kWSpeed: 3000 rpmWorking dimensions: Width: 2.00 m, Length: 3.5 mControl: Control type: NBS 300Production number: 1513Voltage: 230 VFrequency: 50 HzConnection: 330 VAReference: Plasma cutting - Falkenberg Auction-ID: A7-46763-127

Maximum tube length 8000 mmMinimum tube diameter 100 mmMaximum tube diameter 750 mmMinimum tube thickness 3 mmMaximum tube thickness 20 mmCutting with bevel and V and Y bevel TheSUPRAREX SXE3100 machine consists of:n. 1 main machine body equipped with longitudinal and transverse guides made with precision rack / pinion systems and brushless motors. The X-axis, with a guide length of 11,000 mm, is equipped with a double motorization n. 1 synchronized axis spindle for tube cuttingn. 3 trolleys for tube support, with manual positioning by means of a trapezoidal screwn. 1 trolley for ESAB iSerie300 plasma generator with maximum power of 300A n. 1 bevel cutting unit model VBA WRISTn. 1 iSeries300i plasma generatorFOR MORE INFORMATION DOWNLOAD THE COMPLETE TECHNICAL SPECIFICATIONSSHEET Machine equipped with manuals and EC declaration of conformityAll technical data shown are indicative and may ...

Auction-ID: A1-41998-100
