extruders used for sale (284)

Here is a list of available equipment for pipes and profile extrusion from EU constructors., New equipment is constructed by renouned German Constructors, Used equipment is in good working conditions, Check the PDF list below and revert to us with your inquiries., Be very specific in yuoe questions and please don not forget to give your full contact, yourname, your Company name, Country, Whatsapp and phone no. Well be happy to assist you.

ROTATING SCREEN, construction in Aisi304 stainless steel, previously working on a 160 mm extrusion line, stainless steel screen with 17 mm holes, 2 exits for lumps and good materials, 0,25 kw motor, Bonfiglioli gearbox, loading hopper 305 x 505 mm., excellent conditions, installed power - used power in work: about 60-65% : 0,25 kw, availability: immediate, conditions: excellent

PREALPINA CDM EXTRUSION LINE 105 mm strand, loading hopper for hard plastics (possible addition of feeding screw on request), extruder with screw Ø 105 mm 35 L/D, n.1 vacuum degassing pump, d.c. motor 117 kw 400 V 3Ph.50 Hz, semi-automatic, non-stop, hydraulic screen changer, hydraulic pack, strand die, cooling bath, air drying tunnel, strand pelletizer, vibro classifier, The line is offered reconditioned, availability: 6 weeks from confirmation, options available: different cutting, different screen, upstream and downstream equipment, capacity: 400 kg/h, conditions: reconditioned with warranty, type: single screw

CRAMMED FEEDING UNIT, reconditioned, This unit can be synchronized to feeding screw from buffer silo and horizontal screw in extruder to grant a uniform, continuous feeding, for light scraps, mounted on a 130 mm extrusion line, totally reconditioned, possible addition of mastebatch feeder, availability: in stock, conditions: reconditioned, type: for up to 700 kg/h extruders

PRT WATER RING PELLETIZER, for PE PP PS PC ABS, nominal capacity 600-700 kg/h (tested up to 900 with PS), N.4 cutting blades, N.1 thermoregulation zones, Heating power 8.00 kW, Cutting motor power 4.00 kW, N.1 water pumps, heat exchanging unit, Single water pump power 3.00 kW, Vertical centrifuge power 5.50 kW, Steam vacuum power 0.25 kW, soundproofed discharging cyclon, Total installed power 20.75 kW, constructed in 2006, only 200 worked hours, excellent conditions, installed power - used power in work: about 60-65% : 20.75, conditions: as new, availability: immediate, capacity: up to 600-700 kg/h (tested with PS 900 kg/h), PRESENT CONDITIONS: as new, excellent quality, price is less than 50% of a new one

COMAC TWIN SCREW EXTRUDER EBC60, barrel with n. 2 x 60 mm. diam co-rotating screws, 42 L/D, for PE PP ABS PC PS, compounds, masterbatches, Average throughput rate 600 kg/h depending on material and feeding rate, 2 spare screws and 1 barrel reconditioned to 100% performances, Mounted: screws + barrel in very good conditions, n.1 dosing unit with hopper, N.2 vacuum degassing points, d.c.132 kw Siemens main drive 400V 50 Hz (possible replacement with a.c.motor), non-stop hydraulic screen-changer with 90 mm screens (available with fully automatic screenchanger, on separate request), hydraulic pack, fitted with strand die (available with water ring pelletizer on request) + stainless steel cooling bath with heat exchanging unit + air-blowing dryer, electric cabinet (for extruder, screen-changer, hydraulic pack), pelletizer for strands, TVV Cooling column for granule., constructed i n 2001, The ...

FIMIC RAS 325 BACKFLUSH, fully automatic screenchanger, for back-flush only, so for contamination under 5%, no costs for doctor blades, no cost for laser filter., works with standard mesh, capacity related to screening mesh - with a 250 µ mesh, up to 700 kg/h, connected for test, offered totally reconditioned, with new control panel (or with drawings only), availability: 4 -5 weeks time, capacity: Max 500-600 kg/h, conditions: totally reconditioned, type: fully automatic - backflush

PLASTIMAC LAB EXTRUDER, for blown film, suitable for testing granulate, 25 mm screw diameter, 70 mm diam. die, 500 mm collection frame, 7,5 Hp drive, complete wuth supporting structure, (corona treatment+small printer can be sold separately if required), installed power - used power in work: about 60-65% : 7,5 Hp, working width: 500 mm, conditions: good

VENANZETTI COOLING TOWER, for granule. This system allows to cool the granule after extrusion with little space taken, READ CONSTRUCTORS DESCRIPTION :, Spiral elevators, The spiral elevator is the perfect solution for moving a product upwards while simultaneously treating it thermally in very small spaces., The conveyor surface is a rising helicoidal trough, or rather a spiral with a constant pitch. The width of the trough is determined by the difference between the helicoid’s external and internal diameter. The product moves upwards on the conveyor by means of an oscillating thrust movement with controlled frequency and amplitude, and the direction is inclined in order to throw the product upwards., The advantages of this solution are:, -, very small layout space;, - thermal treatments while the product is on the conveyor (heating, cooling, drying, curing, etc.);, - speed on the conve ...

GAMMA MECCANICA GM 125 COMPAC - TOTALLY RECONDITIONED, Extrusion line with pre-compactor, Nominal throughput rate 700-800 kg/h depending on the type of material and feeding rate, Average energy consumption : 0.25-0,30 kwh/kg, The line includes:, Loading belt, tunnel metal detector, compactor with dosing unit, extruder with 125 mm screw diameter, 35 L/D, nitrided screw and barrel in very good conditions., The line was working with LDPE film and PPL non woven., Previous owner never pushed the extruder over 600 kg/h, semi-automatic, non-stop hydraulic screenchanger, oleo-dynamic pack, water ring pelletizer, drying centrifuge, recycling water tank, electric cabinet for the complete management of the line, The line is offered reconditioned, See Constructors [description](.gamma-meccanica.it/en/plastic-recycling/plastic-recycli ng-compac/) for a new line like this one, availability: immediate, ...

FULLY-AUTOMATIC can be used in SEMI- AUTOMATIC mode with small different batches on and off when needed No operator (you save 1 man per shift) Low maintenance costs (no discs, just knives which can be re-sharpened) No need to reduce size, on most scraps. Suitable for film + foam + fibers, moisture and some contamination are well tolerated. Best degassing in the process, compared with other systems. Remote assistance through modem Agglomerator with barrel diam. 1500 mm.,LxWxH 4,3 x 2,3 x 5,050 mt. 570 kw , installed power abput 370 kw in work Steel cylinder case with inspection door, Side opening panel for inspection and replacing blades Power switchboard, Exchangeable inner steel liner for barrel Oleo-dynamic power station 0,75 kw with electro-valve opening, Hub temperature control system, Grease lubricated drive bearings, 0,4 kw ventilator for belt cooling with air conveyor, Steam vacuu ...

This LEISTRITZ ZSE60MAXX-48D was manufactured in 2012. A co-rotating twin-screw extruder, its designed for high-performance compounding of advanced polymer materials, including biodegradable polymers. Adaptable to various extrusion processes, its ideal for bioplastics, masterbatch production, or specialty compounding. Contact us for more information about this machine.

FIMIC RAS 325 SCRAPER, fully automatic screenchanger, screening surface 77.900 mm², Throughput: up to 600 kg/h depending on material and contamination, with scraping system, suitable for extrusion lines with capacity up to ca 500 kg/h or more depending on screening, Just disconnected, excellent conditions, constructed in 2023, immediately available, We can supply spare screens for this machine at competitive prices., Laser screen from 80 to 300 µ - Mesh from 180 to 50, Punched screen from 400 to 2.000 µ - Mesh from 40 to 10, capacity: 600 kg/h depending on material and mesh, availability: immediate, type: fully automatic

Gamma Meccanica 105 mm 40 L/D, for LDPE HDPE PP ABS PC PS, Nominal throughput rate 300-400 kg/h depending on feeding rate and material, Average energy consumption : 0,23-0,28 kWh/kg including buffer-silo feeding auger crammed feeder extruder with 105 mm screw 40 LD, n.1 vacuum degassing pump 110 kw a.c.drive with inverter non-stop hydraulic screenchanger (can be fitted with a [fully automatic screenchanger](.germanplast/listings/7610249-used-fimic-ras-325-automa tic-screenchanger)) water ring pelletizer drying centrifuge electrical cabinet user’s manuals and drawings constructed in 2000 offered RECONDITIONED, Total length 11.000 mt., Possible addition of upstream and downstream equipment., options available: fully automatic used screenchanger, capacity: 300-400 kg/h with only 0,23-0,28 kWh per kg produced, conditions: reconditioned, type: buffer silo+crammed feeder, Location: IT- 11020 ...

NGR S-GRAN 65 VHD, Constructed in 2011, nominal throughput rate 250 kg/h max, offered checked for good conditions, including:, loading conveyor belt, tunnel metal detector, densifier, extruder with 65 mm Ø screw, degassing point, hydraulic screenchanger, water ring pelletizer, drying centrifuge, extraction vent with cyclon and bag supporting structure., The line is offered reconditioned, capacity: 250 kg/h, conditions: used, checked, type: compact recycling line

GAMMAMECCANICA TANDEM SYSTEM 125 mm. 950 kg/h double screening, Throughput rate up to 600-950 kg/h ca, depending on material and feeding rate only 0,30-0,40 Kwh/kg., Line suitable for the recycling for heavily printed, high humidity and contaminated materials., High performance degassing chamber for removal of up to 10 times more gas and humidity in the melted material compared to other systems (so you save on the cost of an agglomerator), The line includes :, Loading conveyor belt, tunnel metal detector, automatic compactor, N.2 Dosing unit for masterbatches and more, 1st extruder with 125 mm. screw Ø 28 L/D, 1st degassing point, FIMIC RAS 500 fully aumatic screenchanger, control cabinet, 2nd extruder with 140 mm. screw Ø 18 L/D, 2nd degassing point, BD-PLAST non-stop screen-changer, TDA6 GM water ring pelletizer, heat exchanging unit, vibrating screen, blower, Water treatment unit ,  ...

EREMA RECYCLING LINE for PE PP, Type RM80E, constructed in 2004, including :, loading belt with metal detector, compactor, extruder 85 mm screw Ø, non-stop hhydraulic screenchanger, water ring pelletizer, sacking station, electric cabinet, availability: immediate, conditions: stored

CMG-MAM BLOWN FILM EXTRUDER for LDPE, extruder with screw diam. 80 mm., Production rate about 150 kg/h, die diam. 150 mm. on rotating head, haul off unit width 1.200 mm., corona treatment, winder mm.1.200, max reel diam. 1.200 mm., min/max film width 600/1200 mm

GAMMAMECCANICA Compac 125 mm. Construction year 1998 Including Loading conveyor belt, Metal detector, Compactor with driven haul off for reels, master dosing unit Engin Plast, Extruder 125 mm diam. 36 L/D with degassing pump d.c. Ansaldo drive 197 kW, Total installed power 501 kW motor, BD plast non-stop screenchanger diam. 200 mm, hydraulic power station, water ring pelletizer M 8500, Electrical cabinet, Type of machine: GAMMAMECCANICA PLASTIC RECYCLING LINE 125 mm.

PRT RECYCLING EXTRUDER for PE PP PC PS ABS, Extruder with 85 mm screw, 30 L/D, Constructed in year 2000 - very few hours of work, NEW Crammed feeder new 2023 FF85VE, 60 kw Siemens drive 2.200 rpm, Average throughput rate 200 kg/h, depending on materials and feeding rate, Total heaters power 38,6 kw, N.1 vacuum degassing pump, Manual screenchanger, NEW 2023 Water ring pelletizer WF150, Drying centrifuge, Total installed power cutting group 14 kw, Vibro classifier, Total weight about 3 Tonnes, excellent conditions, MATERIALS: PE PP PC PS ABS PS, capacity: ca.200 kg/h depending on materials and feeding rate, availability: ready-to-go

FIMIC RAS 325 SCRAPER, fully automatic screenchanger, screening surface 77.900 mm², Throughput: up to 600 kg/h depending on material and contamination, with scraping system, suitable for extrusion lines with capacity up to ca 500 kg/h or more depending on screening, Just disconnected, excellent conditions, constructed in 2017, immediately available, We can supply spare screens for this machine at competitive prices., Laser screen from 80 to 300 µ - Mesh from 180 to 50, Punched screen from 400 to 2.000 µ - Mesh from 40 to 10, availability: immediate, type: fully automatic

CINCINNATI CMT 35 APC, twin conical screw extruder, 2x35 mm screws, Control panel, 7,1 kw drive, 57.000 working hours, installed power - used power in work: about 60-65% : 7,1, type: PVC

TECNOVA RECYCLING EXTRUDER for BIO - PE PP ABS PC PS, Barrel with 90 mm screw diam. 37 L/D, Crammed feeding unit, Is working with BIO at 70 rpm yielding 270 kg/h, with PE at 100 rpm yelds 120 kg/h, N.1 degassing point, hydraulic screenchanger, water ring pelletizer from Gamma Meccanica, drying centrifuge, rotating classifier, electric cabinet for omplete management of the line, availability: 4 weeks for reconditioning or 1 week for AS IS, capacity: 120-270 kg/h, conditions: reconditioned, type: 90 mm. crammed feeder for light scraps

PVC PROFILE EXTRUSION LINE EVC BRAND, single screw extruder with 60 mm 28 LD, constructed in 1998, for 180 mm max width, 44 kw drive, control panel, Calibrating desk 3,7 m.long with 1 x 9 kw.pump, Caterpillar pull off unit, 180 mm wide, saw, 6,0 mt.long discharging table.

CINCINNATI-MILACRON TWIN SCREW EXTRUDER, for PVC profiles, extruder with 2 x 45 mm conical screws, average production 100 kg/h, 14 kw drive, for profiles with max width 250 mm., calibration desk with 2 pumps x 5 kw, caterpillar pull off unit, contact length 1500 mm, width250 mm., planetary saw, collection table, installed power - used power in work: about 60-65% : 14, capacity: 100 kg/h ca, screws: 45 mm. conical

TWIN SCREW EXTRUSION LINE, Top Italian Constructor, for PVC both soft and rigid, max infeed 10-12 mm size, forced feeding hopper, dosing unit, 2 parallel, counter-rotating screws 118 mm diam. 25 L/D, pressure control;, nitrided steel barrel with degassing vent 2,2 kW, Barrel heating bands kW 76,00, Extruder cooling barrel motors power 4x 0,37 kw, n.7 Heating zones, Extruder a.c. motor 120 KW, Extruder tot power 205 kw, Extruder average absorbed power 105,00 kW, Extruder rpm 8-45, Lubrication pump 1,50 kW, Electric cabinet with inverter and modem for remote diagnosis, semi automatic screenchanger for PVC, granulating head, die face dry pelletizer, cooling unit, Installation and start up included (boarding and travel costs on Buyers charge), Total installed power: 205 kw - 105 kw average in use

UNION SINGLE SCREW EXTRUDER, barrel with 150 mm Ø screw, 40 L/D, electric cabinet, degassing system, nominal throughput rate ca.700 kg/h, missing of screenchanger - available semi-automatic on separate offer, missing of cutting unit - possible addition of strand/water ring/underwater on separate offer, This is an evergreen sturdy extruder

PREALPINA EXTRUDER 130 mm., For PE PP ABS PS PC PS, nominal throughput rate 500-600 kg/h depending on material and feeding rate, 200 kw. d.c. drive and starter (new 2019), Electric cabinet (in need of some refurbishing), CE compliance, users manual, electrical drawings, crammed feeding unit, Barrel with screw diam.130 mm.35 L/D, N.1 vacuum degassing pump, Constructed 1996,, offered : as is where is, good working conditions, installed power - used power in work: about 60-65% : 200, conditions: AS IS OR RECONDITIONED TO YOUR BUDGET EXTENT, options available: AS IS or RECONDITIONED, capacity: 500-600 kg/h nominal capacity

PRT EXTRUDER for PE PP PC PS ABS, Extruder with 85 mm screw, 30 L/D, 60 kw d.c.Siemens drive 2.200 rpm, Average throughput rate 200 kg/h, depending on materials and feeding rate, Total heaters power 38,6 kw, N.1 vacuum degassing pump, manual screenchanger 120 mm, water ring pelletizer, electric cabinet to be reconditioned - drawings available, New in 1999, availability: READY, capacity: nominal capacity 200 kg/h, conditions: as is where is, installed power - used power in work: about 60-65% : 100 kw ca

CENTRIFUGAL DRYER for pellets (to go with an existing pelletizer), for a 350/400 kg/h capacity of PE PP ABS PS PC flakes, made of sturdy AISI304 stainless steel with vertical axis, driven by a 2.2 kW 3 Ph.asynchronous motor,, complete with soundproofed discharge cyclone, stainless steel tank for water recovery and recycling, 1.1 kW water ump,, equipped with drainage for overflowing, HEAT EXCHANGER GROUP, made of painted carbon steel, internal copper tube bundle, with removable head to facilitate cleaning, fixed to the tank using brackets, float with water replenishment valve, Electrical board of machine wiring, Users manual, CE compliance, installed power - used power in work: about 60-65% : 2.2, conditions: new machine, type: for granulate - this machine goes after the pelletizer, capacity: 300-450 kg/h
