boring mills, machining centers used for sale (530)

Manufacturer: Eigenbau, Control: hand, Work piece width min-max mm: 480, Min.-max. workpiece height in mm: 10-80, Milling spindles vertical: yes, Milling engine 1 hours power: 0,75, FREE TEXT: Bohrgerät für Halogen Bohrungen die Kabelzuführung muss mit einer separaten Bohrmaschine von vorne gebohrt werden, über die angeflanschte Bohrbrille. ,

Manufacturer: Koch , Type: BLG, Year: 1992, Control: hand, Program-controlled: yes, Software: 300, Work piece width min-max mm: 200-2500, Min.-max. workpiece length in mm: 10-60, Program: yes, Lochraster: alle 2, Drilling engine kW: 60/80, Working range max mm: 2 von hinten, Drilling supprt from bottom: 2, Drill supports from behind: 7, Work piece refeeding: yes, Taktleitung min: 1, Dovel insertion: yes, Overhauled on: alle Bohrgetriebe drehbar 360 Grad, Year :1992

Manufacturer: KOCH, Type: DL 60, Year: ca.1992, Control: umgerüstet auf elektronische Leimventile, Work bays: 1, Work piece width min-max mm: 60, Min.-max. workpiece length in mm: 40, Min.-max. workpiece height in mm: 2800, Work piece depth mm: 800, Work piece width min-max mm: 60, Feeding speed m/min: ca.40, Centre support: no, Beleimwerkzeuge: 6, Dovel insertion: yes, Dovel diameter mm: 8, Work piece clamping: pneumatisch, Low-pressure gluing system: 2, Year :ca.1992

Manufacturer: Weeke, Type: BP 195 T, Year: 1996, Throuh running machine: yes, Working range X: 3200, Working range Y-axis: 1300, Number of milling spindles: 1, Tool adaption system: HSK 63, Milling engine 1 hours power: 7,5, r.p.m: 18000, r.p.m: 18000, Number of tool magazines: 1, Number of tools per tool-magazine: 8, Rollentisch: yes, Vacuum pumps m³/h: 120, Bohrer vertikal: 44, Auslegermaschine : yes, zwei getrennte Bohrgetriebe mit einzelnen Achsen Raster 32 mm, Year :1996

Manufacturer: Koch , Type: SBD-B, Control: Siemens, Min.-max. working length in mm: 250-2500, Working width min-max mm: 10-150, Min.-max. workpiece thickness in mm: 10-60, Drilling support horizontal: 2, Drill gearings: 6, Drill gearings: 6, Drill support from top: 4, Drill gearings: 6, Drilling engine kW: ca.1,5, Working range max mm: 60, Dovel lenght mm: 10 X 30, Number of doveling tools: 4, Glue high-pressure pump: yes, Glue quantity setting: yes, Dowels horizontal: yes, FREE TEXT: mitMagazin und Rückführung der Werkstücke,

Manufacturer: Koch, Type: Compact, Year: 1991, Control: Programm, Working widht max mm: 150-2500, Arbeitstiefe max mm: 200, Working thickness max mm: 80, Schwenkbereich Grad in X: +30-90, Dovel units: 3, Dovel diameter mm: 10-12, Drill gearings: 2, Drill gearings: 2, Drill gearings: 2, Drill spindles per support: 5, Gluing: yes, Dovel insertion: yes, Raster 32 mm: yes, Compressed air bar: 6, Wight approx. kg: 3000, Year :1991

Manufacturer: Format 4, Type: Profit H20, Year: 2014, Feeding speed max m/min: X-80, Y-80, Z-20, Working range X: 3830, Working range Y-axis: 1680, Working range Z: 275, Vacuum pumps m³/h: 90, incl. tools: yes, Gesamtanschluss kw: 18, Weight approx. kg: 3350, Year :2014

Manufacturer: Blum, Type: Einbohrgerät für Topfbänder, Drill gearings: 1, Drill gearings: 1, Drill gearings: 1, Number of spindles: 3,

Manufacturer: Koch Contuorfräsmaschine, Type: Sprint PTP 2 1800, Year: 2012, Control: Beckhoff, Program: Koch-Wop, Online connection: möglich, Machining stations: 2, 4 Achsensteuerung: yes, Work piece width min-max mm: 120-1360, Work piece length min-max mm: 120-1360, Work piece thickness min-max mm: 19-25, Number of milling spindles: 1, Milling spindles horizontal: 1, Tastend Aggregat: 1, Power kW 1: ca.0,75, RPM min-max 1: 18000, FREE TEXT: zusätzliche Festplatte/Windows XP, Year :2012

Manufacturer: Stegherr, Type: FDE, Year: 1993, Control: Verdübelung von Kämpfer-Setz- hölzern, Sprossen und Türelementen., Program: PC Steuerung, Work piece width min-max mm: 20-150, Min.-max. workpiece length in mm: 400-3300, Min.-max. workpiece height in mm: 10-80, One or two Spot machine: 2, Year :1993

Manufacturer: IMA , Type: BIMA 810 V, Year: 2000, Control: IMATRONIC, Software: IMAWOP, Working range X: 5200, Working range Y-axis: 1600, Working range Z: 180, C axis: yes, Pendulum processing: yes, Number of milling spindles vertical: 1, Tool adaption system: HSK 63, Milling engine 1 hours power: 12, Number of tool changers: 1, Number of tools per tool-magazine: 18, Vertical drills-X: 11, Drill vertical Y: 11, 2 station allocation: yes, 4 station allocation: yes, Vacuum pumps m³/h: 2 x 100 , Edgebanding unit: yes, Edgeband hight mm: 55, Year :2000

Manufacturer: Spotbohrmaschine, Function: Spot Bohrrung mit Seitlicher kabelbohrung ca.25 cm, Work piece width min-max mm: ca.540 mm, Milling spindles vertical: Bohspindel Forstner Bohrer,

Manufacturer: Hettich, Type: Blue Max mini, Control: hand, Bänderbohrstationen: yes, Number of spindles: 3, Milling engine 1 hours power: 0,5, Number of tables: 1,

Key data: 4000 mm

Power Control PC85, Woodwop, ATC 12-fold, A lot of accessories, Gluing unit, ... 2 retractable and extendable changing tables, two-part clamping table with 2 processing stations for pendulum assignment, edge height max. 65 mm, chip and offcut disposal, drill head 17 spindles, main spindle 14.5 KW, speed 24000 1/min Incl. many accessories Condition: dismantled

In-line drilling rig with 8 height- and width-adjustable drilling spindles (optionally up to 12 drilling spindles and an extension to a drilling area of 4,000 mm x 240 mm – without moving the workpiece) VIDEO LINK on request Drive power 0.75 kW per drilling spindle (optionally, the system can be supplied with more powerful drilling spindles - 1 kW / 1.25 kW - 1.5 kW), drilling spindle speeds up to 12,000 rpm - infinitely variable via potentiometer and frequency converter - set speed can be read analogously, drill tension by collets ER25, largest drill diameter 12 mm, drilling feed speed infinitely adjustable, drilling depth of each drilling unit individually infinitely adjustable, largest drill slide stroke 80 mm - Adjustment range for angled holes +/- 30 °, smallest distance from drill center to drill center 110 mm, horizontal adjustment range of the beam of the drilling units ...

In-line drilling rig with 8 height- and width-adjustable drilling spindles (optionally up to 12 drilling spindles and an extension to a drilling area of 4,000 mm x 240 mm – without moving the workpiece) VIDEO LINK on request Drive power 0.75 kW per drilling spindle (optionally, the system can be supplied with more powerful drilling spindles - 1 kW / 1.25 kW - 1.5 kW), drilling spindle speeds up to 12,000 rpm - infinitely variable via potentiometer and frequency converter - set speed can be read analogously, drill tension by collets ER25, largest drill diameter 12 mm, drilling feed speed infinitely adjustable, drilling depth of each drilling unit individually infinitely adjustable, largest drill slide stroke 80 mm - Adjustment range for angled holes +/- 30 °, smallest distance from drill center to drill center 110 mm, horizontal adjustment range of the beam of the drilling units ...

In-line drilling rig with 8 height- and width-adjustable drilling spindles (optionally up to 12 drilling spindles and an extension to a drilling area of 4,000 mm x 240 mm – without moving the workpiece) VIDEO LINK on request Drive power 0.75 kW per drilling spindle (optionally, the system can be supplied with more powerful drilling spindles - 1 kW / 1.25 kW - 1.5 kW), drilling spindle speeds up to 12,000 rpm - infinitely variable via potentiometer and frequency converter - set speed can be read analogously, drill tension by collets ER25, largest drill diameter 12 mm, drilling feed speed infinitely adjustable, drilling depth of each drilling unit individually infinitely adjustable, largest drill slide stroke 80 mm - Adjustment range for angled holes +/- 30 °, smallest distance from drill center to drill center 110 mm, horizontal adjustment range of the beam of the drilling units ...

Flatbed panel and panel machining center equipped with three, four or five CNC axes. These CNC machines are suitable for the processing of solid wood panels – HPL – laminate boards such as FUNDERMAX® – chipboard – MDF boards – plastic boards (e.g. – PVC / PE) – synthetic resin boards and other boards and panels that can be tensioned by vacuum. The machines of the PLANUS series are offered with two different clamping options. - In version 1 - the material tension is done by vacuum on a synthetic resin plate - in version 2 - the material tension is also carried out by vacuum, but the suction blocks are located on tensioner bridges that can be moved lengthwise. Drilling – milling – sawing, all with one machine. The machines can be configured according to the customer's requirements. - Milling spindle drive power 11 kW to 18 kW - Tool holder in the SK30/SK40  ...

Flatbed panel and panel machining center equipped with three, four or five CNC axes. These CNC machines are suitable for the processing of solid wood panels – HPL – laminate boards such as FUNDERMAX® – chipboard – MDF boards – plastic boards (e.g. – PVC / PE) – synthetic resin boards and other boards and panels that can be tensioned by vacuum. The machines of the PLANUS series are offered with two different clamping options. - In version 1 - the material tension is done by vacuum on a synthetic resin plate - in version 2 - the material tension is also carried out by vacuum, but the suction blocks are located on tensioner bridges that can be moved lengthwise. Drilling – milling – sawing, all with one machine. The machines can be configured according to the customer's requirements. - Milling spindle drive power 11 kW to 18 kW - Tool holder in the SK30/SK40  ...

Key data: 3000 mm, 1300 mm

Flatbed panel and panel machining center equipped with three, four or five CNC axes. These CNC machines are suitable for the processing of solid wood panels – HPL – laminate boards such as FUNDERMAX® – chipboard – MDF boards – plastic boards (e.g. – PVC / PE) – synthetic resin boards and other boards and panels that can be tensioned by vacuum. The machines of the PLANUS series are offered with two different clamping options. - In version 1 - the material tension is done by vacuum on a synthetic resin plate - in version 2 - the material tension is also carried out by vacuum, but the suction blocks are located on tensioner bridges that can be moved lengthwise. Drilling – milling – sawing, all with one machine. The machines can be configured according to the customer's requirements. - Milling spindle drive power 11 kW to 18 kW - Tool holder in the SK30/SK40  ...

CNC controlled three-axis under-table cross-cut saw with additional drilling unit for wood and wood-like materials, but also suitable for sawing aluminium non-ferrous metals and plastics. Closed compact production island, low noise pollution and no chips in the machine environment. Our automatic sawing and drilling machine KA 550 CNC - SAW and DRILL is versatile einsetzbar_ – Only saws in automatic mode and for single cuts - Drilling only - Combines drilling and sawing in a single operation The possibilities to work with the drilling unit include drilling and countersinking, combined drilling + countersinking with a combination tool, drill milling of longitudinal holes – longitudinal holes transversely – rectangular cut-outs. The drill feed speed and the drilling pressure can be sensitively adjusted. Technical data Circular Saw and Drilling Machine KA 550 CNC - SAW an ...

-) 2-jaw drill chuck 20 mm -) Dowel drilling device with 4-compartment grid 16-32-22-25 mm -) 90° frame stop pluggable -) Miter stop 45° and 22.5° pluggable -) Moving equipment -) Workpiece clamp manual 2 pieces -) Suction connection D 100 mm Optional accessory: -) Gauge in handwheel -) infinitely variable double angle miter stop -) 1 lever operation -) switchable pneumatic stroke for two planes -) Leaser on request

Table top height: 910 mm Table top size: 700 x 380 mm Max drilling depth: 145 mm Max long hole length: 240 mm Height adjustment distance 135 mm Engine power: 1.5 kW Voltage: 400 V / 50 Hz Speed: 3,000 rpm Net weight: approx. 200 kg Suction nozzle: 100 mm Dm Dowel drilling device: Pitch 16, 22, 25, 32 mm with precision grid roller Driving equipment: Yes Frame stop 90°: pluggable Two-jaw chuck: up to 20 mm clamping range Hand eccentric tensioner: 1 piece 1 Lever control: Yes Measuring clock in handwheel: Yes Miter stop: Yes, double angle adjustment stop from 22.5° to 75° infinitely adjustable

In-line drilling rigs with 8 pieces of drilling spindles for the processing of easily machinable materials such as wood - aluminium - non-ferrous metals, composite materials and various plastics. Each of the drilling units produces 450 watts. Infinitely adjustable drilling feed speed Infinitely adjustable drilling depth and return path of the drilling unit. Slanted holes in the range +/- 30°. Pneumatic workpiece tension Table size 3,000 x 800 mm (optionally larger) Working height approx. 870 mm. Horizontal adjustment of the drilling units 240 mm. Vertical adjustment of the drilling units 320 mm. Dimensions 3 x 1.25 x H 1.98 m Weight approx. 1,000 kg

horizontal boring - glue injection - dowel insertingSingle drill and inserter which can be freely programmedDrilling depth manually adjustableZ-axis with manual settingWorkpiece sizes: Length min/max: 20 / 1250 mmWidth min/max: 50 / 800 mmThickness min/max: 10 / 60 mmmax. workpiecewidth with middle fence on 2 fields: 600 mm, on 1 field: 1200 mmMiddle fence with pneumatic rise/fall6 vertical pressure unitsDouble membrane glue pump 1:1 Glue viscosity 350 mPasDowels: 8 mm x 30 mm, 8 mm x 35 mmControlls: Powercontrol PC85 with Woodwop software

boring unit with 23 spindles grid 32mm, motor 1,5kWboring unit tiltable 0? to 90?max stroke of the boring unit 80mmtable 1000mm x 400mmpneumatic clamping of the workpiecefence left and right manually adaptablewith foot pedal

Hardware drilling and recessing machine, with multi-spindle headTable mountedMotor 1,1 kWFence left and right, 1,5 m. long

Max drilling depth 150 mmMax drilling length 310 mmHeading 270 x 90 mmHead rotation +/- 45?Min/max height door/window 600/1000 mmWorktable dimensions 420 x 60 mmTilt adjustment work table +/- 45?Motor chain 2,2 kWFront mechanical pusherAutomatic chain lubrication pump

Length work table: 600 mmWidth work table: 320 mmWork table height: 850 mmMax. drill length: 240 mmMax. Traverse stroke: 200 mmVertical stroke: 150 mmTilting of the boring head: 45? 0? 45?tool clamp 0-20 mmRevolutions: 2860 tr/minMotor Power: 2,2 KW

Machine to the dowel, drill and saw the company EKM spezialmaschinen connection value: 4,4 kW 1 pneum. Workpiece clamping system 1 drill head with 5 spindles in row spacing 25 mm / 40 mm / 40 mm / 25 mm 4 piece glue - and plugs Tools 4 piece adjustable on width 220 mm Under table saw Control PLC Siemens Simatic Fully functional replacement for PLC program on CD,. Shipping dimensions: L 1500 mm x W 1500 mm x H 2400 mm Machine weight: 1000 kg Condition good, fully functional
