machines and plants for process engineering used for sale (7,610)

Mobile 290L vessel incl. discharge with valve, inspection glass, etc.

Planetary mixer, vessel and stirrer made of stainless steel, two vessels with a volume of 60l each.

Heating- and drying oven for temperatures from +20°C up to 300°C. Special turnstile drive for 1L bulkhead jars, TwinDISPLAY. Max. loading of chamber: 300 kg.

Gral high shear granulator, stainless steel consctruction, 75-liter -shell hopper with vessel scale, side reject with side discharge, stand alone construction for main mixer. This one-pot processor is suitable for effective and fast mixing, granulating and drying in the same container. In explosion-proof version, for wall installation. Batch size: 25-50 Liter
. Temp. in double jacket: 20-85° C.


Mobile 4-gloves Isolator for sterility testing. Working chamber with 4 sleeves for working with sterile materials. Incl. air sampler Theo MAS-100/ISO. PLC: SIEMENS S5. Unit requirements cleanroom Grade A.

Washer for efficient and gentle washing of ampoules, vials and bottles. Output: up to 2'500 vials/h. Machine comes with format parts for 5-, 10- and 20 ml vials.

Steam air sterilizer for the counterpressure sterilization of aqueous solutions in sealed containers. Pass-through autoclave with semi-automatic doors on two fronts. Hydraulic system made entirely of stainless steel. Capacity: 1470 litres. Operating temperature: 138.9°. Chamber size: 800 x 800 x 1250 mm (depth).

Hot air sterilization for dry heat sterilization and depyrogenation. Autoclave with single-leaf door on both sides. Operating temperature: 160/250°. Chamber size: 1000 x 1450 x 1450 mm (depth).

Diatomaceous earth filter capacity 45 liters, operating pressure 2.5 bar. Suitable for filtration of cutting oils of automatic lathes.

A steam-powered freeze drying plant HOF with 1.8 m2 usable space. With stainless steel chamber door, ice capacitor, set of actuators (6 pcs.) sep. Panel.

Used microfiltration system made by Membra Flow with ceramic membranes, program Simatic, capacity 12.000 liters / h. After general renovation and service it was taken out of production (not working again).

The Mac Ewans Centrifugal pump is a pump for use in sanitary applications. Previous used in a Casein plant. Motor: 7,5 kW - 380/415 V - 50 Hz - 1.455 rpm - 14,6/13,4 A. Diameter of the impellor: 180 mm. Connections on the inlet: 3. Connections on the outlet: 2,5. Estimated capacity: ± 30.000 ltr/h., macewans.co.nz/, Type of Machine: Centrifugal pump, Stock Number: 1445, Diameter of the impellor: 180 mm, Motor: 7,5 kW - 380/415 V - 50 Hz - 1.455 rpm - 14,6/13,4 A, Estimated capacity: ± 30 m3/h

Gettinge GE 91413 ARC-2 pass-through autoclave in a two-door pass-through design with an automatic, horizontally sliding door; unit fitted with a cross-contamination barrier; previously used for metal format parts, dosing pumps, stoppers, filters, clothing, etc., chamber dimensions 950 x 1450 x 1350 mm (WxHxD), usable chamber space 920 x 1450 x 1350 mm (WxHxD), chamber volume approx. 1859 litres, chamber pressure -1.0 / +3.0 bar, design temperature 143.6 °C, colour laser printer for programme documentation, Siemens S7-300 machine control system, Siemens MP 277 Touch control panel, electrical supply 230/400 V/50 Hz/3-phase, machine dimensions approx. 3100 x 2350 x 1710 mm (WxHxD), autoclave unladen weight approx. 2450 kg

Bosch SBM Schoeller-Bleckmann Vakutherm ADV-12.09.12/2 steam steriliser, internal chamber dimensions 1300 x 1000 x 1250 mm (HxWxD), chamber usable space 1200 x 900 x 1200 mm (HxWxD), entry height 450 mm, chamber: cubic with rectangular door opening and jacket for heating and cooling, chamber made of 1.4404 (316L), 0.8 µm, polished. Design pressure, chamber: -1.0 / +3.0 bar (g), design pressure, jacket: 0.0 / +3.0 bar, design temperature: 150 °C, vacuum pump with water-saving circuit for evacuating the steriliser chamber; transport trolley for loading the steriliser fitted with 2 swivel castors and 2 fixed castors; machine dimensions with integrated control cabinet: 3,900 x 4,515 x 1,850 mm (HxWxD); empty weight of the steriliser: approx. 3,000 kg

Machine name: Chamber filter press used Manufacturer: Diefenbach Type: FP DE800-90 Year of Make: 1997 Plate format: 800 x 800 mm Number of plates: 90 Press capacity: approx. 1350 litres Filter area: Approx. 99 m2 Filter pressure: 15 bar Cake thickness: 30 mm Procedure: Closed Plate Conveyor: Automatic Panel material: Polypropylene Design: Bridge spar press Filter Cloth Washer: No Filter Cloths: No Dimensions: L 8500 x W 1300 x H 2100 mm Empty weight: approx. 8000 kg Tech. Documentation: Yes Accessories: A control cabinet, a hydraulic system, a light barrier Condition: Used Price: On request

Machine name: Filter press used Manufacturer: Netzsch Type: 800/80 Year of Make: 1998 Plate format: 800 x 800 mm Number of plates: 81 Press capacity: approx. 1200 litres Filter area: Approx. 88 m2 Filter pressure: 15 bar Cake thickness: 30 mm Procedure: Closed Plate Feed: Manual Panel material: Polypropylene Design: Side-spar press Filter Cloth Washer: Yes Filter Cloths: No Empty weight: approx. 7000 kg Tech. Documentation: Yes Accessories: A control cabinet, a hydraulic system, a light barrier, a filter cloth washer, high-pressure pump. Condition: Used Price: On request

Compact 2-deck vibratory screening system (custom-made) For sale is a robust, fully functional 2-deck vibratory screening system custom-built in 2017. The system was specially designed for the precise screening and dusting/classification of feed pellets, but is also ideally suited for a wide range of other bulk materials (e.g. granules, pellets, seeds, wood pellets, etc.). The screening plant is in good, well-maintained condition, is immediately ready for use and is characterized by its compact design and high-quality workmanship. Technical data & equipment: - Type/type: Vibratory screening system / Linear vibrating screen (custom-made) - Year of construction: 2017 - Condition: Used, good, fully functional - Drive: 2x Netter Vibration Motors (Type NEG 50120) - Power connection: 400 V high-voltage current (incl. connection cable and CEE plug) - Screen levels /  ...

For sale is a high-quality and fully equipped laboratory / compact pellet press from the renowned manufacturer Amandus Kahl (Type 14-175) including precise K-Tron dosing screw, Rittal control cabinet and extensive accessories/spare parts. The system is ideal for test setups, laboratory applications or smaller productions in the pharmaceutical, chemical or food industries as well as for special applications, as the parts in contact with the product are made of high-quality stainless steel. Technical data & equipment: Pellet mill Amandus Kahl: - Manufacturer: Amandus Kahl (Hamburg, Germany) - Type: Press 14-175 - Machine No.: 22374 - Year of construction: 2006 - Certification: CE - Drive motor: 3.0 kW (220–240 / 380–415 volts) - Speed: Infinitely variable up to 101 rpm - Die: Diameter 150 mm - Press rollers: 2 pieces K-Tron dosing screw (produ ...

Stainless Steel Continuous Mixer Manufacturer: MWM Type 400 V-K Content: 400 litres Technical specifications : Machines No. 650 Continuous Mixer with Inclined Bucket Mixing Tool and Chopper Dimensions: length 3.00 m, height 1.00 m + 1.10 frame, width 1.30 m Engine: Power 15 kW, 1,460 /94 rpm Mixing shaft 94 rpm Documents: Nameplate

An FGC extraction system for the extraction of oil and coolant aerosols from one or more CNC machines is offered. Volumetric flow rate: 600m³/h, motor power: 1.5kW. Including telescopic stand. The filters should be replaced. An on-site inspection is possible.

A mixing tank with propeller agitator is offered. Volume: approx. 4000l, internal height: approx. 2000mm, internal diameter: approx. 1650mm, internal material: acid- and alkali-resistant plastic, outer shell: GRP. Equipped with mixing system: variable-speed propeller agitator, manhole, air-operated diaphragm pump for product feed, bottom drain, extraction system and working platform. An on-site inspection is possible.

Temperature controller, temperature control unit, temperature regulator, modular temperature control unit -Manufacturer: GWK, temperature control unit teco wi -Type: teco 1000 -Heating output: 18 kW -Nominal cooling capacity: 100 kW -Technical data: see photo of the type plate -Dimensions: 1190/320/H745 mm -Weight: 102 kg

1) Zyklomat coolant cleaning system, application: cleaning of grinding emulsion, cleaning capacity: 350l/min, recirculation clean tank-dirty tank: 100-350l/min, max. machine supply: 250l/min, supply pressure: 3.5bar, filtration principle: ZYKLOMAT high-performance hydrocyclone Z1B-9/3, separation limit: approx. 5µm, medium: emulsion 3-6%, max. medium temperature: 50°C, solid particles: brass particles, max. solids quantity: 15kg/h, total volume: 5.14m³, operating volume: 3.6-4.58m³, process: fully automatic full-flow filtration, sludge discharge: fully automatic, with non-flowing consistency, 2) double scraper tank for grinding sludge KR 1.75-5.1, total volume: 5.14m³, max. volume: 4.58m³, length: 4,000mm, including 70mm reinforcement, width: 1,890mm, including 140mm reinforcement, height: 1,105mm, including 100mm base profile, neck height: 2,300mm, max. theoretical discharge capac ...

Filter area: approx. 8m², number of filter leaves: 9, vessel capacity: 720l, allowable operating overpressure: 6bar, allowable operating temperature: 80°C, vessel diameter: approx. 760mm, inlet: DN50, outlet: DN50, vent: DN25, solids discharge: DN350. Pumps and piping are available. Filter empty weight: approx. 750kg, space requirement X/Y/Z: approx. 2000mm/1790mm/2800mm. Inspection possible by arrangement.
