milling machines used for sale (2,383)

Specifications: Longitudinal travel (x-axis) 15,900 mm Horizontal feed path (z-axis) 790 mm Vertical feed path (y-axis) 500 mm Swivel range of the milling spindle 45°F +/- Wheel spindle drive power of the DC motor 50 kW Milling spindle diameter in the front bearing 160 mm Tool holder inside ISO No. 50 DIN 2079 Tool holder outside ISO No. 60 Tool feed - manual via threaded rod M24 Spindle speeds infinitely variable in 2 ranges from 50-500 rpm. Speed range in the 1st stage 50-250 rpm. Speed range in the 2nd stage 100-500 rpm. Step Jump 1:2 Constant power range 160 rpm. Max. torque on the milling spindle 2,000 Nm Milling feed in the x direction infinitely variable from 40-4,000 mm/min. Rapid traverse 8,000 mm/min. Adjustment speed in the y- and z- direction infinitely variable from 20-500 mm/min. Rapid traverse for y- and z-axis 1,00 ...

CNC MACHINING CENTER ALZMETALL BAZ 15, Year of manufacture : 1998 Specifications: X : 600mm Y : 400mm Z : 600mm Table : 750 x 450mm Main spindle : 10,000RPM Control : Siemens Sinumerik

Travel: x=1600mm Y=800mm Z=900mm Spindle speed max. 2000 revolutions per minute Control HH 407 A Cover of the z axis present but defective.

gebr. Milling machine, Fabr. Maho 1000 S x-travel: 1000 mm Y-travel: 600 mm z-travel: 800 mm Kne Uretrnrpehyxkjb Spindle holder ISO: 50 Control is the Philips 432 with pallet changer, in working condition, recently overhauled rotary table

Fanuc ROBODRILL ALFA T10 B, Built in 1995 Revolutions 8000 rpm Picture Sk 30 Control Fanuc 16 M Tool changer 10-fold

Argo A51, built in 2008 Travel Distances X 510 mm, Y 350 mm, Z 300 mm Table: approx. 600 × 300 mm Control: FANUC Dimensions 2,610 × 1,720 × 2,460 mm. Weight: ≈ 2,700 kg.

Topper TMV-510 Built in 2008. Travel distances of X = 510 mm, Y = 360 mm, Z = 300 mm. Table surface 600 × 360 mm Controllers Fanuc 0i-MF

gebr. V. Processing Center, Fabr. Homa, Type Ecocenter V350 x-travel 450 mm y-travel 350 mm z-travel 350 mm Table size 650 x 350 mm Speed 6000 rpm Control Fanuc 0M

Heckert CWK 400 Built in 1995 Control Siemens 840 Travel X/Y/Z 650/650/680 mm Spindle speed up to 10,000 rpm HSK 40 Tool Changer Rotary table 400 x 500 mm, Conveyor Weight 12.5 t.

OKUMA Euro Center V50, built in 2004 Control: OSP-10M Travel: X-1020 Y-510 Z-525 Table load 680kg Clamping area 1200x510 Tool changer 20-fold

gebr. Milling machine, Fabr. Stanko Type 6175 Travel X/Y/Z: 320/210/300 mm Spindle speed: 50 - 2040 rpm Feed speed: 13 - 395 mm/min Drive power: 1.5 kW Tool holder: 4 MK Groove width: 14 mm Number of grooves: 3 pieces Groove spacing: 50 mm

Tool milling machine Manufacturer: INFRATIREA, Type: FUS-32, built in 1988 Specifications: Table 950 x 450 mm Travel X / Y / Z: 500 / 320 / 400 mm Spindle speeds 25 - 2000 rpm with digital display

CNC Mill, Cover, FP4-AT, 3 Axis X560/Y500/Z450 Speed range 40-4000 min-1 Control Contur-3, Mounting SK-40, weight approx. 3.4 t.

1 gebr. CNC Milling Machine, Fabr. TOS, Type FNG 63 Travel: X 800 mm Y 500 mm Z 630 mm Heidenhain Control

Univ. Tool Milling Machine DECKEL Type FP 1 Masch. No. 37101 Year of construction approx. 1969 Travel X: 300 mm Y: 150 mm Z: 340 mm Table size 600 x 200 mm Spindle holder MK 4 - S20 x 2 Spindle speed vertical 95-1900 rpm. 12 steps Spindle speed horizontal: 60-1200 rpm. 12 steps Motor power 1.0 and 1.5 kW pole-switchable Mains connection 380 volts, 50 Hz - Spindle speed over 2 motor speeds and 6 gear stages - Feed in the X and Z axes - Coolant device with mechanical pump in the machine foot - Quill shift on the vertical milling head 60 mm - Adjacent control cabinet Space requirements L x W x H 1000 x 900 x 1750 mm Weight 690 kg good condition Accessories: -Collets -Roundtable -Vice - Counter holder H. milling

gebr. Engraving Milling Machine, Lid GK12 with Accessories

Heidenhain TNC 426/430 Year of construction 1998 Total Spindle Hours 17000 Travels X/Y/Z axis 500/380/380 mm Tool changer for 24 tools Tool holder SK40 Spindle speed 15000 rpm NC swivel rotary table 500 x 380 mm Feed speed max. 20000 mm/min Rapid traverse 30m/min Weight approx. 4000 kg Coolant Setup The machine is in very good condition. Milling spindle and axes run smoothly and very precisely.

CNC controller: MITSUBISHI MSX-853 IV Axes X-axis travel mm: 560 Y-axis travel mm: 560 Z-axis travel mm: 660 Distance spindle nose - table surface mm: 80-640 Feed rates m/min: 0-60 Worktable Number of pallets: 2 Table dimensions mm: 400 x 400 Maximum workpiece size (D x H) mm: 630x900 Max. workpiece weight kg: 400 APC time s: 9 División estandar Grados: 360 - 0.001º Spindle Spindle speed rpm: 12.000 Spindle drive power kW: 15/11 Spindle torque Nm: 110 Bearing Inner Diameter mm.: 80 Tipo: SJ-2B4351TK Tool system Tool magazine slots: 40 Max. Tool Diameter: 70 With free neighboring places mm: 170 Max. Tool Length mm: 450 Max tool weight kg: 8 Tool Shanks : MAS-BT40 Equipment Chip conveyor Workarea light 4th axis Cooling Tank capacity: 170L High-pressure bar: 15 Machine running times Under power: 64.734 Rated power kVA: ...

CNC Control: FANUC 31i-B Axes X-axis travel mm: 1050 Y-axis travel mm: 850 Z-axis travel mm: 970 B-axis degrees: 0.001º Distance between spindle - table top mm: 100-950 Work table Number of pallets: 2 Table dimensions mm: 630x630 Maximum part size (D x H) mm: ø1.100x1.100 Maximum weight of the piece kg: 1200 APC Time: 15.5 Spindle Spindle speed rpm: 10000 Spindle power kW: 30 (25% ED) Spindle torque Nm: 420 (25% ED) Tooling System Tool Holder: HSK-A100 Tool Magazine Positions: 90 Max. tool diameter mm: ø250 Max. tool length mm: 550 Tool-to-tool time: 2.4 Chip to chip time: 4.5 Equipment Electronic steering wheel Chip extractor Washing Gun Signal light High Pressure Pump Mist collector 4th axis RS 232 Interface Internal cooling 3D Renishaw tool probe 4x pallets Toolholders are not included Machine Run Times Hea ...

Key data: 600 mm, 400 mm, 420 mm

Hermle UWF 900 Universal CNC Milling Machine BAZ Year of Make: 1996 Machine number: 11410 Machine weight: 2,900 kg Availability: By arrangement. Machine is still energized and in perfect condition.

Control Philips CNC 432 Travels X/Y/Z 600 x 400 x 450 mm Spindle speed 4,000 min-1 20-cavity tool magazine SK 40 4th Lehmann axis


Universal tool milling machine TOS FNGJ 32 3 Axis Heidenhain Digital Display Year of Make: 1999 Travel: X 600 Y 400 Z 400 Speed range: 40 – 2000 rpm With the following accessories: Rigid angle table 800 x 400 mm clamping surface Vertical milling head Extendable drill quill Various tool holders SK 40 Safeguard Chip tray Machine Light Automatic central lubrication pump for X,Y,Z axis Coolant Setup 4 pcs machine shoes

X-axis: 560mm, Y-axis: 500mm, Z-axis: 400mm, clamping table dimensions vertical: 300/450mm, number of threaded holes: 2/6, threaded hole spacing: 45mm, thread: M16, angle table clamping surface: 460/800mm, number of T-slots: 7, T-slot spacing: 63mm, T-slot width: 14mm, max. workpiece weight (recommended): 350kg. Milling spindle drive number of working spindle speeds: 21, speed (geometrically graduated): 40-4000/min, step increment: 1.259, spindle motor power: 3.3/4kW, tool holder: ISO 40 / M16 with draw-in groove, vertical quill stroke: 90mm, feed in all 3 axes steplessly adjustable: 2-3000mm/min, rapid traverse X-axis and Y-axis: 6000mm/min, rapid traverse Z-axis: 4000mm/min, feed motor torque longitudinal and transverse: each 3.5Nm, feed motor torque vertical: 7Nm, control: Heidenhain TNC 407, connected load: 8.7kW, length: 3705mm, width: 2430mm, height: 3100mm, weight of the machine w ...

2 x milling machines Kunzmann WF 650 BJ 2005

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmMax. Turning Length1200 mmTurning diameter500 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle diametre on front bearing130 mmSpindle bore87 mmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking m ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmBar diameter max.65 mmMax. Turning Length1200 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperCapto C6 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22 kW ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.75 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN ...

A Lasercomb CNC high-speed die milling machine is available. Travel X/Y: 1070mm/1070mm, number of spindles: 4, spindle speed: 50000rpm, continuous power: 180W. Documentation available. An on-site inspection is possible.

PINNACLE DV - CNC PORTAL MILLING MACHINE Year of construction 2010 Mitsubishi M70 Table : 2200 X 1200 mm X-axis travel 2200 mm Y-axis travel 1200 mm Z-axis travel 1000 mm Motor power: 32 kW With tool changer Total weight : 19t approx. Horizontal Head 90 Degree

VISION WIDE SF-2116 CNC PORTAL MILLING MACHINE Year of construction 2016 Fanuc 31i ModelB Table : 2000 X 1500 mm X-axis travel 2000 mm Y-axis travel 1500 mm Z-axis travel 800 mm Engine power: 44 kW With tool changer Total weight : 20t approx. Horizontal Head 90 Degree
