machines and plants for process engineering used for sale (7,698)

Used containers Good condition Dimensions see photo

Frequency inverter inverter Plant: frequency inverter inverter needed Manufacturer: VEE Voith-Elin electronics Type: Elovert SD 400/18 5C22P 8853540.00 Input: Data L: 400 V + 10-15% q: 50/60 Hz +/-5% I: 36A/46A Output: Data L: 0.. 380 (415) V q: 0... 200 Hz I: nominal 40A / 50A continuous Protection IP: 20 Serial No.: 256559 Condition: well maintained

Plant: frequency inverter inverter needed Manufacturer: VEE Voith-Elin electronics Type: Elovert SD 400/15C18.5P 8852520.00 Input: Data L: 400 V + 10-15% q: 50/60 Hz +/-5% I: 27A/35A Output: Data L: 0.. 380 (415) V q: 0.. 300 Hz I: 30A nominal / 38 A continuous Protection IP: 20 Serial No.: 255999 Condition: well maintained

Attachment: eccentric screw pump used Manufacturer: Allweiler Type: SNP 25.1 Version: H1P01 Machine number: 7655566/2 Year of construction: 1982 Capacity: 10L / min Speed: 230 RPM

Attachment: eccentric screw pump used Manufacturer: Netsch Type: NE 30 A Commissions No.: 305699 Machine number: 115945 Year of construction: 1980 Capacity: 2, 1 m³/h at 6 bar Speed: 355 1/min

Plant: Second-hand Grundfos pressure increase station Type: CR30-20 Model: 50000 PL9017 -: 2900 min Performance: 30 m, m³/h Height: 20.5 m Maximum pressure: 16 bar Temperature: Max 110 C.

: Plant used separation / separation system Manufacturer: Schauenburg Type: MAB 200 Year of construction: 1991 1: mixture task box DN 150 Usage: for the slurry task on the average grading railway of the Schwingentwässeres Execution mixture task box: welded and bolted steel sheet construction with a 10 mm strong LINATEX lining and a removable, with 20 mm LINATEX baffle wall. Inlet port: DN 150 flange, born after DN 10 2: Schwingentwässerer type 1240 Machine number: 1127 Dimensions: Width 1200, length 4000 mm Execution: The sieve bin and the actuator yoke, welded and bolted steel construction with one-piece side, rear window, dropping snout rubberized. Drive unit: 1 double unbalance Exciter type S3, 1 drive motor 7,5 kW, 1000 rpm, design B3 3: screen surfaces Classification: single-track plan screening surface width 385 mm, stoma lengthwise in the direction of request, gap width  ...

Type: diving motor unit Flygt submersible pump Pump: 3085891 Data: 259 mm / M15-09-2AL Y/A: 2,4 kW r/min: 2840 V: 4.7 / 8.1 kg: 55

Attachment: Schneider air compressor Compressor: UNM STV 460-10-200 t no.: T800-140 Suction power: 460 l / min EFF. Quantity: 375 l / min Final compression pressure: 10 bar Rated motor power: 3 kW Voltage: 400 v Frequency: 50 Hz Year of construction: 2008 Condition: mint condition - very good

Type: LOWARA used water pump Machine number: 02193 Pump: C0350/09/A Q: 6-24 m m³/h H: 12.7-5.9 m P2: 0.9 kW Hmin: 5.9 m Engine: 3 SM71BG / 309-50 Hz

Type: LOWARA used water pump Machine number: 02192 Pump: C0350/09/A Q: 6-24 m m³/h H: 12.7-5.9 m P2: 0.9 kW Hmin: 5.9 m Engine: 3 SM71BG / 309-50 Hz

Material: mild steel Year of construction: 2003 Drive: 5.5 KW Weight: 2150 kg Area per deck: 5.3 m2 Machine fully reconditioned with new bearings. Optional: ball knocking cleaning, basket of your choice: 0.1-20 mm.

Volume: 1000 ltr. Material: mild steel

Volume: 220 ltr. Material: Stainless steel Heater jacket: 6 bar Operating temperature: 140 ° C Length x width x height (mm): 2300 x 1000 x 2000 Pharmamaschine, suitable for high vacuum.

Multiple filters of layers of make Didier Filtertechnik with double jacket to the heat, explosion-proof, mobile, closed system, operating temperature up to 200 ° C

Used V2A polymer station - 3 chambers -2 Agitators Dimensions: Lxwxh 2, 25 x 0, 75 x 1, 25 m -Adjustable speed -Pulverdosierer adjustable 2 kg to 8 kg / h -Inverter -electronic level control on exactly 1 mm -Water valve 1 "with water quantity measurement 1 litre per pulse (Concentration is calculated automatically) Cabinet: Siemns, PLC and LCD display in the door Active substance concentration adjustable LCD display The plant is located in top condition!

Mixer/Agglomerator Type: Flexomix 160 in stainless steel

Used eccentric screw pump SMI - Ruhr pumps Series: SMI Size: 150 Year of construction: 2003 Capacity: 150 m m³/h maximum

used, kpl. 1 year warranty, plate size 1000 x 1000 mm, 90 plates, closed outlet, 30 mm cake thickness, pressure 15 bar, capacity approx. 2300 liters, filter area 153m2, dimensions 8500 x 1600 x 2100 mm, weight 14,000 kg hydraulics, engine, automatic. Plate transport, with or without filter cloths

used, kpl. 1 year warranty, plate size 1200 x 1200 mm, 70 plates, closed outlet, 30 mm cake thickness, pressure 10/15 bar, capacity approx. 2100 liters, filter area 162m2, dimensions 7500 x 1600 x 2300 mm, weight 18,000 kg, motor hydraulics, automatic. Plate transport, with or without filter cloths

used, kpl. 1 year warranty, plate size 1200 x 1200 mm, 80 plates, closed outlet, 30 mm cake thickness, pressure 15 bar, capacity approx. 2400 liters, filter area 185m2, dimensions 7500 x 1600 x 2300 mm, weight 18,000 kg hydraulics, engine, automatic. Plate transport, with or without filter cloths

used, kpl. 1 year warranty, plate size 1200 x 1200 mm, 100 plates, closed outlet, 20 mm cake thickness, pressure 15 bar, capacity approx. 1850 liters, filter area 224m2, dimensions 9500 x 1600 x 2300 mm, weight 18,000 kg, motor, automatic hydraulics. Plate transport, with or without filter cloths

used, kpl. 1 year warranty, plate size 800 x 800 mm, 100 plates, open outlet, 25 mm cake thickness, pressure 15 bar, capacity approx. 1320 liters, filter area 106m2, dimensions 9000 x 1300 x 2200 mm, weight 11,000 kg, motor hydraulics, filtrate channel, with or without filter cloths

used, kpl. 1 year warranty, plate size 800 x 800 mm, 60 plates, open outlet, 25 mm cake thickness, pressure 15 bar, capacity approx. 800 liters, filter area 64m2, dimensions 6000 x1300 x 1500 mm, weight 5800 kg, motor hydraulics, drip plate, filtrate channel, with or without filter cloths

used, kpl. 1 year warranty, plate size 800 x 800 mm, 55 plates, open outlet, 25 mm cake thickness, pressure 15 bar, capacity approx. 710 liters, filter area 58m2, dimensions 6000 x 1400 x 1800 mm, weight 6500 kg, motor hydraulics, automatic. Plate transport, drip plate, filtrate channel, with or without filter cloths

used, kpl. 1 year warranty, plate size 630 x 630 mm, 40 plates, open outlet, 30 mm cake thickness, pressure 7/15 bar, capacity approx. 384 liters, filter area 17m2, dimensions 4500 x 1200 x 1500 mm, weight 350 kg, motor hydraulics, automatic. Plate transport, drip plate, filtrate channel, with or without filter cloths

used, kpl. 1 year warranty, plate size 630 x 630 mm, 40 plates + 40 frame, closed outlet, 40 mm cake thickness, pressure max. 6 bar, capacity approx. 500 liters, filter area 27m2, dimensions 4800 x 1200 x 1600 mm, weight 2.5 tons, hand hydraulics, drip plate, filtrate channel, with or without Filter cloths

used, kpl. 1 year warranty, plate size 470 x 470 mm, 35 plates, open outlet, 25 mm cake thickness, pressure max. 12 bar, capacity approx. 150 liters, filter area 12m2, dimensions 2500 x 900 x 1200 mm, weight 800 kg, hand hydraulics, drip plate, filtrate channel, with or without filter cloths

used, kpl. 1 year warranty, plate size 630 x 630 mm, 45 plates, open outlet, 25 mm cake thickness, pressure max. 10 bar, capacity approx. 360 liters, filter area 28m2, dimensions 3800 x 1400 x 1600 mm, weight 2.5 to, motor hydraulics, drip plate, filtrate channel, with or without filter cloths
