grinding machines used for sale (2,122)

- CNC Dresser KW with Siemens 840D new in 2002 - HeidenHain measuring scales - Siemens Servo engines - Crankshaft and External grinding - Large steady rest package - Large stone and flanch package

- Self centerring device- Double column slide ways- Dressing Unit- Tailstock by rack & pinion- Eccentric adjustment 0 - 20 mm- Large Cone-Stone tooling package

Key data: 340 mm, 160 mm

Surface Grinding Machine Lipemec PM300 XYZ = 340 x 160 x 240 mm Permanent magnet 250 x 130 mm Max. diameter of whetstone 200 mm Distance between table top and spindle axis 315 mm All feeds manually Digital display Heidenhein, 0.001 mm steps on 2 axes Table brake Dressing Diamond

Surface Grinding Machine Aba FFK High-quality, hand-operated surface grinding machine Magnet size: 250 x 150 mm Dressing device on top of the spindle Maximum stroke in X direction: 390 mm Maximum stroke in Y-direction 180mm Height from magnet to spindle center: 395 mm Large Vernier Rings Includes 5 flanges with grinding wheels Dot diamond for magnet A dust extraction system is also available.

Grinding wheel diameter: 200 mm Clamping surface: 250 x 150 mm Diameter magnetic table: 120 mm Spindle speeds: 11 - 3,150 rpm Country of origin: Italy Machine LxWxH: 1,000 x 700 x 1,600 mm Machine weight: 250 kg

grinding length: 6100 mmgrinding width: 350 mmworkpiece height: 300 mmControl: total power requirement: 75/92,5 kWweight of the machine ca.: 20 tdimensions of the machine ca.: 12.500 x 1.800 x 2.600 mBrand ReformMachine no 2050-SL377Type AR 61 Type 8/CNCCNC Brand SiemensCNC Type Sinumerik 805Year of make 1997Machine weight 20.000 kgHorizontal Grinding length 6.100 mmgrinding width 350 mmGrinding height 300 mmEngine power 75 / 92.5 KwAutomatic depth feed Grinding stone diameter 600 mm øMagnetic plate size 5x 1.200 x 350 mmCooler with magnetic filter Machine size (lxwxh) 12.500 x 1.800 x 2.600 mm5x Magnetic plate, adjustable in degrees.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Walter AG Helitronic Power CNC Universal 5-Axis Tool Grinding Machine CNC control HMC 400 CNC X-axis travel 400 mm Y-axis travel 250 mm Z-axis travel 580 mm C-axis (table rotation) ± 200° Max. grinding wheel diameter Ø 200 mm Spindle speed (grinding) 3000 / 6000 rpm If you have any questions about the machine, please do not hesitate to contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.

220627 Code Description Universal Cylindrical Grinder Make Jones - Shipman Model 1310 ( 8" x 18" ) Serial No. Year ? Grinding length, max. 450 mm Grinding diameter, max. 203 mm Center height 103 mm Weight workpiece kg Table tilting angle - 15 ° till + 15° Diam. Grinding wheel 350 mm Width Grinding wheel, max. 40 mm Motor power grindingwheel 1.5 kW Speeds Grindingwheel 1750 / 2300 rpm Speeds workpieceholder ( 6x ) 30 – 415 rpm Total power 3.5 kVA 380 Volts Machine size L x W x H 1.7 x 1.2 x 1.75 meters Weight 1800 kg Accessories internal grinding ( 10500-16500-24500 rpm ) coolant some tooling Condition Machine is in good condition

Surface grinding machine Make: LECHLER Model: 500 x 150

Deburring pipes, rods, profiles and sheets after separation is a must. But only the right system enables cost-effective, safe and flawless deburring – namely the optimal adaptation of the machine concept and the high-performance brush to the workpiece properties and material quality.

Code 5976 Description Hydr. Surface grinding machine Make DANOBAT Type RT – 1200 Machine No. 565 Manufacturing date 1989 ( 1990 in use ) Table size 1400 x 700 mm Grinding dimensions L x W x H 1200 x 750 ( 800 ) x 800 mm Magnetic plate size L x W 1000 x 600 mm Table speed movement 1 - 25 m/min. Max. distance table surface – centre grinding wheel 1000 mm Speeds cross 0,1 - 5 m/min. Vertical movement 0,005 – 0,05 mm Spindle rotation 1500 rpm Spindle power 7,5 kW Grinding wheel size Ø 400 x 50 ( 100 ) x Ø 127 mm Weight 8.500 kgs Total power 12 kW – 380 Volt Accessoiries Electro magnetic plate 1000 x 600 mm from Tecnomagnete Coolant Pendel control Condition Machine is in good condition

Grinding range: 400 x 200 mm Magnet table: 400 x 175 mm Height adjustment: 410 mm Grinding wheel dimensions: 225 x 25 x 50.8 mm Grinding wheel speed: 1420 / 2840 rpm. Equipped with: - Coolant device - Band filter - Hydraulic system - Operating instructions Country of origin: Germany Motor power: 1.5 kW Machine LxWxH: 2200 x 1500 x 2100 mm Machine Weight: 1100 kg

Grinding length: 500 mm Grinding diameter: 300 mm Grinding wheel diameter: 400 mm Equipped with: - Bezel - Grinding wheels Country of origin: Germany Machine LxWxH: 2300 x 1700 x 1700 mm Machine Weight: 3500 kg

grinding diameter: 610 mmgrinding length: 3000 mmcentre height: mmtotal power requirement: 30 kWweight of the machine ca.: tdimensions of the machine ca.: mStocknumber 1310015Type of machine Cylindric grinderMake STANKOType 3M193/149Build in 1988Max. grinding diameter 610Max. grinding length 3000Grinding wheel diameter 700Grinding wheel widht 75Total Power (KW) 30 Additional informationIncl. 2 staedysThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 250 mmgrinding length: 650 mmcentre height: mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mBrand: GlauchauType: SI 6/3CNC brand: SiemensCNC model: SinumerikYear of make: 1997CNC controlledMaximum grinding depth: 250 mmGrinding diameter: 650 mm øRapid traverse: 10 m/minSpeed: 50 - 500 RPMInner grinderX (inner grinding device): 155 mmLength displacement interior grinding device on the table: 540 mmTool grinding deviceZ (table move): 700 mmCirculation diameter: 650 mm øGrindig diameter for internal grinding: 10 - 500 mm øThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 1400 mmgrinding length: 3500 mmcentre height: mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mStocknumber 1310013Type of machine Super finishing machineMake NAXOS UNIONType WT 140/3500Build in 1975Max. grinding diameter 1400 mmMax. grinding length 3500 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Code 171305 Description CNC surface grinding machine Make DANOBAT Model PSG - 1000 Serial No. 30102 A Control Fanuc 210i - M Year 2001 Tablesize 1000 x 500 mm Grinding surface L x W x H 1000 x 600 x 450 mm Long ( X axes ) 1150 mm Cross ( Z axes ) 500 mm Speed table movement 1 – 30 m/min. Max. distance table – centre grinding wheel 650 mm Max. workpiece weigth 1500 kg Max. table load 1500 kg Magnetical plate size L x W 1000 x 500 mm Grinding stone dim. Stone x Wide x Taper Ø 400 x 100 x Ø 127 mm Spindel power 7,5 kW Spindel speed 1500 rpm Motor power 7,5 kW – 380 Volt Total electr.com. 20 kW Total space L x W x H 3950 x 3150 x 2550 mm Weight 5500 kgs Accessoiries Elec. Magneticplate 1000 x 500 mm Coolant with paperfilter Digital readout Grinding stones, etc. Condition Machin ...

Code 101237 Description Universal Cylindrical Grinder Make WMW Heckert Model SA 5 U x 630 Serial No. 3115 Year 1981 Grinding length, max. 630 mm Grinding diameter, max. 275 mm Centerheight 140 mm Max. Weight workpiece 125 kg Table tilting angle - 5° till + 11,5° Diam. Grinding wheel 500 mm Width Grinding wheel, max. 100 mm Motorpower grindingwheel 5,5 kW Speeds workpieceholder 31,5 – 710 rpm Total power 12,5 kVA 380 Volts Machine size L x W x H 3,9 x 2,3 x 1,6 meter Weight 4800 kg Accessories coolant with magnetic some tooling Condition Machine is in good condition

Code 9602 DESCRIPTION Vertical JIG Grinder Make HAUSER Modell 3 SMO Serial No. 257 Machine No. 1519-2564 Table surface 600 x 320 mm Table movement longitude (X) 400 mm Table movement cross (Y) 250 mm Max. grinding diameter Ø 190 mm Column-Spindle 300 mm Max. height under spindle 500 mm Vertical movement spindle 90 mm Vertical movement grindinghead 500 mm Max. speeds grindingspindle up to 80.000 omw./min Weight 2000 kg Total power 6,6 kW – 380 Volts Accessories Grinding spindles, etc. Condition Machine is in good condition

Code 81199 Description Hydr. Surface grinding machine Make DANOBAT Type RT – 1200 Machine No. 504 Manufacturing date 1987 Table size 1400 x 450 mm Grinding dimensions L x W x H 1200 x 600 x 450 mm Magnetic plate size L x W 1200 x 450 mm Table speed movement 1 - 30 m/min. Max. distance table surface – centre grinding wheel 675 mm Speeds cross 0,1 - 5 m/min. Vertical movement 0,005 – 0,05 mm Spindle rotation 1200 rpm Spindle power 7,5 kW Grinding wheel size Ø 450 x 50 ( 100 ) x Ø 127 mm Weight 6000 kgs Size of machine 3250 x 1850 x 2600 mm Total power 19 kW – 380 Volt Accessoiries Electro magnetic plate 1200 x 450 mm from Tecnomagnete Coolant Pendel control Condition Machine is in normal condition

Code 71164 Description Universal Hydraulic Cylindrical Grinder Make SHIGIYA SEIKI Model GU – 27.100 H Serial No. 10222 Year 1978 Grinding length, max. 1000 mm Grinding diameter, max. 265 mm Centre height 135 mm Max. Weight workpiece 130 kg Table tilting angle - 3° till + 7° Table speeds 0,05 – 7 m/min Diam. Grinding wheel 350 mm Width Grinding wheel, max. 25 – 50 mm Motorpower grindingwheel 3,7 kW Speeds workpieceholder steples from 17 – 250 rpm Total power 9,3 kVA 380 Volts Machine size L x W x H 4,0 x 1,8 x 1,6 meter Weight 3200 kg Accessories Coolant, books, electric cabinet,etc. Condition Machine is in good condition

Gantry type grinding machine Make: Hiatachi Seiki Modell: 9GA-NRAA Table: 2500 x 1200 mm Max. Table travel: 2000 mm Capacity: 1500 x 900 x 500 mm Control: Fanuc 15 MA Year: 1995

Code 61063 Description Surface grinding machine Make ABA Model FFU 2000/60 Serial No. 208 125 Control Abamatic 3 Year 1986 Tablesize 2510 x 500 mm Grinding surface L x B x H 2000 x 600 x 700 mm Magnetical plate size L x B 2000 x 500 mm Speed table movement 3 – 30 m/min. Max. distance table – centre grinding wheel 900 mm Grinding stone dim. Stone x Wide x Taper Ø 400 x 50 x Ø 127 mm Spindel power 26 kW Spindel speed 1600 - 3000 rpm Motor power 26 kW – 380 Volt Total electr.com. 34 kW Total space L x W x H 7000 x 3500 x 2650 mm Weight 10500 kgs Accessoiries Elec. Magneticplate 2000 x 500 mm Coolant with paperfilter Digital readout Grinding stones, etc. Condition Machine is in good condition

Code 61062 Description Hydr. Surface grinding machine Make DANOBAT Type RTS - 1600 Machine No. 16 220 Manufacturing date 1975 Table size 1800 x 550 mm Grinding dimensions L x W x H 1600 x 600 x 650 mm Magnetic plate size L x W 1600 x 550 mm Table speed movement 1 - 25 m/min. Max. distance table surface – centre grinding wheel 750 mm Speeds cross 0,1 - 5 m/min. Vertical movement 0,005 – 0,05 mm Spindle rotation 1500 rpm Spindle power 15 kW Grinding wheel size Ø 400 x 50 ( 100 ) x Ø 127 mm Weight 10.000 kgs Total power 20 kW – 380 Volt Accessoiries Electro magnetic plate 1600 x 550 mm from Tecnomagnete Coolant Vertical grinding spindel Condition Machine is in good condition

Code 61047 Description Hydr. Surface grinding machine Make ALPA Model RT 1000 Serial No. 53377 Year 1985 Tablesize 1200 x 300 mm Table grinding size L x B x H 1000 x 350 x 400 mm Base size L x B 1000 x 300 mm Speed table movement 3 – 40 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 600 mm Grinding stone diam. Stone x Wide x Taper Ø 400 x 50 x 127 mm Spindel power 8,8 kW Spindel speed 1460 rpm Weight 3000 kgs Motor power 8,8 kW – 380 Volt Accessoiries Magneticplate 1000 x 300 mm Coolant Grinding stones, etc. Condition Machine is in normal condition

Code 4925 Description Surface grinding machine Make ELB Model OPTIMAL 1 VA II Serial No. 180730982 Year 1982 Tablesize 900 x 250 mm Table grinding size L x B x H 600 x 300 x 250 mm Magnetical plate size L x B 500 x 250 mm Speed table movement 1 – 25 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 500 mm Grinding stone dim. Stone x Wide x Taper 300 x 50 x Ø 75 mm Spindel power 3,7 and 4,5 kW Spindel speed 1400 and 2800 rpm Weight 3500 kgs Motor power 3,7 and 4,5 kW – 380 Volt Accessoiries Elec. Magneticplate 500 x 250 mm Coolant with paperfilter 2 x DRO Grinding stones, etc. Condition Machine is in good condition

Code 5976 Description Hydr. Surface grinding machine Make DANOBAT Type RT – 1200 Machine No. 565 Manufacturing date 1989 ( 1990 in use ) Table size 1400 x 700 mm Grinding dimensions L x W x H 1200 x 750 ( 800 ) x 800 mm Magnetic plate size L x W 1000 x 600 mm Table speed movement 1 - 25 m/min. Max. distance table surface – centre grinding wheel 1000 mm Speeds cross 0,1 - 5 m/min. Vertical movement 0,005 – 0,05 mm Spindle rotation 1500 rpm Spindle power 7,5 kW Grinding wheel size Ø 400 x 50 ( 100 ) x Ø 127 mm Weight 8.500 kgs Total power 12 kW – 380 Volt Accessoiries Electro magnetic plate 1000 x 600 mm from Tecnomagnete Coolant Pendel control Condition Machine is in good condition
