Surface Grinding Machines used for sale (66)

Code 61047 Description Hydr. Surface grinding machine Make ALPA Model RT 1000 Serial No. 53377 Year 1985 Tablesize 1200 x 300 mm Table grinding size L x B x H 1000 x 350 x 400 mm Base size L x B 1000 x 300 mm Speed table movement 3 – 40 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 600 mm Grinding stone diam. Stone x Wide x Taper Ø 400 x 50 x 127 mm Spindel power 8,8 kW Spindel speed 1460 rpm Weight 3000 kgs Motor power 8,8 kW – 380 Volt Accessoiries Magneticplate 1000 x 300 mm Coolant Grinding stones, etc. Condition Machine is in normal condition

General Description Hydraulic precision surface grinding machine manufactured by BLOHM, model HFS 204. Designed for high-precision surface grinding of tool steel, hardened components and precision mechanical parts. The machine is equipped with a hydraulic reciprocating table, electromagnetic chuck and automatic profile dressing system. Technical Details Manufacturer: BLOHM Model: HFS 204 Machine type: Hydraulic precision surface grinder Hydraulic reciprocating table Walker-Hagou electromagnetic chuck Diaform wheel/profile dressing attachment Heidenhain digital readouts (Y and Z axes) Coolant system Separate hydraulic power unit Dust extraction / filtration unit Wheel balancing flange Condition Used industrial condition. The machine appears complete with hydraulic table, electromagnetic chuck, Diaform dresser, Heidenhain digital readouts, coolant system, hydraulic power unit and dust ex ...

Code 4925 Description Surface grinding machine Make ELB Model OPTIMAL 1 VA II Serial No. 180730982 Year 1982 Tablesize 900 x 250 mm Table grinding size L x B x H 600 x 300 x 250 mm Magnetical plate size L x B 500 x 250 mm Speed table movement 1 – 25 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 500 mm Grinding stone dim. Stone x Wide x Taper 300 x 50 x Ø 75 mm Spindel power 3,7 and 4,5 kW Spindel speed 1400 and 2800 rpm Weight 3500 kgs Motor power 3,7 and 4,5 kW – 380 Volt Accessoiries Elec. Magneticplate 500 x 250 mm Coolant with paperfilter 2 x DRO Grinding stones, etc. Condition Machine is in good condition

General Description Horizontal spindle surface grinding machine, model FG251, designed for precision grinding of flat surfaces on tool steel, hardened components and precision mechanical parts. The machine is equipped with a hydraulic reciprocating table and automatic table reversing for efficient surface grinding operations. Technical Details Model: FG251 Machine type: Horizontal spindle surface grinding machine Horizontal grinding spindle Vertical wheel-head feed Hydraulic longitudinal table movement Manual cross feed Automatic table reversing Speed/feed selector panel Lubrication system with original lubrication diagram Integrated hydraulic and electrical cabinet in the rear column Approximate table travel: 700–900 mm Approximate table width: 200–250 mm Condition Used industrial condition. The machine appears complete with grinding spindle, hydraulic table drive, wheel-head feed ...

Code 5976 Description Hydr. Surface grinding machine Make DANOBAT Type RT – 1200 Machine No. 565 Manufacturing date 1989 ( 1990 in use ) Table size 1400 x 700 mm Grinding dimensions L x W x H 1200 x 750 ( 800 ) x 800 mm Magnetic plate size L x W 1000 x 600 mm Table speed movement 1 - 25 m/min. Max. distance table surface – centre grinding wheel 1000 mm Speeds cross 0,1 - 5 m/min. Vertical movement 0,005 – 0,05 mm Spindle rotation 1500 rpm Spindle power 7,5 kW Grinding wheel size Ø 400 x 50 ( 100 ) x Ø 127 mm Weight 8.500 kgs Total power 12 kW – 380 Volt Accessoiries Electro magnetic plate 1000 x 600 mm from Tecnomagnete Coolant Pendel control Condition Machine is in good condition

Auction-ID: A1-48474-92

Code 0736 Description hydraulic surface grinding machine Make ORION ( HAHN & KOLB ) Model 308 Serial No. 5128 Year 1978 Tablesize 1520 x 300 mm Table grinding size L x B x H 800 x 350 x 500 mm Magnetical plate size L x B 800 x 300 mm Speed table movement 2 - 30 m/min. Rapide vertical movement 0,4 m/min Max. distance table – centre grinding wheel 640 mm Max Grindingstone diameter x Wide x Taper 300 x 50 x Ø 76 mm Spindel power 5,5 and 7,5 kW Spindel speed 1440 and 2880 rpm Weight 3500 kgs Motor power 5,5 / 7,5 kW – 380 Volt Accessoiries Elec. Magneticplate 800 x 300 mm Coolant Condition Machine is in good condition

General Description Vertical spindle rotary surface grinding machine designed for precision grinding of large flat components. The machine is equipped with a rotary electromagnetic chuck, hydraulic controls and a vertical grinding spindle for efficient surface grinding operations. Technical Details Machine type: Vertical spindle rotary surface grinder Rotary electromagnetic chuck Chuck diameter: 800 mm Vertical grinding spindle Wheelhead Hydraulic controls Operator control panel Electrical control cabinet Condition Used industrial condition. The machine appears complete with rotary electromagnetic chuck, grinding wheelhead, hydraulic controls and electrical cabinet. Operational status, spindle condition and grinding accuracy have not been tested. Auction-ID: A7-49124-45

Surface grinding machine. Magnetic chuck of 550x250mm. Table travel: 700mm. Grind surface area: 600x350mm. Max. height: 375mm. Cross travel: 300mm. Wheel: 350x127x50 / 300x127x100 Weight: 2900Kg.

General Description Hydraulic precision surface grinding machine manufactured by BLOHM, model HFS 204. Designed for precision surface grinding of tool steel, hardened components and precision mechanical parts. The machine is equipped with a hydraulic reciprocating table, automatic downfeed and Diaform wheel dressing system. Technical Details Manufacturer: BLOHM Model: HFS 204 Machine type: Hydraulic precision surface grinder Hydraulic reciprocating table BLOHM-Digit controller Vertical grinding spindle Automatic downfeed Diaform wheel dresser mounted on the wheelhead Separate electrical control cabinet Hydraulic power unit Coolant system Condition Used industrial condition. The machine appears complete with hydraulic table, BLOHM-Digit controller, vertical grinding spindle, Diaform wheel dresser, hydraulic power unit, coolant system and separate electrical cabinet. Operational status,  ...

Equipped with 3-jaw chuck ø 130mm and magnetic clamping plate ø 120mm Auction-ID: A1-48457-189

Table dimensions: 1800 x 550 mm, Magnetic table: SELTER SN 5536, Dimensions of the magnetic table: 1210 x 610 mm, Grinding dimensions: 1200 x 550 mm, Maximum transverse movement: 500 mm approx., Maximum grinding weight: 1200 Kg

Surface grinding machine, Asyst PNC100 CNC [ELB], 600200, wheel 300 mm 40, The machine is in our warehouse in Gussago BS.

Surface Grinding Machine FAVRETTO MC130, 1300x700 mm, magnetic plate, sistem Digit Plus FAVRETTO, Information about technical data are not binding., Machine available subject to prior sale., Max working dimensions: 1500x750 mm, Working table size: 1300x500 mm, Longitudinal travel x axis: 1640mm, Cross travel y axis: 650 mm, Clearance between worktable and spindle axis: 850 mm, Feed rate x axis: 1 - 40 m/1, Feed rate y axes: 0 - 2000 m m/1, Wheel speed: Stepless by Variable speed drive AC, Wheel dimension: 400x152,4x100 mm, Spindle motor power: 15Kw, Nc: Digit FAVRETTO, Weight: 8.000 Kg, Accessories: Electro permanent magnetic plate 1300x500 mm, coolant tank with paper filter
