51 JUNG used machine for sale

grinding length: 600 mm grinding width: 400 mm workpiece height: 375 mm digital readout: 2 Achsen HEIDENHAIN table-size: 650 x 350 mm max. table load: 400 kg magnetic clamping plate: 600 x 350 mm dist. center of grinding spindle - table: 525 mm table travel longitudinal: 650 mm table travel cross: 350 mm table feed: 2 - 28 m/min grinding wheel size: 300 x 30 x 76,2 mm dressing device: Kopfabrichter voltage: 400 V total power requirement: 11,0 kW weight of the machine ca.: 2,1 t dimensions of the machine ca.: 2,20 x 1,70 x 2,25 m band filter unit: 1,00 x 0,75 x 0,80 m electric cabinet: 0,90 x 0,40 x 2,25 m - Serial-No.: 18090201 - Automatic vertical feed - Electric handwheel - HEIDENHAIN digital display, 2 axes - Head dresser - Coolant device - Belt filter system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 600 mm grinding width: 200 mm workpiece height: 250 mm table surface area: 700 x 200 mm table load: 250 kg grinding wheel size: 200 x 16-25 / 51 mm grinding wheel speeds: 2800 U/min longitudinal feed of the table: 1 - 20 mm with vertical adjustment: 290 mm total power requirement: 1,5 kW weight: 1300 kg range L-W-H: 1,6 x 1,2 x 1,9 mm partly overhauled in 2022 - (Control panel still need to be electrically completed!) - magnetic clamping plate 510 x 200mm - autom. cross feed - Hydraulic table movement, infinitely variable - Manual fine adjustment (0,01 / 0,005mm) - Grinding wheel extractor - Central lubrication - VENTI Dust-Suction - 5 grinding wheels The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

centre height: 76 mm centre distance: 190 mm spindle bore: 21 mm taper MK: 3 weight of the machine ca.: 40 kg dimensions of the machine ca.: 720 x 210 x 215 mm collets: tailstock: dead centres: Barely used Jung optical dividing head with tailstock in a wooden box with 9 collets: 3, 4, 5, 6, 7, 8, 9, 10, 11 mm. Reduced special price. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding wheel dia. x width: ca. 200 x 25 mm magnetic clamping plate: ca. 450 x 170 mm cross feed of the table: 200 mm revolutions of grinding spindle: 3000 U/min grinding wheel hole diameter: 51 mm weight: ca. 1300 kg : 0,001 - 0,013 mm grinding length: 600 mm Surface grinding machine Includes extractor 1 additional grinding wheel holder Machine was in occasional use until recently The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

workpiece diameter: 300 mm workpiece weight: 999 kg workpiece height: 999 mm grinding length: mm grinding width: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Ausstattung: -Digitalanzeige senkrecht Achse -Automatische Zustellung -Automatische Endabschaltung programmierbar -Schleifspindelantrieb mit stufenloser, elektronischer Drehzahlregelung -stufenlos regelbarer Quervorschub, und Tischdrehung -24V Magnetspannplatte 300 mm -diverse Arbeitsschutzeinrichtungen z.B. Schutzhaubenüberwachung, Betriebszustandsanzeige per Ampel -Schmierölstandsüberwachung -die Maschine wurde 2015 generalüberholt, damals Austausch der gesamten Elektrik auf SPS-Steuerung und 24V Steuerspannung -Papierbandfilteranlage speziell für diese Maschine passend Folgende Arbeiten wurden nun noch durchgeführt: -Austausch Faltenbalg und Riemen -Schleifspindel neu gelager ...

Rear grinding machine with permanent magnetic clamping plate JUNG type HA 20EquipmentNo: 3344Profile depth: max. 15 mmAngle adjustment: 0 to 2Magnetic plate: 115 x 115 mmClamping range: 110 x 75 mmHeight magnetic plate: 119 mmWorkpiece dimensions L x W x H: max. 60 x 100 x 50 mmPower consumption: 1 ampereOperating voltage: 24 volts, direct voltage (V/DC)- mechanically switchable permanent magnetDimensions L x W x H: 500 x 200 x 125 mmWeight: 25 kggood conditionSuitable for cutting tool mold making for conical background cutting plates or

CONTROLS   electronic controls WORKING RANGE SURFACE GRINDING   grinding length: 600 mm   grinding width: 200 mm TABLE (SURFACE GRINDING)   magnetic table: yes MAGNETIC TABLE   length: 600 mm   width: 200 mm   weight: 100 kg SPINDLESTOCK GRINDING SPINDLE   spindle revolutions (max): 4200 /min GRINDING TOOL   type of grinding tool: wheel   diameter (max): 250 mm   borehole: diameter: 51 mm   width: 25 mm ELECTRICAL SPECIFICATIONS   total power consumption: 7.5 kW   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 3000 mm   space requirements -front/back-: 2540 mm   total height: 1850 mm   total weight approx.: 2000 kg

CONTROLS   CNC controls SIEMENS SINUMERIK WORKING RANGE SURFACE GRINDING   grinding length: 880 mm   grinding width: 510 mm TABLE (SURFACE GRINDING)   table surface (left-right): 800 mm   table surface (front-back): 430 mm   workpiece load (max): 800 kg MAGNETIC TABLE   length: 800 mm   width: 400 mm SPINDLESTOCK GRINDING SPINDLE   spindle revolutions (min): 1500 /min   spindle revolutions (max): 3500 /min GRINDING TOOL   type of grinding tool: wheel   diameter (min): 210 mm   diameter (max): 400 mm   borehole: diameter: 127 mm   width: 100 mm ELECTRICAL SPECIFICATIONS   mains power supply: 30 kVA DIMENSIONS / WEIGHTS   space requirements -left/right-: 3150 mm   space requirements -front/back-: 2350 mm  & ...

Inv. Num. : 6614 Type: - Producer: JUNG Generated: Parameters: Equipment: DRO In good technical condition.

Inv. Num. : 4518 Type: JA 500 A Producer: JUNG Created: 1994 Parameters: Control system: Siemens Operating hours: 10662 h Maximum grinding height of the workpiece: 375 mm Maximum spindle speed: 4200 1/min Minimum travel speed longitudinally (X-axis): 24 m/min Maximum travel speed longitudinally (X-axis): 24 m/min Grinding wheel diameter new: 250 mm Spindle power: 7.5 kW Maximum grinding length without grinding wheel extension (X-axis): 600 mm Maximum sanding length: 200 mm Machine height: 1000 mm Machine length: 3700 mm Machine width: 2100 mm Machine weight: 2,500 kg

This 3-axis JUNG J 630 E surface grinding machine was manufactured in 1999. It features a travel of 660 mm in the X-axis, 360 mm in the Y-axis, and 280 mm in the Z-axis. With a robust machine weight of 3000 kg, this machine is designed for precision grinding applications. If you are looking to get high-quality grinding capabilities, consider the JUNG J 630 E machine we have for sale. Contact us for further details.

This 3-axis JUNG JF 525 N surface grinding machine was manufactured in 2007. It features an X-axis travel of approximately 630 mm and has a machine weight of 2200 kg. If you are looking to get high-quality grinding capabilities, consider the JUNG JF 525 N machine we have for sale. Contact us for further details.

Optical dividing head, precision dividing head -Max. tip height: 76 mm -Max. center distance: 200 mm -with collets: 3, 4, 5, 6, 7, 8, 9, 10, 16 mm -wooden box -Total weight per box: 42 kg Quantity: 1 piece available

Magnetic plate, magnetic table, sine table, sine plate, relief grinding device, grinding machine accessories -Design: Cutting tool mold making for conically ground cutting plates or mold inserts -Angle head for surface grinding machine or measuring machine -Magnetic plate -Angle: adjustable -Wooden box -Total weight with box: 35 kg

Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinding machine, center grinding machine -Max. shaft diameter: 320 mm -Max. grinding length: 345 mm -Chuck size: Ø 133 mm -Dimensions: 1925/1135/H1755 mm -Weight: 1592 kg -functionally tested

Machine spindle, precision spindle, double grinder spindle, precision spindle for belt drive, belt drive spindle -Manufacturer: Jung, machine spindle -Type: MP 5z -Speed: max rpm -Recording: Dimensions see photos -Dimensions total: 460/210/115 mm -Weight: 16.2 kg

Machine spindle, precision spindle, double grinder spindle, precision spindle for belt drive, belt drive spindle -Manufacturer: Jung, machine spindle -Type: MP 10z -Speed: max rpm -Recording: Dimensions see photos -Dimensions total: 545/210/120 mm -Weight: 23.5 kg

Surface grinding machine, grinding machine -hydraulic horizontal surface grinding machine -Magnetic plate: 300 x 150 mm -Grinding wheel motor: 1.1 kW 2800 rpm -Water cooling with: filter -Grinding disc diameter: 200 mm -Transport dimensions: 1470/1170/H1920 mm -Weight: 1090 kg

Grinding dimensions X/Y: 600mm/305mm, max. workpiece height: 350mm, feed rate X: 24m/min, feed rate Y/Z: 2m/min, machine dimensions X/Y/Z: approx. 3000mm/2700mm/2500mm, weight: approx. 3200kg, control: Siemens Sinumerik. The control has a circuit board defect. Documentation vorhanden. An inspection on site is possible.

JUNG D22 / Internal Cylindrical Grinding Machine -Machine suitable for inner round + surface grinding -Smallest grindable bore 14mm -Largest grindable bore 150mm -Grinding length without face grinding device 250mm -Grinding length with face grinding device -6x workpiece speeds 46-270 rpm -Spindle box right/left swivel 30 degrees -Distance of the spindle axis over the center of the table 250mm -Largest workpiece spindle/grinding support distance 935mm -Spindle box / inclined position 30 degrees each -Work table / tilt forward/backward 5 degrees each -Hand/automatic operation -Taper grinding device -Bezel -Three-jaw chuck -Replacement grinding spindles

Key data: 400 mm, 150 mm

Year of manufacture 1983 Grinding length 400 mm Grinding width 150 mm Installation height 400 mm Table load 75 kg All feeds are infinitely variable Drive power 1.5 kw Automatic delivery Magnetic Plate 400 x 150 mm Puller Wet grinding device Machine is in good condition

Grinding length: 600 mm Grinding width: 200 mm Clamping surface of the table: 600 x 200 mm Greatest distance between table and grinding spindle center: 500 mm Grinding wheel dimensions: 250 x 25 x 51 mm Table longitudinal feed hydraulically infinitely variable: 1 - 24 m/min Table transverse feed per hand rotation: 4 mm Grinding spindle speed infinitely variable via DC drive: 800 - 4200 rpm DC drive: 1.5 - 5.0 kW Net weight with control cabinet approx.: 2000 kg Approx. space requirement: 3100 x 1700 x 1900 mm

workpiece diameter: 350 mm workpiece weight: 99999999 kg workpiece height: 240 mm Control: total power requirement: 7,5 kW weight of the machine ca.: 2 t dimensions of the machine ca.: m Seltene Gelegenheit: Teilüberholte Hochpräzisions-Rundtischflachschleifmaschine Mit komplett neuem Schaltschrank und neuer Steuerung mit BEMA Schleifsoftware Rundtisch-Durchmesser 380mm Magnet-Durchmesser 350mm Schleifscheibenabmaße 300x25x76,2mm Tischdrehzahl variabel max. 200U/min Schwenkwinkel des Tisches +-3 Grad Schleifspindeldrehzahl 800-4200 U/min Leistung Schleifspindelantrieb 5KW Verfahrweg quer max. 225mm Verfahrweg vertikal max. 480mm Abstand zwischen Magnetspannfutter und Spindelmitte, max. 390mm Automatischer Kopfabrichter AF65: zum zylidrischen Abrichten der Schleifscheibe im CD-Abrichtverfahren (Abrichten während de ...

grinding length: 500 mm grinding width: 200 mm workpiece height: 300 mm total power requirement: 3 kW weight of the machine ca.: 1,6 t dimensions of the machine ca.: 2,621,7 m Package 5 x JUNG HF 50 EXW near Frankfurt The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A CNC surface grinding machine Jung, overhauled in 2003, is available. Grinding length: 500mm, grinding width: 200mm, max. workpiece height: 250mm, table dimensions X/Y: 600mm/200mm, grinding wheel dimensions X/Y/Z: 225mm/25mm/51mm, speed: 4200rpm, weight: approx. 2500kg, operating hours: approx. 16602h. Documentation available. An on-site inspection is possible.

workpiece diameter: 350 mm workpiece weight: 99999999 kg workpiece height: 240 mm total power requirement: 7,5 kW weight of the machine ca.: 2 t dimensions of the machine ca.: m Seltene Gelegenheit: Teilüberholte Hochpräzisions-Rundtischflachschleifmaschine Rundtisch-Durchmesser 380mm Magnet-Durchmesser 350mm Schleifscheibenabmaße 300x25x76,2mm Tischdrehzahl variabel max. 200U/min Schwenkwinkel des Tisches +-3 Grad Schleifspindeldrehzahl 800-4200 U/min Leistung Schleifspindelantrieb 5KW Verfahrweg quer max. 225mm Verfahrweg vertikal max. 480mm Abstand zwischen Magnetspannfutter und Spindelmitte, max. 390mm Automatischer Kopfabrichter AF65: zum zylidrischen Abrichten der Schleifscheibe im CD-Abrichtverfahren (Abrichten während des Schleifprozesses) Hierdurch werden Schleifzeiten reduziert und Abrichtzeiten eingespa ...

Surface Grinding Machine Manufacturer: Jung Type: JA 500 CNC-C Year of Make: 1995 Overhauled in: 2003 Grinding length: 500 mm Grinding width: 200 mm Max. workpiece height: 250 mm Table dimensions X/Y: 600 mm / 200 mm Grinding wheel diameter: 225 mm Grinding wheel width: 25 mm Grinding wheel bore: 51 mm Speed: 4,200 rpm Machine weight: approx. 2,500 kg

: 450 mm Länge x-travel: 500 mm workpiece height: . mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 500 mm grinding width: 200 mm workpiece height: 250 mm turning speeds: 1000 - 4000 U/min table surface area: 600 x 200 mm grinding wheel size: 225 x 20 x 51 mm grinding spindle drive: 1,5 kW table feed: 1 - 20 m/min total power requirement: 2,6 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,6 x 1,6 x 1,8 m Automatic feed, 2-axis digital display, stepless speed control, Water-cooled sine angle magnetic clamping plate 400x135mm, 10mm magnetic pitch Sony digital display with scales for transverse and height adjustment Swing-out dresser on the grinding head Table direction reversal with contactless inductive switches LOSMA belt filter coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
