Horizontal Numerically Controlled Machining Centres used for sale (50)

Key data: 1 mm, 1 mm, 2 mm

CNC 5-Axis Horizontal Machining Center Burkhardt + Weber MCC 800 A Year of construction 2019 Siemens 840D sl – OPERATE 2 pallets Pallet size 1,000 × 1,000 mm Table load max. 2,500 kg 4e Axis NC Rotary Table B-Axis 0.001° 5e axis NC swivel milling head A-axis +45° / -110° X 1,400 mm Y 1,200 mm Z 1,600 mm Spindle Holder HSK-A100 Spindle drive power 30 / 38 kW Spindle speeds 20 – 10,000 rpm 128 + 32 tool magazine positions Spindle hours: 6280 Very good Zutsnad - Excellent High precision, high productivity, cutting-edge technology, extreme reliability from a leading machining center manufacturer. This is a great opportunity for customers who machine complex parts. Offer number MH-6511

Serial Number: SH501AG0061 Power: 22 kW Type: CNC Horizontal Machining Center with Pallet Changer (2 Pallets) Routes: X 800 mm, Y 700 mm, Z 700 mm Pallet size: 500 x 500 mm Maximum load per pallet: 500 kg Spindle speed: up to 12000 rpm Tool Holder Cone: MORE BT-40 Tool Capacity: 40 Fast Feed: 50000 mm/min Voltage: 200 V Description: Machine suitable for high-precision machining with automatic tool changer and pallet system Manufactured in: Japan Auction-ID: A7-44864-11

Key data: 5005 mm, 3586 mm, 1106 mm

year of production: 2007 automatic tool change Work spaces [mm]: 5000x2500 Groove distance [mm]: 200 Travel ranges [mm]: 5005x3586x1106 Work feed [m/min]: 35m/min Rapid feed [m/min]: 40 Spindle speed [rpm]: 35 - 6000 Spindle torque [kW]: 37kW Max. torque [Nm/rpm]: 670/525 Tool clamping: HSK-A 100 Tool magazine [pcs.]: 100ks Machine control system: iTNC 530 2x univerzální úhlová hlava 45° Direct outlet head Power supply

Auction-ID: A7-45667-1

GENERAL Project No.: 905821 Quantity: 1 pcs. Manufacturer: SW Schwäbische Werkzeugmaschinen Type: BA 422 Control: Siemens 840 D solutionline Year of Make: 2017 Condition: Used machine Approx (hrs): 18302 Spindle in approx. (hrs.): 4718 DESCRIPTION MILLING 5 axes Travel in X 400 mm Travel in Y 500 (775) mm Travel in Z 425 mm Max. feed speed in X/Y/Z 55/70/75 m/min Max. acceleration in X/Y/Z 8/8/15 m/s2 Feed force in X/Y/Z 15000/15000/2x8000 N Direct displacement measurement system BLOCK - Milling spindle unit Tool holder HSK A-80 Max. speed milling spindle 10000 1/min Max. power at ED 10-40/100% 2x27 kW Max. torque at ED 10-40/100% 2x200 Nm Spindle diameter in the front bearing 80 mm 2 pcs horizontally arranged milling spindle(s) Spindle spacing 400 mm Pneumatic tool system control Chain tool magazine 2x30 stations Max. tool diameter 80 mm Max. ...

Auction-ID: A1-44765-264

MORI SEIKI MH 40 FANUC horizontal machining centre X-axis travel: 560 mm Y-axis travel: 510 mm Z-axis travel: 510 mm Pallet size: 400 x 400 mm Table Rotation (B-Axis): 360° (with minimum division 1° or 0.001°) Spindle Mount: BT-40 Spindle Speed: 6,000 rpm Tool Changer (ATC): 40 Total machine weight: approx. 9,500 - 10,500 kg Floor Dimensions (W x D): Approx. 2,300 x 4,200 mm Height 2350 mm Auction-ID: A7-44885-21

Double Pallet Control Unit: Siemens 840D Travels :X: 560 mmY: 510 mmZ: 560 mm B: 360° Spindle speed: 18.000 rpm Table size: 400 mm x 400 mm Tool changer: 60 position Chip conveyor, Tool measurement Unit,High pressure coolant unit Can be inspected under power

Auction-ID: A1-41275-2

Key data: 560 , 560 , 630

Tool stations 50 pieces As a spare parts donor Auction-ID: A1-44728-11

Max. X-axis stroke730 mm Max. Y-axis stroke730 mm Max. Z-axis stroke880 mm Max. workpiece diameter800 mm Max. workpiece height1,000 mm Max. workpiece weight700 kg Control & software SIEMENS

NC Rotary Table Division: 360,000 × 0.001° Rotation speed: 20 1/min Pallet changing system Pallet dimensions: 500 × 630 mm Maximum workpiece diameter: 900 mm Maximum workpiece height: 1,000 mm Chain magazine Tool stations: 80 pieces Maximum tool length: 450 mm Maximum tool diameter: 160 mm Coolant pressure 50 bar Auction-ID: A1-44728-13

Control Siemens Sinumerik 840D Travel X/Y/Z: 560 x 560 x 510 mm Spindle speed 15,000 min-1 2-fold pallet changer 400 x 400 mm Tool magazine for 40 Wkz., SK 40 Paper filter Conveyor

Tool System / Tool Magazine Magazine Type: Chain Tool stations 80 pieces With electrical defect Coolant pressure 50 bar Auction-ID: A1-44728-31

CNC controller: HEIDENHAIN iTNC 530 Axes X-axis travel mm: 700 Y-axis travel mm: 700 Z-axis travel mm: 700 Distance spindle nose - table surface mm: 100 - 800 Rapid traverse m/min: 60 Acceleration in the axes m/s2: 6 / 6 / 5 Worktable Number of pallets: 2 + 5 Table dimensions mm: 500 x 500 Maximum workpiece size (D x H) mm: 800 x 1.000 Max. workpiece weight kg: 600 T-Slot version: DIN 55201-A2 APC time s: 9,5 División estandar Grados: 360º (1º) Spindle Spindle speed rpm: 18.000 Spindle drive power kW: 34 / 28 Spindle torque Nm: 110 Tool system Tool holder: HSK-A63 Tool magazine slots: 120 Max. Tool Diameter: 80 Max. Tool Length mm: 550 Max tool weight kg: 12 Chip-to-chip time s: 2,9 Equipment Electronic Handwheel Chip conveyor Rotating inspection windows Rinsing gun Signal lamp Tool breakage probe 3D quickSET Workare ...

6. Pallet system Pallet size: 500 × 630 mm 7.2 Tool magazine Magazine Type: Chain Stack slots: 80 Auction-ID: A1-44728-7

Control: Heidenhain iTNC 530 Year of Make: 2009 Travel: X-axis: 650 mm Y-axis: 700 mm Z-axis: 700 mm B-axis: 360 C° Recording: 40 ISO Tool magazine: 120-fold Speed: 12,000 rpm Conveyor Coolant system with filter 600 L and 40 bar 2-fold pallet changer 3-D Probe (Renishaw) Blum Laser New Weiss spindle in 2022

Tool System / Tool Magazine Tool stations 80 pieces Magazine Type: Chain Coolant pressure 50 bar4 additional working pallets 400mmx 500mm Auction-ID: A1-44728-23

Key data: 730 mm, 730 mm, 740 mm

Mazak PFH 5800 (10 Pallet) CNC Horizontal Machining Center CNC control Mazatrol 640M Pallet table size 500 x 500 mm Number of pallets 10 Table load 700 kg X-axis travel 730 mm Y-axis travel 730 mm Z-axis travel 740 mm Table indexing 360 x1° Spindle taper CAT 40 Spindle 12,000 1/min Spindle motor 22/15 kW Magazine capacity 80 Required footprint 9850 x 10145 mm If you have any questions about the machine, please do not hesitate to contact us by phone or e-mail. Feel free to check out our other ads for a full overview of our stock.

Tool System / Tool Magazine Magazine Type: Chain Tool spaces 80 pieces each Built in 1999 / 2001, a working one can be built from both machines Auction-ID: A1-44728-27

Key data: 730 mm, 730 mm, 740 mm

Mazak HC Nexus 5000-ll CNC Horizontal Machining Center CNC Control Mazatrol Matrix Pallet table size 500 x 500 mm Number of pallets 2 Table load 700 KG Travel X-Y-Z axes 730x 730x740 mm Table Indexing 0.001° Spindle taper DIN 69871A-40 Spindle speed 18,000 1/min Spindle motor 35-26 kW Mazgazin capacity 80 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail.

NC Rotary Table Speed rotary table (B-axis): 40 1/min Tool magazine Tool stations 80 pieces, 60 of which are still populated Coolant pressure 50 bar including 2 additional work pallets Auction-ID: A1-44728-19

Key data: 880 mm, 730 mm, 730 mm

GENERAL Project No.: 905698 Quantity: 1 pcs. Manufacturer: DMG MORI Type: NHX 5000 Control: Siemens 840 D solutionline Year of Make: 2016 Condition: Used machine Approx. (hrs): 26,341 Spindle in approx. (hrs.): 9,666 DESCRIPTION MILL Travel in X 880 mm Travel in Y 730 mm Travel in Z 730 mm Max. rapid traverse speed in X/Y/Z 60/60/60 m/min Max. feed speed in X/Y/Z 6/6/6 m/min Tool holder HSK 63 Max. speed milling spindle 20000 1/min Max. power at ED 10-40/100% 15/11 kW Tool magazine 40 stations Rotating pallet changer (set-up station can be rotated by motor) 2-fold Max. workpiece weight per pallet 500 kg Rotary table NC-controlled Clamping hydraulics OTHER EQUIPMENT IR Workpiece Probes Tool breakage detection by means of a probe Splash protection cladding with fully encapsulated working area Rotating viewing window Lighting in the work area Scrap ...

Duration 14394 Hours Workspace Distance pallet surface – spindle center: 75 – 995 mm Distance between pallet centre and spindle head: 150 – 1,140 mm Max. workpiece size: 1,050 × 1,115 mm Pallet table Pallet size: 630 × 630 mm (option 800 × 800 mm) Max. table load: 1,200 kg Spindle Speed range: 45 – 12,000 rpm⁻¹ Max. torque: 451 Nm (up to 550 rpm⁻¹) Tool holder: HSK 100 High-pressure cooling Coolant pressure: 50 bar Tool Changer Tool stations. 60 Pieces Max. tool weight: 20 kg (option 30 kg) Max. tool diameter: 110 mm (at full occupancy) 230 mm (for free neighboring stations) Max. tool length: 600 mm NC table (B-axis) Indexing increment: 0.001° Indexing time 90° (incl. clamps): 2.1 s Indexing time 180° (incl. terminals): 2.5 s Indexing Accuracy: 5\" Repeatability: ± 2\" Rapid traverse B-axis: 27,000°/min B-axis feed: 0 – 27,000°/min Scraper plate must  ...

Key data: 400 mm, 500 mm, 425 mm

GENERAL Project No.: 905673 Quantity: 1 pcs. Manufacturer: SW (Schwäbische Werkzeugmaschinen) Type: BA W04-22 Control: Siemens 840 D Year of Make: 2008 Condition: Used machine Layers approx.: 2-3 layers DESCRIPTION MILL Travel in X 400 mm Travel in Y 500 (775) mm Travel in Z 425 mm Max. rapid traverse speed in X/Y/Z 100/100/100 m/min Max. acceleration in X/Y/Z 14/14/20 m/s2 Feed force in X/Y/Z 10000/10000/2×5000 N Direct displacement measurement system X/Y/Z/A(U)/C1(C2)/W1(W2) Linear Actuator X/Y/Z Tool holder HSK-A 63 Max. speed milling spindle 17500 1/min Max. power at ED 10-40/100% 35/26 kW Max. torque at ED 10-40/100% 80/60 Nm Spindle diameter in the front bearing 80 mm 2 pcs horizontally arranged milling spindle Spindle spacing 400 mm Pneumatic tool system control Pneumatic tool taper cleaning in milling spindle Torque support for multi-spindle  ...

Tool magazine Magazine slots: 50 Auction-ID: A1-44728-15

Key data: 1400 mm, 1200 mm, 1350 mm

A horizontal machining center from the manufacturer Mori Seiki NH 8000 DCG is offered here. The machine is in good condition and can be visited. Make: Mori Seiki Huzvdlw Type: NH 8000 DCG Year of Make: 2008 Control: Fanuc MSX-701III Specifications: Travel: X-axis 1400 mm Y-axis 1200 mm Z-axis 1350 mm B-axis rotary table 360x0.001° automaton. Tool changer with 60 tool positions Tool holder HSK 100 2-fold pallet changing system Pallet dimensions 800 mm x 800 mm max. tool length 800 mm max. tool weight 30 kg Spindle power 37 KW Max. spindle speed 8000rpm. IKZ cooling system

Tool magazine and tool changer Magazine Type: Chain Tool stations 80 pieces Maximum tool diameter: All seats occupied: 95 mm Adjacent places available NC Rotary Table Speed rotary table (B-axis): 20 1/min Coolant pressure 50 bar Auction-ID: A1-44728-17

Key data: 6000 , 4100 , 800

Gantry/Bridge Mill Make: Okuma Model: MCR-A5CII Year: 2015 Machine Location: Upon Request Additional Specifications Available Upon Request Travels: X: 263.78″ (Table Front/Back) Y: 161.42″ (Spindlehead Horizontal) Z: 31.50″ (Ram Vertical) W: 47.24″ (Crossrail Vertical) Effective Width Between Columns: 143.70″ Table to Spindle Nose: 0″ to 70.87″ Table: 118.1″ x 255.9″ (3000 mm x 6500 mm) Max. Load: 81,400lbs T-Slots: 24H7 Width x 15# Spindle: 30 to 6,000 30 to 10,000 7/24 Taper No. 50 ATC Equipped With Accessories: -Main motor and standard electricals: 30 to 4,000 min-1 -Spindle cooler: Oil controller -Thermo-Friendly specs: TAS-S, TAS-T -Synchronized W axis NC (NC crossrail): Absoscale detection (W axis) -Auto Tool changer: 50 tools -ATC air blower and spindle air curtain: Air blower (blast) -Seesaw pendant operation panel: Vertical travel ...

Tool positions in the magazine: 80 pieces Coolant pressure 50 bar including 2 additional work pallets Auction-ID: A1-44728-25

HELLER MC16 4-axis horizontal milling center YOM 2000 4-Axis SIEMENS CNC Path Control, Model SINUMERIC 840 D Longitudinal X-axis 630 mm Vertical Y-axis 630 mm Cross Z-axis 630 mm NC rotary table Tilting B axis 360.000 x 0,001 ° Pallet size 400 x 500 mm Max. workpiece size Ø x height 720 x 800 mm Max. workpiece weight 500 kg Pallet exchange time 9 sec. Turning Speed B axis 40 rpm/min Tool holder cone HSK 63 Tool size Ø x lg. x weight 150 x 227 x 12 mm/kg Spindle speeds, infinitely variable 45 – 24,000 rpm Feeds / quick feeds XYZ: 1 – 60,000 mm/min Feed force 10.000 nm Spindel torque 48/72 nm Spindle drive 30 kW Total electrical load, approx. 60 kW - 400 V - 50 Hz Total weight 12.5 tons Accessories / Special Features : -Separate standing 80 position Rack-Type tool Magazine with tool placement door and double Swivel gripper, own SIEMENS PC-Control with screen To ...

NC Rotary Table Division: 360,000 × 0.001° Rotation speed: 20 1/min Pallet changing system Pallet dimensions: 500 × 630 mm Maximum workpiece diameter: 900 mm Maximum workpiece height: 1,000 mm Maximum clamping mass Axle dynamics power: 1,400 kg Axis dynamics speed: 800 kg Chain magazine Tool slots 40 pieces Maximum tool length: 450 mm Maximum tool diameter: 160 mm Auction-ID: A1-44728-3

5-Axis Horizontal Machining Centre MCM Tank 1300 5-AXIS New in 2017 Siemens 840D solution line Twin pallets 630 x 800 mm Work weight max. 1500 kg NC rotary table - 4th axis B-Axis 360° / 0.001° NC-Tilting head 5th axis A-Axis +80°/-95° / 0.001° X 1300 mm Y 1400 mm Z 1400 mm Feeds and rapids to 50000 mm/min. Spindle drive 40/52 KW Spindle speeds to 10000 rpm Tool taper ISO 50 199 tool ATC Linear scales for higher accuracies Renishaw sample Chip conveyor CTS 65 bar Beautiful machine – excellent condition Operating hours 11544 - 05/2020) Spindle Working hours 6784 (05/2021) Inspect under power Proposal Number MH-6155

Tool magazine Chain Tool stations 100 pieces Max. tool diameter (all slots occupied): 112 mm Max. permissible tool weight: 25 / 35 daN Max. permissible weight torque of the tool on the gripper: 2200 / 5000 Ncm Max. tool length (from spindle nose): 600 mm NC Rotary Table Division: 360 × 1° Pallet Changer Pallet dimensions: 800 × 800 mm Coolant Setup Coolant pressure 50 bar Auction-ID: A1-44728-9

5-Axis Horizontal Machining Center with Pallet changer Mandelli Spark 3500X New in 2018 Siemens Sinumerik 840D control Number of pallets 2 Pallet size 1250 x 1600 mm Pallet load capacity max. 5100 kg 4th axis 0.001° NC rotary table 5th Axis NC-Tilting milling head A-Axis +80° ~ -120° X 3500mm Y 1850mm Z 1800 mm Feeds X,Y,Z up to 20000 mm/min. Rapids X,Y,Z up to 35000 mm/min. Tool taper HSK-A100 Spindle drive motor rating 46/67.7 kW Spindle speeds up to 6000 rpm. Spindle torque max. 1851 Nm 200 station tool magazines. Tool diameter max. 120 mm/425 mm Tool length max. 600 mm Tool weight max. 35 kg Coolant through the spindle 25/40/60 bar Proposal Number MH-6234

Tool magazine and tool changer Magazine Type: Chain Tool stations 80 pieces With electrical defect Coolant pressure 50 bar 2 additional work tables 400mm x 500mm Auction-ID: A1-44728-21

x-travel: 1400 mmy-travel: 1200 mmz-travel: 1325 mmcontrol: Mazatrol Smotth G numbers of pallets: 2 size of pallet: 800 x 800 mmmax. workpiece height: 1450 mmmax. workpiecediameter: 1450 mmturning speed range - milling: 10000 U/mintool taper: BT 50 Tool changer: 120 pos.power capacity - milling spindle: 37 kWb-axis (table): 360000 x 1 °rapid traverse: 60 m/minworkpiece weight: 2200 kgtotal power requirement: 102 kVAweight of the machine ca.: 31 tdimensions of the machine ca.: 3,88 x 8,05 mequipped with:- CNC Control MAZATROL Smooth G- ATC 120-fold (BT 50)- Chip Conveyor- HP Coolant with internal Spindle Cooling 70 BAR- 360000 ° positions indexing table- pallet changer with safety cover (2 Pallets)- Spindle cooling unit- Flood cooling- Niagara cooling / rinsing system- Blowout through the spindle- Coolant and chip protection through fully enclosed working space- Workspace door lock- wor ...

as spare parts dispenser, suitable for lot 31 Auction-ID: A1-44728-33

Tool magazine Tool stations 80 pieces Maximum tool weight: 25 kg Maximum tool length: 500 mm Maximum tool diameter: 228 mm NC Rotary Table Division: 360,000 × 0.001° Swivel range: 360° Pallet changing system Pallet dimensions: 630 × 630 mm Coolant Setup Coolant pressure 50 bar Auction-ID: A1-44728-5

x-travel: 1300 mmy-travel: 1300 mmz-travel: 1300 mmControl: Siemens 840D SL table-size: dia. 800 mmtable weight: 1500 Kgc-axis: 360 / 0,0001 °number of spindle speeds: 10000 U/min/rpmtool taper: ISO 50 spindle drive: 40 / 52 kWrapid travel x/y/z: 50 m/minTools changer: 199 pos.dimension of workpiece: 1400 x 1120 mmtotal power requirement: 42 kVAweight of the machine ca.: - tdimensions of the machine ca.: 11,9 x 6,1 x 5,2 m4-axis BAZequipped with:- CNC control Siemens 840D Solution Line- pallet changer with 4 pallets (dia. 800mm)- rotary table (B axis)- tool changer 199-fold (SK 50)- coolant system- Chip conveyorThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 2200 mmy-travel: 1600 mmz-travel: 1850 mmcontrol: Mazatrol Matrix Smooth G max. workpiece diameter: dia 2400 x 2000 mmmax. table load: 6000 kgsize of pallet: 1250 x 1250 mmB - Axis: 0,0001 °turning speeds: 10000 U/mindrive capacity - spindle motor: 37/30 kWmax. torque on the spindle: 350 Nmno. of tools in magazin: 120 tool adaptor: BT 50 Rapid Travel X / Y / Z-Achse: 43 m/mindimensions of the machine ca.: 11 x 7,1 x 4,5 mdistance spindle /table: 100 - 1700 mmtotal power requirement: 120 kVAweight of the machine ca.: 57,5 tequipped with:- CNC control Mazatrol Smooth G- B-axis (0.0001°)- ATC 80-fold (BT 50)- Chip Conveyor- 2-fold Pallet Changer- High Pressure cooling through Unit- Chip Conveyor- Renishaw Laser Tool Measur.- Thread Cutting Function-Power-On Time: , Automatic Cutting: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mmy-travel: 750 mmz-travel: 770 mmControl: FANUC Prof 3/A rapid travel x/y/z: 30000 mm/minpalets changer: 630 x 630 table weight: 1200 Kgspindle speed:: 14000 U/minspindle taper: HSK A 63 spindle motor: 30/25 kWtool change unit: 40 posdistance spindle center to table: 100-850 mmInternal cooling system: weight of the machine ca.: 17 tdimensions of the machine ca.: 7,9 x 4,2 x 3,3 mEquipped with:- Fanuc Professional 3/A CNC control- Coolant through spindle- Pallet changer- Tool changer (HSK-A63)- Knoll coolant system (renewed)- Chip conveyor- Mütek briquette press (2015)The machine has been used reliably in single-shift operation in recent years, operating hours: Spindle hours:The scope of delivery includes numerous HSK-63 tool holders – both thosecurrently in the machine and a complete Euro pallet withadditional tool holders.- Two clamping towers (without pallets)The  ...

x-travel: 730 mmy-travel: 730 mmz-travel: 880 mmControl: FANUC 31i-B spindle turning speed - stepless: 15000 U/minspindle taper: BT 40 Big Plus spindle motor: 18,5 / 30 kWpallet table size: 500 x 500 mmworkpiece weight: 500 kgdistance spindle center to table: 80 - 810 mmRapid Travel X / Y / Z-Achse: 60 m/mindimension of workpiece: 800 x 1000 mmtotal power requirement: 80 kVAweight of the machine ca.: 11,5 tdimensions of the machine ca.: 5,45 x 2,68 x 2,88 mHorizontal CNC machining centre- CNC control FANUC 31i-B- Tool changer 60-fold (BT 40 Big Plus)- 2 pallet changer(pallet 24-M16)- Table / Pallet indexing Full B axis.- Pullstud Nikken PS-806. Maximum torque 229.9/ 206.9/ 147.2/ 119.4N.m.- Coolant/Filtering Unit- Chip Conveyor- ExhausterThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-axis: 550 mmy-axis: 450 mmz-axis: 375 mmcontrol: SIEMENS 840D SL spindle turning speed range: 1-17.500 U/minweight of the machine ca.: 10 tdimensions of the machine ca.: H 6,30 x 3,85 x 3,70 mThe machine is designed for friction stir welding.Reinforced Z-axis (5000 N) required for the welding process.Spindle speed increased to 1-17,500 rpm.including swivel axisOperating hours: approx. 11,111 h.Spindle running time: approx. 4,116 h.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1400 mmy-travel: 1050 mmz-travel: 1200 mmControl: Fanuc 31i spindle turning speed - stepless: 6000 U/minspindle taper: ISO 50 spindle motor: 35 / 22 kWpallet table size: 800 x 800 mmworkpiece weight: 2000 kgdistance spindle center to table: 75 - 1125 mmRapid Travel X / Y / Z-Achse: 24 m/mindimension of workpiece: 1450 x 1550 mmtotal power requirement: 71 kVAweight of the machine ca.: 27 tdimensions of the machine ca.: 7,3 x 4,3 x 3,75 mHorizontal 4-axis CNC machining centre- Fanuc 31i CNC control- 60-position tool changer (ISO 50)- Rotary table (1° division) with 2 pallets- High-pressure cooling 70 bar with cyclone filter system- Chip conveyor- Tool loading management- Renishaw RMP 60- TS 27R tool probeSpindle running hours 6000h, running hours: 8050hThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1000 mmy-travel: 800 mmz-travel: 800 mmcontrol: SIN840D speeds: 10 - 10.000 U/minfeed range: 1 - 36000 mm/minB - axis: 360 x 1 °surface area: 2 x 500 x 630 mmrepeating accuracy: + / - 3 tool diameter: 100 mmworkpiece length: 650 mmworkpiece weight max.: 40 kgtool taper DIN 69871: SK 50 workpiece weight: 800 kg tool magacine with: 100 Plätzenwotkpiece diameter with 2 vacant positions: 325 mmChip to chip time: ca. 8,00 sec.change time of pallets: ca. 12,00 sectotal power requirement: 65,00 kWweight of the machine ca.: 20,00 tdimensions of the machine ca.: 7,80 x 3,50 x H3,40 mHorizontal machining center with SIEMENS SIN840D control.NC-rotary table, chip conveyor, coolant-unit, coolant through the spindleMagazine with 2 cassette à 50 pockets.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Horizontal machining center, 6 pallets, Priced to sell - dismantled and loaded into truck, OKUMA MA40 HA 6P OSP U100M CNC 6 pallets 400mm x 400mm max 400 kgs max workpiece dimensions 600710 Spindle BT40 / coolant through the spindle 4th axis 1° Tool changer: 100 pos. X = 560mm, Y = 610mm, Z = 560mm 40 m/min under power Mimu Machine Tools (Italy), X: 560, pallet: 6, Pallet size: 400400

x-travel: 600 mmy-travel: 560 mmz-travel: 560 mmB-axis (table): 360 mmControl: Siemens 840D total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
