High Speed Machining Centres (HSC) used for sale (9)

CHIRON FZ 08K S Magnum HSP High-Speed CNC Machining Center TECHNICAL FEATURES: Year: 2007 NC Type: FANUC 18i-MB5 Number of axes: 7 X-axis travel: 450 [mm] Y-axis travel: 270 [mm] Z-axis travel: 310 [mm] X, Y and Z fast travel speed: 75000 [mm/min] Maximum diameter in bar turning spindle: 32 [mm] A-axis angular travel: 360 [°] A-axis indexing accuracy: 0.001 [°] B-axis angular travel: -20° / +115 [°] B-axis indexing accuracy: 0.001 [°] Pin Attachment: HSK40 Maximum speed Spindle: 30000 [rpm] Number of tool magazine stations: 40 Installed power: 17 [kVA] Supply voltage: 400 [V] Dimensions: 1500 x 2600 x 2300 [mm] Weight: 3400 [Kg] EQUIPMENT INCLUDED: x1 RENISHAW probe type TS27R x1 Spindle Cooling Unit x1 watering tray x1 unit for 6th side machining x1SCHUNK gripping system x84 HSK40 Type Tool Holder x14 Collet Type F35 x1 Electrical Cabinet Air C ...

x-travel: 600 mmy-travel: 450 mmz-travel: 300 mmCNC-control: Roeders RMS6 table-size: 700 x 550 mmmax. table load: 800 kgspindle taper ISO: spindle turning speed range: 42.000 U/minfeed stepless: 0 - 30.000 mm/minrapid traverse: 30 m/mindrive capacity - spindle motor: 14 kWtool change unit: Pick-up 18 Pos.voltage: 400 Vtotal power requirement: 20 kVAweight of the machine ca.: 5,2 tdimensions of the machine ca.: 3,00 x 2,30 x 2,70 m- Serial No.: 88231-83- HSC spindle Fischer MFW1230/42- Dust extraction systemThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The machine is in good technical condition, after prior agreement it is possible to test it. Control system: Siemens Sinumerick 840D Total hours: 12,058 h Operating hours: 5,039 h Worktable length: 1200 mm Worktable width: 5 Spindle rotation: 8000 1/min Number of axes: 3 X-axis travel: 1035 mm Y-axis travel: 560 mm Z-axis travel: 510 mm

Five axis machining centre CME QUICK 200 CNC - 2000x1000x1300 mm, 18.000 rpm, CNC SELCA 4045PD, Information about technical data are not binding., Machine available subject to prior sale., Working table size: 2100x850 mm, Longitudinal travel x axis: 2100 mm, Cross travel y axis: 1000 mm, Vertical travel z axis: 1300 mm, Cnc: SELCA 4045 PD, Spindle motor power: 26 Kw, Spindle speed: 18000 rpm, Spindle taper type: HSK 63, Automatic tools change nr.: 20, Approx net weight: 18.000 kg, Accessories: Continuos round table 800 mm, coolant thrugh spindle 15 bar, electronic handwheel SELCA SILBOX 2, chip conveyor

The machine is in good technical condition, testing is possible by prior arrangement. X-axis travel distance:1,035 mm Y-axis travel:560 mm Z-axis travel:510 mm X-axis rapid traverse:30 m/min Y-axis rapid traverse:30 m/min Z-axis rapid traverse:30 m Y-axis feed length:560 mm Z-axis feed length:510 mm X-axis feed:30 m/min Y-axis feed speed:30 m/min Z-axis feed speed:30 m/min Rated (apparent) power:17 kVA Torque:83 Nm Controller manufacturer: Sie 137 mm Overall width:3,355 mm Table width:560 mm Table length:1,200 mm Table load:1,000 kg Overall weight:4,250 kg Spindle speed (min.):20 rpm Maximum spindle speed:8 000 rpm Tool operation:20 Tool length:300 mm Tool diameter:80 mm Tool weight:6,000 g Equipment:documentation / manual, chip conveyor, infinitely adjustable speed

The machine is in good technical condition, testing is possible by prior arrangement. X-axis travel distance:3,200 mm Y-axis travel:1,400 mm Z-axis travel:900 mm X-axis rapid traverse:16 m/min Y-axis rapid traverse:20 m/min Rapid traverse: m/min Y-axis feed rate:10 m/min Z-axis feed rate:10 m/min Nominal (apparent) power:50 kVA Controller manufacturer:Fanuc α 30/3000i 7.0 Workpiece length (max.):4,000 mm Workpiece width (max.): max. 000 kg Total height: 4,500 mm Total length: 8,130 mm Total width: 4,150 mm Table width: 1,200 mm Table length: 3,200 mm Table load: 8,000 kg Total weight: 17,000 kg Maximum spindle speed: 8,000 rpm Diameter: 50 mm Tool length: 350 mm Tool diameter: 127 mm Tool weight: 20 g Equipment: documentation / manual, chip conveyor, infinitely adjustable speed

Key data: 300 mm, 1130 mm, 300 mm

4 Spindle High Speed Train Milling Machine, ANGER, HCP 10/5, 2005 Control : NUM, very few operating hours. Methods: X-300, Y-1130, Z-300, - 4-axis +/- 180 degrees 4 high frequency spindles : Precise 60000 / 160000 / 18000 / 16000 rpm , rpm Tool holder : Collets depending on the spindle Chip conveyor, ATC, recooling unit, external measuring system Renishaw Power consumption 41 kw

CHIRON FZ08 KS Magnum High Speed Plus (HSP) High-Speed Machining Center (HSP) TECHNICAL FEATURES: Year: 2006 NC Type: FANUC 18i-MB5 Number of axes: 7 X-axis travel: 450 [mm] Y-axis travel: 270 [mm] Z-axis travel: 310 [mm] X, Y and Z fast travel speed: 75000 [mm/min] Maximum diameter in bar turning spindle: 32 [mm] Maximum speed Turning spindle: 8000 [rpm] Maximum power turning spindle: 12 [kW] A-axis angular travel: 360 [°] A-axis indexing accuracy: 0.001 [°] B-axis angular travel: -20° / +115 [°] B-axis indexing accuracy: 0.001 [°] Pin Attachment: HSK40 Maximum speed Spindle: 30000 [rpm] Number of tool magazine stations: 40 Turning part by robot (6th side machining): Yes RS232 Port: Yes Installed power: 17 [kVA] Supply voltage: 400 [V] Operating hours: 9911 [h] Dimensions: 1500 x 2600 x 2300 [mm] Weight: 3400 [Kg] EQUIPMENT INCLUDED: x1 RENISHAW p ...

Key data: 500 mm, 400 mm, 300 mm

High Speed Cutting - Special machining center with FANUC® nano-contour technology for the fashion accessories and jewelry industry and similar industrial processes where the greatest possible precision is required, such as dental technology – medical technology – mold making. For the processing of precious metal alloys, as well as aluminium – copper – brass – bronze and similar non-ferrous metals. The raw material to be processed is forged – cast or rolled flat bars up to 150 mm wide and maximum 500 mm long, which are stored in a blank magazine. Automatic loading of flat bars (raw or raw material), material thickness from 1 mm to 15 mm – automatic unloading of finished flat bars. Milling spindle drive power 8 kW Milling spindle speeds up to 36,000 rpm Tool holder HSK40 Tool magazine for 24 pieces of tools - Automatic pneumatic flat bar clamping - Automatic ...
