maag gear cutting and hobbing machines used for sale

max. wheel diameter: 750 mm gear width: 215 mm max. module: 10 (25) min. module: 1 max. ram stroke: 225 mm number of teeth: 6 - 300 max.helical angle: 60 ° no. of strokes: 32,2 - 200 Hub/min workpiece weight: 800 kg total power requirement: 10,5 kW weight of the machine ca.: 6 t Equipped with: 1 internal ramming device, type: JV 75 with approx. 10 ramming wheels 1 set of interchangeable wheels 1 rotary flap for helical planing combs, type: DS 45 1 hydraulic control unit with clamping unit recessed in the rotary table 2 mechanical clamping devices with bayonet lock 13 workpiece holders in various dimensions 325 (!) planing combs for straight and helical teeth (some new) 14 single-tooth tools with holders 1 MAAG tooth pitch measuring device for external teeth, type: TMA 1 MAAG tooth pitch measuring device for internal teeth, type: TMI The data for this ad was created with ModulMWS - the ...

max. wheel diameter: 450 mm gear width: 120 mm max. module: 6 min. module: 1 min. wheel diameter: 20 mm tooth helical angle min/max: 15 - 60 ° number of teeth: 6 - 250 table diameter: 360 mm table load capacity: 400 kp stroke of ram - solid: 0 - 145 mm stroke position adjustment: 200 mm number of strokes per dividing: 9 - 80 no. of strokes: 37,5 - 235 Stück total power requirement: 9 kW weight of the machine ca.: 3,7 t set of change gears Approximately 30 planer combs, clamping fixtures The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SH75 max. wheel diameter 750 mm gear width 200 mm max. module 10 min. module 1 min. wheel diameter 30 mm max. number of teeth 300 min. number of teeth 6 tooth helical angle min/max 0 / 60 ° min. ram stroke 0 mm max. ram stroke 225 mm table diameter 500 mm table load 0,8 t no. of strokes 23,5 - 150 Hub/min table hole 90 mm total power requirement 7 kW weight of the machine ca. 3,8 t dimensions of the machine ca. 2,1 x 1,7 x 2,1 m

Planing comb to Maag gear planing machine

MAX DIAMETER 750,MAX MODULE 10

max. wheel diameter: 1000 mm gear width: 630 mm max. module: 16 min. module: 1 wheel diameter with counterstay: 800 mm max. number of teeth: 999 clamping length: 1060 mm workpiece weight: 1500 kg max.helical angle: 45 ° grinding spindle drive: ca. 20 kW Control: Opal / Siemens total power requirement: 70 kW weight of the machine ca.: 17,5 t - CNC control Opal / Indramat with Siemens S5 PLC - paperbandfilter - oil mist exhauster - complete covering The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Ref. -No.: 10103 Manufacturer: MAAG Year of construction: 1976 Type of control: Konventionell Control: N/A Storage location: Halberstadt Country of origin: Schweiz Minimum number of teeth: 6 Max. Number of teeth: 300 Serial no.: 4216 Gear width: 200 mm Max. Pile driving: 225 mm Max. Wheel Diameter: 750 mm Min. Wheel Diameter: 30 mm Table Diameter: 500 mm Max. Module: 10 mm Min. Module: 1 mm Spiral Angle: 0/60 °

max. wheel diameter: 600 mm gear width: 150 mm max. module: 15 min. module: 1 clamping length min.: 45 mm clamping length max.: 750 mm workpiece weight: 150 kg total power requirement: kW weight of the machine ca.: 0,55 t dimensions of the machine ca.: 1,2x0,8x1,95 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: NA mm gear width: NA mm max. module: min. module: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Manually operated 2-Flank Gear Tester The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 620 mm gear width: 90 mm max. module: 12 min. module: - no. of teeth: 6 - 100 pivoting angle: 0 - 90 Grad spindle taper: metr. 100 milling head speed: 28 - 56 U/min connected load: 18 kVA Control: total power requirement: 14 kW weight of the machine ca.: 12 t 2020 Retrofit with new control/electrical system) - CNC control NTC (Fanuc) (German/English) - electric handwheel - new motors/ electrics - various change wheels - chip conveyor - coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cone distance min./max.: 0-108 mm Pitch angle min/max: 5°/84° Control: GE Fanuc Series 0-GC Pitch diameter (1:1 ratio): 152 mm pitch diameter (10:1 ratio): 216 mm Diametral pitch (finest/coarsest): 1.3/8.5 Mod. Face width gear wheel max.: 35 mm Knife spindle - Speed range: 41-121 U/min working spindle speed range: 0-33.33 U/min weight: 9025 kg dimensions of the machine ca.: 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: -Knife -Chip conveyor -Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 406,4 mm gear width: 66 mm max. module: ca. 12,5 min. module: Control: Zyklengesteuert total power requirement: 21 kW weight of the machine ca.: 12,5 t dimensions of the machine ca.: 3,3 x 2,5 m The GLEASON 641 G-PLETE bevel gear generating machine is a proven and robust solution for the production of spiral bevel gears, hypoid gears, and Zerol bevel gears usingthe well-established Gleason generating method. Designed for reliable and repeatable machining processes, this machine is ideally suited for small to medium batch production in industrial gear manufacturing. The 641 supports both roughing and finishing operations in a single setup (completing process), ensuring consistent gear quality while reducing handling time. Its mechanical generating system with variable roll ratio and plunge feedmechanism allows precise control of the tooth geometry, making it a depend ...

[ 5000 characters max., no information about the advertiser ] Brand:MODUL Model:ZFWZ 2000/3 Type:Gear Hobbers Year:1981 Location:Czech Republic Specification: Max diameter of gear without tailstock 2100 mm Max diameter of gear with tailstock 1450 mm Max face of gear 1060mm Max module with hobbing head 22 Max/ Min center distance 1240/150 mm Min number of teeth 10 Max pressure angel 45 deg Table dia / number of slots 1800 mm/12 Bore in table / length 600/800 mm Max dia of hob / length 300/330 mm Max weight of workpiece 15000 kg Accessories: Standard milling head Tailstock (no clamping) Set of gear supports (shoes) Set of arbors Set of change gears

Circulation cutter from Klingelberg

Gear hobbing machine 53A50H, STANKO, with change gears

Gear hobbing machine STAEHELY mod. SH25US + n. 2 Basket sanders D 1700 and D 1400

KOEPFER 151 Gear Hobbing Machine - Horizontal Available 2 machines. Semi-automatic machine Max. gear dia 150 mm Module 2 Max Profile depth / Plunge cut depth 7 mm Max hobbing length 135 mm Max length of workpiece, approx. 280 mm Hob slide swivable 250 degrees Hob size dia x length 65 x 60 mm Hob shifting, manually max. 40 mm Hob Spindle speeds 140 – 1120 rpm Workspindle bore 24 mm Bore of collet chuck, max. 3 – 24 mm Feed range, axial/plunge cut 0.06 – 2 mm/rev No. of teeth, min./max. 6 - 200 Spindle Drive/Total electrical load, approx. 2,2 / 4 kW Weight, approx. 1,400 kg Very good condition

MAX DIAMETER 640 MAX MODUL 8 TABLE DIAMEER 550

Key data: 460 mm, 10

BEVEL GEAR SPIRAL GENERATOR

max diam 340 , max modul 8

max. wheel diameter: 200 mm gear width: 400 mm max. module: 4,5 min. module: 0,3 weight of the machine ca.: 6 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 630 mm gear width: 375 mm max. module: 10 clamping table: 550 mm table hole: 125 mm milling spindle speeds infinitely variable: 62 - 390 U/min taper: MORSE 5 axial-feeds: 0,40 - 6,80 mm/U radial feeds: 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle: 50 - 425 mm no. of teeth: min. 8 milling cutter dia. x width: 192 / 215 mm shifting: 200 mm main drive motor: 7,5 kW total power requirement: 21 kVa weight of the machine ca.: 8,2 t Main features: -Universal hob head with tangential movement -Automatic shifting -Automatic dwell attachment -Hydraulic clamping in table -Pressure reduce valve for outer steady -Magnetic swarf conveyor Accessory: 1 set of tools for operating and maintenance 1 set differential gears, module 1,75 1 set indexing change gears module 2,5 1 change gear cabinet The data for this ad was created with ModulMWS - the software solution of Lo ...

Key data: 1600 mm, 460 mm, 16

TABLE DIAM 1350

Gear hobbing machine PFAUTER 1200mm, modul 12, with change gears

x-travel: 350 mm y-travel: 200 mm z-travel: 350 mm table surface area: 700 x 280 mm spindle taper: SK 40 : 150 - 1660 U/min feeds: 25 - 285 mm/min rapid traverse: 1 m/min quill stroke: 80 mm milling-head swivable +/-: 45 ° total power requirement: 3 kW weight of the machine ca.: 1,2 t dimensions of machine L x W x H: 1,27 x 1,1 x 1,65 m Accessories: vertical head with quill retraction, solid table, univ. table, rotary table 250 mmø, dividing unit with 3-jaw chuck 135 mmø, counter bearing, various tool fixtures, drill chuck, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MODUL ZFWZ 3150/3 Gear hobbing machine max. wheel dia. 3150 mm min. wheel dia. 500 mm max. wheel diameter with outboard-support 1600 mm max. module 30 mm gear width 1000 mm max. helical angle 45 deg tangential adjustment 500 mm cutter length max. 440 mm diameter of cutter (hob) 350 mm table diameter 2400 mm table bore diameter 500 mm depth of hole 1100 m table load max. 30 t Accessories Dimnsions 6700x5400x4800 mm Weight 65000 kg

max. wheel diameter: 400 mm gear width: 275 mm max. module: 6 Overall size: 300x330x245 cm weight of the machine ca.: 5,5 t dist. cutter spindle - workpiece spindle: 40/265 mm hob turning speeds: 50-400 U/min Specification: Max wheel diameter: 400 mm Min module: 1 Max module: 6 Table diameter: 370 mm Max wheel diameter: -With counterstay: 340 mm -Without counterstay: 400 mm Max axial offset: 275 mm Max tangential adjustment: 100 mm Tooth helical angle: 45 degrees Max cutter diameter: 145 mm Max hobbing length: 170 mm Hob turning speeds capacity: 63-180 U/min Feeds infinitely variable axial: 0,2-10 mm/U Feeds infinitely variable tangential: 0,1-5 mm/U Radial for spur gears: 0,1-4 mm/U Radial for worm gears: 0,025-1 mm/U Rapid traverse axial: 500 mm/min Rapid traverse tangential: 250 mm/min Radial for spur gears: 400 mm/U Radial for worm gears: 100 mm/U Motor power: 7.4 kW The data for t ...

max. wheel diameter: 180 mm table diameter: 145 mm max. module: 3-5 mm gear width: 250 mm table turning speeds: 800 U/min milling head vertical adjustable: 400 mm Milling axis swiveling range: + / - 45 ° max. milling cutter diameter: 90 mm hob turning speeds: 0 - 6000 U/min cutter length max.: 211 mm control: Siemens 840 D total power requirement: 23 kW weight of the machine ca.: ca. 10 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Machine in top condition, equipped with loading unit, many accessories. This machine is equipped with manual deburring function with a cutting wheel, no chamfering. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MODUL ZFWZ 630 Gear hobbing machine Wheel diameter 630-710 mm Gear width 400 mm Module 1-10 Max. axial feeding travel 400 mm Max. tangential feeding travel (hob shift) 200 mm Max. helix angle 45 degrees Min. number of teeth hobbed 10 Min. number of teeth hobbed with indexing drive 5 Max. hob diameter 200 mm Max. hob length 250 mm Diameter of working table 580 mm Hole in working table 100-250 mm Depth of hole in working table 45-300 mm Distance center of hob to working table surface 175-575 mm Driving taper for hob arbor (step taper) 50 mm Hob speeds of universal hobbing head steeped 50-400 rpm Milling spindle speeds (infinitely variable) 40-400 rpm Power capacity 29 kW Machine dimensions 3380x2715x2250 mm Machine weight: 9200 kg

max. wheel diameter: 400 mm gear width: 275 mm gear width: 275 mm max. module: 6 weight of the machine ca.: 5,5 t shifting: 100 mm dist. cutter spindle - workpiece spindle: 40/265 mm hob turning speeds: 50-400 U/min The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Gear hobbing machine vertical Pfauter P251 With accessories

Pfauter RS 2 With accessories

Under power , complete

Gear hobbing machine LIEBHERR ET 1200

max. wheel diameter: 5500 mm gear width: 1500 mm max. module: 32 faceplate diameter: 3740 mm swing diameter: 6200 mm turning height: 1200 mm control: FANUC 31i MODEL B : 1250 mm cross rail - adjustment: 3000 mm turning speeds: 3-15 U/min spindle turning speed - stepless: 15 - 1500 U/min workpiece weight: 39,4 t max. dia. of teeth cutting: 5500 mm tooth width: 550 mm module: 32 cutter speeds: 10 -150 U/min milling cutter dia. x width: 450 x 110 mm milling head axial adjustable: 2060 mm total power requirement: - kW weight of the machine ca.: - t dimensions of the machine ca.: - m Complex TurnMill & Gear Cutting Machine - CNC control FANUC 31i B - Turning and Milling Function - ATC - Angular Milling Head - Gear Hobbing (internal and external) - Chip Conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Gear hobbing machine STANKO 5K32 with accessories.

max. wheel diameter: 250 mm gear width: 242 mm max. module: 4 min. module: 0,5 table diameter: 250 mm table bore diameter: 68 mm milling cutter dia. x width: 130 x 130 mm spindle stroke - max.: 110 mm min. number of teeth: 6 center distance betw. workpiece-tool min/max.: 10 - 210 mm milling spindle speeds (infinitely variable): 80 - 500 U/min feeds axial: 0,32 - 4 mm/WU radial feed: 0,05 - 1,6 mm/WU feeds - tangential: 0,16 - 2 mm/WU Control: LAUER PCS table diameter: 250 mm table hole: 62 mm milling cutter dia. x width: 130 x 130 mm total power requirement: 16 kVa weight of the machine ca.: 3,6 t dimensions of the machine ca.: 2,8 x 2,4 x 1,9 m Machine ideal for electrical retrofitting Equipped with: - LAUER PCS NC control - Siemens Simatic S5 PLC - Loading device/magazine for workpiece size max. 140 mm Ø - Shifting - 2-cut cycle The data for this ad was created with ModulMWS - the s ...

MODUL ZFWZ 1250x14I gear hober (can do 1580 mm) Max. Diameter: 1250 mm Cutting width: 600 mm Module 2-16 Maximum size of the hob: 240 x 280 mm Table diameter: 1020 mm Speeds: 28 – 200 rpm Axial feed rates: 0.28 – 8 mm/min Radial feed rates: 0.1 – 2 mm/min Tangential feeds: 0.16 – 4 mm/min Stand tilt – left/right: +/- 45 Main motor power: 5 / 19.5 kW Power of the rapids motor: 12,5 kW Max. diameter of the part without tailstock: 1,250 mm Max. diameter of the part with tailstock: 800 mm Weight of the machine : 16 t Machine dimensions approx. 4.5 x 2.1 x h 3.3 m EQUIPMENT: Extended driven shaft for gear cutting up to Ø 1580 mm Capability to work with hob cutters Ø 235 mm and length 380 mm. Inverter control of the main electric motor. Expanded set of change gears

CHURCHILL PH3615 gear hobbing machine Max workpiece diameter 914 mm Max diametral/ pitch- 8 Module, 3 D.P. Horizontal centre distance:-63,5- 559 mm Max horizontal travel 469 mm Height hob centre to worktable: 127- 508 mm Max travel of vertical feed 381 mm Max height worktable to tailstock centre768 mm Table diameter 762 mm Table hole (diameter x depth) 89 x 381 mm Hob dia x length 178 x 203 mm Max travel of hob slide 127 mm Diameter of hob arbor 32 mm Hob spindle speeds, infinitely variable 50 – 200 rpm Vertical feeds 0.38 – 5 mm Main drive motor 10 HP Floor area 3960 x 2130 x 2300 mm Weight 11,500 kg Extended set of change gears Complete documentation Operational variable speed drives for main motor and feed drives

max. wheel diameter: 600 mm gear width: 0 mm max. module: 16 (25) min. module: 1 center distance betw. workpiece-tool min/max.: 40 - 590 mm diameter of hob: 290 mm cutter length max.: 470 mm tangential adjustment: 450 mm milling head -swivable +/-: 45 ° milling head speed: 15 - 380 U/min table rotation speed: 50 U/min milling spindle drive: 37 kW table diameter: mm table load: 3750 kg feeds: 2000 mm/min Control: Siemens 840D total power requirement: 115 kVA weight of the machine ca.: 31 t dimensions of the machine ca.: m - 6-axis CNC control Siemens Sinumerik 840 D - complete covering - counter stay - Coolant Unit - Chip Conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 1250 mm gear width: 600 mm max. module: 16 min. module: 2 tooth width: 490 mm Zahnschrägungswinkel max.: 45 ° shifting: 200 mm max. number of teeth: 12 diameter of hob: 240 mm cutter length max.: 280 mm table diameter: 1020 mm milling spindle speeds (infinitely variable): 28 - 200 U/min power capacity: 25 kW weight of the machine ca.: 16,2 t dimensions of the machine ca.: 4,5 x 4,6 x 2,7 m equipped with: - universal hob head - change gears machine has been partly overhauled (electrical and machnical) and is now with programmable, digital Infeed The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 2500 mm gear width: 750 mm max. module: 18 / 22 min. module: table diameter: 1800 mm min. number of teeth: 12 table hole: 300 mm hob turning speeds: 20 - 100 U/min table load: 10 t milling cutter dia. x width: 250 x 340 mm shifting: 150 mm feeds - tangential: 0,25 - 3 mm/min feeds - radial: 0,07 - 1,5 mm/min feeds - longitudinal: 0,55 - 3,5 mm/min milling feeds: 13,4 - 80 (Einzelteilen) mm/min total power requirement: ca. 30 kW weight of the machine ca.: 28 t - change gears, arbors, toolings, clamping plots - universal hob head - swiveling outer steady - single indexing device party overhauled in 2023 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 3000 mm gear width: 500 mm max. module: 25 / 40 spindle turning speed range: 250 U/min feed speeds: max. 4000 mm/min faceplate diameter: 2000 mm table bore diameter: 700 mm table turning speeds: 51 U/min power capacity - milling spindle: 53 kW drive motor for milling spindle: - kW axial adjustment: 1200 mm milling head swivable ca.: +/- 45 ° control: Siemens 840D total power requirement: - kW weight of the machine ca.: 55 t - CNC Control Siemens 840D - Internal Hob Head IFK - External Hob Head The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Gear hobbing machine TOS OF-71 with change gears

max. wheel diameter: 160 mm gear width: 355 mm max. module: 4,5 min. module: 0,5 centre distance: 450 mm total power requirement: 11 kW weight of the machine ca.: 3,8 t dimensions of the machine ca.: 2x17,1,6 m Wheel diameter - max. 160.175 mm Wheel width 355 mm Module - max. 4.5 Spindle bore 75 mm Center distance 410 mm Number of teeth - min. 2, 3 Cutter diameter max. 115 mm Cutter length max. 105 mm Center distance between milling cutter and workpiece - max. 138 mm Center distance between milling cutter and workpiece - min. 30 mm Milling head - swivels 120 ° Milling cutter speeds 70 - 400 rpm Axial feeds 0.25 - 4.0 mm/rev Radial feeds 0.09 - 1.5 mm/rev Total power requirement approx. 9.5 kW Machine weight approx. 3.5 t Space requirement approx. 1730x1400x1440 mm Equipment/accessories: - Changing wheels - milling arbors - Clamping device Dra8M7 - documentation The data for this ad wa ...

Machine : Gear Hob 1 set of gear hobs 20 pcs. Angle of engagement 20 degrees Module : Set all sizes M 1 2x M 3 M 1.25 M 3.25 M 1.5 2 x M 3.5 M 1.75 M 3.75 M 2 M 4 M 2.25 M 4.5 M 2.5 M 5 M 2.75 M 5.5 M 6 Gear hobs : M 1 , 20 degrees , φ 70x50, 80% M 1.5 20 degrees, φ 54x56, 90%, M 2 20 degrees, φ 72x72 90% M 2.5 20 degrees, φ 60x65, 80% M 4 20 degrees, φ 90x78, 80% M 2.5 20 degrees φ 78x190, 30% M 1.6 30 degrees, φ 85x130, 90% M 1.5875, 30, φ 82x120, 90% Other tools : See photo

max. wheel diameter: 600 mm max. module: 6 range L-W-H: 2540 x 1500 x 1920 mm table diameter: 160 mm weight of the machine ca.: 3,6 t High-performance gear hobbing machine Tooth helix angle 15° Tooth width 270 mm Wheel diameter 620 mm Tooth helix angle 30° Tooth width 250 mm Wheel diameter 610 mm Tooth helix angle 45° Tooth width 200 mm Wheel diameter 500 mm Tooth angle 60° Tooth width 100 mm Wheel diameter 450 mm Maximum cutter diameter 105 mm Maximum cutter width 115 mm Clamping table diameter 420 mm Bore of clamping table 75 mm Depth of bore below table surface — mm Diameter of workpiece clamping wheel 450 mm of clamping mandrel 30 mm of milling mandrels 22–27–32 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MAX DIAMETER 800 , MAX MODULE 10

A Pfauter vertical CNC gear hobbing machine is available. Modules min./max.: 1/3, max. workpiece diameter: 150mm, max. tooth width: 150mm, milling head tilt: +/-45°, milling cutter axis-table axis distance: 10mm-160mm, table diameter: 160mm, table bore: 63mm. Tool holder: SK40, max. cutter diameter: 130mm, max. cutter length: 220mm, speed: 600rpm, feed: 1500mm/min, tangential path: 170mm, rapid traverse: 3m/min. Machine dimensions X/Y/Z: approx. 4000mm/3000mm/2500mm, weight: approx. 6500kg. On-site inspection is possible.

Gear hobbing machine MIKRON 102 Max. workpiece diameter 120 mm Max. Modul 2 Max. lenght of teeth 130 mm Min./max.nr of teeth 6 – 325 Angle on helical gears 0 – 90 °

max. wheel diameter:180 mm max. module:7 hob turning speeds:200-2000 U/min min. number of teeth:4 excluding conveyor belt

max. wheel diameter:180 mm gear width: mm max. module:4 total power requirement:14 kW weight of the machine ca.:8 t slide travel axial ( Z-axis ):300 mm work piece - max.:490-640 mm

control:siemens 1P 6SL 3054--0CE01-1AA0 Documents:vorhanden

max. wheel diameter: 3000 mm gear width: 1200 mm max. module: 30/40 min. module: 2 table diameter: 2500 mm table load capacity: 400 kN hob dia. - max.: 450 x 500 mm milling spindle speeds: 10 - 165 U/min hob length max.: 500 mm tip circle diameter: 2050 mm tooth helical angle min/max: 0 - 45 ° center distance betw. workpiece-tool min/max.: 150 - 1750 mm milling slide swivelling: 50 Grad distance table / counter stay: 1050 - 2050 mm shifting: 300 mm workpiece weight: 40 t table bore diameter: 800 mm depth of hole: 1100 mm main drive motor: 37 kW min. workpiece diameter: 290 mm min. number of teeth: Wälzfräsen 20 min. number of teeth: Formfräsen 2 taper: MK 100 feeds axial: 1 - 1800 mm/min radial feed: 1 - 500 mm/min feed: Tangential 1 - 450 mm/min rapid traverse: 1875 / 530 / 470 mm/min electrics - voltage/frequency: 380 / 50 V/Hz control: Siemens Sinumerik 3M total power requirement: ...

max. wheel diameter: 2000 mm gear width: . mm max. module: 22 max. hob diameter: 250 mm hob turning speeds: 16-92 U/min total power requirement: 13 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 4400 mm gear width: 645 mm max. module: 35 Control: Siemens main drive motor: 37 kW table diameter: 2500 mm max.helical angle: +/- 30 ° workpiece weight: 40000 kg total power requirement: 142 kVA weight of the machine ca.: 75 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 406 mm gear width: 420 mm max. module: 4,3 min. module: 0,5 hob turning speeds: 49 - 246 U/min table bore diameter: 80 mm total power requirement: 7 kW weight of the machine ca.: 3,5 t dimensions of the machine ca.: 2,8 x 1,6 x 2,2 m Year of construction approx. 1980 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

weight of the machine ca.: 5 t working width: max. 300 mm : 6 extensive accessories: viele Wechselräder Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 400 mm gear width: 280 mm max. module: 1 min. module: 4 total power requirement: 15 kW weight of the machine ca.: 6000 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 0 mm gear width: 150 mm max. module: 2,5 min. module: total power requirement: 10 kW weight of the machine ca.: 2400 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 80 mm gear width: 120 mm max. module: 3 min. module: 1 control: SIEMENS 840 C total power requirement: 30 kW weight of the machine ca.: 7500 t dimensions of the machine ca.: m L I E B H E R R CNC – Controlled Gear Hobbing Machine Type LC 82 Baujahr 1995 Ser.-Nr. 0836 ______________________________________________________ Gear-Diam. max. 80 mm Module Range 1 - 3 Helix Angle +/- 45 ° Distance Table Center to Tool Center 15 – 160 mm Hobbing Head Slide stroke vertical 250 mm Tangential Travel / Shift Travel of Tool slide 180 mm Minimum Number of Teeth 3 (!) Hob Size max. Ø x length approx. 90 - 200 mm Taper of Hob spindle HSK 50 A Workpiece Clamping length (table/Tailstock) 250 mm Infeed rate ...

max. wheel diameter: 80 mm gear width: 150 mm max. module: 2,5 min. module: total power requirement: 10 kW weight of the machine ca.: 2400 kg M I K R O N (Switzerland) Fully Automatic Gear Hobber for Worm Gears Model A 33 / 1 Year 1985 Ser.-No. 14.06/14.07/14.15 ____________________________________________________________ max. gear- without feed magazine approx. 80 mm max. gear- with feed magazine approx. 50 mm Module max. 2, / 2,5 Axial milling length approx. 150 mm max. workpiece-mounting length approx. 200 mm Milling slide can be swivelled up to 90 degrees Milling cutter - 24 - 50/63 mm Max. radial distance of milling slide 0-14/18 mm Milling cutter adjustment max. 25 mm Milling cutter speed 212 - 2.000 rpm Axial feed range infinitely adjustable 0,05 - 4,0 mm/workpiece rotation radial infinitely adjustable 0,2 - 200 mm/min.  ...

max. wheel diameter: 150 mm gear width: 300 mm max. module: 4,5 min. module: total power requirement: 20 kW weight of the machine ca.: 6 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 900 mm gear width: 500 mm max. module: 1 min. module: 10 total power requirement: 16 kW weight of the machine ca.: 8.500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: --- mm gear width: --- mm max. module: --- min. module: --- total power requirement: --- kW weight of the machine ca.: --- t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 150 mm max. module: 5 min. module: 0,5 Control: weight of the machine ca.: 10.000 kg dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8631 Type: OFA 16 A Producer: TOS Created: 1976 Parameters: Machine weight: 3550 kg

Wheel diameter: 160mm, max. wheel width: 355mm, module range: 0.5-4.5, max. cutter diameter: 115mm, max. cutter length: 105mm, cutter head swivel range: 120°, speed: 400rpm, distance between centers: 410mm. Machine dimensions X/Y/Z: approx. 2000mm/1500mm/2000mm, weight: approx. 3500kg. An on-site inspection is possible.

Inv. Num. : 8799 Type: FO-10 Producer: TOS Created: 1958 Parameters: Maximum gear diameter: 1000 mm Maximum module: 10 Machine dimensions: 3120 x 1870 x 2525 mm Machine weight: 9000 kg

max. wheel diameter: 150 mm gear width: . mm max. module: 5 min. module: 0,5 Control: . total power requirement: . kW weight of the machine ca.: 10.000 t dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 150 mm max. module: 5 min. module: 0,5 Control: weight of the machine ca.: 10.000 t dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 150 mm max. module: 5 min. module: 0,5 Control: weight of the machine ca.: 10.000 t dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 150 mm gear width: . mm max. module: 5 min. module: 0,5 Control: . total power requirement: . kW weight of the machine ca.: 10.000 t dimensions of the machine ca.: 6500 × 2700× 3600 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 8974 Type: OFA 16 SC Producer: TOS Generated: Parameters: Machine weight: 5 t

max. wheel diameter: 500 mm gear width: 400 mm max. module: 10 mm Control: SIEMENS Sinumerik 840D sl max. workpiece diameter: 500 mm Max. Distance from table to counterholder: 1.120 mm Max. Distance table to center of milling spindle: 585 mm Min./max. center distance between milling spindle: 50/475 mm table diameter: 420 mm table hole - depth: 150 mm Table equipped with hydraulic clamping device: : milling spindle: : milling spindle speeds: 48- 480 1/min stufenlos milling head swivelling angle: +/- 50 A-Achse Grad tool taper: SK 40 Tangential path of the milling carriage: 200 mm milling cutter diameter: 170 mm Max milling width: 250 mm electrical supply data: : voltage: 400 V operating frequency: 50 Hz connecting power: 55 kVA weight of the machine ca.: 10,5 t dimensions of the machine ca.: 6,2 x 4,2 x 3,e m Equipment and Accessories • High-performance CNC gear hobbing machine LIEBHER ...

Gear hobbing machine, milling machine, tool milling machine, vertical milling machine, roller milling machine, gear hobbing machine, gear hobbing machine, high-performance hobbing machine -Manufacturer: Liebherr, high-performance gear hobbing machine type SS 5- K/500 -Working area: Ø max. 500 mm -Max. cutter diameter: 186 mm -Accessories: including extensive accessories see photos -Machine dimensions: 2300/1460/H1870 mm -Dimensions accessories: pallets 1420/1300/H300 / 1200/800/300 mm -Weight: 5300 kg plus 535 kg accessories

Hydraulic tailstock, Ø max. gear: 250 with 3 cutter, Module: 5,5, Hobbing length: 70, Cutter module: 5,5, Outside ø max. acknowledged: 300 mm, Ø spindle: 85 mm, Ø hole table: 39 mm, Ø table: External centering Ø139,75, Power tool motor (b): 4 Cv, High: 1.800 mm, Long: 1.450 mm, Weight: 2.450 Kg, Width: 1.000 mm

WMW MODUL ZFWZ 160/3 gear hobbing machine was built in 1971 in the GDR by VEB Werkzeugmaschinenkombinat 7. Oktober” Berlin. The machine is used in plants manufacturing extremely precise drive components for, among others, the automotive, aerospace and machinery industries. It enables the efficient machining of spur and worm gears with a maximum external diameter of 160 mm. The machining process is performed by means of a spindle with a cutter with a maximum diameter of 110 mm. The spindle of the MODUL ZFWZ 160X3 machine moves along the contour of the workpiece, cutting the material along its entire circumference. Using this method, it is possible to achieve the desired shapes and teeth finish with the highest accuracy. The WMW MODUL ZFWZ gear hobbing machine weighs 3000 kg. Technical specifications of the WMW MODUL ZFWZ 160/3 gear hobbing machine General data - maximum external di ...

max. wheel diameter: 36 mm gear width: 36 mm max. module: 10 min. module: total power requirement: 12 kW weight of the machine ca.: 11,2 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MAX DIAMETER 800 , MAX MODULE 10

Inv. Num. : 9204 Type: FO-6 Producer: TOS Created: GO 1976 Parameters: Table diameter: 420 mm Maximum module: 6 Maximum gear diameter: 800 mm Machine dimensions: 2600 × 1400 × 1900 mm Machine weight: 4000 kg Equipment: 3 boxes of hobs and shape milling cutters

WIEPOFAMA ZFB-50 gear hobbing machine was manufactured in 1970 in Poland by Wielkopolska Fabryka Urządzeń Mechanicznych-Poznań. The machine is used for the precision hobbing of spur and helical gears. Machining is performed by means of the hobbing method, in which the teeth are gradually formed around the entire circumference of the workpiece. The use of this method ensures high dimensional accuracy and repeatability of the produced parts. The ZFB 50 gear hobbing machine enables the machining of gears with a maximum module of 10 mm and a diameter of 700 mm. The set of interchangeable wheels included in the offer enables flexible adjustment of working parameters to a specific type of tooth profile. All this is complemented by a robust design that ensures high stability even during the most demanding challenges. All of this makes the WIEPOFAMA ZFB 50 gear hobbing machine the best cho ...

Liebherr / Lorenz S800 Gear - Hobbing Machine -Max. workpiece length with counter holder 600mm -Max. workpiece length with retracted counter holder 800mm -Max. travel of the milling carriage 360mm -Largest millable pitch for the largest workpiece 5 Pi / in the normal power range 8 Pi -Pick-up taper - milling spindle MK 5 -Mandrel 22/27/32/40mm -Max. cutter diameter 186mm -Max. cutter length 170mm -Max. cutter displacement 80mm -Milling cutter speeds 40-220 rpm -Feeds infinitely variable / horizontal -Feeds infinitely variable / vertical -Feeds infinitely variable / tangential -Clamping table without water rim 550mm -Clamping table hole 100mm -Mandrel taper MK5 Accessories: 1x pallet interchangeable wheels 1x pallet hob 1x pallet clamping mandrels Documentation Machine feet Dimensions: LxWxH 3.6x1.8x1.9 meters / weight 5000Kg

max. wheel diameter:200 mm gear width:250 mm max. module:3 min. module:0,5 total power requirement:45 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:4,4 x 2,4 x 2,7 m Machine out of prototype production Without automation

weight of the machine ca.:8 t dimensions of the machine ca.:2,95 x 1,6 x 2,36 m chucking diameter:250 mm swing diameter:265 mm x-travel:170 mm z-travel:200 mm spindle turning speed range:1.500 U/min spindle bearing diameter:100 mm Pick-up machine
