power generators used for sale (1,793)

TRIOGEN E-BOX ORC for sale. Model: E-BOX ORC Year: 2017 Hours: 0 Capacity: 170 kW Hz: 50 Voltage: 400 V Scope of supply: Complete ORC E-Box. The E-Box is primarily an E-Box 170kWe Power, but can be also an E-Box 170 CHP (Vario). General Information: E-Box 170 Power – this is when the working fluid condensing (cooling) temperature is at 55degC, this is specific to recovering hot gas at around 500degC (engine exhaust for example). To achieve full power (170kWe gross), the cooling water needs to operate at 55degC, this generating maximum power of 170kWe refer to graph given at cooling temp of 55degC = 170kWe. Price: £240,000.

Key data: 117

Make and Model: GE WHG-125 Year: 2011 Hours : 16,000 & 35,000 Capacity kW: 117 HZ : 50/60 Voltage: 400/480 V Scope of supply: Each ORC skid has its own heat exchangers for evaporation and condensing of the refrigerant (working fluid). You would need to install a water heat source and a water cooling circuit, no cooling towers or blowers are included with what we have in storage. Condition: The containerised units were decommissioned towards the end of 2018. Both of the units were operational before decommissioning. Unit 1 has the upgraded 3600 MBC (magnetic bearing controller). Both of the units are containerised at present but can be removed. Extra: These units run on a working fluid (refrigerant R245Fa) that does not come with the units as this was sent for recycling after commissioning. This will need to be purchased and filled during installation and commissioning .  ...

Make and Model: GE WHG-125 Year: 2011 Hours: 6000 approx. Year : 117 HZ : 50/60 Voltage: 400/480 V Scope of supply: Each ORC skid has its own heat exchangers for evaporation and condensing of the refrigerant (working fluid). You would need to install a water heat source and a water cooling circuit, no cooling towers or blowers are included with what we have in storage. Condition: These units have been decommissioned and been in storage since May 2016. Unit 1 and 2 had a report of an MBC fault (magnetic bearing controller). Unit 3 has several parts missing due to a failure in the power electronics. Some parts of the Power electronics, PLC, speed drive for the refrigerant pump are missing. Unit 4 had a failed heat exchanger and filled the ORC with water, would need stripping to determine the full extent of the repairs needed. Extra: These units run on a working fluid (refri ...

Key data: 300

Dürr Eco+Energy ORC 300 HT. 2016 - 500 Hours Model: Eco+Energy ORC 300 HT KWK Year: 2016 Hours: 500 Capacity: 300 kW Hz: 50 Voltage: 400 V Scope of supply: Complete ORC with oil pump skid. Available for Sale. Price : €240,000

Make and Model: 3 phase oil-filled transformer Voltage: Primary Voltage: 11000 Voltage: Secondary Voltage: 415 HZ: 50 Year: 2004 Scope of supply : 800 KVA used Transformer with a 1000A LV panel. LV Panel comprised of 1 x 1000A MCB. Price: € 12,500

Model: KR16-06 Operating Pressure: 150 mbar Design Pressure: 500 mbar Scope of supply: this is fitted to all landfill gas engines as a prefilter before the gas goes into the engine. It removes water and particulate. Kelburn KR16-06 Coalescer Filter Vessel comprising of one off 400mm diameter demister/filter vessel, polyester / borosilicate microglass coalescing filter cartridge, RF flanged inlet, RF flanged outlet, ¾” BSPT (F) tapped drain connection, ¾” BSPT (F) tapped and plugged vent connection. Coalescer Filter Vessel complete with automatic liquid float drainer, differential pressure gauge complete with stainless steel isolating valves, fittings and pipework, sight level gauges, flanged access cover and davit arm and flanged and blanked inspection cover, 1 Complete set of interconnecting pipe work from filter vessels and automatic liquid float drainer, 1 Skid base ...

Key data: 125

3 x GE CALNETIX HEAT TO POWER ORC GENERATOR Model: X2 Year: 2011 Hours: 10,000 Capacity: 125 kW Condition: Good. Operated on full maintenance contract Scope: Complete ORC unit Price : €80,000 each Available for sale from Gas Engine Exchange. Please check our complete range of equipment at gasengineexchange Yours sincerely, Edward Dulake Tel: (+44) 07595 426 731 Gas Engine Exchange Ltd

Key data: 7290 KW, 13800 V

36.45 MW power plant consisting of five Wärtsilä W18V32 generating sets. Plant Overview • Total Capacity: 36.45 MW (comprising 5 units). • Engine Model: Wärtsilä W18V32. • Year of Manufacture: 2001. • Condition: Used, with approximately 22,000 total running hours per unit. Technical Specifications Engine Details • Type: 4-stroke, V-type configuration. • Cylinders: 18 cylinders. • Bore & Stroke: 320 mm bore and 400 mm stroke. • Operating Speed: 720 or 750 RPM. • Displacement: Approximately 32 liters per cylinder. Electrical Data • Unit Power Output: 7,290 kW. • Voltage: 13,800 V. • Frequency: 60 Hz. • Generator Type: ABB Industry Synchronous Generator (8813 kVA). Fuel Performance • Primary Fuel: Heavy Fuel Oil (HFO). • Consumption: Approximately 185.6~g/kWh at full load. • HFO Viscosity: Typic ...

Key data: 1150 KW, 1437 kVA, 480 V

Two (2) New Waukesha generator model VHP7104GSI, 1150 kW, 480v. 60 Hz. Natural Gas Generator Set, Dual Frequency, without radiator, from year 2025 with factory warranty. 1150 KW – VHP7044GSI – S4 - ESM2 – 1200 RPM, 60 HZ, 480 VAC - Or 1050 KW – VHP7104GSI – S4 - ESM2 – 1000 RPM, 50 HZ, 400 VAC For remote radiator application. Customer needs to supply radiator BASIC BILL OF MATERIAL EBW271, 1150 kw - VHP7104GSI – S4 – ESM - 2 - 1150 kw, 480 VAC, 3 PH, 1200 rpm, 60 HZ – ISO. For Remote Radiator application, or - 1050 Kw - 1000 RPM, 400v. 50 HZ ECP8000, ECP8000 Panel with ESM 2 - with ComAp InteliSys NTC-based control panel with paralleling capabilities, mounted on Enginator - included in the price 5203, Lubrication oil level regulator - Kenco 5230, 24 V DC Pre-lube Motor 6018, Load Sharing Dongle for multiple units in Island operation Enables2 9975qb, Operation  ...

Key data: 2500 KW, 3125 kVA, 13800 V

Five (5) Quality Used Mobile Caterpillar G3520, 2.5 MW, (Each) 13.8 kV, 60 Hz. Enclosed with Trailer Chassis. · Caterpillar G3520, 2.5 MW, 3125 kVA Continuous, 13,800v. 60 Hz. Natural Gas Generator sets. · Charging Alternator, 24v. 50 amps. · NLA-EPA Certification 1 Gram/BHP-Hr · Generator End Arrangement 3042 Permanent Magnet, 105°C Temperature rise over 40°C Ambient temperature. · Jacket Water Heater 480v. · NLA Electric Prelube Pump · EMPC 4.4 Control Panel · 53” Sound Attenuation Enclosure · Quadruple Axel Trailer Chassis · Cooling System · Exhaust System · Air Filters · Duplex Oil Filters · Fire Suppression Tanks · 24v. Battery Charger · Mobile Natural Gas Generator Sets · Plug & Play · MANUFACTURING YEAR 2023 & 2024 Units are ready for shipment.

NEW Virginia Transformer 120 MVA Step-Up Transformer, 34.5kV Grounded Wye -> 230kV Grounded Wye One (1) New, Substation Transformer 120 MVA, 230/34.5/13.8 kV. 60 Hz. 3 Phase INSULATION LEVEL (BILL) HV Line WDG / BUSHING: 750/900 KV HV Neutral WDG / BUSHING: 200/200 KV LV Line WDG / BUSHING: 200/250KV LV Neutral WDG / BUSHING: 200/200KV STANDARDS: IEEE C57.12.00 - 2015 Frequency: 60 Hz. Vector Group: YNyn0+d1 Oil Preservation system: Conservator Insulation Oil: Type II Mineral Oil Rated voltage (volts): 230 000 GrdY/132 790 - 34 500 GrdY/19 919 -13 800D Manufacturing Year: 2022 Warranty expiration Date: April, 2031.

Key data: 1472 KW, 1840 kVA, 450 V

Two (2) Surplus Caterpillar Marine Generator 3512B, 1472 kW Cont. 450v. 60 Hz. Two (2) Surplus/Never Used/Never Installed Caterpillar 3512B, 1472kW Continuous, 450v. 60 Hz. Marine Diesel Generators Two (2) Surplus, Never Used, Never Installed, Caterpillar 3512B, 1472 kW Continuous, 450v, 60 Hz. 0.8 P.F. 1800 RPM, Leroy Somer Generator, Control Panel, Diesel Generator set, Year 2016. APPLICATION: Marine Generator Set.

Key data: 1000 KW, 1250 kVA, 480 V

Quality Use Cummins KTA34 G4, 1000kW Standby, 480v. 60 Hz. Diesel Generator set Quality Use Enclosed Cummins KTA34 G4, 1,000 kW, 1250 kVA Standby, 480v. 60 Hz. Diesel generator sets. It can be set with multiple voltages. Model year 1998 with about 400 hours of use since new in a Sound Attenuated Enclosure and PowerControl Control. Ready for delivery.

Key data: 800 KW, 1000 kVA, 400 V

NEW/Surplus MWN 3016 V 16, 800 kW, 400v. 50 Hz. CHP Enclosed Natural Gas Generator Set Rating: 800kW, Electric Power: 800kWe Power factor (cos. phi): 1.0, 400 Volts, 3Ph, 50Hz, 1500 Rpm Altitude: max 1100m a.s.l., Ambient temperature: +5 up to +53 degC Engine: MWM 3016 V 16, 16 cylinders in V, water cooled, turbo charged with intercooler Alternator: 800kW / 400V synchronous, 3 phases, brushless, self-exciting, self-regulating, air cross flow ventilated, protection mode IP23, engine flywheel and generator shaft coupled, engine and generator coupled over SAE flange and fixed to one unit, genset mounted with vibration dampers. Control unit MMC consisting of: Electronic speed regulation for the engine,  Cos. phi regulation for the engine, Complete engine monitoring and control, Complete generator monitoring, Display of all relevant data (voltage, frequency, power, temperatures, oil pr ...

Key data: 7370 KW, 9213 kVA, 11 V

Five (5) Surplus/Never use/Never Installed, Caterpillar 16CM32C, 7370 kW, 11,000v. 60 Hz. These units can burn Diesel, Gas Oil, Marine Gas Oils (MGO), Marine Diesel Oil (MDO). Year of Manufacturing of this power plant is 2009. The sale of these units include: Barring Gear, Air Intake System, Fresh Cooling Water System, Exhaust System, Diesel Oil System, Lubrication System, Air Starting System, Control Systems and more The generator is a GE Synchronous Generator, 9213 kVA, 7370 kW, 10 Poles, 720 RPM, 11,000v. 60 Hz. 0.8 P.F. IP54 IC81W. This unit comes with IMO Tier II certification and ABS certifications for the Heat Exchangers, Flexible Couplings, Diesel Engine and Generator. The shelf life of these units is over the five-year limit given by Caterpillar. Therefore, these units no longer have the Caterpillar Warranty. Unit is now ready for shipment.

Key data: 9 KW, 10 kVA, 13 V

SURPLUS Wartsila Power Plant, with two (2) – 9.38 Mw = 18.76 Mw – ISO - Wartsila Generator, W20V34SG Engine-Generator sets, 60 Hz, 13,.8 kV. DOM – 2018 – warranty expired – sold as is – where is - Condition. Surplus – Never used – Never Installed With balance of plant – Brief description below with prefabricated building W20V34SG Engine Generator set – open Generator set, Starting Air system + Starting Air Bottle, Maintenance Water Tank, Ventilation Inlet Air duct, LV Switchgear / MCC – Review SLD, Engine Control Panel – Start stop – Synchronization, Neutral Point Cubicle, Exhaust Gas Silencer, Charge Air Dry Filter, Cooling Radiators + Expansion Vessel, Exhaust Gas Module, Charge Air Filter Charge Air silencer, Exhaust Gas Branch pipe, Explosion relief valve, Exhaust Gas Silencer, Exhaust pipe ventilation fan, Flexible bellows, Oil mist separa ...

Key data: 1560 KW, 4160 V

Introducing the MWM TCG 2020 V16K generator, a powerhouse of energy efficiency and reliability. Built in 2010, this generator is in pristine condition, unused and ready to deliver exceptional performance. With a rated power of 1418 kW and the ability to run on a variety of gases, including natural gas, biogas, mine gas, sewage, or landfill gas, it offers versatility like no other. Equipped with a Marelli Generators alternator, this generator boasts a power output of 1560 kW, operating at 4160 V with a speed of 1500 RPM and a frequency of 60 Hz. Weighing 16500 pounds, this robust machine is located in the USA and is competitively priced for your convenience. For more information on this top-tier MWM generator, contact us

Key data: 21000 KW

168 MW Power Plant WARTSILA General Overview • Installed Capacity: 168 MW, 8x WARTSILA W20V46F engines, 600RPM, 480V, 60Hz, HFO • Operational Since: January 2010 • Contract Duration: 15 years (until December 2024) • Average Running Hours: 21,500 Scope of Supply • Civil: Dismantlable buildings and structures • Mechanical: All equipment and auxiliary modules • Electrical & Control: Panels and cabling (excluding HV systems) ELECTRIC & CONTROL All equipments, panels and cabling (feasible to dismantle). High voltage system is out of the scope.

Forty two (42) Quality Used Cummins/Aggreko NCH20-QSK60G22, Dual Frequency 1875 kVA, 480v. 60 Hz. or 1875 kVA, 400v. 50 Hz. Natural gas generator sets. These 1875 kVA units are set for continuous an parallel to gird IPP applications. These units have less than 5000 hours of use since new. The generator is a gas engine driven alternator with control electronics, mounted on a bedplate and housed within a custom-built 20ft stackable container. The standard package is composed of the following: Alternator and engine assembly, Pressurized oil system, Automated control system, Instrumentation, Safety provisions, Engine cooler pack, Silencer, Gas lines including external Low Pressure Gas Train & internal Solenoid Valve The engine and alternator are integrally mounted. This assembly is isolated from the bedplate base by rubber isolation mounts. A 20ft containerised Gas Cooling Module (G ...

Key data: 2000 KW, 2500 kVA, 400 V

SPECIAL PRICE GENERATOR SET NEEDS REPAIRS! One (1) Quality Used Caterpillar CG170-20 2000 kW Continuous Duty, 400v. 50 Hz. Natural Gas Generator set for CHP applications with only 14 hours of use since new from year 2016. The generator is a gas engine driven alternator with EMCP Control Panel, mounted on a bedplate and housed within a custom-built sound attenuated container. The standard package is composed of the following: Alternator and engine assembly, Automated control system, Instrumentation, Safety provisions, Engine cooler remote radiator, Silencer and CHP module. This unit is ready for delivery and sold "as is" .

Key data: 2000 KW, 400 V

Caterpillar G3516H, 2000 kW, 400v. 50 Hz NEW Caterpillar G3516H, 2000 kW, 400v. 50 Hz NEW Caterpillar G3516H, 2000 kW, 400v. 50 Hz NEW Caterpillar G3516H, 2000 kW, 400v. 50 Hz Ten (10) New Caterpillar G3516H, 2000 kW, 400v. 50 Hz. Natural gas generator sets. These 2500 kVA units are set for continuous an parallel to gird applications. They come with a prelube pump, Jacket Water Heater, no CSA or EU certifications, 4.3 EMCP control panel, 1800 frame generator, open skids Manufacturing year 2023 & 2024.

Key data: 2250 KW, 2812 kVA

This genset was purchased for a project, but never used. Manufactured 10/2022 - It is in new condition. Genset 2022 CATERPILLAR 2250KW 3516C GENSET ASCO 4000 AMP Automatic Transfer Switch Genset Drop Over Enclosure Containment Solutions Gen Cube 3500 Gallon Fuel Tank SCR Support Equipment and Controls Container Submittals. Factory Tests Reports, O&M Manuals, Owners Manuals

Key data: 1045 KW, 600 V

Surplus/Never used, Zero Hours, Caterpillar 3512C, Land Drill Module 1045 kW Prime Power, 600v, 1200 RPM, 0.733 P.F. with Jacket Water Heater, Air Cleaners, Radiator 46/CVS, 12" Spark Arrester Muffler, EMCP Control Panel, Simplex Oil Filter, designed for Petro Drilling applications, zero hours, from year 2015.

Key data: 1200 KW, 1714 kVA, 600 V

Two (2) Surplus/Never Used/Never Installed, 3512B Land Drill Module, 1714 kVA (1200 kW), 600v. 50 Hz. Diesel generator set Open Skids, from year 2014. Heavy Duty Air Cleaner, Fuel Filter & Prime Pump, Simplex Oil Filter, Charging Alternator, Electric Starter, Jacket Water Heater, EMCP Panel, Generator Frame 826, 2 bearing, 1500 RPM, 14” Spark Arrester Muffler, Y Adapter 8” X 14”, Radiator 46/CVD 0.52 Ratio

Key data: 2000 KW, 2500 kVA, 400 V

Fifteen (15) New Caterpillar G3516H, 2000 kW, 400v. 50 Hz. Natural gas generator sets. These 2500 kVA units are set for continuous an parallel to gird applications. They come with a prelube pump, Jacket Water Heater, no CSA or EU certifications, 4.3 EMCP control panel, 1800 frame generator, open skids Manufacturing year 2024 & 2025.

Key data: 2500 KW, 3125 kVA, 400 V

Twelve (12) New Caterpillar G3520H, 2500 kW, 400v. 50 Hz. Natural gas generator sets. These 3125 kVA units are set for continuous an parallel to gird applications. They come with a prelube pump, Jacket Water Heater, no CSA or EU certifications, 4.3 EMCP control panel, 1800 frame generator, open skids Manufacturing year 2024 & 2025

2015 Manufacture Date 0 hours since manufacture Stored continuously been stored indoors a temperature-controlled building since delivery (still crated) 7901S Taurus 60 (SoLoNOx) 5670/kWe Generator 13800 Volt 60 HZ (1800 RPM) 3 Phase No enclosure, open skid TURBOTRONICS PLC 4 with TT4000 Display FAT tested by Solar Turbines VFD start system Complete Air inlet filtration system Complete site (equipment) inspection performed by Solar 2019

1,000kW 60Hz 61HR CAT 3508 Generator Set This CAT 3508 generator set was decommissioned in Feb 2023 and has been currently being stored. This generator set has been used as an emergency standby generator for a government office building in Korea. Since the operation time is very short at 61 hours and maintenance has been excellent, it is currently in the best condition and can be operated immediately. Main specifications: - Engine Model: CAT 3508 x 1 Set - Maker: CATERPILLER - Application: STANDBY - Output: 1,000kW x 1,800 rpm - Frequency & Voltage: 60Hz & 380V - Year of Production: 2004 - Running Hours: 61hrs - Fuel Oil: Diesel Oil

MTU Containerised generators. Model reference MTU 16V4000G23 PPU. Fuel Diesel. 1500 RPM YOM 2019. Surplus never used. Voltage 400v Power output 1635kw. Alternator Leroy Stamford. There are 20 units available.

Manufactured Year: 2014 Engine Manufacturer: Hyundai Himsen Model Number: 9H 25/33 Alternator Manufacturer: Hyundai ESS Model Number: HRS7 637-8P Condition: New, Not Operated Fuel Type: Diesel/HFO/MDO Power Output: 2100 kWe Engine Speed: 750 rpm Frequency : 50 Hz Voltage Output: 6000 V Sale Includes: Engine and Alternator along with control panel for each generator and engine components ( such as built in pumps, turbo charger and other engine parts and supports)
