other wood working machines used for sale (1,492)

Machine designed for machining solid wood doors with frame and raised panelsWorkpiece dimensions Length 150 - 3000 mm Width 40 - 300 mm Thickness 20 - 60 mm Material: hard woods/soft woods Machine equiped with 2 working areas, including - 3 NC-axes X, Y, Z- telephone modem- 1 sawing unit- 1 horizontal boring unit- distance horizontal drill above table (Z):max. 40 mm- fixed workpiece table- central lubrication- CE package- max. workpiece length 2.400 mm KOCH Numeric with 3 NC-axes Positioning control with PC Pentium CPU Operating system Windows XP Professional: english 15? Touchpanel VGA + Touchscreen by means of LVDS connection USB-connection on PC and on Touchpanel Seriel and parallel interface on the PC Hard disk 2,5? Input of machine commands and motor control through the Touchpanel PS2 connection for external keyboard Office PC software Stretched machine bas for max. workpiece width ...

Drum crusher with hydraulic pusherKnife drum width: 800 mmMouth 800 x 1200 mmMotor: 18,5 kWextraction connection diameter 200 mm

Single sided postforming line, capable of doing L - and U profiles, with or without insert.Workpiece thickness: 16 to 60 mm.Min. workpiece width: 150 mm.Workpiece overhang: 70 mm.Max. laminate overhang: 105 mm.Feed speed 3 - 18 m/min.Fence side at the leftEquipment:Squaring and shaping part:1 x Postforming squaring unit, 2 motors each 1kW, 1st motor removing the laminate, 2nd motor trimming the overhaning laminate1 x scoring, motor 1 kW, top position1 x milling unit for the laminate when doing U profiles 1 x laminate support Postforming part1 x blow cleaning nozzle 6 x glue nozzle for the glue application 2 x glue roller9 x IR heating, each 2,2 kW2 x Hot air blower, each 10 kW1 x Basic postforming pressure zone for L-profiles, using rollers1 x Basic postforming pressure zone for U-profiles, using rollers1 x VF postforming pressure zone for special profiles, using pressure pathsFinishing  ...

Semi-automatic

Max working width: 1300mmMax working thickness: 140mmMax. machining width: 1300mmMotorized feed rollers2 brushing units

Fixed side at the leftPanel thickness min/max: 16/45 mmMin. panel width: 150 mmLateral panel support for panel width up to 900 mmMin/max. panel length: 700 / 3100 mmMax. laminate overhang: 110 mmMax. laminate thickness: 0,8 mmRadius min/max: 6 / 22 mm (depends the laminate)Feedspeed max. 18 m/minTop pressure by beltEquipment:Infeed fence, adjustable, defines the panel overhang2 x trimming unit 0,4 kW, HSK 25 toolholder1 x PVAc glue application5 x glue nozzle, adjustable1 x hot air blower3 x IR heating on top (55 cm length), 3 x bottom (90 cm length)Postforming zone 1,8 m. lengthVarious pre-installed profiling sets 1 x top trimmer 0,4 kW

Fixed side at the leftFeedspeed 18 - 25 m/minWorking width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mmPanel overhang 30mmPanel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations)Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mmCoil diameter 830 mmEquipment:Sprayers release agentSquaring device with 2 motors each 3 kWEdge heatingEdge magazine for 2 coils, guillotine for edges up to 3 mmGlueing part A20 with quickmelt applicationLateral pressure zone K, 1 driven and 6 after pressing rollersEnd trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kWContour trimming, 2 exchange unitsProfile scraping PN10Flat scrapers FA11Sprayers cleaning agentBuffingAutomation package straight/chamfer:-Automatic adjustment infeed fence-Automatic setting of pressure rollers-Pneumatic setting of end trims-Pneumatic setting of rough trims-Automatic setting of chamfer/ra ...

Workpiece thickness: 8 - 90 mm, electronically adjustableFeed rate: 18-32 m/min frequency controlledEdge thickness: 0.3 - 3 mm for roll edges, strips up to 20 mmEquipment:Inlet guide automatically adjustable via the control, extension 500 mmJoint milling unit: 2 x 3.0 KWworkpiece preheatingGluing unit A34edging magazine for rollPressure zone with 1 driven, 6 non-driven rollers, automatic adjustment from the controlCutting unit WK14, straight, 2 motors 0.8 kWPre-milling unit: 2 x 1.5 KW, pneumatic adjustmentForm milling unit FF 12 automatic, 2 motors 0.4 kWradius/phase milling unit FF12 automatic 4 motors 0.4 KWuniversal milling aggregate controlled UF11, 4 kWProfile scrapers PN20Glue scrapersNozzles for detergent and anti-stickPolishing unitControl: Power Control PC22

Single sided edge bander with hot melt, fixed side at the right, pre-milling unitEdge thickness: 0,4 to 12 mmWorkpiece thickness: 8 - 60 mmFeedspeed 8-20 m/min (limited to 10 m/min using the contour trimming)Workpiece transport by chain, top pressures with rubber rollersSound enclosure over all trimming motorsEquipment:Adjustable fencePre-milling with 2 shapers, each 2,2 kWCoil and strip magazine Hot melt unit, Quickmelt type Pressure zone with1 driven and 2 non-driven pneum. Loaded rollersEnd trims, 2 x 0,35 kW motors, straight and chamfer 15?Top/bottom trimming, motors 2 x 0,35 kWRadius trimmmingContour trimming unit, leading and following edge, 2 x 0,35 kWRadius scraping unitGlue scrapersBuffing unitControlls PC 20+

Panel thickness: 8 - 50 mmThickness of the edges: 0,4- 3 mmFeed speed 8 - 11 m / minPU pressure rollersEquipment:Squaring unit, 2 motors 2,2 kWPanel edge heatingEdge magazine for coil and stripsHot melt application with rollerAirtec AT4510 unitThe Airtec aggregate is positioned so you can use Airtec or the standard glue potMotorized side pressure unitEnd trims, 2 motors, pneumatic positioning straight and with chamfertrimming unit above / belowContour trimming unitProfile scraping unitGlue scraping unitPolishing unitDetergent spray systemcentral lubrication

machine 1:Fixed side at the left, working width 220 mm to 2500 mmWorkpiece overhang max. 110 mmElectronic width adjustmentPanel thickness 8 - 90 mmTop pressure by beltsRolling chain with automatic lubrication, automatic pop-up dogs every 1000 mmFeed speed 10 - 40 m/minChain infeed taking 1,62 m. panels in front of the dogsPanel alignment at the infeedMiddle supportNC 30 controllsEquipment left and right:1+1 Jump universal shaper 6 kW1+1 Twin hogging unit, motors 6,6 kW (2 motors)1+1 Universal shaper 6 kW1+1 Jump universal shaper 6 kWpanel turning device HOMAG TD 31/30/13Year 1989machine 2:Fixed side at the left, working width 220 mm to 3000 mmWorkpiece overhang max. 110 mmElectronic width adjustmentPanel thickness 8 - 90 mmTop pressure by beltsRolling chain with automatic lubrication, automatic pop-up dogs every 1000 mmFeed speed 8 - 40 m/minChain infeed taking 1,62 m. panels in front of ...

Workpiece thickness: 8 - 50 mmEdge thickness: Coil edges 0.4 - 3 mmFeed speed 10 m/minEquipment:manual height adjustment.Joint milling unit, 2 motors Panel edge heatingGluing area Pressure zone 1 driven and 2 non-driven rollersEnd trims, 2 x 0,8 kW motors, straight and chamfer 15?Top and bottom trimmingProfile scraping unit for PVC edgingGlue scrapers

4-side squaring and edge banding lineMachine 1:Fixed side right, moving side leftRolling chain, feed 10 - 40 m/minControlls NC 21Panel thickness 8 - 60 mmMax. panel width 1500 mmEdges: coil 0,3 - 3 mm, strips 0,4 - 20 mmEntry fence for veneered panelsEquipment:1+1 Compact-twin hogger, 2 motors 6,6 kW1+1 Compact hot melt unit A20 with panel edge pre-heating, glue roller Q34, twin coil magazine, lateral pressure rollers C including anti-stick application1+1 Free space for solid wood edges up to 2,54 m length1+1 Rough trimming, 2 x 1,5 kW 1+1 Fine- or radius trimming, 2 x 0,4 kW (edges up to 6 mm)1+1 Universal shaper 8,1 kW1+1 Universal shaper 8,1 kW1+1 Edge sander KS 101+1 Disc sander DS 401+1 Disc sander DS 40Angular transfer to the right, TWR 24/30/12/SPanel sizes: width 250 - 1200 mm, length 250 - 3000 mm, thickness 8 - 45 mmMachine 2Machine II + infeed magazine TW 24Fixed side right, m ...

Motorised height-adjustmentSound enclosure over all trimming motorsEquipment:Coil and strip magazineHot melt unit Pressure zone End trims, chamfer and straight, automatic adjustmentTop/bottom rough trimmingTop/bottom fine trimming, tilting, Contour trimming unitScraping unitBuffing unitreturn conveyor Ligmatech ZHR 05

Edgebander manufactured in 2008. This BIESSE Edge Stream B1 features a comprehensive set of tools including a PU-gluing machine, pre-milling unit, edge trimmer, and fine milling unit. It also includes rounding and edge scraper units, along with swaying brushes and an edge heater. If you are looking to get high-quality edging capabilities, consider the BIESSE Edge Stream B1 machine we have for sale. Contact us for further details.

Wood production line manufactured in 2023. This ISM ATM-01 is a custom-made automatic production line designed for the fully automated manufacturing of wooden garden screens from individual planks. It features automatic discharge and stacking of finished screens, tilting stacks for efficient processing, and is adjustable for five different screen types. If you are looking to get high-quality wood processing capabilities, consider the ISM ATM-01 machine we have for sale. Contact us for further details.

Quality scanner manufactured in 2014. This MICROTEC GOLDENEYE GLD 600 DSC is designed for the inspection of large boards and panels up to 1.8 meters in width. It integrates geometric, visual, and X-ray multi-sensor cameras to assess both external and internal properties of lumber, providing a comprehensive evaluation of material quality. If you are looking to get high-quality inspection capabilities, consider the MICROTEC GOLDENEYE GLD 600 DSC machine we have for sale. Contact us for further details.

This FORMAT4 TEMPORA 60.06 glueBox x-motion edgebander was manufactured in 2024. It features a turntable magazine with a diameter of 750 mm for edging material ranging from 0.4-3 mm, a GlueBox application unit, and upper and lower polishing units. The machine includes advanced x-motion Plus control with a 15 SmartTouch screen and a multifunctional milling unit for precise plastic edge machining. Contact us for more information about this machine.

Inv. Num. : 8894 Type: B24-TH300 DX/DW PU Producer: H&H Maschinenbau Created: 2020 Parameters: Weight: 498 kg Equipment: PUVS 280 P melting machine for 20 kg drums of PUR adhesive

Inv. Num. : 8874 Type: TRIATHLON 1487 V Producer: HOLZHER Created: 2003 Parameters: Binding height: 55 mm Machine dimensions: 7500 x 1300 x 1800 mm

Inv. Num. : 8663 Type: Opticontrol Producer: Weinig Generated: Parameters: Max. tool diameter: 300 mm Max. tool length: 330 mm

Inv. Num. : 8465 Type: SP-300x4C Producer: Prochera Created: 2015 Parameters: Max. speed: 1500 1/min Working feed: 0-23 m/min Max. width: 300 mm Max. height: 100 mm Number of brushes: 4 Weight: 1500 kg Equipment: Replacement brushes

Inv. Num. : 8372 Type: ZLSM-4x1.20-3x1.20-0 Producer: Mühlböck Generated: Parameters: Depth: 5400 mm Height: 4200 mm Length: 6520 mm Capacity: 12 x 8 63 m3 (103 68 m3) Load: 100 kg per 1m2 Number of fans: 4 pieces

I am selling a disassembled Kovos SR 4 dryer without electronics. Without thermal insulation (glass wool) 2x fans, 2x heating coils. Dimensions of the dryer: Exterior height 3.2 m x width 4.1 m x length 4.55 m, interior height 2.1 m x width 3.8 m x length 4.1 m. The dryer is complete, it is possible to visit it partially built. Described parts for assembly. Material aluminum, very good condition. It was stored in the hall for 15 years.

Driven heavy roller conveyor for a gang saw, band saw Machine dimensions: total length 8300 mm, width 1800 mm, roller width 1600 mm, height roller of floor 580 mm, Roller Number 11 pieces Gear motor Power 2 kW/1400 rpm Total weight 2000 kg. As good as new

Nail series: 34° paper collated Strip nails Wire diameter: 3.8-4.6 mm Nail length: 100-160 mm Working pressure: 5-8 bar Weight: 7.10 kg Magazine capacity: 72 nails + Paper collated Strip nails of 4.6 x 160 19200 piece (600 St / carton, 32 piece box, order No. 140037) Compressed air nail machine 1100 EUR, 19200 ships nails 640 EUR

CNC unit for boring, routing and sawing Brand: Atemag Type: Function Line Duo With two tool interfaces, angle 90° Max. drive speed 10,000 R.P.M. Max. tool spindle speed 15,000 R.P.M Gear ratio i = 1:1,5 Turning direction left/right Torque max. 20 Nm Tool interfaces: ER25, ER 32, saw blade flange 30 mm, sawblade dia. max. 180 mm or modular
