milling machines wood used for sale (597)

Manufacturer: Friulmac , Type: Quadromat S, Year: 2010, Machine no 1: yes, Motore Maschine 1: 3, Machine 2: yes, Motore Maschine 2: 3, Conveyor: yes, Work piece width min-max mm: 207-800, Min.-max. workpiece length in mm: 250-2010, Min.-max. workpiece height in mm: 7-22, Feeding speed min-max m/min: 10-90, Feed stepless: yes, Overall milling units: 3+3, Year :2010

Manufacturer: Haberkorn, Type: FZS, Year: 1996, Trimming saw: oben, Durchmesser Säge: 400, Saw kW: 3, rotations controlled: 2800, Length lifting spindle mm: 252, Diameter of the spindle mm: 40, Spindle travel range total mm: 220, Travels of spindle: 1, Milling spindle kW: 40, rotations controlled: 2800, Working stations: 2, Angular adjustment horizontally: +/- 65 °, Hauptmotor kW : 9, Wight approx. kg: 2000, Feeding - manually: yes, Mitre Window: yes, Spannsystem: 2 Druckluft-Spanner, Exhaust diameter mm: 1x100 + 1x 180, Required space L x W x H mm: 2225x1720x1835, Year :1996

Manufacturer: SCM , Year: ca.1995, Control: hand, Number of profile spindle: 1, Tracer: yes, Max. operating height mm: 50, Spindle travel range total mm: 110, Number of milling spindles: 1, Milling spindle kW: ca.1,5, Milling engine rpm: 10000/20000, Grid depth setting: yes, Tracer pin in the table: yes, Number of tables: 1, Table size in mm: 7700 X 900, FREE TEXT: Tischub per Handrad 200 mm/pneumatisch Fusspedal, Year :ca.1995

Manufacturer: Celaschi, Type: TSA 520, Year: 1987, Maschinensteuerung: max. 290, Motore Maschine 1: 150, Magazine: 150, Schrumpftunnel: 2x3, Min.-max. workpiece height in mm: 5,5, Working hight min-max mm: 5,5, Cam distance mm: 5,5, Year :1987

Manufacturer: Homag, Type: FL 62/25, Year: 1988, Maschinensteuerung: Homag, Min.-max. workpiece length in mm: 250-1500, Min.-max. workpiece height in mm: 3-80, Cam distance mm: 900, Feeding speed min-max m/min: 5-40, Feed stepless: yes, Min-max protrusion of workpiece mm: 30, verängerte Kette mm: 900, Nockenaushebung: no, gesteuerte Fräsaggregate: 2, Scoring saw controlled: yes, 1st milling unit kW / rpm: 4,5/5890, 2nd milling unit kW / rpm: 4,5/5890, Year :1988

Manufacturer: Torwegge, Type: H634.1, Year: ca. 1996, Year :ca. 1996

Manufacturer: Hofmann Eckverbinder Maschine, Type: PU, Control: hand, Min.-max. workpiece height in mm: 150, Vertikal moulding unit: 1, Groove saw: Schwalbenschwanzfräser, Automatic clamping system: yes, Incl. stopper system: yes, Trench deepth max mm: 115, Total power kW: ca.1000 watt,

Manufacturer: Haffner , Type: SL 100, Year: ca.1980, Work piece width min-max mm: 550-1050, Face plate aggregate: yes, Key hole boring aggregate: yes, Clamping hight max. mm: 1050, Trench deepth max mm: 150, Trench lenght max mm: 315, Vertikal spindles: 1, Horizontal spindles: 1, Milling chain motor Kw: ca.1,0, Milling widths stop system: 315, Total power kW: 1,5, Lifting device: Pneumatisch, Year :ca.1980

Manufacturer: Zuckermann, Year: ca., Control: Hand, Moulding spindles: 3, Tool-fly circle: ca.150, Tools Spindle 1: yes, Spindel 2 Werkzeuge: yes, Spindel 3 Werkzeuge: yes, Moulding gauge operation: yes, Frässpindel U/min: 6000, Fräsbereich horizontal nach Schablone mm: yes, Kopierstift: yes, Spannbereich Werkstücke mm: 1600, Arbeitshöhe max mm: 120, Arbeitshöhe min mm: 10, Pneumatical pressure for keying: yes, Driven work piece conveyor: yes, Total power kW: ca.4, Vorschub Stufenlos: yes, die 4 Station ist als Schleifstation ausgerüstet, Year :ca.

Manufacturer: Okoma, Type: SF3 SFA , Year: 1983, Control: elektronisch, Controlled lenght stopper: no, 4-fach Konterholz: 2-fach, Studioeinrichtung Winkel: yes, Nutspindel: yes, Diameter of the spindle mm: 40, Length of tenoning spindle mm: 250, Tool travel range tenoning spindle: 2, Moulding spindles: 1, 1 length of profile spindle in mm: ca.200, Spindle for fittings groove mm: yes, Diameter of the spindle mm: 40, Constant stroke mm: 68, Main engine kW: ca 7,5, Outer profiling package: yes, Horizontal spindle clocked: yes, Work piece re-charging: no, Year :1983

Manufacturer: Gubisch, Type: ES 2000, Year: 1991, Control: Hand, Trimming saw: yes, Durchmesser Säge: 400, Saw kW: 3, rotations controlled: 2800, Working hight mm: 120, Vertikal spindle: yes, Working range Z-axis mm: 300, Length lifting spindle mm: 300, Diameter of the spindle mm: 50, Travels of spindle: 2 x100 mm, Milling spindle kW: 50, rotations controlled: 2800, Working stations: 1, Angular adjustment horizontally: yes, Work piece hight max mm: 120, Hauptmotor kW : 7,5, Wight approx. kg: 2000, Vorschub Stufenlos: yes, Mitre Window: yes, Year :1991

Manufacturer: Kölle Tischfräse, Type: F 50, Year: 1990, Control: oben, revolutions rpm: 3000/6000/9000, Length lifting spindle mm: 150, Diameter of the spindle mm: 30, Spindle travel range total mm: 120, Spindle swivel-mounted max Grad: no, Main engine kW: ca.4, Feeding speed: yes, Table extension - lenght: yes, Exhaust diameter mm: 150, Wight approx. kg: ca.900, FREE TEXT: Anschlag ausziehbar/Haffner Vorschub, Year :1990

Manufacturer: Rapid, Type: Kettenstemmer, Year: ca.1980, Min.-max. workpiece height in mm: 200-1200, Vertikal moulding unit: 1, Motor kW: ca.1,0, Travel top to down mm: 150, Travel longitudinal mm: ca.300, Max door width mm: 1200, Max. mortise hole dimensions L X W X D mm: 150 X ca.300, Drill spindles: 1, Face plate aggregate: no, Key hole boring aggregate: no, Year :ca.1980

Manufacturer: Schneider Doppelspindelfräse, Type: SK-02, Year: 1981, Control: hand, Program: 2, Work piece width min-max mm: 3000/4000/6000/8000/10000, Min.-max. workpiece length in mm: 150, Vertikal spindle: 30, Spindle lift: no, Diameter of the spindle mm: 5,8, Spindle travel range total mm: no, Feeding speed: 1800 kg, Year :1981

Manufacturer: Homag, Type: NFL 26/6/10/PW/L, Year: 2002, Control: Homag, Work piece width min-max mm: 136-250, Min.-max. workpiece length in mm: 2500, Min.-max. workpiece height in mm: 10-25, Working width min-max mm: 136 - 250, Feeding speed min-max m/min: 15 - 60, 1st milling unit kW / rpm: Ritzen 4,5 kW/6000 U/min, 2nd milling unit kW / rpm: Ritzen 4,5 kW/6000 U/min, 3rd milling unit kW / rpm: 6,6 kW Profilfräsen 6000 U/min, Free space for units: 2x 460 mm, Machine overhauled: no, System dismantled: yes, Year :2002

Manufacturer: Framar, Bauyeshr : 1992, Control: hand, Work stations: 1, Vertikal moulding unit: yes, Motor Kw: 3, Travel top to down mm: 120, Travel longitudinal mm: 275, Max door width mm: 1000, Max. mortise hole dimensions L X W X D mm: 20 X 75 X 110, Min. mortise hole dimensions L X W X D mm: 2 X 20 X 35, Automatic clamping system: yes, Incl. stopper system: yes, Trench deepth max mm: 110, Lifting device: yes, Wight approx. kg: 900, Year :1992

Manufacturer: Maka, Type: STV 71, Year: ca. 1980, Control: hand, Work stations: 1, Horizontal moulding unit: 1, Motor kW: 3, Clamping hight max. mm: 120, Trench deepth max mm: 130, Lifting device: yes, Year :ca. 1980

Manufacturer: Mekanika, Type: Nut und Federfräse, Year: unbekannt, Work piece width min-max mm: 10-250/300, Working width min-max mm: 10-ca.300, Working hight min-max mm: 10-30, Feeding speed min-max m/min: pneumatisch, Overall milling units: 3 +2, 1st milling unit kW / rpm: 2,5/2580, 2nd milling unit kW / rpm: 2,5/2580, 3rd milling unit kW / rpm: 2,5/2580, 4th milling unit kW / rpm: 2,5/2580, 5th milling unit kW / rpm: 2,5/2580, Diameter of the spindle mm: 30, Diameter of the spindle mm: 30, Year :unbekannt

Manufacturer: Lehbrink , Type: WL 38, Year: 1991, Control: Programm, Work piece winding off lenth max. mm : 3000-550, Through running lenght (Cutting lenght) max. mm: 550, Work piece thickness min mm: 10, Angular adjustable saw supports: yes, Pneumatically going in/out: yes, Fräsmotore Stk: 4, Power of milling engines kW: 4,2, Fräsmotore U/min: 6000, Automatical foil glueing device: yes, Scoring unit for foil glueing: yes, Length stopper: yes, Year :1991

This 4-axis WEIRATHER KS1300/4 was manufactured in 2004. It features a maximum milling length of 1300 mm and a milling diameter of 300 mm, making it suitable for various applications such as tool handles and furniture components. The machine operates with a Siemens control system and has a cutter shaft speed of 5300 rpm. If you are looking to get high-quality milling capabilities, consider the WEIRATHER KS1300/4 wood mill we have for sale. Contact us for further details.

Wooden entrance length: min. 130 mm Max. 1000mm Ø370mm Wood cross-section: Min. 20x40mm Max. 80x180mm Wooden output length: Min.3700mm Max.7400mm Tine version vertical/horizontal 10/11 3.8mm pitch PVAC White Glue, 2-sided glue application Connected load 65 kW

Wooden entrance length: min. 130 mm Max. 1000mm Ø370mm Wood cross-section: Min. 20x40mm Max. 80x180mm Wooden output length: Min.3700mm Max.7400mm Tine version vertical/horizontal 10/11 3.8mm pitch PVAC White Glue, 2-sided glue application Connected load 65 kW

Bruks RR800 Capacity: at roller conveyor feed rate 60 m/min for logs with diameter 60 cm - 4 logs/min at roller conveyor feed rate 30 m/min for logs with diameter 60 cm - 3 logs/min Maximum removal 200 mm Max log diameter 800 mm measured 1500 mm from the root and Length min 3,2 m max 6,2 m Number of cutting tools 30 Cutting tool width 60 mm Cutting motor 37 kW, 1500 rpm Cutting length 900 mm Roller chain driver: gear reductior transmission motor of 2.2 kW Hydraulic unit 5,5 kW Total weght including main motor 5000 kg

1 x used double-sided Rotoles S600 with 2 grinding units and 1x brush Working width 600mmm Speed 60m/min Calibration milling planing machines with feed rollers Best accuracy of the boards and excellent results in delamination attempts, at any speed. ROTOLES S calibration machines are the best choice for calibrating boards and slats before gluing. Rotoles S calibration milling planing machines with feed rollers Best accuracy of the boards and excellent results in delamination attempts, at any speed. ROTOLES S calibration machines are the best choice for calibrating boards and slats before gluing.

ROOT START REDUCER LOG END REDUCER60 m / min for logs with diameter 60 cm - 4 logs / min at roller conveyor feed rate 30 m / min for logs with diameter 60 cm - 3 logs / min Maximum removal 200 mm Max log diameter 700 mm measured 1500 mm measured 1500 mm from the root and length min 3.2 m max 6.2 m Number of cutting tools 30 Cutting tool width 60 mm Cuttin motor 37 kW, 1500 rpm

According to the PDF prospectus!

Kettenstemmer (chain Mortiser) carpentry: â?¢ handy Kettenstemmer with strong pulling engine â?¢ Adjustable depth stop to 125 mm â?¢ Adjustable RIP fence 25-180 mm â?¢ Chain guide with integrated lubrication â?¢ Housing, handles and base plate made of sturdy die-cast aluminium â?¢ Security Beidhandschalter for the protection of the user â?¢ Including high-quality chain set Technical specifications: â?¢ wattage 1350 Watts â?¢ Idling speed min-1 3,400 â?¢ Maximum mortising depth 100 mm â?¢ Press width 40 mm â?¢ Dimensions 261 x 320 x 382 mm â?¢ Weight 10 kg Scope of delivery: â?¢ power cord 5 m â?¢ RIP fence â?¢ Open end wrench â?¢ Allen key â?¢ Chain set (sword, chain, grea ...

BUTT END REDUCER consist of cone roller (8 m) with log turner, Cross conveyor 4 strings, butt end reducer (motor 50 kW) steper to feed...

) Mortising depth 100 / 150 mm-) nominal no load speed 1/min - 4050) rated power 2500 W-) weight 8.7 kg-) universal motor 230 V / 50 Hz transverse stop best. No. 200954 1 Allen key 4 mm best. No. 093074 1 Allen key 8 mm best. No. 093070 1 connection cable 10 m best. No. 087612 â?¾Zapfenlöcher â?¾Materialeinsatz such as: Solid wood, laminated wood â?¾Ergonomische handle and switch arrangement - for safe, efficient and energy-saving work. â?¾Geringes weight - ideal for use on construction sites. â?¾Extrem powerful motor - for high efficiency and saving time. â?¾Einzigartiges light-weight 8.7 kg. â?¾Der long cross fence holder with large adjustment range allows you to work on large-scale wood. â?¾DAS clamping system in the LS 103 EC allows a quick chain change. Even a tighten ...

Kervenfräse (carpentry): The machine is almost as good as new, and there is also a warranty on the machine! Technical data "MAFELL Kervenfräse ZK 115 EC": -) Smoothing depth: 0-83.5 mm ) Milling tool - standard: 150 x 115 mm mm -) Swivelling range: 0-60 ° -) Nominal no-load speed: 4050 1/min -) Rated power: 3000 W ) Weight (with standard milling head): 21.1 kg ) Universal motor: 230 V / 50 Hz Scope of delivery: 1 Kervenfräskopf, complete, Ã? 150 x 115 mm 1 RIP fence 1 spanner 10 mm 1 wrench, Torx T-15 1 connection cable 10 m
