presses used for sale (1,635)

This stamping machine was manufactured in 1992. It features a robust Eccentric H-frame, monoblock design with a press force of 1600 kN and a fixed stroke of 160 mm. The machine includes a magnetic conveyor for scraps, a quick die cart system, and a millutensil oiling system. Ideal for high-quality stamping capabilities, consider the RAVNE PRESSES Manzoni 160 machine we have for sale. Contact us for more information about this machine.

Hydraulic Press DEGUMA P12-12 II

Eccentric press PEE I 250, in working conditon.

Eccentric press LEK 160

Key data: 75 t, 80 mm, 120 1/min

Pressure 75 t Stroke rate 120-600 / min Sheet width 10-300 mm Table size 1050 x 820 mm Pusher clamping surface 960x820 mm Distance table - UK plunger 380 mm Adjustable stroke - max. 80 mm Feed length 0-150 mm Total power requirement 20 kW Machine weight approx. 13 t Feed unit with max. belt speed 70 m/min Eccentric shaft with 4-fold bearings 2 connecting rods Central lubrication incl. magnetic belt conveyor - in use until 2020 -Operating instructions -Manual - Circuit diagram etc..

Key data: 400 t, 30000 mm

The machine is in good technical condition, inspection and test drive is possible by prior arrangement.

SCHULER HYDRAP SH 630 - 1.6 x 1.3 (2005)Total weight 74,000 kgRated force 6,300 kNMax. stroke length 600 mmMounting height 900 mmCloses quickly 500 mm/sMax. working speed 23 mm/sMin. working speed 51 mm/sBase and tool max. (xH) 2,280 x 1,200 mmBase and tool min. (xH) 1,250 x 600 mmTool height min. 300 mmTotal tool weight max. 2,500 kgTotal tool weight max. 5,000 kgPermissible eccentrichydraulic pressload left rightPermissible eccentricload front rear 490 kNm 250 kNmInstalled power 295 kWRated current 565 AVoltage 400 VFrequency 50 HzOperating hydraulic pressure 278 barTotal oil volume 5.185 lOil type HLP 68 in accordance with DIN 51524

Šmeral Trnava Metal Lepa 63 PACategory: MetalBrand: Šmeral TrnavaModel: Lepa 63 PAYear of manufacturing: 1988Under power: Yes630 kN

Key data: 100 t, 355 mm, 125 mm

Press force 100 t The dimensions of the table top 1000 x 640 mm Stroke adjustment 125 mm Plunger adjustment 90 mm Stroke rate 75-150 rpm Main motor power 6/10 kW Machine dimensions L x W x H 1725 x 2230 x 2970 mm Machine weight 10100 kg

Used High Quality Bystronic pressbrake 6-axis for a sale.

Key data: 10 t, 300 mm, 300 mm

more info on request

Eccentric press LEK 250, new in 1987, in good condition.

Nominal force 400 kN Stroke rate - 70/140 / min Motor 3/4 kW Exploitable stroke - at constant. Clutch brake temperature 50/45/min Capacity - material thickness 4-6.4 m - with single strokes, 2-3.2 mm - with continuous stroke Table 660 x 530 mm, table top 650 x 515 x 75 mm Stroke adjustment - 10-125 mm, Dimensions 1250 x 1600 x 2370 mm - High , Btto 4500 kg Reconditioned machine - warranty 9 months from delivery date

Nominal force 100 t Stroke - 250 mm motor 3 kW more info on request

MontagePRESSE with central lubrication, pneumat. Feed and PLC control. Documents More info on request

Pressure capacity: 8000 kg Maximum cutting area - 200 mm2 for material strength 40 kg / mm2 Horizontal radius 200 mm Clearance between the side walls 160 mm Fixed hub 35 mm Pin hole in the Stossel 38 x 60 mm Adjustability of the Stossels 70 mm Weight of 400 kg of the Presse Operating instructions The machine is located in the new value. State, probably never in use. Control actuator Stober

Tech. Data Nominal press force 1000 kN at maximum stroke adjustment - commute 6.5 mm 1250 kN at maximum stroke adjustment - commute 3.5 mm Strokes with endurance 125/83/63 Hube/min Usable stroke rate 50 50 38 / min. Throat depth 320 mm, clamp 380 mm Stroke adjustment 10-120 mm, Stosselverstellung 80 mm Stosselflaeche 800 x 320 mm, recording journal 50 / 85 Tabletop table top hole, 900 x 630 mm 230 mm, Durchfalloch in the table 300 / 400 x 250 mm Drive - 7,5 / 5,5 kW Bulk 1350 x 2080 x 2780 mm, Btto 8900 kg

Pressure: 65 tons -Stroke: 140 mm -Table size: 720 x 600 mm -Plunger surface: 500 x 300 mm -Tappet adjustment: 80 mm -Strokes: 20-40 per min. -. Weight: 6000 kg -Dimensions (L x W x H): height 3.1 m -Clamping hole ø 60 x 80 mm More info on request

Single column - eccentric press, STANKO, K 1430 A - 100t BJ. 1985 Tech. Condition very good, - pressure: 100 t -Projection: 320 mm -Stroke: 10-130 mm -Mounting height: 400 mm -Table size: 850 x 560 mm x 100 mm -Tappet adjustment: 100 mm -Stroke: 50-53 / per min. -Machine weight: 8800 kg -Dimensions (W x D x H): 1.60 x 1.85 x 2.9 m Camshaft gear ROSS/Herion Herion valve Auxiliary brake DESCH Lutex ZB 200 Two hand release -transverse eccentric shaft and pneumatically actuated clutch / brake Komi nation -suitable for inlays in two-hand operation -secure setting -Single stroke, continuous stroke MOT testing in 04/2016

45 To-Stoessel performance adjustable 45 mm hub adjustable 8-80 mm table size 690 x 410 mm punch mounting 50 mm unloaded 200 mm height 400 mm electric pneumat. Ortlinghaus single-disc clutch and disc brakes with auxiliary brake, Central grease lubrication system, Hohenverstellbar. Report, Wellenrissprufung, see table, UVV - 2014 - still in use ? see operating instructions, Tech.Zustand - good, ready for use

Capacity 50 tons Stroke 750 mm Table size 1500x1000 mm

SLIDE  total force (nominal): 880 to  stroke: 305 mm  cutting velocity min.: 5 mm/s  cutting velocity max.: 70 mm/s  closing velocity: 200 mm/s  returning velocity: 200 mm/sV-RING  nominal force: 400 to  stroke: 40 mmCOUNTER RAM  nominal force: 200 to  stroke: 40 mmTOOL DIMENSIONS  lower table (left-right): 1010 mm  lower table (front-back): 1600 mm  upper table (left-right): 1000 mm  upper table (front-back): 1000 mm  shut height max.: 460 mmSTRIP-FEEDER  feeder type: roll feeder   sheet width max.: 450 mm  sheet thickness max.: 16 mm  feeding step min.: 1 mm  feeding step max.: 999.9 mm  sheet length min: 3950 mm  speed max.: 48 m/min  Vertical adjustment: 140 ...

Capacity: 1600 tons Slide stroke: 300 mm Slide stroke length at maximum force: 0,16 mm Distance adjustment between table and slider: 10 mm Slide stroke number in 1 min: 75 Length of a rod: 920 mm The closed height: 660 mm Table overall dimensions: 940x1200 mm Table height above floor level: 450 mm Slide overall dimensions: 860x910 mm The size of lateral windows: -Height: 560 mm -Width: 600 mm Main motor: 110 kW Press overall dimensions: -Length: 5060 mm -Width: 3940 mm -Height above floor level: 5125 mm Press weight: 120 tons

Air steam die forging hammer : Capacity : 16 tons, Nominal mass of drop parts : 16000 kg, Impact energy : 400 KJ, Ram stroke : 1500 mm, Ram stroke per minute : 20, Distance clear between guides : 1180 mm, Ram dimensions front to back : 1500 mm, Die holder dimensions front to back : 1600 mm, Bottom die impression to floor distance : 500 mm, Steam/air pressure : 0.7-0.9 MPa, Overal dimensions : - Floor space : 4500 x 2450 mm, - Height above floor level : 7920 mm, Mass of anvil block : 325 tons, Total weight of hammer : 425 tons.

Technical data: Capacity, ton 1000 Ram stroke, mm 400 Max. ram strokes per min. 20 Shut height,mm 1000 Ram adjustment, mm 320 Table size, mm 3150 x 1800 Ram size (front-to-back), mm 1700 Column gap size, mm 1500 x 1900 Bolster plate thickness, mm 250 Ram travel to its extreme position where it develops nominal capacity, mm 12 Pneumatic cushion capacity, ton 200 Pneumatic cushion E51031468 stroke, mm 200 Upper knock-out capacity, ton 50 Main motor power, kW 132 Press dimensions, mm 5150 x 4700 x 7830 Press weight, kg 200000

Capacity: 1600 tons Slide stroke: 300 mm Slide stroke length at maximum force: 0,16 mm Distance adjustment between tableand slider: 10 mm Slide stroke number in 1 min: 75 Length of a rod: 920 mm The closed height: 660 mm Table overall dimensions: 940x1200 mm Table height above floor level: 450 mm Slide overall dimensions: 860x910 mm The size of lateral windows: -Height: 560 E5931468 mm -Width: 600 mm Main motor: 110 kW Press overall dimensions: -Length: 5060 mm -Width: 3940 mm -Height above floor level: 5125 mm Press weight: 120 tons

Capacity (ton) 315 Table size, mm 2500 x 1250 Slider stroke, mm 400 Shut height,mm 750 Strokes per min 25 Press weight, kg 50900

-Max pressure at the end of stroke – 4000 ton -Press stroke – 400 mm -Number of stroke – 50 per minute -Max distance of stroke from the table – 1400 mm -Dimensions of slider: 1320 x 1320 mm -Bed dimensions: 1120 x 1600 mm -Bed movement by height – 20 mm -Max pressure of upper ejector – 20 t -Max stroke of upper ejector – 65 mm -Max pressure of lower ejector – 40t -Max stroke of lower ejector – 80 mm -Main motor power – 225 kW -Main motor speed – 730 rpm -Total width — 6280 mm -Total depth – 4885 mm -Total height – 8870 mm -Height over the bed – 7315 mm -Total net weight – 280 092 kg

for production of forgings by forging of ferrous, non-ferrous metals and alloys in the hammer dies model M212 Impact energy, 50 kJ Nominal weight of falling parts, kg 2000 Stroke woman, mm 1200 Stroke woman, mm 1200 Machine dimensions Length Width Height (mm) 3650X1660X5310 Weight kg 58.310, spare parts available

Maximum force ton-force 400 Slider stroke length mm 400 Slider strokes per minute 25 Maximum distance between table and slider (in lower position of slider) mm 470 Size of adjustment of distance between down-stamp a plate and slider mm 160 Table overall dimensions: mm ·from front to rear 1000 ·from left to right 1000 Slider overall dimensions: mm ·from front to rear 800 Main electric motor power kW 40 Press overall dimensions mm ·length 3470 ·width 3140 ·height 5940 Press weight kg 32600
