other metal working machines used for sale (10,802)

Tube laser Bodor T230 Laser power: 1 kW Round tubes 20 mm to 230 mm Square tubes 20 x 20 mm to 160 x 160 mm Cutting of welded assemblies Year of construction 2017, but installed and put into operation in 2018

ERMAKSAN LASERMAK 6000 6X2 laser cutter was produced in 2014. Technical parameters: – laser source: 6000 W CO2-laser GE Fanuc C6000i-Model C – RF-excitation: 2 MHz – power stability: ± 2% (power monitor) – laser wave length: 10.6 μM – beam mode: Fanuc Low Order Mode – laser shutter: mechanical safety shutter – laser gas composition: CO2 / He / N2 – gas consumption by laser: 20 l / h – cooling water flow rate: 250 l / min – maximum cutting capacity: mild steel 25 mm (during tests the maximum achieved: 30 mm), stainless steel 15 mm, aluminum 12 mm - machine activation time: 22899 h - working time: 10122 h - cutting time: 8429 h – total energy requirement: 100-120 kW – cutting head focal length: 5 -7” -10 inch – maximum worksheet size: 6150 x 2000 mm – maximum burden capacity: 4000 kg – machine axes: 5 axes [X, Y, Z, U (X2), V] – axis ...

Wire EDM machine SODICK A 600 manufactured in 1997. Technical parameters of the SODICK A 600 EDM machine: - table travel (X axis): 600 mm - table travel (Y axis): 400 mm - Z axis travel: 270 mm - maximum dimensions of the processed part (width x depth x height): 800 x 550 x 260 mm - maximum weight of the workpiece: 900 - auxiliary table travel (U axis x V axis): 70 x 70 mm - wire diameter: 0.1 ~ 0.3 mm - maximum wire speed: 250 mm / sec. - wire tension: 0.2 ~ 2.8 kgf - cutting inclination at an angle: + -15 degrees per 100 mm of thickness - height from the floor to the surface of the working table: 1000 mm - machine tool dimensions (width x depth x height): 2188 x 2645 x 2100 mm - machine tool weight: 3700 kg

IMR Model F.A. 2.5 S Sand Core Shooter, 2.5 litres San Capacity, 10 Sec Dry Cycle Time, 25 kg Sand Hopper Capacity, 100kg Core Box Weight. Size of heating plates: 200x350x60mm Max. size of core box: 400300x200Sp.mm Max. weight of core box: 100kg Max. distance between heating plates: 400mm Max. closing stroke: 300mm

Max. useful capacity [dm3] 170 Max. batch weight [kg] 500 Blast room inside dimensions [mm] : Ø700 x 988 Max. workpiece diagonal [mm] : 350 Max. weight per workpiece [kg] : 23 Number of blast wheels : 1 Power per blast wheel [kW] : 11 Abrasive throughput, max. [kg/min] : 180 Initial abrasive filling [kg] : 180 Air required for dust collection [m3/h] : 1 600 Installed power, approx. [kW] : 12,3 Dimensions, approx. [mm] A : 3 730 x B: 2 070 x C : 1 610 Weight, approx. [kg] : 2 300 Max. carrying capacity of loader [kg] : 500 Power of loader [kW] : 7,5 Weight of loader [kg] : 1 250

More information on request Excellence working condition

Working range: tube Ø 21,3 – 114,3 mm Wall thickness 2,3 - 11 mm Length: 6-12m Composed of two RFA14 chamfering machines with transport devices between the machines. The task of machines is to chamfer inside and outside both ends of the tubes. The range of diameters of chamfered tubes 21.3-114,3mm and wall thickness of 2.3-11mm in the length range of 6-12m. The task of transport in the area of the chamfering machines is to collect the tubes from the roller table and move them between the chamfering machines. Machine is new, never used.

Line is equipped with the following: • 25 ton EAF w/356mm electrode & 16 MVA trsfmr (rblt 2006) • 25 ton LF w/305mm electrode & 3 MVA trsfmr new 2006 • 25 ton VOD/VAD w/305mm electrode & 3 MVA trsfmr23297 • 2-Strand VAI Caster new 1990's: Hand & Auto Controls 6 ton tundish (ladle) movable crystalizer electromagnetic stirrer • 8 ton ESR (2 pillars) w/4MVA transformer will produce 1 to 10 ton ingots • Dust collection system • 12.5 ton charging cranes • 50 ton ladle cranes • 12.5 ton service cranes • ingot moulds • ladles

The list of equipment for sale from molding line: 1. Moulding Machine HSP-2D (22kW, 70f / h) 2. Lifting table 3. Pressure plate 4. The dispensing sand tank

No of nails manufactured: 900 pcs/min Min. diam. of wire: 0,7mm Max. diam. of wire: 1,4 mm

Ram stroke: 750 mm Energy of full blow: 1840 kgm Quantity of stroke: 120 u/min Mass of anvil block: 12,5 t Mass of hammer with anvil block: 21,9 t

Mass of falling parts: 1000 kg Ram stroke: 800 mm Energy of full blow: 3600kgm Quantity of stroke: 110 Mass of hammer: 35t Year of production: 1974r.

This 4-axis WOTAN Rapid 1 boring machine was manufactured in 1995 and retrofitted in 2017. It features an impressive X-axis travel of 1,500 mm, Y-axis travel of 1,000 mm, and Z-axis travel of 1,000 mm. The 360° rotary table allows for multi-sided machining, enhancing efficiency. If you are looking to get high-quality boring capabilities, consider the WOTAN Rapid 1 machine we have for sale. Contact us for further details.

Small manual machine

Used industrial machine offered by IBEXTRA.

Used industrial machine offered by IBEXTRA.

This 3-axis ONA QX4 die-sinking EDM machine was manufactured in 2017. It features an X-axis travel of 600 mm, Y-axis travel of 400 mm, and Z-axis travel of 400 mm. The work tank dimensions are 1060 x 750 x 480 mm, accommodating a maximum workpiece weight of 1500 kg. If you are looking to get high-quality die-sinking capabilities, consider the ONA QX4 machine we have for sale. Contact us for further details.

This 3-axis Sodick Picka PF-32A was manufactured in 2010. Its an electron-beam processing machine designed for high-precision surface treatments. Features include a vacuum chamber, a max workpiece size of 300 × 200 × 100 mm, and a beam diameter of up to 60 mm. Ideal for applications requiring fine finishing. Contact us for more information.

This DEPO HF milling machine was made in the year 2012 and has 7 axis. The Stable 7-axis machine is specially developed for the manufacture of tools, molds and matrices.

Metal 3D printer manufactured in 2022. This TRUMPF TruPrint 1000 multilaser features two 200W fiber lasers, providing multilaser productivity with 7,500 operating hours per laser. It is designed for high-precision dental and medical components, utilizing Bego Mediloy S-Co (Cobalt-Chrome alloy). Consider the opportunity to buy this TRUMPF TruPrint 1000 multilaser metal 3D printer. Contact us for further details.

This 4-axis LOLA BH 110 CNC was manufactured in 2005. It features a generous X-axis travel of 1750 mm, Y-axis travel of 1650 mm, and Z-axis travel of 630 mm. The working table measures 1550 x 1250 mm and can support a load of up to 4500 kg. If you are looking to get high-quality boring capabilities, consider the LOLA BH 110 CNC boring machine we have for sale. Contact us for further information.

The facility includes a comprehensive range of production and support equipment, including: 4 Cold Rolling Mills (4Hi & 2Hi) – including tandem rolling lines with speeds up to 500 m/min, processing strip widths from 4–100 mm and thicknesses from 0.4–4.5 mm. 9 Annealing Furnace Units – stretch and batch furnaces operating with nitrogen and hydrogen atmospheres, with temperatures up to 1,000°C. Inspection, NDT & Finishing Lines – including eddy current inspection, surface grinding, shaving, and coil-to-bundle conversion. 2 CRM Work Roll Grinders (WMW, Germany) – together with blanking lines capable of producing up to 240 hacksaw blanks per minute. Laboratory & Auxiliary Equipment – including tensile testing equipment, optical microscopes, compressors, punch presses, and other supporting machinery. In combination lot, but also available for individual pu ...

This OTEC DF10 was manufactured in 2016. It features a stainless steel process container and jog mode for easy workpiece changes. Includes additional storage for workpieces and holders, accommodating up to 10 holders. Equipped with water cooling DF-7 and a cooling compressor, its suitable for ambient temperatures between 10-40°C. Ideal for efficient media mixing and tool handling. Reach out for more information.

This 5-axis Brother HS-70A wire EDM machine was manufactured in 2003. It features a CNC-A50 control, working strokes of 410 x 260 x 170 mm, and can handle workpieces up to 350 kg. The wire diameter ranges from 0.1 to 0.3 mm, supporting precise cutting. If you are looking to get high-quality EDM capabilities, consider the Brother HS-70A machine we have for sale. Contact us for more information about this machine.

This AGIE Agiecut VERTEX 3 Erosion machine was manufactured in the year 2006 in Switzerland and has 37021 erosion hours. It is equipped with an Agievision 5 Software version 07.08.01 control unit.

Optical measuring machine manufactured in 2009. This TESA visio 300 dcc features a measuring range of 300 mm in the X-axis, 200 mm in the Y-axis, and 200 mm in the Z-axis. It includes a high-resolution CCD camera and interchangeable zoom optics for enhanced measurement capabilities. If you are looking to get high-quality optical measurement capabilities, consider the TESA visio 300 dcc machine we have for sale. Contact us for further details.

CMM machine manufactured in 2004. This Mitutoyo Crysta-Apex C 776 features a measuring range of 700 mm in both X and Y axes, and 600 mm in Z. It includes advanced components such as a motorized Renishaw probe head and automatic temperature compensation. If you are looking to get high-quality measurement capabilities, consider the Mitutoyo Crysta-Apex C 776 machine we have for sale. Contact us for further details.

This cmm machine was manufactured in 2011. Featuring a granite table measuring 1400 mm x 1900 mm and a total height of 2800 mm, it is equipped with Ferranti 315 software for startup. Ideal for precise measurements with a spacious setup, including 880 mm space under the bridge. A great opportunity to buy this FERRANTI INTERNATIONAL MERLIN 1100 cmm machine. For more information about this cmm machine, please reach out to us.

3D printer manufactured in 2021. This 3D SYSTEMS Projet 2500 Plus is equipped with essential features like 3D Sprint Basic for streamlined operation and a VisiJet M2R-CL Starter Kit for clear plastic prints. With only 10 working hours, its practically new. Its MJP EasyClean System ensures hassle-free maintenance, and the ProJet Finisher guarantees professional finishing. If you seek reliability and quality, buy this ProJet 2500 Plus 3D printer. For further details, contact us.

This CHARMILLES ROBOFORM 51 Erosion machine was made in 1998. The machine has a table size of 750x500 mm.
