grinding machines used for sale (2,181)

TOS BUC 63A/3000 Cylindrical Grinding Machine Grinding Diameter 630 mm Grinding Length 3000 mm Height of centers 315 mm Workpiece Weight 2500 Kg Max. Grinding wheel dimensions 750 x 100 x 305 mm Spindle Speed 840/970 rpm Workpiece Spindle Speed 8 - 315 rpm Grinding support stroke 90 / 280 mm Table Speed: Variable - from 0.01 to 3.6 m / min Grinding Head Swivel 90 Degree Table Swivel +/- 5 Degree Work Head Tilts from 90 taper - Morse 6 Spindle Drive 15 KW Machine Dimensions 10000 x 3400 x 2000 mm Machine Weight 13.7 Ton Machine weight approx. 12 t Space requirement approx. 12 x 4.3 x 1.9 m Total power input 22 kW

WMW SI 4/1 Internal Grinding Machine YOM 52/1999 VEB Berliner Werkzeugmaschinenfabrik Grinding diameter 5-250 mm Max. grinding length 250 mm Max workpiece dia 370/450 mm (with/without safety cover) Spindle head speed 35-1400/min Work piece spindle speed 70-775 mm Max. table travel 560 mm Table speed stepless 0,5-6 m/min. Total power 16,5 kW Total Dimensions 3300x1440x2000 mm Machine 2200x1400x2000 mm Weight 4.8t.

Semi-automatic machine Workpiece diameter 40-400 mm Max. workpiece length 2000 mm Spindle rotation frequency 16-1460 rpm Workpiece spindle speed 3-180 rpm Max. diameter of grinding: -In steady rest 120 mm -Without steady rest 360 mm Max. grinding length 1800 mm Height of centers above the table- 210 mm Max. work-piece weight- 1000 kg Grinding wheel dia min/max 500-750 mm Max. length of table travel- 1800 mm Spindle taper- Morze 6 Motor power: 13 kW Periodical feed of grinding headstock: -Max.: 0,030±0,0025 mm -Min.: 0,0025±0,0006 mm Max. axial travel of grinding headstock spindle: ±2,5 mm

YOM 1987. Worked not more than 10 years, one shift Grinding length 3000 mm Grinding width 1700 mm Workpiece height 1600 mm Distance between columns 1860 mm Grinding heads- 2 Table surface 3230x1600 mm Number of slots of the table 10 pcs Permissible table load with evenly distributed load 5000kg/m Weight of work-piece 15t Table travel speed 1-40m/min

CONTROLS  electronic controls WORKING RANGE SURFACE GRINDING  grinding length: 600 mm  grinding width: 200 mmTABLE (SURFACE GRINDING)  magnetic table: yes MAGNETIC TABLE  length: 600 mm  width: 200 mm  weight: 100 kgSPINDLESTOCK GRINDING SPINDLE  spindle revolutions (max): 4200 /minGRINDING TOOL  type of grinding tool: wheel   diameter (max): 250 mm  borehole: diameter: 51 mm  width: 25 mmELECTRICAL SPECIFICATIONS  total power consumption: 7.5 kW  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 3000 mm  space requirements -front/back-: 2540 mm  total height: 1850 mm  total weight approx.: 2000 kg

CONTROLS  CNC controls GE FANUC 16IT WORKING RANGE CYLINDRICAL GRINDING  swing diameter (max): 340 mm  workpiece weight between centers (max): 80 kgWORKING RANGE EXTERNAL GRINDING  grinding diameter (max): 340 mm  grinding length: 650 mmWORKPIECE SPINDLESTOCK  c-axis: yes TAILSTOCK  distance betw. centers (max): 650 mmSPINDLESTOCK GRINDING SPINDLE  X-axis travel: 370 mm  Z-axis travel: 800 mm  tilting range (B-direction) min: -30 °  rotating range B-axis up to: 225 °  spindle revolutions (min): 1 /min  spindle revolutions (max): 1500 /minGRINDING TOOL  type of grinding tool: wheel   diameter (max): 500 mm  borehole: diameter: 203 mm  width: 63 mmSPINDLESTOCK INTERNAL GRINDING  spindle revolutions (max ...

This 5s SAACKE UWIF cylindrical grinding machine was manufactured in 2008. It features a maximum spindle speed of 600 rpm and a powerful grinding spindle peak power of 16 kW. The machine supports a variety of workpiece sizes, with a maximum diameter of Ø 20 mm and a weight capacity of 1 kg. If you are looking to get high-quality grinding capabilities, consider the SAACKE UWIF cylindrical grinding machine we have for sale. Contact us for further details.

This STUDER S242 was manufactured in 2008, a cylindrical grinding machine known for its robustness and precision. It features a swing diameter of 180 mm, max workpiece weight of 20 kg, and grinding spindle speeds up to 50 m/s. The machine includes shaft automation, grinding wheels, and is still powered up and fully functional. Annual maintenance by Studer ensures reliability. For more information about this machine, please reach out to us.

This 4-axis STUDER S33 cylindrical grinding machine was manufactured in 2023. It features a distance between centers of 650 mm, center height of 175 mm, and can handle a maximum workpiece weight of 150 kg. Equipped with a Fanuc 31i-B control system, it also includes a measuring probe, fire extinguishing system, oil mist separator, and coolers. Consider the opportunity to buy this STUDER S33 cylindrical grinding machine. Contact us for more information about this machine.

WORKING RANGE CYLINDRICAL GRINDING  swing diameter (max): 515 mm  workpiece weight between centers (max): 500 kg  workpiece weight flying (max): 120 kgWORKING RANGE EXTERNAL GRINDING  grinding diameter (max): 515 mm  grinding length: 1500 mmTABLE -CYLINDRICAL GRINDING-  tilting range (B-direction) min: 8.3 °  rotating range B-axis up to: -4 °  longitudinal travel: 1680 mmWORKPIECE SPINDLESTOCK  spindle revolutions (min): 14 /min  spindle revolutions (max): 114 /min  number of gears: 2   drive power: 1.5 kW  tool fixture: MK 6 TAILSTOCK  sleeve stroke: 40 mm  taper: MK 5 SPINDLESTOCK GRINDING SPINDLE  tilting range (B-direction) min: -10 °  rotating range B-axis up to: 10 °  drive power: 15  ...

CONTROLS  PLC SIEMENS S7 300 WORKING RANGE SURFACE GRINDING  grinding length: 800 mm  grinding width: 600 mm  vertical travel: 400 mmTABLE (SURFACE GRINDING)  table surface (left-right): 1300 mm  table surface (front-back): 550 mm  workpiece load (max): 700 kg  magnetic table: yes MAGNETIC TABLE  length: 800 mm  width: 500 mmSPINDLESTOCK GRINDING SPINDLE  spindle revolutions (max): 1400 /min  drive power: 11 kWGRINDING TOOL  type of grinding tool: wheel   diameter (max): 400 mm  borehole: diameter: 127 mm  width: 100 mmAXIS DRIVES  traverse velocity X (min): 1 mm/min  traverse velocity X (max): 30 mm/minDRESSING DEVICE  dressing tool: single diamond   operation modus: discontinuous DIMENSION ...

CONTROLS  CNC controls SIEMENS 840 D WORKING RANGE SURFACE GRINDING  grinding length: 1000 mm  grinding width: 600 mm  vertical travel: 350 mmTABLE (SURFACE GRINDING)  table surface (left-right): 1360 mm  table surface (front-back): 550 mm  workpiece load (max): 1000 kgSPINDLESTOCK GRINDING SPINDLE  spindle revolutions (min): 1000 /min  spindle revolutions (max): 6500 /minGRINDING TOOL  type of grinding tool: wheel   diameter (min): 500 mm  borehole: diameter: 203 mm  width: 100 mmELECTRICAL SPECIFICATIONS  total power consumption: 91 kW  mains voltage: 400 V  mains frequency: 50 Hz

CONTROLS  electronic controls ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 Hz

CONTROLS  CNC controls SIEMENS S7 ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 2550 kgStream finishing machine with robot loadingfor processing watch partswith a dry polishing process- Automatic loading from the right- 3 workpieces weighing up to 2 kg- One lifting unit for each workpiece- Media capacity: approx. 220 liters- High-quality machine enclosure

CONTROLS  CNC controls SIEMENS 840 D SL Microfinishing machine type Microstar 284 in vertical design with 8 workpiece holders and 4 microfinishing units for machining slide and counter ring grinding.- 6500 houersWorkpiece spindles: 8 piecesSpeed max 2000 rpmNumber of finishing units 4 piecesmax. speed 10'000 rpmmax workpiece length 160 mmLoading height 1200 mm

CONTROLS  CNC controls SIEMENS 840 D SL ELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  total weight approx.: 5200 kgMicrofinishing machine type Microstar 284 in vertical design with 8 workpiece holders and 4 microfinishing units for machining slide and counter ring grinding.-11000 houersWorkpiece spindles: 8 piecesSpeed max 2000 rpmNumber of finishing units 4 piecesmax. speed 10'000 rpmmax workpiece length 160 mmLoading height 1200 mm

CONTROLS  CNC controls SIEMENS 840 D WORKING RANGE SURFACE GRINDING  grinding length: 1600 mm  grinding width: 900 mm  workpiece height (max) with largest wheel: 600 mm  number of processing axes (excl parallel axes): 3 TABLE (SURFACE GRINDING)  table surface (left-right): 1600 mm  table surface (front-back): 800 mmSPINDLESTOCK GRINDING SPINDLE  X-axis travel: 1700 mm  spindle revolutions (max): 1000 /minGRINDING TOOL  type of grinding tool: wheel   diameter (max): 500 mm  borehole: diameter: 203.2 mm  width: 100 mmELECTRICAL SPECIFICATIONS  total power consumption: 30 kW  mains voltage: 400 V  mains frequency: 50 Hz

CONTROLS  CNC controls SIEMENS 840 C WORKING RANGE (DOUBLE DISC GRINDER)  Grinding wheel diameter: 457 mm  grinding width max. - throughfeed grinding: 80 mm  material thickness max. - throughfeed grindin: 20 mm  grinding width max. - plunge cut grinding: 205 mm  material thickness - plunge cut grinding: 80 mmGRINDING SPINDLE 1  drive power: 23 kWGRINDING SPINDLE 2  drive power: 23 kWCOMPONENT-FEEDER  Feeder Design: rotary Feeder   feeder velocity max.: 240 mm/min  feeder velocity min.: 20 mm/minScope of delivery:- Machine- emulsion tank new in 2012Measuring control IONIC 17A

CONTROLS  CNC controls SIEMENS SINUMERIK WORKING RANGE SURFACE GRINDING  grinding length: 880 mm  grinding width: 510 mmTABLE (SURFACE GRINDING)  table surface (left-right): 800 mm  table surface (front-back): 430 mm  workpiece load (max): 800 kgMAGNETIC TABLE  length: 800 mm  width: 400 mmSPINDLESTOCK GRINDING SPINDLE  spindle revolutions (min): 1500 /min  spindle revolutions (max): 3500 /minGRINDING TOOL  type of grinding tool: wheel   diameter (min): 210 mm  diameter (max): 400 mm  borehole: diameter: 127 mm  width: 100 mmELECTRICAL SPECIFICATIONS  mains power supply: 30 kVADIMENSIONS / WEIGHTS  space requirements -left/right-: 3150 mm  space requirements -front/back-: 2350 mm  total weight approx. ...

grinding length: 400 mmgrinding width: 200 mmmagnetic plate size: 350 x 150 mmweight of the machine ca.: 1.15 tdimensions of the machine ca.: 2 x 1.6 x 2 mBalancing device integratedMagnetic plate 500x200mm www.marcels-maschinen.chThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 520 mmy-travel: X mmz-travel: X mmweight of the machine ca.: 0.2 tDividing head with colletswww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 650 mmgrinding width: 450 mmworkpiece height: 325 mmtable-size: 600x350 mmgrinding wheel diameter: 350 mmweight of the machine ca.: 2.7 tMagnetic table 600x400mmMisc.accessorieswww.marcels-maschinen.chThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 370 mmplate thickness: 0-2 mmwork piece width: x mmweight of the machine ca.: 0.2 tdimensions of the machine ca.: 0.6x0.4x1.1 mDressing deviceExhausting devicewww.marcels-maschinen.chThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 800 mmgrinding width: 500 mmworkpiece height: 480 mmtable-size: 800x400 mmweight of the machine ca.: 3.4 tMagnetic plate 800x400mmwww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding wheel diameter: 300 mmno. of working stations: 2 Stücktotal power requirement: 1,1 kWweight of the machine ca.: 0.2 t1x Cup wheel diameter 300mm1x tangential wheel 260x50mmDrill sharpening deviceMore details on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

work table:: 290x130 mmtable - tiltable +/-: 15 °cross adjustment: grinding wheel diameter: 150 mmturning speeds:: 1 dimensions of the machine ca.: 780X630X1100 mmxmmxmmweight of the machine ca.: 185 kgcoolant: komplett The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

center hole: 2-50 mmworkpiece diameter: 8-125 mmworkpiece length - min.: 50 mmworkpiece length - max.: 1000 mmcolumn - center height: 145 mmgrinding wheel speeds:: number: 3 from/to: 13000-45000 U/minspindle turning speed range: 400 U/mindimensions of the machine ca.: 750x850x1800 mmweight of the machine ca.: 475 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 400 mmgrinding width: 250 mmworkpiece height: 375 mmgrinding wheel diameter: 300 mmweight of the machine ca.: 2.9 tMagnetic plate 400x250mmwww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. grinding diameter: 200 mmcentre height: 100 mmcentre distance: 525 mmweight of the machine ca.: 700 kgdimensions of the machine ca.: 120x100x150 cmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. grinding diameter: 200 mmgrinding length: 525 mmcentre height: 102 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
