other metal working machines used for sale (11,390)

amount: 1 STKTool holderThese chucks are designed for high-speed machining.These are precision tools from the Italian company DAndreaThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: Thielenhaus Model: MicroStar 284 Year of Manufacture: 2020 ( unit 1 ) 2018 ( unit 2) Power Supply: 3-phase (3~) Frequency: 50 Hz Operating Voltage: 400 V Rated Current: 48 A Control Voltage: 230 V / 24 VDC Main Fuse Rating: 63 A Certification: CE Find more here - / Contact us at -

max. wheel diameter: 600 mmgear width: 500 mmmax. module: 15 min. module: 1 total power requirement: 2 kWweight of the machine ca.: 2 tdimensions of the machine ca.: 2x1,5x2 mThe rounding of the teeth is obtained by coordinating alternative movement of the cutter and rotary movement of the piece. The alternative movement of the cutter is obtained by rotating a cam, shaped in order to obtain radius or cusp rounding. A series of 4 cams allows to work modululus from 1 and 16 included. An regulation device allows change the modulus between the minimum and maximum value of every cam. The rotation of the piece is controlled by a three-stage gear wheel which forms the dividing system. The piece lock and the movement of the rapid entry of the cutter to the piece is controlled by pneumatic servo devices. The practicality and rapidity of the equipment, as well as the wide range of profiles availab ...

Manufacturer: Tox Pressotechnik Model: MAG 075.222.A.001 Year of Manufacture: 2008 Condition : Excellent Min./Max. Air Pressure: 0.3 / 0.5 MPa ; 3 / 5 bar Max. Press Force at Max. Air Pressure: 680 kN Total Stroke: 100 mm Power Stroke: 11 mm Machine Weight (without tool): 3420 kg Find more here - / Contact us at -

Manufacturer: Matec Model: 30 HV Year of Manufacture: 1997 Type of Machine : 5-axis CNC vertical machining center - Well-maintained condition. - Working area: X = 2000 mm, Y = 600 mm, Z = 800 mm. - Equipped with rotary table Ø310 mm. - Swivel head with 1° Hirth toothing. - Heidenhain TNC426 control unit. - SK40 spindle with 12000 rpm. - Tool magazine with 24 positions. - Vacuum clamping plate dimensions: L = 1250 mm, W = 630 mm, with 8x8 mm grid and 5 mm groove. - Side opening for inserting long parts. Find more here - / Contact us at -

Manufacturer: Prima Power Model: EP1030 Year of Manufacture: 2012 Technical Data: - Power Supply Range: 340–440 V - Frequency: 50/60 Hz - Max. Power Consumption: 10 kW - Operating Temperature (standard): +5°C to +30°C - Operating Temperature (with Fan - optional): +5°C to +35°C - Operating Temperature (with Air Conditioner - optional): +5°C to +42°C - Relative Humidity: 20% to 75% (temporarily up to 90%) - Sound Pressure Level at Workplace: 72 dB(A) - Max. Pressing Force: 105 kN - Max. Beam Opening: 600 / 650 / 700 mm - Stroke of Press Beam: 310 mm - Approach Speed (Y-axis return): 110 mm/s - Approach Speed (Y-axis approach): 110 mm/s - Working Speed (Y-axis): 10 mm/s - Stroke (X-axis): 550 / 1000 mm - Stroke (R-axis): 200 mm - Positioning Speed (X1-axis): 800 mm/s - Positioning Speed (R-axis): 200 mm/s - Positioning Accuracy (X1-axis): 0.01 mm - Positioning Accuracy (R-axi ...

Manufacturer: ADIGE Model: LT652/B Year of Manufacture: 2002 Machine Description: - Tube laser system LT652, manufactured in 2002. - Equipped with a CO2 laser source with 2 kW power. - Loading length: 6500 mm - Unloading length: 3500 mm The machine is in good technical condition for its age. The cooling system requires occasional maintenance. Find more here - / Contact us at -

feed pressure: 10 barliter capacity: 2,71 m³ / minmotor speeds:: 3000 U/mindimensions: 1300 x 1000 x 1900 mmtotal power requirement: 18,5 kWweight of the machine ca.: 500 kgFeatures:- Focus Control 2.0 control system- Network pressure sensor- Belt-driven drive system- SoundproofedThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Laser cutting machine Type: MSF 4001.20Ltk+T500 4kW IPG Manufacturer: MicroStep Year: 2016 Working area: 4000 x 2000mm + space for pipe cutting Laser: 4000 W IPG Linear guides Rexroth Gear racks Precision helical gears ATLANTA on all axes, double-sided driven portal STOBER gearboxes Drives maintenance-free, processor-controlled AC-servos Panasonic Max. positioning speed 130 m/min - one axis, 180 m/min simultaneously 2 axes. Acceleration 10 m/s2 Z-axis positioning speed 50 m/min Z-axis travel 150 mm Z-axis acceleration 0.75 G Position deviation Pa 0.07 mm in accordance with VDI/DGQ 3441 Repeat return accuracy Ps 0.03 mm in accordance with VDI/DGQ 3441 Ambient operating temperature +10 °C to +35 °C Relative humidity 0 to 90 % Machine in very good condition, under power Find more here - / Contact us at -

Jesco JAGUAR 2260 — a CNC lathe machine. Type of machine: CNC turning lathe Specifications: - Manufacturer: Jesco Machinery Ltd. - Model: JAGUAR 2260 - Swing over bed: 560 mm - Centre height: 280 mm - Max turning length (distance between centres): 1500 mm - Spindle bore: 80 mm - Control unit: FAGOR 8060 - Country of origin: Taiwan The machine is in very good condition and has been used very little. Find more here - / Contact us at -

Manufacturer: FRECH Model: DAW 125 S RC Year of Manufacture:1998 Type of Machine : zinc die-casting system Condition : The machine is fully functional and was used to manufacture bathroom accessories (shower handles). After just over a year of downtime, an oil change is required. Locking Force: 1250 kN Working Pressure: 105 bar Machine Weight: 6000 kg Rated Current: 40 A Rated Voltage: 3×400 V Control Voltage: 24 V Frequency: 50 Hz Find more here - / Contact us at -

Manufacturer:GRIMME Model: G-DT-F 12/10 SB Year of Manufacture: 2015 Power: 24.5 kW Voltage: 230 / 400 V Frequency: 50 Hz Motor Type: SERVO Spindle Type: Z80-K530.04 Drive Type: SIE / HD Certification: CE Find more here - / Contact us at -

Manufacturer: Reichenbacher Model: ECO RS3 Year of Manufacture: 2016 Type of Machine : 5 Axis Milling Machine CE Certified: Yes Find more here - / Contact us at -
