High Precision Turning Machines (Lathes) used for sale (8)

Klaaßen SDM15-5 turning machining centre, The top lathe we offer has the following in the basic configuration Technical parameters: ▪ SDM 4-5 CNC 4-Panel Bed Precision Lathe - Z-travel (slide longitudinal)= 5,000 mm (6,000 with TAE3) X-travel (face slide transverse)= 1,000 mm Y-axis (vertical movement)= 350 mm Maximum workpiece Ø = 1,500 mm Circulation diameter over face slide = 1,500 mm - Center width = 4,500 mm (5,500 with TAE3) ▪ CNC machine designed as a 4-lane tip lathe with full drive-over of the Bezels and superstructures - - - Cross slides and face slides restrict the diameter range by lateral arrangement on the lathe bed. As a result, there is no accompanying Diameter restriction above the face slide/tool carrier. Cross slide unit can be fully attached to the steady rests, HSSL and tailstock. This significantly reduces t ...

Manufacturer: RAMOType: Conventional precision parallel latheEquipment: 3-jaw chuck, longitudinal and transverse carriage, tool turret, tailstock, gearbox and feeds, coolant system. Threads: visible adjustment tables for metric and Whitworth pitches. Remarks: machine on rack, manual controls by handwheels and levers. Visible condition of use. Auction-ID: A1-50714-4308

Tip height 102 mm Top width 450 mm Leit.-/ spindle Collets W20 available Rotational speed: approx. 210 3000 rpm Reduction gear Links.-right rotation 2-stage drive L x W x H: CA. 1760 x 595 x 1230 mm Weight: approx. 650 kg

Tip height: 130 mm Top width: 450 mm Rotational speed: approx. 55-3000 rpm Pneumatic clamping system Spindle nose: W 25 Div. W25 collets available Div. holder available BERGER LAHR axis motors Combitec EIP E-500 control Manual control available Coolant system available Machine lamp available Machine feet available Dimension (Lxwxh): approx. 1400 x 560 x 1230 mm Weight: approx. 550 kg The machine is located in a clean good condition!

Tip height: 102 mm Top width: 450 mm Spindle bore: 32 mm Reduction gear Links.-right rotation 2-stage drive Vario speed: 270-3000 rpm Knee circuit Turning diameter over bed: 200 mm Spindle nose: W 20 Tailstock Quill: MK 2 Dimension (Lxwxh): approx. 140 x 56 x 123 cm Weight: approx. 550 kg Accessories available Manual available The machine is located in a clean good condition!
