290 DMG MORI used machine for sale

Control CNC: HEIDENHAIN iTNC530 Axes X-axis travel mm: 200 Y-axis travel mm: 220 Z-axis travel mm: 280 C-axis degrees: 360º A-axis degrees: -15º max.130º Work Table Table dimensions mm: ø200 Maximum workpiece weight kg: 15 Spindle Spindle speed rpm: 42.000 Cooling Cooling through the spindle bar: 40 Tool System Tool holder: HSK-E32 Tool magazine slots: 60 Max. tool diameter mm: ø50 Max. tool length mm: 200 Chip-to-chip time s: 10 Equipment Automation LM100 (EROWA ITS72, 5 levels of 9 positions); 10 kg maximum manipulation Electronic handwheel Chip conveyor Infrared probe High-pressure pump NC rotary tilting table Rated power kVA: 40

Key data: 700 mm, 420 mm, 380 mm

Specifications: Manufacturer: DMG MORI Type: Milltap 700 Year of Make: 2016 Control: Siemens 840D SL Travel: X 700 mm Y 420 mm Z 380 mm Switch-on hours: 32,722 h Program runtime: 24,284 h Spindle running time: 12,539 h Spindle Speed: 10,000 rpm Tool holder: DIN30 NC swivel rotary table Table load: max. 100 kg Swivel range A: -100/+120° Rotation range C: 360° Dimensions and weight Dimensions: 2,500 mm x 1,650 mm x 2,950 mm Weight: approx. 3,400 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Tool Changer Conveyor IKZ Internal tool cooling with high-pressure system Preparation for automation

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with HEIDENHAIN TNC7 Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® toolsDrive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63Toolchanger with set up station for tool loadingNumber of tools 30Clamping System HSK-A 63IoTconnectorIoTconnector The IoTconnector allows the use of online services of DMG MORI (e.g. NETservice)NETserviceNETservice Qualified support by Internet-based remote diagnosticsMessenger V4Messenger V4 Clear presentation of the machine live status.Service AgentService Agent Overview of  ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 100 mm - B-axis ±110° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 5 bar; 20l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor - USB interface, Ethernet interface; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length750 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range- 5000 rpmDrive power (40% DC)32 kWMax. torque (40% DC)360 NmC-Axis Speed-5000 rpmTorque of C-Axis (holding torque)280 NmT ...

DMG MORI NLX2500/700 with tool drive and C-axis Universal lathe with 3-axis Turning length 700 mm Main spindle with integrated motor spindle ISM (rod diameter in mm) Hydr. Clamping devices, clamping cylinders, chucks C-axis with hydr. Spindle brake 10-speed BMT star revolver 10-speed tool drive NC tailstock CELOS with Mitsubishi control M730UM

Key data: 700 mm, 420 mm, 380 mm

Specifications: Manufacturer: DMG MORI Type: Milltap 700 Year of Make: 2014 Control: Siemens 840D SL Travel: X 700 mm Y 420 mm Z 380 mm Machine hours: 52,616 h Spindle Speed: 10,000 rpm Tool holder: DIN30 NC swivel rotary table Table load: max. 100 kg Swivel range A: -100/+120° Rotation range C: 360° Dimensions and weight Dimensions: 2,500 mm x 1,650 mm x 2,950 mm Weight: approx. 3,400 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Tool Changer Conveyor IKZ Internal tool cooling with high-pressure system Preparation for automation

Travel X/Y/Z: 450mm/580mm/400mm, swivel range A/B: -110°/+10°, rotation range C: 360°, table dimensions X/Y: 400mm/400mm, tool positions: 30, tool holder: HSK-E50, spindle speed: 42000rpm, max. workpiece weight: 200kg, feed: 80m/min, max. tool length/diameter: 250mm/80mm. Machine dimensions X/Y/Z: approx. 3250mm/2950mm/2900mm, weight: approx. 9500kg, control: Heidenhain iTNC530. Documentation available. An on-site inspection is possible. The machine is located in China.

GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Work spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmWorking areaSwing diameter over guide ways700 mmTurning diameter410 mmTransverse stroke300 mmLongitudinal stroke850 mmClamping chuck diameter max.315 mmMax. Turning Length800 mmBar diameter max.65 mmMain drive 1Drive power (100% DC)33 kWSpeed range20 - 4000 rpmTorque (100% DC)580 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-4000 rpmPower max. (40% DC)11,3 kWFloor space/WeightDimensions (L x W x H)3,99 x 2,69 x 1,99 mWeight approx.6500 KgTechnologie cycle alternating speedTechnology cycle for the  ...

CNC controller: Siemens 840D sl with CELOS ERGOline Capacity X-axis travel mm: 480 (–10) Y-axis travel mm: ±100 Z-axis travel mm: 845 B-axis travel mm: ±110° (0,001º) C-axis: 360º (0,001º) Turning length mm: 800 Max. turning diameter mm: ø: 500 Distance between spindle centers mm: 1.020 Turn-mill spindle Speed spindle rpm: 12.000 Drive power kW: 22 / 19 Tool magazine Magazine places: 24 Tool holder: HSK-A63 Tool length max. mm: 300 Tool diameter max. mm: 125 Tool weight max kg: 7 Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 25 / 34 (100 / 40%) Spindle bore mm: 67 Maximun torque Nm: 380 / 280 Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 20 / 27 (100 % / 40%) Spindle bore mm: 52 Maximun torque Nm: 170 Counter spindle travel mm: 800 Coolant system Tank capacity liter: 600 L High-pre ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmMax. Turning Length1200 mmTurning diameter500 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle diametre on front bearing130 mmSpindle bore87 mmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment8 ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmBar diameter max.65 mmMax. Turning Length1200 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperCapto C6 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22 kWTorque ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.75 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmMax. Turning Length1200 mmTurning diameter500 mmBar diameter max.65 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

turning diameter: max. 356 mm turning length: 705 mm control: M730 UM Mapps CELOS greates pass round over bed: 920 mm Swing dia. over traverse guideway: 742 mm Main spindle:: turning speed range - main spindle: 4.000 min/-1 power capacity - main spindel: 18,5 / 15 kW spindle nose: JIS A2-8 spindle bore: 80 (91) mm C-Axis: 0,001 ° Subspindel:: Spindle speed range subspindle: 6.000 min/-1 power capacity - Sub spindle: 11 / 7,5 kW spindle bore: 43 mm C-Axis: 0,001 ° axis stroke:: x-travel: 260 mm z-travel: 795 mm Y - Axis: +/-50 mm rapid traverse ( X / Y / Z ): 30 / 10 / 30 m/min turret:: number of toolpositions: 12 pos. Schank height for square tool: 25 mm Drill shank diameter: 50 mm turret change time: 0,27 sec. Driven Tool Positions:: Spindle speed - driven tools: max. 10.000 min -1 power capacity - driven tools: 5,5 / 4,2 kW total power requirement: 41 kVA weight of the machine c ...

GeneralVertical Machining centre; Control: CELOS X with HEIDENHAIN TNC7 CharacteristicsTable surface1400 x 600 mmTool Magazine with30 PositionsMovement X / Y / Z1100/600/510 mmRapid feed X / Y / Z42/42/42 m/minMotor spindle speedMASTER® 20.000 rpmMotor spindle speedMASTER® 20.000 rpm AC main drive: 35/25 kW (40/100% ED) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Air Coolant Internal (through spindle centre) switchable via M-FunctionAir Coolant Internal (through spindle centre) switchable via M-Function

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaTurning diameter500 mmSwing diameter over guide ways500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% ...

x-travel: 1800 mm y-travel: 700 mm z-travel: 700 mm control: Heidenhain iTNC 530 table surface area: 2100 x 700 mm table load: 1500 kg turning speeds: 20 - 18000 U/min taper ISO: SK 40 spindle motor: 35 / 25 kW rapid traverse: 40 m/min tool change unit: 60 -fach dimensions of the machine ca.: 5,5 x 3,5 x 2,7 m total power requirement: kW weight of the machine ca.: 14 t - Control Heidenhain iTNC 530 - 5-axis - Fixed table with integrated rotary table dia. 750mm (500kg) - IKZ 40 bar - Tool changer 60-fold (SK 40) - Milling head with B-axis - Chip conveyor - Spray gun - 3d Quick Set - BLUM laser measuring system - Direct distance measuring system - 2 Rotary Clean Windows - The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV Multi-Touch CharacteristicsTable surface900 x 600 mmTool Magazine with30 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemTouch Probe Heidenhain TS 460Touch Probe HEIDENHAIN for workpiece measuring Option includes: - TS 460 Touch probe with optical signal transmission - measuring cycles - calibration ring - case for equipmentTouch probe Heidenhain TT160Touch Probe HEIDENHAIN for tool length and diameter measurement Option includes: - TT160 probe for tool measurement - measuring cycles with tool breakage monitoring - calibration tool Note: Additionally to ...

CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z42/42/42 m/minGeneralVertical Machining centre; Control: DMG MORI ERGOline IV HEIDENHAIN TNC 7 Spindle speed range 20 to 12.000 rpmSpindle speed range 20 to 12.000 rpm AC main drive:13/9 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 80 barProduction Package 80 bar Option includes: - Internal coolant supply 80 bar - Tank capacity: 600l with papertype filter - Chip conveyor (scraper type) with tank capacity: 200 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - EActive cooling systemActive cooling system for selected mechanical components in order to increase machine thermal stabilityAir coola ...

GeneralUniversal Milling Centre - Direct Measuring System X, Y, Z inclusive air purge for measuring system - Coolant Air-Blast Changeover external switchable via M-Function - DMG MORI NETservice - RMS device (Relocation Machine Security); Control: DMG MORI ERGOline IV Multi-Touch CharacteristicsMovement X / Y / Z800/600/510 mmType of magazineChain Tool Magazine with60 PositionsClamping SystemDIN 69872 Spindle taperSK 40 DIN 69871 Drive power (40% DC)20 kWDrive power (100% DC)14,5 kWSpeed max.12000 rpmRapid feed X / Y / Z42/42/42 m/minTable surfaceØ 800 x 620 mmMovement C-Axis360 degreeMovement B-Axis(-15/+110) degreeType of gripperDouble gripper Production Package 80 bar with chip conveyorProduction Package 80 bar Option includes: - Internal coolant supply 80 bar - Tank capacity: 600l with papertype filter - Chip conveyor (scraper type) with tank capacity: 205 l (left) - Bed and ATC ar ...

GeneralVertical Machining Centre - Direct Measuring System X, Y, Z - Coolant air-blast changeover external switchable via M-Function; - Thermal compensation - DMG MORI NETservice; Control: DMG MORI ERGOline X Multi-Touch control Siemens CharacteristicsMovement X / Y / Z800/600/510 mmType of magazineChain Tool Magazine with30 PositionsClamping SystemDIN 69872 Spindle taperSK 40 DIN 69871 Drive power (40% DC)20 kWDrive power (100% DC)14,5 kWSpeed max.15000 rpmRapid feed X / Y / Z42/42/42 m/minTable surfaceØ 800 x 620 mmMovement C-Axis360 degreeMovement B-Axis(-15/+110) degreeType of gripperDouble gripper Production Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar; - Chip conveyor (scraper type) with tank capacity: 205 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electr ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataRapid traverse longitudinal/transverse/vertical40/40/40 m/minFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Tool magazine, chain vert., 60 pocketsTool magazine Vertical chain magazine basic with 60 magazine pockets SK 40 or optionally chosen spindle taper ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataRapid traverse longitudinal/transverse/vertical40/40/40 m/minFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Cross650 mmLongitudinal735 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Sl ...

GeneralHighly productive compact machining centres; Control: Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical1-60000/1-60000/1-60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross420 mmVertical380 mmMiscellaneousClamping SystemMAS 403 - 45° Floor space/WeightDimensions (L x W x H)1,65 x 2,34 x 2,5 (1,65 x 2,95 x 2,55) mWeight approx.4100 KgSpindle speed up to 24,000 r.p.m. BT30Spindle 24,000rpm with tool taper BT30 JIS B 6339 (MAS 403-45°) AC-Motor 20 / 4 KW (max. / 100% ED) Watercooling Spindle and Spindle motor via heat exchanger (fan)TableTable surface 840 x 420 mmMaximum load (table centre) 300 KgSlot width 14 mmNumber of Slots 2Clamping grid M 12, 100 x 100 mmTool clamping for BBT 30 (Big+)Tool taper BBT 30 - Big+ Pull stud MAS 403 - 45°Tool magazine 25 placesTool magazine 25 places (suita ...

Axes: 5, travel X/Y/Z: 400mm/400mm/375mm, spindle speed: 18000rpm, power: 35kW, tool holder: HSK-A63, tool positions: 60, rapid traverse: 30m/min, table dimensions X/Y: 480mm/480mm, max. workpiece weight: 250kg, machine weight: approx. 8150kg, operating hours: approx. 50950h, spindle hours: approx. 20200h. The lifting and swivel unit of the pallet changer are defective. Documentation available. An on-site inspection is possible.

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic HandwheelSoftware option - DXF ImportSoftware Option - DXF Import Possibility to open DXF files directly on the controller in order to extract contour and import it to the program.

x-travel: 600 mm y-travel: 560 mm z-travel: 560 mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A chip conveyor for DMG Mori machines is available. Height: 1650mm, width: 1870mm, length: 3560mm, weight: approx. 600kg. Without pump and skimmer. Approximately half of the rails for further transportation are defective. Documentation available. On-site inspection is possible.
