alzmetall boring mills and machining centers used for sale

Multi-stand drill Prior sale reserved - errors possible Internal Reference Number: D-1143-1

CNC Milling-Turning Center Alzmetall GS 600/5-FDT Milling-turning machine Commissioning 05/2021 At call! Heidenhain TNC640 Spindle HSK-T 63 / 18,000 rpm Balancing system (only for FDT) Kinematics Opt Electr. Handwheel Skiving (only for FDT) Dyn. Collision Monitoring Heidenhain DNC Heidenhain Remote Desktop 3D model of the machine Advanced tool management Operating mode 3 Probe Heidenhain Tool Measurement Blum Laser Signal tower on the machine 18,000 spindle HSK-T 63 Continuous air through the spindle (with lubrication interval) Continuous air from the outside 76 mm tool magazine Spray gun Chip flushing of the working area (recommended for Al) Emulsion Mist Extraction Production package C, 80 bar, hinged belt conveyor Machine Interior Trim Remote diagnostics The options list is complete! No interest in dealer enquiries! No separate dealer price! WB me ...

CNC Milling-Turning Center Alzmetall GS 600/5-FDT Milling-turning machine Commissioning 03/2019 At call! Heidenhain TNC640 Spindle HSK-T 63 / 18,000 rpm Balancing system (only for FDT) Kinematics Opt Electr. Handwheel Skiving (only for FDT) Dyn. Collision Monitoring Heidenhain DNC Heidenhain Remote Desktop 3D model of the machine Advanced tool management Operating mode 3 Probe Heidenhain Tool Measurement Blum Laser Signal tower on the machine 18,000 spindle HSK-T 63 Continuous air through the spindle (with lubrication interval) Continuous air from the outside 76 mm tool magazine Spray gun Chip flushing of the working area (recommended for Al) Emulsion Mist Extraction Production package C, 80 bar, hinged belt conveyor Machine Interior Trim Remote diagnostics The options list is complete! No interest in dealer enquiries! No separate dealer price! WB me ...

CNC MACHINING CENTER ALZMETALL BAZ 15, Year of manufacture : 1998 Specifications: X : 600mm Y : 400mm Z : 600mm Table : 750 x 450mm Main spindle : 10,000RPM Control : Siemens Sinumerik

Incl. chip conveyor Dimensions: 3700x2270x2820mm Chip conveyor dimensions: 800x4000x1500mm Condition and details see pictures Year of manufacture 1996

Used machine in good condition. Available for immediate delivery. - Max. tool length: 300/225 [350/225] - Number of tool stations: 33 - Control: HEIDENHAIN ITNC 530 - Working area (X x Y x Z): 650 x 650 x 550 mm - C-axis: 360 ? - Max. tool weight: 10 kg - Operating hours: 51.651 - Axes: 5 - Power: installed max: 16 kW - Weight: 13.000 - Dimensions (long x wide x high): 2.345 x 4.250 x 2.600 mm

serial number: 1296 : ja changer: ja fach documentation: ja control: Heidenhain 426 weight of the machine ca.: 6 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 5-axis Alzmetall GS 1000/5-FDT was manufactured in 2018. It features a spindle speed of 12,000 RPM and a tool capacity of 125-126 positions, utilizing HSK 63 A and T holders for versatile operations. The machine includes a robust table load capacity of 1,000 kg and a high-pressure coolant system. If you are looking to get high-quality machining capabilities, consider the Alzmetall GS 1000/5-FDT vertical machining centre we have for sale. Contact us for further details.

distance spindle /table:min /max 190 / 570 mm distance spindle /table:190 - 570 mm surface area:650 x 300 mm Boring power:in GG 20 40 mm bore capacity in steel:ST 60 32 mm turning speed range::50 - 5000 UpM total power requirement:2,2 kW threading:GG 20 M30 threading::ST 60 M 24 weight of the machine ca.:1400 kg table load:max. 150 kg table height:770 mm traversing speed:max X-, Y- u. W-Achse 5 m/min max. traversing speed:Z-Achse 3 m/min w-axis:380 mm workpiece height max.:495 mm tool changing time:ca. 3 sec x-travel:450 mm y-travel:300 mm z-travel:180 mm workpiece weight:1,5 kg

Alzmetall AB 40 SV Price 9500,-€ Drilling capacity : 45mm Spindle : MK 4 Drilling capacity 45mm Spindle MK 4 Speed 65-1750 rpm Feed rate Yes 0.1 - 0.2 - 0.3 Drilling stroke 165mm Connection 50Hz 380V Motor 2.4KW Machine weight approx. 500kg

Alzmetall AB4SJ Tool holder MK4 automatic feed with 3 feed speeds 2 shoot stages and infinitely variable speed control right left barrel, thread cutting device Cooling agent device in the foot Round table with holes without rev counter Machine hood modern made of plastic with cracks and loechers Speed: 80-710 rpm Table diameter: 450 mm Max distance from spindle to foot: 1200 mm Extension to center spindle: 170 mm Machine hoe approx. 200 cm Bt323s8 SPECIAL PRICE due to visually poor condition according to photos, technically usable condition, the drill is not locked at the shaft drill spindle tool holder in the rotational motion (see photos). If the drill is not firmly in the drill spindle, it rotates through. Special price

see side sheet below, with 2-spindle drill head Franz X. LINDNER SBS-2/2, spindle distance 300 mm, (translation 1:1)

with NC round table WALTER 1000 mm, see pictures

Drill diameter: 65mm, outreach: 380mm, tool holder: SK50, speed: 1600rpm, table dimensions X/Y: 630mm/500mm, rapid traverse Z: 4750mm/min, drilling capacity steel/cast iron: 65mm/80mm, thread cutting capacity steel/cast iron: M68/M72, machine dimensions X/Y/Z: approx. 1500mm/1200mm/2950mm, weight: approx. 2000kg, control: PLC. Including three tool holders, safety enclosure, minimum quantity lubrication system, spare parts and digital readout. Without milling head attachment and drill crown. The control cabinet has optical damage. Documentation available. An on-site inspection is possible.

Drilling capacity in St 60: 40 mm threading in St 60: M 24 mm threading in GG 20: M 30 bore stroke: 120 mm Short spindle: MK 3 throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle - machine table min./max.: 117 / 701 mm feed: 0,10 + 0,20 mm/U spindle turning speed range: 160 - 2250 UpM total power requirement: 1,45 / 1,9 kW height of the machine: 1840 mm weight of the machine ca.: 285 kg Standard equipment: - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for right-left rotation - Motor protection switch - Speed adjustment stepless - Speed display digital - Feed overload protection - Protection IP 54 - Connector (fully assembled, cable length 2 m) - Spindle protection with electrical protection Pos. 25 Coolant device B, consisting of: separate container (33l), Pu ...

: 55 mm : M 30 : M 36 : MK 4 spindle turning speed - stepless: 70-1.200 U/min spindle stroke: 140 mm throat: 300 mm column diameter: 145 mm : 615x430 mm distance spindle /table: min./max. 150/735 mm : 2 x 14 x 224 mm feed: 0,1 + 0,3 mm/U Machine height: 1850 mm weight: 380 kg drive motor: 1,8/2,9 kW Standard equipment: - Lockable main switch with motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP - Infinitely variable speed adjustment - Digital speed display - Feed overload protection - Protection class IP 54 - Spindle protection with electrical fuse Item 20.1 Thread cutting device with foot switch, for thread cutting with Stop, max. 6 threads / min., (Thread cutting performance dependent on spindle speed) ! NEW FOR YOU AS A SERVICE ! Machine leasing up to 60 months without down payment, without residual value, personal advice and individual leasing rate calcu ...

bore capacity in steel (diameter): 40 mm throat: 293 mm bore stroke: 120 mm spindle taper MT: 3 column diameter: 115 mm table surface area: 514 x 360 mm spindle turning speed - stepless: 160 - 2250 U/min total power requirement: 1,0/1,6 kW weight of the machine ca.: 0,285 t dimensions of the machine ca.: m Condition: new / unused: The machine can be viewed under current.: 37981 400 V, 50 Hz, colour: light grey RAL 7035 continuous speed control, digital speed indication, push button for emergency switch off, turning switch for clockwise/counterclockwise rotation, motor protection switch, IP 54, connecting plug, finish: structure varnish, new spindle bearing, new step pulleys, belts aso. operation manual, wiring diagram. Machine has been checked in our workshop, including electr. testing report. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

weight: 1,4 t : 227 : ja The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Alzmetall AB 35 HST / Box Column Drill & Walter Gras Arbo3 Interchangeable Head -Drilling capacity / steel approx. 40mm -Drilling capacity / casting approx. 45mm -Threading max. M25 -Spindle holder MK 4 -Spindle stroke 180mm -Speed range (INFINITELY VARIABLE) 65 - 1750 rpm -Switchable speed range 130-480 / 480-1750 rpm -Automatic feeds 0.1-0.2-0.3mm/rev -Drilling depth adjustable via depth scale -Speed display -Right/counterclockwise rotation -Swivel drill head with tools -Height-adjustable work table by hand crank -Coolant device -Emergency / Off -Work light Dimensions: LxWxH 1x0.8x2.1 meters / Weight approx. 1200KG

Column Drilling Machine ALZMETALL AB3 ESV Spindle: CM3 Rotation: 1 range 220 -800 RPM + 1 range 800-2900 RPM Table size: Length 615 mm x Width 470 mm Spindle travel: 160 mm Throat depth: 280 mm Speed adjustment by belt drive Rotative table at 360° Automatic Descent 3 speeds: 0,006 - 0,12 - 0,18 mm/min. Lubricant pump Voltage: 380 V Width: 800 mm Depth: 1300 mm Total height: 1900 mm Weight: approx 800 kg

offer 22326 Specifications: - Drilling capacity in steel ST 60 35 mm - Drilling capacity in steel ST 60 40 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 170 mm - Projection 345 mm - Rotary table with 2 T-slots 550 mm - distance table – drilling spindle 650 mm - distance base plate – drilling spindle 1000 mm - Feed rates 0.09 - 0.16 - 0.28 mm/rev - AZ transmission continuously variable with manual transmission - Drilling spindle speeds infinitely adjustable 40 - 720 rpm -Right. - Left-hand rotation - Drive 400 V / 2.5 kW -Lighting - Coolant device - Space requirement approx. W 750 x H 1950 x D 1000 mm - Weight approx. 700 kg

Drilling capacity steel/GG: 18/23 mm Spindle mount: 2 MK Projection: 250 mm Table size: 250 x 370 mm Spindle speeds: 400 - 5000 rpm Drive motor: 0.48/0.6 kW Space requirements: 750 x 500 x 1670 mm Weight: 130 kg

Box column drill Alzstar 40S 16 A 380 V Speed 160 - 2250 rpm Length 1 m Width 0.80 m Height 1.80 m Weight 270 kg Work lamp Color: White

bore stroke:170 mm total power requirement:3,5 kW dimensions of the machine ca.:0,75 x 1,10 m bore spindle turning speed range:30-3000 U/min bore range:diameter:4-60 mm

total power requirement:2.2 kW bore spindle turning speed range:70-4000 in 4 stufen U/min

- Drilling capacity in St 60, 30 mm - Short spindle MK 3 - Spindle stroke 120 mm - Projection 293 mm - Table support 420 x 300 mm, 2 T-slots - Machined base plate 320 x 329 mm, 2 T-slots - Distance base plate - drill chuck 1000 mm - Feed via turnstile - Weight 220 kg - Spindle speed 160 - 2250 rpm. - Operating voltage 380V-50Hz - Infinitely variable speed adjustment, by means of an adjustment lever - Engine speed in 2 stages, 700/1435 rpm - Tapping device with rotation direction change after reaching the end stops - Coolant device fully installed. - Coolant tank in machine base - Work light with LED - RÖHM drill chuck 1 - 16 mm - Precision machine vice new (test winner)

Specifications: - Drilling capacity in steel ST 60 40 mm - Drilling capacity in steel ST 60 50 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 180 mm - Drilling spindle speeds infinitely adjustable with countershaft - Level 1: 60 - 210 rpm - Level 2 210 - 765 rpm - Projection 330 mm - 3 feeds 0.1 - 0.2 - 0.3 rpm - Table with 2 T-slots 720 x 360 mm - Table height-adjustable via rack with hand crank - Max. distance table – drilling spindle approx. 780 mm - Max. distance between machined base plate and drilling spindle approx. 1250 mm - Coolant device -Lighting - Drive 400 V / 4 kW - Space requirement approx. W 720 x H 2050 x D 1150 mm - Weight approx. 500 kg

Key data: 50 mm, 800 1/min

Speeds infinitely variable from 40 - 800 rpm 4 drill feeds . Clearly good original condition

bore capacity in steel (diameter): 50 mm throat: 385 mm bore stroke: 240 mm table surface area: ø 500 mm spindle taper MT: 5 spindle turning speed range: 40 - 800 U/min feeds: 0,1/0,14/0,2/0,28/0,4 mm/U column diameter: 220 mm distance between table/spindle: max. 670 mm distance spindle/base plate: 1180 mm total power requirement: 4 kW weight of the machine ca.: 1,4 t dimensions of machine L x W x H: 1,5 x 0,75 x 2,4 m Accessories: drill chuck, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40 mm throat: mm bore stroke: mm total power requirement: 4 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 60 mm throat: 400 mm bore stroke: mm total power requirement: 4,4 kW weight of the machine ca.: 1,7 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offer 25170 Specifications: - Drilling capacity in steel ST 60 40 mm - Drilling capacity in steel ST 60 50 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 180 mm - Drilling spindle speeds infinitely adjustable with countershaft - Level 1: 60 - 210 rpm - Level 2 210 - 765 rpm - Level 3 120 - 420 rpm - Level 4: 420 - 1530 rpm - Projection 330 mm - 3 feeds 0.1 - 0.2 - 0.3 rpm - Table with 2 T-slots 720 x 360 mm - Height-adjustable via rack with hand crank - Max. distance table – drilling spindle approx. 780 mm - Max. distance machined base plate - drilling spindle 1250 mm - Coolant device -Lighting - Machine vise - div. 10 pcs HSS - Drill - Drive 400 V / 2.6 / 4 kW - Space requirement approx. W 720 x H 2050 x D 1150 mm - Weight approx. 350 kg

bore capacity in steel (diameter): 40 mm throat: 325 mm bore stroke: 170 mm table surface area: 730 x 590 mm 0: 130 - 1200 U/min feed: 0,09 - 0,16 - 0,28 mm/U tool taper: MK 4 total power requirement: 1,8 kW weight of the machine ca.: 0,7 t dimensions: 1,2 x 0,8 x 2,15 m Drill with: Feed 2 gears Left/right rotation Foot switch Machine light The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): mm throat: 290 mm bore stroke: 180 mm total power requirement: 1,9 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 18.0 mm throat: 190 mm bore stroke: 80 mm morse taper: 2 Kurzspindel MK turning speeds: 225 - 4.300 U/min voltage: 400 / 50 Hz Volt table:: 300 x 240 mm column diameter: 65 mm engine output: 0.37 / 0.55 kW weight: 110 kg Furnishing: - Large spindle speed range - stepless speed adjustment - machined base plate - Electrically secured spindle protection - Main switch lockable with motor protection switch - Reversing switch for clockwise and counterclockwise rotation - Operating instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40.0 mm threading: M 24 throat: 293 mm bore stroke: 120 mm morse taper: 3 Kurzspindel MK table:: 515 x 360 mm turning speeds: 80 - 1125 U/min feed: 0.10 + 0.20 mm/U column diameter: 115 mm distance spindle /table: 117 / 701 mm total power requirement: 1.0 / 1.6 kW weight: 270 kg height of the machine: 1840 mm Furnishing: - Lockable main switch with motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP - Infinitely variable speed adjustment - Digital speed display - Feed overload protection - Protection class IP 54 - Spindle protection with electrical fuse - Operating instructions in German including special equipment: - Thread cutting device pos. 20.0 (Thread cutting with stop) - Coolant device B pos. 25. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40.0 mm bore capacity in cast iron: 50.0 mm throat: 300 mm bore stroke: 160 mm morse taper: 4 MK table:: 615 x 430 mm threading: 24 in ST M threading: 30 in GG M turning speeds: 100 - 1.800 U/min feed: 0.1-0.2-0.3-0.4 mm/U distance spindle /table: 147 / 688 mm total power requirement: 0.6 / 1.8 kW weight: 470 kg height of the machine: 1865 m Furnishing: - Electromagnetic feed clutch - with overload protection and electrical cross-handle switch - Lockable main switch - Motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP, in the front panel - Infinitely variable speed adjustment - Digital speed display - Protection class IP 54 - Spindle protection with electrical fuse - Motor insulation class F (155 degrees) - Operating instructions in German including special equipment: - LED machine light pos. 12. - Thre ...

Specifications - Clamping surface (left-right): 370 mm - Clamping surface (front-rear): 614 mm - Control: electronic control - Quill stroke: 180 mm - Speed range up to: 55 - 5000 rpm - Projection: 320 mm - Tool holder: MK 4 - Connected voltage: 400 V - Total height approx.: 2.06 m -Documentation - Weight approx.: 600 kg

Specifications - Clamping surface (left-right): 390 mm - Clamping surface (front-rear): 420 mm - Control: electronic control - Quill stroke: 120 mm - Speed range up to: 7500 rpm - Tool holder: MK 3 - Connected voltage: 400 V - Mains frequency: 50 Hz - Total height approx.: 1.90 m -Documentation - Weight approx.: 400 kg

taper MK: 4 serial number: 520 weight of the machine ca.: 440 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number of spindles: 3 bore capacity in steel (diameter): 40 mm bore stroke: 180 mm weight of the machine ca.: 2,3 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offer 25032 Technical data: - Drilling capacity in steel ST 60 50 mm - Drilling capacity in steel ST 60 65 mm - Tapping device up to M 60 - Drilling spindle holder MK 5 - Drilling spindle stroke 240 mm - Projection 400 mm - Table with 2 T-slots 720 x 560 mm - max distance table – drilling spindle approx. 850 mm - 4 feeds 0.1 - 0.2 - 0.3 - 0.4 mm/rev - AZ continuously variable transmission with manual transmission - Drilling spindle speeds infinitely adjustable 40 - 1600 rpm - Drive 400 V / 5.5 kW - Space requirement approx. W 850 x H 2480 x D 1350 mm - Weight approx. 1450 kg

bore capacity in steel (diameter): 40 mm throat: 345 mm bore stroke: 200 mm table surface area: 720 x 560 mm 0: 60 - 765 U/min feed: 0,15 - 0,2 - 0,3 - 0,36 mm/U tool taper: MK 4 total power requirement: 3,0 kW weight of the machine ca.: 0,4 t Drill with: Feed 2 gears Left/right rotation Foot switch Coolant pump Machine light new quick-release chuck The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Drill, pillar drill, column drill, column drill -Manufacturer: Alzmetall, pillar drilling machine type AB5/S -Engine: VKS 3 kW -Speed: 40 - 800 rpm, continuously variable right-left rotation -Feed: 0.1 - 0.14 - 0.2 - 0.28 - 0.4 mm/rev. -Table size: Ø 500 mm, travel 470 mm -Spindle holder: MK5 -Spindle stroke: 240 mm -Projection: 380 mm -Column Ø: 220 mm -Dimensions: 1450/680/H2160 mm -Weight: 1262 kg

Drilling machine, bench drill, pillar drill, column drill -Manufacturer: Alzmetall, Pillar drilling machine type AX2 S -Spindle mount: MK2 -Motor: 0.37 / 0.55 kW -Speed adjustment: stepless -Speeds: 450 - 4300 rpm -Table size: 250 x 250 mm -Travel distance: 560 mm -Spindle stroke: 90 mm -Protrusion: 250 mm -Column Ø: 90 mm -Dimensions: 720/540/H1650 mm -Weight: 145 kg

Key data: 35 mm, 280 mm, 180 mm

Column drilling machine ALZMETALL AB 3 ES – Powerful & immediately ready for use For sale is a high-quality column drill from the renowned manufacturer Alzmetall, model AB 3 ES. The machine impresses with its robust design, precise operation and reliable performance. Ideally suited for workshop, metalworking and industrial applications. General information: Machine Type: Column Drilling Machine Manufacturer: Alzmetall Model: AB 3 ES Condition: Used, good general condition, fully functional Shipping time: Immediately available Technical data: Drilling capacity in steel: approx. 35 mm Projection: approx. 280 mm Drilling stroke: approx. 180 mm Recording: MK 3 Speed: Infinitely variable Table size: approx. 600 × 470 mm Equipment: • Drilling depth stop • Drill chuck Machine data: Dimensions (L × W × H): approx. 1200 × 800 × 2100 mm Weight:  ...

Column Drilling Machine Alzmetall Column Drilling Machine Flott

Heavy Duty Column Drill Technical data: - Drilling capacity in steel ST 60 28 mm - Drilling capacity in steel ST 60 32 mm - Drilling spindle holder MK 3 - Drilling spindle stroke 180 mm - Drilling spindle speeds infinitely adjustable - Stage 1. 130 - 480 rpm - Stage 2. 480 - 1750 rpm - 3 feeds 0.1; 0,2; 0.3 mm/rev - Projection 290 mm - Max. distance table - drilling spindle 620 mm - Table with 2 T-slots 450 x 450 mm - Height adjustable via rack with hand crank - Separate coolant device - Drive 400 V / 0.9 / 1.3 kW - Space requirement approx. W 660 x H 1900 x D 700 mm - Weight approx. 280 kg

Various metalworking machines, including a larger Wagner radial drilling machine, are available. 1) Column radial drilling machine Wagner PRC 50, year of manufacture: 2011, drilling capacity (steel): 50mm, spindle stroke: 315mm, outreach range: 350mm-1600mm, spindle-base plate distance: 370mm-1270mm, speed: 2000rpm, machine dimensions X/Y/Z: approx. 2500mm/1100mm/2900mm, weight: approx. 3500kg. The machine has an unknown defect. 2) Column drilling machine Alzmetall AX3/SV, year of manufacture: 2000, drilling capacity (steel): 32mm, spindle stroke: 120mm, outreach: 293mm, column diameter: 115mm, table dimensions X/Y: 515mm/360mm, speed: 2250rpm, weight: approx. 300kg. 3) 2x metal circular saw Macc NTM 350, year of manufacture: 1998/2010, saw blade diameter: 350mm, cutting capacity: 120mm, weight: approx. 450kg. 4) Belt grinding machine Grit A/S GIS 150, year of manufacture: 2014, belt dim ...

Kaltenbach Saw Column Drilling Machine Alzmetall Welding machine Kemppi Pulse welding machine

Offer 25511 Technical data: - Drilling capacity in steel ST 60 28 mm - Drilling capacity in steel ST 60 32 mm - Tapping device - Drilling spindle holder MK 3 long spindle - Drilling spindle stroke 180 mm - 10 drilling spindle speeds 250 - 2100 rpm - Projection approx. 290 mm - Max. distance table – drilling spindle approx. 620 mm - Table with 2 T-slots height-adjustable 520 x 450 mm - Drive 400 V / 1.0 / 1.3 kW - Space requirement approx. W 600 x H 1850 x D 700 mm - Weight approx. 280 kg

Key data: 28 mm, 285 mm

Drilling capacity in steel: approx. 28mm Projection approx. 285mm Drilling depth approx. 125mm Spindle mount MK3 Infinitely variable speeds from 130-1150 rpm 3 automatic feeds 0.1 - 0.2 - 0.3mm/rev Table clamping area approx. 500 x 370mm Table adjustable in height via rack Machining base plate approx. 350 x 320mm With motor 1.5kW, 1415 rpm, 380/220V Weight: approx. 380kg Condition and details see pictures

Offer 25491 Technical data: - Drilling capacity in steel ST 60 40 mm - Drilling capacity in steel ST 60 50 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 160 mm - Digital speed display - Projection 300 mm - Turning table with vice 440 x 440 mm - Column diameter 145 mm - Feeds-Electromagnetic 0.1 - 0.2 - 0.3 - 0.4 mm/rev - Drilling spindle speeds infinitely adjustable with digital display - 200 - 3200 rpm - Drive 400 V / 1.8 / 2.9 kW - Lighting - E. footswitch - Space requirement approx. W 650 x H 1900 x D 800 mm - Weight approx. 470 kg

Alzmetall AB 3 ES - Column Drilling Machine -Drilling capacity / steel 35mm -Projection 280mm -Drilling stroke 180mm Hebkn Auevtzrvj S Tol -Recording MK 3 -Table size 600x470mm -Stepless speed regulation -Drilling depth stop -Drill chuck -Documentation Dimensions: LxWxH1.2x0.8x2.1 meters / Weight 550 kg

bore capacity in steel (diameter): 28 mm arm length: 700 mm workpiece height max.: 1300 mm tool taper: MK3 feeds: 0,1-0,3 mm/U spindle turning speed range: 100-1.220 U/min total power requirement: 1,4 kW weight of the machine ca.: 1,3 t dimensions of the machine ca.: LBH 1,8 x 0,8 x 2,3 m Incl. cube table Incl. drilling feed Mechanical clamping The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

General Manufacturer: Alzmetall Type: AC 32/AS Year of Make: 1991 Performance Drilling capacity St 60: D32 mm, v=20 m/min, s=0.27 mm/rev Drilling capacity GG 20: D40 mm, v=20 m/min, s=0.27 mm/rev Drilling capacity St 60: D45 mm, v=20 m/min, s=0.15 mm/rev Tapping capacity St 60: M 24 Threading capacity GG 20: M 30 Drive Main drive: 3 kW – 1,500 rpm Main spindle speed range: 55 – 5,000 rpm Feed Feed drive: automatic, infinitely variable Feed speed: 1 – 3,000 mm/min Rapid traverse: 3 m/min Spindle Tool holder: MK4 Spindle head diameter: 46 mm Quill stroke: 180 mm Projection: 322 mm Column diameter: 145 mm Table Table clamping area: 415 mm x 508 mm Number of T-slots x width x spacing: 5 x 14 x 100 Table stroke: 663 mm Distance from spindle table max: 663 mm Spindle-machined base plate distance: 1,083 mm Dimensions and weight Dimensions: 720 mm  ...

Drilling Ø: 28/35 mm Spindle holder: MK 3 Projection: 293 mm Table size: 300 x 440 x 500 mm Table swivel on round column and height-adjustable via hand crank and rack Large distance between table and drill quill: 630 mm Quill stroke: 180 mm Spindle speeds adjustable in 4 groups: 65 - 1750 rpm Drive motor: 380 V, 0.9/1.3 kW Weight: 340 kg Space requirement: 1100 x 900 x 1880 mm

Drilling Ø in steel/GG 20: 40/55 mm Spindle holder: MK 4 Projection: 345 mm Table size: 450 x 600 mm Distance between table and drill quill: 785 mm Quill stroke: 180 mm Spindle speeds in 4 groups by pole-switching. Engine and manual transmission as well as infinitely variable control: 160 - 1540 rpm 4 automatic feeds: 0.09; 0,12; 0.18 and 0.22 mm/rev Drive motor: 380 V, 2.6/3.2 kW Weight: 640 kg Space requirement: 700 x 1150 x 2000 mm

Drilling Ø: 28/35 mm Spindle holder: MK 3 Projection: 293 mm Table size: 400 x 400 mm Table swivel on round column and height-adjustable via hand crank and rack Large distance between table and drill quill: 630 mm Quill stroke: 180 mm Spindle speeds in 4 groups adjustable: 65 - 1750 rpm Drive motor: 380 V, 0.9/1.5 kW Weight: 340 kg Space requirement: 600 x 920 x 1880 mm

Tool holder MK 4 Drilling capacity up to 40 mm steel Clockwise and counterclockwise rotation Stepless speed adjustment with display Automatic feed

Drilling Ø: 28/35 mm Spindle holder: MK 3 Projection: 293 mm Table size: 400 x 400 mm Table swivel on round column and height-adjustable via hand crank and rack Large distance between table and drill quill: 630 mm Quill stroke: 180 mm Spindle speeds in 4 groups adjustable: 65 - 1750 rpm Drive motor: 380 V, 0.9/1.5 kW Weight: 340 kg Space requirement: 600 x 920 x 1880 mm

Alzmetall AC 32 Turret Double Head In-Line Drilling Machine Extremely robust and rare double-head in-line drilling machine based on two Alzmetall AC 32 drill tops. This system is a high-quality industrial design designed for highly efficient series or step machining. Instead of simple spindles, this machine is equipped with two separate tool turrets. This enables fully automatic machining cycles (e.g. centering, drilling, countersinking, threading) without the need to manually retool tools. Technical data & equipment (per capita / total system): Manufacturer of drill tops: Alzmetall (Germany) Model: AC 32 (electronically controlled with digital display) Drilling capacity: max. 32 mm in steel Threading capacity: max. M 24 / M 30 Tool changer: 2x swivelling turret heads with several stations Machine table: Solid, ground cast iron table with T-slots for flexible constru ...

Key data: 40 mm, 80 1/min

Column Drill Alzmetall AB 3 / ESV Drive type: AZ continuously variable transmission with two-stage manual transmission Speed range (Gear Stage I): 80-240 rpm or 160-480 rpm Speed range (Gear Stage II): 240–700 rpm or 480–1,400 rpm Automatic feed: 3 stages (0.1 – 0.2 – 0.3 mm/rev) Motor power 1.5 KW - 380 Volt Tool holder: Short spindle MK 3 Spindle stroke (drilling stroke): 160 mm Projection: 285 mm Table clamping surface: 500 x 370 mm Column diameter: 130 mm Machine weight approx. 400 kg Drilling capacity in steel (St 60): 28 mm Drilling capacity in cast iron (GG 20): 35 mm Drilling capacity in steel (St 60): 40 mm Tapping in steel (St 60): Up to max. M 22 Threading in cast iron (GG 20): Up to max. M 33 Retrofitted foot switch and control cabinet Mechanical-hydraulic machine vice Röhm RB 4 (Jaw width 160 mm - clamping range up to 310 mm) Retrofitted f ...

bore capacity in steel (diameter): 45 mm throat: 350 mm bore stroke: 180 mm : 4 speeds: 30 - 765 U/min table-size: 720 x 560 mm total power requirement: 3,4 kW weight: 950 kg dimensions: 1200 x 800 x 2300 mm Features: - Automatic feed - Coolant system - Infinitely variable speed control - Adjustable fixed depth stop - Emergency stop foot switch - Drill chuck The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 120 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 160 - 2250 U/min column diameter: 115 mm thread: M 24 ST60 thread: M 30 GG20 feed: 0.10 + 0.20 mm/U distance spindle /table: 117 / 701 mm engine output: 1.0 / 1.6 kW weight: 270 kg Machine height: 1840 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread depth adjustable via depth stop in the TFT  ...

bore capacity in steel (diameter): 35.0 / 40.0 mm throat: 300 mm bore stroke: 180 mm turning speeds: 110 - 1450 U/min table-size: Ø 455 mm column diameter: 155 mm feed: 0.1 / 0.2 / 0.3 m/min spindle taper MT: 4 MK engine output: 1.5 kW weight: 450 kg range L-W-H: 800 x 650 x 1850 mm Features: - Heavy-duty column drill press (V-belt drive) - Automatic spindle feed - Infinitely variable speed control - Fixed depth stop - Round machine table with T-slots Height-adjustable via hand crank Rotatable - Emergency stop button on the front - Coolant system with separate reservoir - Operatorâs manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: ja feed: 80 - 800 m/min : 1848 weight of the machine ca.: 2,2 t Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore diameter: 65 mm throat: 380 mm Control: PLC-Steuerung bore spindle turning speed range: 63 - 1600 U/min table-size: 630 x 500 mm rapid traverse Z-axis: 4,75 m/min boring feeds:: 0,05 - 0,56 mm/U total power requirement: 9 kW weight of the machine ca.: 2,0 t dimensions of the machine ca.: 1,50 x 1,20 x 2,95 m Drilling capacity in steel ST60: 65 mm Drilling capacity in cast iron GG20: 80 mm Thread cutting ST60: M68 Thread cutting GG M72 SPS-controlled automatic drilling machine with Drilling/deep hole drilling/thread cutting Sequence: 1st rapid traverse to start position 2. switch on the speed 3. switch on the drilling feed 4. drilling until the drilling depth is reached 5. return in rapid traverse to start position Manual operation possible (speed and direction of rotation, rapid traverse positioning, Switching the drill feed on/off) Selection of the drill feeds and spindle speed man ...

ALZMETALL column drilling machine AB 3 ES -Well-maintained original condition -Drilling capacity / steel max. 35mm -Projection approx. 280mm -Table size approx. 600x470mm -Drilling stroke approx. 180mm -Cone mount MK 3 -Stepless speed regulation -Speed range 65 - 1750 rpm -Drilling depth stop -Spindle protection device -Not /Off -Footswitch -Analogue speed display -Drill chuck -Documentation Dimensions: LxWxH 1.2x0.8x2 meters / Weight approx. 500Kg

ALZMETALL AB 35S Column Drilling Machine -Drilling capacity steel: 40 mm -Casting drilling capacity: 45 mm - Spindle holder: MK4 -Projection: 300 mm -Quill stroke (drilling stroke): 175 mm -Spindle speed: 65–1,450 rpm (infinitely variable, 2 gear stages) -Automatic feed: 0.10 / 0.20 / 0.30 mm/rev -Table clamping surface: 600x460mm -Table adjustment: 600 mm -Table height-adjustable via hand crank -T-slot clamping table -Column diameter: 180 mm -Distance from spindle center to base plate: 1,165 mm -Base plate: 360 × 360 mm -Motor power: 3.5 kW -Operating voltage: 400 V -Continuously variable variable transmission -Automatic quill feed -Coolant device -Machine lighting -Speed display Dimensions: LxWxH 1.2x0.6x2.1 meters / Weight 1200Kg

ALZMETALL AB 35S Column Drilling Machine -Drilling capacity steel: 40 mm -Casting drilling capacity: 45 mm - Spindle holder: MK4 -Projection: 300 mm -Quill stroke (drilling stroke): 175 mm -Spindle speed: 65–1,450 rpm (infinitely variable, 2 gear stages) -Automatic feed: 0.10 / 0.20 / 0.30 mm/rev -Table clamping surface: 600x460mm -Table adjustment: 600 mm -Table height-adjustable via hand crank -T-slot clamping table -Column diameter: 180 mm -Distance from spindle center to base plate: 1,165 mm -Base plate: 360 × 360 mm -Motor power: 3.5 kW -Operating voltage: 400 V -Continuously variable variable transmission -Automatic quill feed -Coolant device -Machine lighting -Speed display Dimensions: LxWxH 1.2x0.6x2.1 meters / Weight 1200Kg

Worktable: 710x560 mm

bore capacity in steel (diameter): 55.0 mm throat: 300 mm bore stroke: 140 mm morse taper: 4 MK table:: 615 x 430 mm turning speeds: 70 - 1200 U/min column diameter: 145 mm thread: M 30 ST60 thread: M 36 GG20 feed: 0.10 + 0.30 mm/U distance spindle /table: 150 / 735 mm engine output: 1.8 / 2.9 kW weight: 380 kg Machine height: 1850 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread depth adjustable via depth stop in the TFT - ...

bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 120 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 80 - 1125 U/min column diameter: 115 mm thread: M 24 ST60 thread: M 30 GG20 feed: 0.10 + 0.20 mm/U distance spindle /table: 117 / 701 mm engine output: 1.0 / 1.6 kW weight: 270 kg Machine height: 1840 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread depth adjustable via depth stop in the TFT - ...

bore capacity in steel (diameter): 65 mm throat: 390 mm bore stroke: 250 mm spindle taper MT: 5 table-size: 880x670 mm spindle turning speed - stepless: 40-800 U/min weight of the machine ca.: 1.2 t www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 34 mm : 40 mm : 40 mm : MK 4 : 100-1.800 U/min. throat: 300 mm : 615x430 mm : 2 x 14 x 224 mm : 138/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U Machine height: 1865 mm total power requirement: 1,4/2,2 kW Standard equipment: - Electromagnetic feed clutch with overload protection and electrical Cross Handle Switches - Main switch lockable - Motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel - Speed adjustment stepless - Speed display digital - Protection class IP 54 - Motor insulation class F - Spindle protection with electrical protection Pos. 20.1 Tapping device with foot switch, for thread cutting with Stop, max. 6 threads/min., (Tapping power dependent on spindle speed) Pos. 25. Coolant device B, consisting of: separate container (33 l), pump with Motor protection switch, complete fitting The data for ...

bore capacity in steel St 60: 25 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 : M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514x360 mm T-Slots Amount - Width - Distance: 2x14x224 mm distance spindle - column min./max.: 132/724 mm feed: von Hand 0: stufenlos Spindle Speed: 225-4300 U/min. engine: 1,0/1,6 kW voltage: 400 V Standard equipment: - 7 TFT LCD display with touch function: Manual input of spindle speed set value Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status indicators and warnings on the display Service information Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Thread cutting device, for thread cutting with stop, max. 6 threads/min (thread cutting capacity depending on spi ...

: 16 mm : M 12 : MK 2 : 100-2.000 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel Machine height: 825 mm total power requirement: 0,7 kW weight: 93 kg Standard equipment: 5 TFT LCD display with touch function: Manual input of spindle speed setpoint, speed display actual value, integrated drilling depth display with touch function. setpoint, actual speed display, integrated drilling depth display with touch zero point transfer, virtual drilling depth scale in the display, machine status status indicators and warnings on the display, Service information, Selectable operator language operator language: DE/EN/FR/ES/IT/NL/RU. - AC motor 230 Volt, 50 Hz - Connection plug ready fitted, cable length 3 m - Infinitely variable speed adjustment via potentiometer - Thre ...

: 14 mm : M 10 : MK 2 : 230-4.000 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel Machine height: 825 mm total power requirement: 0,7 kW weight: 93 kg Standard equipment: 5 TFT LCD display with touch function: Manual input of spindle speed setpoint setpoint, actual speed display, integrated drilling depth display with touch zero point transfer, virtual drilling depth scale in the display, machine status status indicators and warnings on the display, Service information, Selectable operator language operator language: DE/EN/FR/ES/IT/NL/RU. - AC motor 230 Volt, 50 Hz - Connection plug ready fitted, cable length 3 m - Infinitely variable speed adjustment via potentiometer - Three separate buttons for clockwise rotation - anticlockwise rotation - stop (spindle  ...

: 18 mm : M 12 : M 14 : MK 2 : 225-4.300 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel total power requirement: 0,37/0,55 kW Machine height: 840 mm weight: 120 kg Standard equipment: - Main switch with motor protection switch lockable - Reversing switch for clockwise and anti-clockwise rotation - Speed adjustment stepless - Protection IP 54 - Mushroom pushbutton (latching) for EMERGENCY STOP - Spindle protection with electrical protection Option 12 - LED machine light, with radially adjustable light beam, power rating 230 V, protection class IP 65 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel St 60: 32 mm bore capacity in cast iron GG 20: 38 mm Drilling capacity in St 60: 40 mm threading in St 60: M 24 threading in GG 20: M 30 Short spindle: MK 3 spindle stroke: 120 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 515 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 117 / 701 mm feed: von Hand spindle turning speed - stepless: 160 - 2250 U/min total power requirement: 1,45/1,9 kW weight of the machine ca.: 260 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 16 mm : M 12 : MK 2 : 100-2.000 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel Machine height: 825 mm total power requirement: 0,7 kW weight: 83 kg Standard equipment: 5 TFT LCD display with touch function: Manual input of spindle speed setpoint, speed display actual value, integrated drilling depth display with touch function. setpoint, actual speed display, integrated drilling depth display with touch zero point transfer, virtual drilling depth scale in the display, machine status status indicators and warnings on the display, Service information, Selectable operator language operator language: DE/EN/FR/ES/IT/NL/RU. - AC motor 230 Volt, 50 Hz - Connection plug ready fitted, cable length 3 m - Infinitely variable speed adjustment via potentiometer - Thre ...
