peripheral equipment (e.g. heating,cooling,drying) used for sale (418)

5 PCS AVAILABLE BRAND FRIGEL MANUFACTURED 2007 CONDITION USED - IN WORKING ORDER QUANTITY AVAILABLE 5 UNITS MODEL RCD180/24 (180 LTS PER HOUR) TEMPERATURE RANGE 23 TO 194 F (CELCIUS -5 TO 90) VOLTAGE 400 VOLTS FREQUENCY 50HZ SHIPPIING WEIGHT 395.00 Kgs MAX CURRENT 52 AMP FLUID H20 MAX PRESSURE 8 BAR REFRIGERANT R407C HIGH PRESSURE 27 BAR LOW PRESSURE 22 BAR abc.FRIGEL.IT

working temperature: 30 °cooling capacity: 7,4 kWfill weight: 1,82 kgoperating pressure: 20/8,6 barvolume capacity: 9,44 Kubikmeter/hvolume capacity: 2900 pro Min.volume capacity: 28,5 barweight of the machine ca.: 160 kgdimensions: 675 x 835 x 1250 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Gravimetry ConPro for Processing of up to 4 components Total capacity: approx. 300 kg/h GraviCon Type PP45-400/l – Basic Version Control terminal with 5'' colour screen (touch screen) Desk housing with stand Dimensions: H 430 mm x D 235 mm x W 245/340 mm 2 x hopper scale I-KTW F36 for components 1 + 2 Throughput: up to 250 kg/h (especially for fibrous materials and poorly free-flowing materials) Base frame Hopper without viewing window Load cell holder with platform load cell 2 x hopper scale I-KTW P3 for components 3 + 4 Throughput: up to 70 kg/h (for paint or aditive in powder form) Base frame Hopper without viewing window Load cell holder with platform load cell 2 x dosing unit type CP22 for components 3 + 4 with 1 set of screws and barrels each – version: 10/18 (min. 1 to max. 20 kg/h) incl. 2 x spec. Neckpiece incl. 2 x storage container type: VB1 ...

1 pc flame pretreatment system with electronic control 1 pc EF 600-1 Burner control consisting of Electrical control with ignition and monitoring device for 1 pc burner, control electronics, control panel with plain text display, Emergency stop setup and interface for external control Mechanical control with Safety valves, gas/air mixers, thermoanemometrial mass flow meters for air and gas, Engine valves, pressure monitors for overpressure and vacuum monitoring and supply air blowers. 1 pcs C24-2300 Film burner, 2200 mm working width, adjustable up to min. 1000 mm with connections for water cooling and water-cooled double T-beam 1 pc spare parts consisting of 2 earth replacement electrodes and 1 replacement fabric Power supply : 400/230 V 50 Hz, 2.5 kVA Gas supply : Natural gas 75 – 100 mbar Heat output : max. ...

Temperature control units GWK central cooling system, project number 21 8729 Designed for: Cooling capacity 300 kW; at max. ambient temperature 32°C and cooling water flow temperature 20°C Composed of: Temperature control unit burner cooling Teco WCC100 / power 13.3 kW, nominal voltage 20.5A Temperature control unit heating roller 1 Tecma Wi 7.700.150D.150, power 7.5 kW, nominal voltage 15A Temperature control unit heating roller 2 Tecma Wi 7.700.150D.150, power 7.5 kW, nominal voltage 15A Temperature control unit heating roller 3 Tecma Wi 7.700.150D.150.D25, power 7.5 kW, nominal voltage 15A Temperature control unit cooling roller 4 Teco wd 500.00.32; Power 5.5 kW, rated voltage 11.5A Temperature control unit cooling roller 5 Teco wd 500.00.32; Power 5.5 kW, rated voltage 11.5A

Surface treatment of plastic films by flame treatment to increase surface tension Field of application: Plastic films Machine unit existing main components • PSA Reversible Unwinding & Reversible Winder 2200/12 PSA W/ARW 2200/12 – Fyling Splice Comm. 2011-001.1 • Hill/ Jungwirth burner unit for gas/air mixture • Suction • Erhardt+ Leimer web edge control • OCS camera system for error detection • Semket labelling system Marking of defects • GWK temperature control units for roller cooling

Plant number 701-246; medium used radionuclide Krypton 85 Type: X1114 Specifications: Connection voltage: 40V +/- 10%, 3 phases, 50 Hz, N, PE Basis weight measurement: measuring range 30-600 μm PA; Measurement accuracy +/- 2; Sigma range (+/-0.4% but maximum +/- 0.4 μm), Measuring gap 10 mm Traverse: maximum useful width 1970 mm, traverse speed 0-10 m/min Ambient temperature: sensors 0-50°C, traverse 0-50°C, control cabinet (control) 10-35°C Humidity max. 90% without condensation

Both filling stations are in good condition, little in use.

1.0 St. gebr. Temperature control unit with 48 control stations Manufacturer: GAMMAFLUX Type: GS1G030F024S4EJ Year of Make: 2019

Key data: 300 °C, 12 kW

1.0 St. gebr. Temperature control unit Manufacturer: TOOL - TEMP Type: TT - OIL 300, 12 kW Year of manufacture: Medium: OIL Temperature: 300° C Heating capacity: 12 kW

MATERIAL TRANSPORT & DOSING SYSTEM - COLORTRONIC WITH 3 COMPONENTS COMPLETE WITH CONTROLLER

MATERIAL TRANSPORT & DOSING SYSTEM - AZO (4x distributors)

Material No.: 1.2487.0 // Serial No.: 1267-3491416 Operating hours: 26512 h Equipment / Additional information: Max. working pressure PS: 13,00 bar Compressed air inlet temp. TS: 3 – 60 °C Ambient temperature: 3 – 50 °C Phases: 3 / Frequency: 50 Hz Voltage: 400 V Full load current: 17 A Full load current drive motor: 14 A Electrical diagram: STG-03000 00

Central supply with drying system Manufacturer Moretto Consisting of the following components: 1.0 pcs Dry Air Dryer Manufacturer Moretto, Type: SX25, Year of Make: 2016 1.0 pcs Pipe Station Manufacturer Moretto 4.0 pcs Drying hopper, capacity: 200 litres, with heating, type: H15T SOPP, year of construction 1999 1.0 pcs drying hopper, capacity: 100 litres, with heating, type: H15T SOPP, built in 1999 1.0 pcs drying hopper, capacity: 30 litres, with heating, type: H15T SOPP, built in 1999 8.0 pcs Material conveyor to the drying hoppers, type: R101 042, year of construction: 1999 8.0 pcs Material conveyor to the machines, type: R101 042, year of construction: 1999 1.0 pcs Vacuum Pump

Connected load: 0.77 kW

Motan conveyor incl. rotary wing level monitoring

A total of 5 material separators a vacuum pump with filter incl. control bus system ( Wittmann ) 2 Koch dry air generators 2 L-bands 1 separating drum

For sale is a temperature control unit from Regloplast Item must be dismantled and loaded by the buyer. Price is net plus VAT All information without guarantee

Regloplast temperature control unit Bj 2011 Technical data in the pictures Price is net plus VAT Dismantling and loading by buyers All information without guarantee

Temperature control unit Manufacturer: Robamat Model Robamat Thermocast 3201 Circles 1 Circuit Device Heating capacity at 400V 20 kW Flow temperature max. 250 °C Year of construction 2012 Remark Oil Appliance Price per piece 2 pieces in stock Price is net plus VAT Dismantling and removal by buyers All information without guarantee

For sale is a Tool Temp temperature control unit Works without any issues. To sell due to business closure. Technical specifications in the pictures. Self-collection and dismantling. Price per piece 2 pieces in stock Price is net plus VAT All information without guarantee

Key data: 140 °C, 6 kW, 45 W

Special items Various temperature control units pressure-overlaid up to 140 C°

Process chiller / chiller air-cooled, Type: TAEevo Tech 602 P3-20 MTA S.p.A. TAEevo Tech 602P3-20 are compact water chillers suitable for outdoor installation (-20°C to +46°C). Including crank pan heating, phase monitoring, electronic expansion valve, buffer tank 500 ltr., built-in P3 circulation pump and winter package -20°C (condenser pressure control). Cold water outlet temperatures from -10°C to +30°C are adjustable. Cooling capacity kW 116 Cold water temp. Exit/Entry: 7 / 12°C Volume flow m³/h 19.8 Available pump pressure (bar) 3.37 Ambient temperature °C 32, Refrigerant R 410A, Electrical data: Voltage V 400, frequency Hz 50, phases Ph 3, Max. power consumption (kW) 60.99 Max. current (A) 102.78 Starting Current Circuit (A) 218.51 Protection class: IP54 Dimensions: Length mm 3294, width mm 1255, height mm 2119, Weight kg 1773 Connection Rp 2 ...

Control System: Touch-screen operator panel Operation: Automatic color mixing and dosing Components of the Machine - Touch-screen control panel (CMA Challenger 151) - Integrated dosing & mixing system - Agitator / stirring unit (working components for mixing) - Pneumatic system / pressure control (pressure gauge and pneumatic connections) - Quick-release connections for tools/stirrers - Recipe management software (AURORA MIX / formula control system or equivalent), with integration into color-matching systems.

Colortronic CTT 30 Granulate Dryer For climate- and air-independent drying of thermoplastic granules and regrind before processing in order to remove the remaining moisture from the inside and outside of the granules. Colortronic dry air dryers work according to the absorption principle. The air is not heated, but the moisture in the drying funnel is absorbed and extracted. Operating voltage: 400 V Control voltage: 24 V Power: 3.5 kW Main fuse: 25 A Year of manufacture: 7/2000 More items - new and used - can be found in our shop! International shipping costs on request!

Laser welding system Föhrenbach

2 x Alpha 18 W-S with integrated redundant pump station Standard Hyfra equipment: Frame construction in stainless steel Economical low-noise scroll compressors Pump built into the housing; Attention: Required Inlet pressure: at least 0.05 bar! Machine with control transformer, no neutral conductor necessary Flow monitors Antifreeze monitoring Fault message with digital display Collective fault message, potential-free External power-on Automatic fan switching from low to high speed Highly efficient condenser with Micro Channel technology Non-cleanable flap evaporators for water Extras: Cooling capacity approx. 25kW at +13°C tank temperature and ambient temperature of +32°C Medium: Water Water-bearing pipes insulated Radiator designed according to the current ECO Design guideline 2021 (adapted compressor, condenser, evaporator) Housing LxWxH 1640 x 71 ...

System Cooler ERS

Key data: 160 °C

Description 1pc 800.--2 pieces 1.500.-- +VAT.HB Therm HB 160U1 max-160°C 8 KW ,year 2000 from resolution plastic production of medical device manufacturer ,operating instructions in the device in special compartment R1329 and R1330our identification no. Display protected by fold-away film Viewing by e-mail appointment is desirable Sale only to traders and under the following conditions The machine is considered to have been taken over when it leaves the company, subsequent complaints cannot be taken into account So no guarantee and return.We do not assume any liability for compliance with all requirements mentioned in the UVV (accident prevention regulations)
