milling machines wood used for sale (597)

Key data: 3 mm, 10 kW, 30 mm

Martin T26 Swivel milling machine with axes, digital display and speed control of the 7.5 kW spindle Brand: Martin Type: T26 with frequency control M-No.: 20000 Year of manufacture: V415216 YouTube: Control: Electrical adjustment digital readout; Spindle height & inclination, jaw stops-chip removal, electrical adjustment of feed device height Control panel: At eye level, swivel Motor: 7.5 kW, 10 hp - 220 V with frequency-controlled speed Milling spindle: ø50 mm spindle met SK40 en Dornfix quick-change system Milling mandrel: -45 to + 45° CNC or electrically manually adjustable with rapid traverse and creep traverse Spindle height positioning: 150 mm electrically adjustable with rapid traverse and creep traverse and digital display Calibration device: For exact 0 positioning of the milling spindle Electro-pneumatic spindle locking mechanism for tool change Millin ...

Martin T25 Swivel spindle milling machine with 5 axis control Brand: Martin Type: T25 M-No.: V252368 Year of Make: 1998 Engine power: 7.5/9.5 kW or 10/13 hp, 2 speeds Dalander engine Swivel milling spindle: -5° to +45° Milling mandrel: ø30 mm Spindle mount: ISO quick-change system with 30 mm Height adjustment milling spindle: 150 mm Speeds: 3000/4500/6000/9000 rpm Table size: Table extension 2,400 mm and table widening (=extendable support) Control panel: CNC control at eye level with LCD screen Spindle height CNC-controlled electromotive spindle height adjustment (program controlled or manual control) Tilt -5° - +45° CNC-controlled electromotive angle adjustment (program controlled or manual control) Stops: CNC-controlled electromotive adjustment of the two stops in relation to the milling mandrel (program controlled or manual control) CNC-controlled electr ...

power capacity: - kWvolt: - Vampere: Atotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Brand: Sicar Type: Wood milling bench + extraction Model: SF70 Chassis number: BO400062003 Construction year: 2003 Weight: 0,28 tons Length mm: 2500 Width mm: 1000 Height mm: 1700 Transport size L x W x H: 2,5 x 1,0 x 1,7 Condition machine : Good

Verboom tenon milling machine Brand: Verboom Type: PN 5 LINKS Standard: BHG / SHA adapted according to the currently valid regulations Labour legislation applicable within the EU Machine data: Pinon milling machine with 5 processing units (1 saw + 4 milling machines) 1. Saw unit positioned over the workpiece, 4.0 kW, ø400 mm 2 tenon milling unit over the workpiece with 2.2 kW 3. Pinon milling unit below the workpiece with 2.2 kW 4. Vertical milling spindle (slot milling unit) with ø40 spindle and 200 mm Clamping length, 4.0 kW direct drive 5. Vertical milling spindle (slot milling unit) with ø40 spindle and 200 mm Clamping length, 4.0 kW direct drive All motors are equipped with zero branch safety, The machine has a pressure guard so that the workpiece must be clamped before the aggregates start, The hood and the protective curtain are equipped with door swi ...

Panhans 261 tenon cutter Brand: Panhans Type: 261 M-No.: 1112 Machine data: saw: 2.6 KW, 3.000rpm, tool: ø400 mm, 160 mm cutting height Slot spindle 7.5 kW - 4,000 rpm, tool: ø400 mm, spigot length: 170 mm spindle clamping length: 160 mm Table: Manuel, with pneumatic workpiece clamps Tish height: Travel 80 mm Stop: Stop can also be used as miter stop Dimensions: approx. 1.9 m x 1.6 m, 1.7 m high, plus tenon table: 0.50.8 m Weight: 600 KG

Okoma PN 2 tenon cutter Brand: Okoma Type: PN2 Year of construction: M-No.: Machine data: saw: 3.0 KW, 2.800 rpm, tool: ø400 mm, 140 mm cutting height - turret head cutting height Slot spindle 7.5 kW - 2,800 rpm, tool: ø400 mm, 4,000 rpm, spigot length: 170 mm spindle clamping length: 160 mm Table: Electric, with pneumatic workpiece clamps Tish height: Travel 80 mm Stop: Stop can also be used as miter stop Dimensions: approx. 2.2 m x 1.6 m, 1.7 m high, plus tenon table: 0.50.8 m Weight: 600 KG

Swing Chiselstemmer Measuring machine Stemmer swing chisel

Copy milling machine - Copy longitudinal milling machine Functionally tested Incl. Tools

Brand: Martin Type: T25 M-No.: V172604 Year of construction: 1990 Motor power: 5/6 kW Swivel milling spindle: -5° - +45° Milling mandrel : 30 mm Height adjustment milling spindle: 150 mm Speeds: 3000/4500/6000/9000 rpm Cone of the milling spindle: MK5 Table size: Table extension 2,500 mm and table distribution (= extendable support) Automatic milling spindle start-up/bremzing via rotary knob Control panel: eye level with digital reading Spindle height -5° - +45° electromotive angle adjustment with digital readout Inclination -5° - +45° 150 mm Electromotive heights Adjustment with digital readout Feed: five-pole. Socket with operation via central control

Brand: Martin Type: Table milling machine with heavy tenon table Spindle: ø30 mm Motor: 4 KW

Brand: Paoloni Type: T140 Motor power: 5 KW Milling mandrel : 30 mm Height adjustment milling spindle: 140 mm Speeds: 3000-4500-6000-9000 Spindle height adjustment: Handwheel adjustment with analog display Feed: HolzHerr 3 roll Option: Aigner integral stop

This 5-axis BIESSE Rover A4.30 was manufactured in 2010. It features a working field of 3,060 mm in the X-axis and 1,320 mm in the Y-axis, along with a powerful 12 kW air-cooled electrospindle. The machine includes advanced programming with BIESSEWORKS and a revolving tool changer with 10 positions. If you are looking to get high-quality CNC wood machining capabilities, consider the BIESSE Rover A4.30 machine we have for sale. Contact us for further details.

This 4-axis BIESSE Rover K1232 was manufactured in 2017. It features an extensive X-axis working range of 3,260 mm and a Y-axis working range of 1,260 mm. The machine is equipped with a tool magazine capacity of 16 positions and an electrospindle power of 19 kW. If you are looking to get high-quality CNC machining capabilities, consider the BIESSE Rover K1232 CNC processing center we have for sale. Contact us for further details.

This 5-axis PADE VELUX CNC Wood Machining Centre was manufactured in 2011. It features an impressive X-axis travel of 3,550 mm, Y-axis travel of 1,800 mm, and Z-axis travel of 750 mm. The machine includes two tandem worktables with six pneumatic clamps, along with two electrospindles for enhanced performance. If you are looking to get high-quality wood machining capabilities, consider the PADE VELUX machine we have for sale. Contact us for further details.

Lower spindle milling machine SCM TF130ps Spindle Diameter 40mm Longitudinal trolley in the worktop Total length of the spindle 180mm 7kw Main Motor Rotation speed change on the belt 3000/4500/6000/7000/10000 Spindle rotation left and right Manual spindle lifting Technical documentation Year of manufacture 2019

This 3-axis BIESSE Skipper 100 was manufactured in 2009. It features a versatile working range with a maximum length of 3,000 mm and a width of 1,000 mm. The machine is equipped with 78 independent drilling spindles, allowing for efficient vertical and horizontal drilling, as well as routing and grooving capabilities. If you are looking to get high-quality CNC processing capabilities, consider the BIESSE Skipper 100 machine we have for sale. Contact us for further details.

This 5-axis BIESSE Rover A Edge 1643 was manufactured in 2017. It features a versatile CNC machining center with an edge banding unit, ideal for various applications. If you are looking to get high-quality CNC processing capabilities, consider the BIESSE Rover A Edge 1643 machine we have for sale. Contact us for further details.

This 4-axis BIESSE Rover K 1532 G was manufactured in 2014. It is a used CNC machining center designed for precision and efficiency. If you are looking to get high-quality CNC processing capabilities, consider the BIESSE Rover K 1532 G machine we have for sale. Contact us for further details.

This 3-axis HOMAG WEEKE OPTIMAT BHX 055 was manufactured in 2018. It features a workpiece length capacity of 200 - 3,050 mm and a workpiece width of 70 - 850 mm. The machine includes 13 vertical drilling spindles and 4 horizontal drilling spindles, providing versatile machining capabilities. If you are looking to get high-quality CNC processing capabilities, consider the HOMAG WEEKE OPTIMAT BHX 055 machine we have for sale. Contact us for further details.

PART NUMBER 7753 SPECIFICATIONS - max diameter of machined dowels 130mm - 110mm bushing fitted - max diameter of input material 160mm - min length of input material 800mm - max machining allowance per side 15mm - 15kW knife head drive motor - 3 types of feed speed + front/rear - 1.1kW feed motor In sequence: - 3 toothed pulling shafts - 3-knife head - 3 smooth pulling output shafts - Dimensions L/W/H 3100x1400x1500mm - weight 2100kg ADVANTAGES – Polish production – 3-knife head – used beam, very good condition Net price: 32900 PLN Net price: 7833 EUR depending on the price 4.20 EUR (Prices may change with higher fluctuations)

Part number 7977 SPECIFICATIONS - range of diameters of machined dowels 40-140mm - max diameter of input material 240mm - min length of input material 600mm - max machining allowance per side 30mm - 100mm diameter sleeve fitted - 18.5kW knife head drive motor - infinitely variable feed speed adjustment + front/back - 1.5kW feed motor In sequence: - Introductory trough - Gear pulling shafts 6pcs - 4-knife head - smooth pulling shafts 6pcs - Extraction port diameter 220mm - dimensions l/w/h 2660x1350x1400mm - weight 1650kg ADVANTAGES – Polish production – DTR documentation – used beam, very good condition Net price: 49900 PLN Net price: 0 EUR depending on the price 4.20 EUR (Prices may change with higher fluctuations)

SCM T130 Low Spindle Milling Machine Spindle Diameter 35mm Total length of the spindle 160mm 5.5kw main motor Rotation speed change on the belt 3000/4500/6000/7000/10000 Spindle rotation left and right Electric spindle lift

This 5-axis FORMAT4 Profit H350 1630 was manufactured in 2018. It features a robust construction with a heavy-duty welded steel frame and dual-driven moving gantry. The machine offers an impressive X-axis travel of 4000 mm, Y-axis travel of 1970 mm, and Z-axis travel of 455 mm. If you are looking to get high-quality CNC machining capabilities, consider the FORMAT4 Profit H350 1630 CNC processing center we have for sale. Contact us for further details.

This 5-axis FORMAT4 PROFIT H350 16.30 CNC processing center was manufactured in 2017. It features an impressive X-axis travel of 4000 mm, Y-axis travel of 1970 mm, and Z-axis travel of 455 mm. The machine is equipped with a powerful 12 kW spindle and a dual-driven gantry system, ensuring high precision and efficiency. If you are looking to get high-quality machining capabilities, consider the FORMAT4 PROFIT H350 16.30 machine we have for sale. Contact us for further details.

Envelope Tenoning Machine Bacci TSG 2T Spindle speed 6000 rpm Maximum trunnion width mm 115+2R Trunnion depth: 10 – 45 mm Table upwards, tilt angle: 0° – 15° Table tilt downwards: 0° – 30° Table side inclination angle: 0° – 20° Machine Weight 1050kg Machine dimensions 1500x1150x1350mm

This 3-axis SCM Accord 20 CNC router was manufactured in 2010. It features a working area with dimensions of 4250 mm in the X-axis and 2280 mm in the Y-axis, making it suitable for nesting production and wood processing. The machine includes a powerful electrospindle with a speed range of 600 to 24,000 rpm and a side tool magazine with 10 positions. If you are looking to get high-quality milling capabilities, consider the SCM Accord 20 CNC router we have for sale. Contact us for further details.

CNC processing center manufactured in 1997. This WEINIG / DIMTER Unicontrol 10 features a maximum workpiece length of 3,600 mm and a maximum workpiece height of 100 mm. It includes a powerful cross-cut saw with a spindle speed of up to 3,000 rpm and a tenoning spindle motor power of 15 kW. If you are looking to get high-quality CNC processing capabilities, consider the WEINIG / DIMTER Unicontrol 10 machine we have for sale. Contact us for further details.

Carousel milling machine Comec FGS-1T Number of generators 1 Unit system: milling unit Pneumatic material central clamp Motor power 11kw Rotational speed adjustable by variator Net price

Router 600 router Spindle to arm distance 600 mm Twin speed spindle drive motor with 2.2/1.5 kw Two spindle speeds 9000/18000 RPM Spindle tilt angle adjustment 45-90-45 degrees Vertical spindle stroke 80mm Height-adjustable table Pneumatic control of the spindle from the pedal
